Belling BI 70 G and Instruction Manual

Belling BI 70 G

The appliance must be installed (and serviced) by a GAS SAFE registered approved installer
or a person competent to ensure that the installation is in accordance with “The Gas Safety
(Installation and Use) Regulations 1994”, and the “The Gas Safety (Installation and Use)
(Amendment) Regulations 1996”. Failure to comply with these Regulations is a criminal
offence.
If you smell gas:
Do not try to light any appliance. Do not touch any electrical switch.
Call the Gas Emergency Helpline at TRANSCO on 0 00 111999
IMPORTANT NOTICE
Please note the cooling fan fitted to this appliance is an integral part of its safety
and functionality.
When the appliance is installed care must be taken that the cooling fans
performance is not impeded by any objects coming into contact with it.
(Installation pipes, leads etc)
Care must also be taken that there is sufficient air flow at the rear of the appliance
for the cooling fan to run at its optimum efficiency. (Particularly Built In appliances)
See clearance dimensions in the installation section of the booklet.
During use the Appliance must never be disconnected from the Mains supply as
this will seriously affect the safety and performance of the appliance, particularly
in relation to surface temperatures becoming hot and gas operated parts not
working efficiently.
The cooling fan is designed to run on after the control knob has been switched off
to keep the front of the appliance and the controls cool until the appliance has
naturally cooled itself.

UserSection..........................................3
Introduction.................................................3
BeSafe-NotSorry............................................5
UsingtheGrill...............................................6
UsingtheOvens..............................................8
UsingtheTopOven ...........................................9
TopOvenbakingguide .......................................10
UsingtheMainOven.........................................11
MainOvenbakingguide ......................................12
Roastingguide..............................................13
RoastTurkey................................................14
Traditionalfruitcakes .........................................14
Slow cooking, Frozen & Chilled food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Automaticcooking ...........................................16
Programmer/clock........................................17-20
Cleaning..................................................21
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 - 36
Regulations&standards .......................................24
Ventilationrequirements........................................24
Step1 Prepareinstallation .....................................25
Step2 Connecttogassupply...................................33
Step 3 Connect to electricity supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Step 4 Secure appliance to housing unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Step 5 Installing a hob above the appliance. . . . . . . . . . . . . . . . . . . . . . . . . 35
Step6 Commissioning........................................36
TechnicalData .......................................37
Belling Customer Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . Back page
Please keep this handbook for future reference, or for anyone else
who may use this appliance.
1
Contents

We hope that the following
information will help you to familiarise
yourself with the features of the
appliance, and to use it successfully
and safely.
Our policy is one of constant
development and improvement. Strict
accuracy of illustrations and specifications
is not guaranteed. Modification to
design and materials may be
necessary subsequent to publication.
This appliance must be installed in
accordance with the regulations in
force and only in a well ventilated
space. Read the instructions before
using or installing this appliance.
Your 1st Year Guarantee
To fulfil the conditions of your guarantee,
this appliance must be correctly
installed and operated, in accordance
with these instructions, and only be
used for normal domestic purposes.
Please note that the guarantee, and
Service availability, only apply to the
UK and Republic of Ireland.
This appliance is designed to be
installed only at low level - ie;
underneath a worktop - it can be
installed either into a housing unit, or
between base units.
Gas & Electrical connection
Please refer to installation instructions
for the Gas & Electrical Safety Regulations
and the Ventilation Requirements.
In your own interest, and that of safety,
it is the law that all gas appliances be
installed by a competent person who
will ensure that the installation is in
accordance with “The Gas Safety
(Installation & Use) Regulations”, & the
“The Gas Safety (Installation & Use)
(Amendment) Regulations. Failure to
comply with these Regulations is a
criminal offence.
Gas Safe registered installers
undertake to work to satisfactory
standards.
Disconnection of gas and electric
appliances should always be carried
out by competent persons.
Warning: This appliance must be
earthed.
In the event of a power cut
1. Switch off the electricity to the
appliance at the socket.
2. When the power returns, see the
‘Programmer / Clock’ section to
‘Set the time of day’.
2
Introduction

