Benchmark 1282 406 User manual

WEAR CSA APPROVED
EYE PROTECTION
WEAR EAR
PROTECTION
WEAR A
FACE MASK
READ ALL INSTRUCTIONS BEFORE FIRST USE.
KEEP THIS MANUAL FOR FUTURE REFERENCE.
KEEP AWAY FROM CHILDREN.
5 Year Limited Warranty
PNEUMATIC COIL
FRAMING NAILER

1
PRODUCT SPECIFICATIONS
PNEUMATIC COIL FRAMING NAILER
Working Pressure 90-110 PSI (6.3-7.5 bar)
Max. pressure 120 PSI (8.3bar)
Recommended lubricant white mineral oil 16#
Magazine angle 15°
Air Inlet Size 1/4" NPT
Average Air Consumption 5.8 CFM @90 PSI
Recommended Hose 1/4" or 3/8"
Fastener Capacity Full head framing nails 1-3/4" -3-1/2" long
(flat wire welded)
Magazine Capacity 225 nails
Weight (without fasteners) 4.3KG (9.4LBS)
NEED ASSISTANCE?
Call us on our toll- free customer support line:
1-866-349-8665 (Monday through Friday 9am – 5pm Eastern Standard Time)
Note these instructions pertain to the tool only. Please refer to your
compressors operators manual and follow the manufacturers instructions.
• Technical questions
• Replacement parts
• Parts missing from package
*Please note (where the ¼” NPT connecter is not already installed on the tool) your
tool may be shipped with a black plastic cap installed in the air inlet. Pry the cap
out prior to installing the ¼” NPT connector.

1282 406
PNEUMATIC COIL FRAMING NAILER
2
TABLE OF CONTENTS
Product Specifications................................................................................... 1
Table of Contents........................................................................................... 2
Safety Guidelines ..................................................................................... 3-6
Symbols ....................................................................................................... 7
Tool Specific Warnings .................................................................................. 8
.............................................. 9
Know Your Pneumatic Coil Framing Nailer
....................................................................... 10-17
Assembly and Operation
Maintenance
Troubleshooting
Exploded View
....................................................................................... 18
Parts List .............................................................................................
............................................................................................
.................................................................................... 18-19
Warranty......................................................................................................
20
21-23
24

3
SAFETY GUIDELINES
DANGER! Potential hazard that will result in serious injury or loss of life.
WARNING:
WARNING! Potential hazard that could result in serious injury or loss of life.
CAUTION! Potential hazard that may result in moderate injury or damage to
equipment.
Note - The word " Note " is used to inform the reader of something he / she needs to
know about the tool.
This manual contains information that relates to PROTECTING PERSONAL SAFETY
and PREVENTING EQUIPMENT PROBLEMS. It is very important to read this manual
carefully and understand it thoroughly before using the product. The symbols listed
below are used to indicate this information.
These precautions are intended for the personal safety of the user and others working
with the user. Please take time to read and understand them.
PERSONAL SAFETY
Do not use oxygen or any other combustible or
bottled gas to power air-powered tools. Failure
to observe this warning can cause explosion
and serious personal injury or death.
Use only the compressed air to power the
air-powered tools. Use a minimum of 25’
(7.6 m) of hose to connect the tool to the
compressor. Failure to comply will result in
serious injury or loss of life.
•
Risk of electric shock: Do not expose a compressor to rain.
Store it indoors. Disconnect the compressor from power
source before servicing. Compressor must be grounded. Do
not use grounding adaptors.
•
Risk of personal injury: Do not direct compressed air from the
air hose towards the user or other personnel.
•
Oxygen
Hydrogen
Explosive
Combustible
SYMBOL MEANING