The cooling fan
The cooling fan helps to keep the
exterior cool during normal use.
When a burner is operated, you
should hear the cooling fan switch on
automatically and be able to feel air
evacuating from the appliance vents
just below the fascia. The cooling fan
will continue to operate for
approximately 10 minutes after
turning off the burners. This is normal.
If there is no such indication that the
fan is operating, the appliance will
require servicing. DO NOT USE THE
APPLIANCE UNTIL IT HAS BEEN
SERVICED. Switch the appliance off
at the mains and contact Customer
Care.
For your safety
This appliance has a built in safety
device to isolate the gas and electric
supplies to various components in the
event of fan failure.
If the programmer/clock and lights do
not function, and the ignition system
stops working, the safety device has
operated. Within an hour, the safety
device will reset itself and the programmer
/clock display will flash.
To reset the programmer/clock, press
the Plus and Minus buttons together for
a few seconds. The ‘’ between the
hours and minutes on the LED will
flash. Use the Plus and Minus buttons
to reset the time.
If when a burner control is turned on,
the fan does not operate in the normal
way, then the appliance will require
servicing. DO NOT USE THE
APPLIANCE UNTIL IT HAS BEEN
SERVICED. Switch the appliance off
at the mains and contact Customer
Care.
Continued use of the appliance
without it being serviced could result in
excessive temperatures being
generated, which in turn could reduce
the life of certain components.
Ventilation
The use of a gas cooking appliance
results in the production of heat and
moisture in the room in which it is
installed. Ensure that the kitchen is well
ventilated; keep natural ventilation holes
open or install a mechanical ventilation
device (mechanical ventilator).
Prolonged intensive use of the appliance
may call for additional ventilation, for
example opening a window, or more
effective ventilation, for example
increasing the level of mechanical
ventilation where present.
This appliance is not connected to a
combustion products evacuation
device. It must be installed and
connected in accordance with current
installation regulations. Particular
attention must be given to the relevant
regulations regarding ventilation.
3
Introduction

Glass door panels
To meet the relevant Standards of
Domestic cooking appliances, all the
glass panels on this appliance are
toughened to meet the fragmentation
requirements of BS3193. This ensures
that, in the unlikely event that a panel
breaks, it does so into small fragments
to minimise the risk of injury.
Please take care when handling, using
or cleaning all glass panels as any
damage to the surfaces or edges may
result in the glass breaking without
warning or apparent cause at a later
date. Should any glass panel be
damaged, we strongly recommend
that it is replaced immediately.
Condensation
When hot and cold air meet,
condensation forms. The outer door is air
cooled and the inner door gets hot, so some
condensation might form; this is normal
and will disappear within 10 - 15 minutes.
Before using the appliance for
the first time, remove any protective
polythene film and wash the oven
shelves in hot soapy water to remove
their protective covering of oil. Even
so, when you first switch on the oven
or grill you may notice a smell and
some smoke.
Environmental Protection
We are committed to protecting the
environment and operate an
Environmental Management System
which complies with BS EN ISO
14001.
Disposal of packaging
All our packaging materials are
recyclable and environmentally
friendly.
Please help us to protect our
environment by disposing of all
packaging in an environmentally
friendly manner.
Please contact your local authority
for the nearest recycling centre.
Ca tion: Packaging materials can
pose a risk of suffocation - keep away
from children.
To replace an oven light bulb
There are 2 oven lights, 1 in each
cavity
WARNING - switch off the electricity
supply to the appliance at the socket,
to avoid the risk of electric shock.
Wait until the oven is cool, then
remove the oven shelves.
The oven light is at the rear of the oven
cavity.
Unscrew the lens cover (turn anticlock-
wise). Unscrew the bulb and replace.
Replace lens cover.
Please note that the oven light bulb is
not covered by guarantee.
4
Introduction

When you are cooking, keep
children away from the vicinity
of the appliance.
This product is designed as a domestic
cooking appliance for the preparation
and cooking of domestic food
products, and should not be used for
any other purpose.
Remove all packaging from the
appliance before using for the
first time.
Make sure you read and
understand the instructions before
using the appliance.
Keep electrical leads short so they
do not drape over the appliance
or the edge of the worktop.
Keep all flammable materials (such
as curtains, furnishings & clothing)
away from the appliance.
Parts of the appliance may be hot
during or immediately after use. Allow
sufficient time for the appliance to
cool after switching off.
Do not drape tea towels over the
flue vents or doors, as this creates
a fire hazard.
Do not use aluminium foil to cover
the grill pan, or put items wrapped
in foil under the grill, as this
creates a fire hazard.
Never use the appliance for
heating a room.
Do not use the oven with the door
inner glass panel removed (glass
oven doors only).
Use oven gloves when removing
hot food / dishes from the oven or
grill. The oven / grill and utensils
will be very hot when in use.
When opening the appliance
door, take care to avoid skin
contact with any steam which may
escape from the cooking.
Do not use foil on oven shelves or
allow it to block the oven flue, as
this creates a fire hazard, and
prevents heat circulation.
When cooking heavy items - eg;
turkeys - do not pull the oven shelf
out with the item still on the shelf.
Switch off the electricity supply
before replacing the oven light
bulb, to avoid the possibility of
electric shock.
All installation, servicing and
maintenance work must be carried
out by a competent person who
will comply with current Regulations,
Standards and Requirements.
Warning: This appliance must
be earthed.

When you have finished
cooking check that all controls
are in the off position.
As with all gas appliances, it is
recommended that your appliance
is serviced regularly.
5
Be Safe - Not Sorry

Ca tion: Accessible parts may
be hot when the grill is used,
young children should be kept
away.
Grill operation
Important: The door must be fully
open when the grill is used.
Open the grill door.
Push in and turn the grill control knob
clockwise to the grill position.
To switch off, turn the control knob
clockwise to return it to the “” off
position.
Preheating
For best results, always preheat the
grill for a few minutes before grilling.
Aluminium foil
Never cover the grill pan or grill grid
with cooking foil, or allow fat to build
up in the grill pan, as this creates a
fire hazard.
Detachable grill pan handle
Place the handle over the edge of the
grill pan, at the narrow side edges.
Slide the handle to the centre, and
locate between the handle position
indicators.
The handle should be removed from
the pan during grilling, to prevent
overheating.
The handle is designed for removing /
inserting the grill pan under the grill
when grilling.
If cleaning the grill pan when it is hot,
use oven gloves to move it. Do not use
the handle to pour hot fats from the
grill pan.
Food for grilling should be positioned
centrally on the grid.
6
Using the Grill

Using the grill
Push the grill pan towards the back of
the shelf, to position it under the grill.
Variation in grilling can be achieved
by moving the grill pan up or down.
The speed of grilling can also be
controlled by selecting a higher or
lower shelf position.
Always use the top shelf position for
fast toasting.
For toasting, and for grilling foods
such as bacon, sausages or steaks,
use the higher shelf position.
For thicker foods such as chops or
chicken joint pieces, use the lower
shelf position.
The grill grid, inside the grill pan, can
be inverted to give a high or low
position, or it may be removed.
When you have finished grilling,
check that the control knob is
returned to the off position.
7
Using the Grill

8
Using the Ovens
When you are cooking, keep
children away from the vicinity
of the oven.
Notes
In the event of the flame being
accidentally extinguished, the flame
will automatically re-light, owing to
the automatic re-ignition system.
If it is found over a period of time that
the oven becomes hotter when used at
a particular gas mark, the thermostat
may need to be replaced.
As part of the cooking process, hot air
is expelled through a vent at the top of
the oven(s). When opening the oven
door, care should be taken to avoid
any possible contact with potentially
hot air, since this may cause
discomfort to people with sensitive
skin. We recommend that you hold the
underneath of the oven door handle.
Oven furniture
Baking tray and roasting tins
For best cooked results and even
browning, the maximum size baking
trays and roasting tins that should be
used are as follows;
Baking tray 350mm x 280mm
This size of baking tray will hold up to
16 small cakes.
Roasting tin 370mm x 320mm
We recommend that you use good
quality cookware. Poor quality trays
and tins may warp when heated,
leading to uneven baking results.
Oven shelves
The oven shelf must be positioned with
the upstand at the rear of the oven and
facing upwards.
Extra shelves may be ordered from the
Customer Care Centre.
You will see that there are differences
between the oven shelves for the top
oven and the main oven.
The top oven shelf helps to ensure
even baking in the top oven. It has a
rear deflector fitted to it, and is not
intended for use in the main oven.
Preheating
The ovens must be preheated for 15
minutes when reheating frozen or
chilled food, and we recommend
preheating for yeast mixtures, batters,
soufflés and whisked sponges.
If you are not preheating the oven, the
cooking times in the Baking Guide
may need to be extended, as they are
based on a preheated oven.