1282 406
PNEUMATIC COIL FRAMING NAILER
4
DANGER!
Keep children away from the work area. Do not allow children to handle
power tools.
Do not use this tool in the presence of flammable liquids or gases. Sparks
that are created during use may ignite gases.
Keep air hose away from heat, oil, and sharp edges. Check air hose for wear
before each use and ensure that all connections are proper.
Always ensure that the workpiece is firmly secured leaving both hands free
to control the tool.
Always ensure that the tool has stopped before putting it down after use, for
safety purposes and to prevent possible damage to the tool/user.
Keep proper footing at all times in order to ensure correct balance.
Always assume that the tool contains fasteners.
Do not point the tool toward yourself or anyone else.
•
•
•
•
•
•
•
•
Risk of inhalation: Never directly inhale the air produced by the
compressor.
•
Risk of bursting: Do not adjust the pressure switch or safety
valve for any reason. They have been pre-set at the factory for
this compressor’s maximum pressure Tampering with the
pressure switch or the safety valve may cause personal injury
or property damage.
•
Risk of burns. The pump and the manifold generate high
temperatures. In order to avoid burns or other injuries, do not
touch the pump, the manifold, or the transfer tube while the
compressor is running. Allow the parts to cool down before
handling or servicing. Keep children away from the compressor
at all times.
•
Risk of bursting: Make sure the regulator is
adjusted so that the compressor outlet
pressure is set lower than the maximum
operating pressure of the tool. Before
starting the compressor, pull the ring on the
safety valve to make sure the valve moves
freely. Drain water from tank after each use.
Do not weld or repair tank. Relieve all
pressure in the hose before removing or
attaching accessories.
•
SYMBOL MEANING

5
WARNING!
Do not allow unskilled or untrained individuals to operate the air tool.
Do not use the tool for any task other than that it is designed to perform.
Locate the compressor in a well-ventilated area for cooling, and a minimum
of 12” (31 cm) away from the nearest wall.
Protect the air hose and the power cord from damage and puncture. Inspect
them for weak or worn spots every week and replace them if necessary.
Always wear hearing protection when using the air compressor. Failure to do
so may result in hearing loss.
Do not carry the compressor while it is running.
Do not operate the compressor if it is not in a stable position.
Do not operate the compressor on a rooftop or an elevated position that
could allow the unit to fall or be tipped over.
Always replace a damaged gauge before operating the unit again.
Do not connect the tool to a compressed air source with a pressure output
that is higher than 120psi.
•
•
•
•
•
•
•
•
•
•
CAUTION!
Always ensure that the tool has stopped before disconnecting the air supply.
Do not wear watches, rings, bracelets, or loose clothing when using any
air- powered tool.
Do not overload the tool. Allow the tool to operate at its optimum speed for
maximum eciency.
Do not use a tool that is leaking air, that has missing or damaged parts, or
that requires repairs. Verify that all screws are securely tightened.
For optimal safety and tool performance, inspect the tool before every
usage, in order to ensure free movement of the trigger, safety mechanisms,
and springs. Always keep your air tool clean and lubricated. Daily lubrication
is essential to avoid internal corrosion and possible failures.
Ensure the floor is not slippery and wear non-slip shoes. Floors should be
kept clean and clear.
Always follow all workshop safety rules, regulations, and conditions when
using the tool and keep the work area clean.
Carry the tool by the handle only, keeping fingers away from the trigger. Do
not carry the tool by the hose, magazine, or any other parts.
Do not use the tool near or below freezing point, as doing so may cause tool
failure. Do not store the tool in a freezing environment to prevent ice
formation on the tools operating valves, as doing so may cause tool failure.
Handling and storage of oil: Use with adequate ventilation. Avoid contact of
oil with eyes, skin, and clothing. Avoid breathing spray or mist. Store in a
tightly closed container in a cool, dry, well-ventilated area free from
Incompatible substances.
Tripping hazard. The air hose may become a tripping hazard when it is
placed in the work area. Use care when walking in the work area.
•
•
•
•
•
•
•
•
•
•
•

1282 406
PNEUMATIC COIL FRAMING NAILER
6
CAUTION!
Disconnect tool from the air supply and turn o the
compressor before performing any maintenance or
changing accessories, when clearing a jammed
fastener, when the tool is not in use, when it is being
handed to another person, and when it is left
unattended. Failure to comply may result in
moderate injury or damage to equipment.
•
Use safety goggles and ear protection: Wear safety
glasses with side shields when operating the
tool/compressor and verify that others in the work
area are also wearing safety glasses. Safety glasses
must conform to American National Standards
Institute (ANSI Z87. 1) requirements and must
provide protection from flying particles from the
front and the sides.
Air-powered tools are loud, and the sound can cause hearing damage.
Always wear ear protection to prevent hearing damage and loss. Failure to
comply may result in moderate injury.
Note: Recycle unwanted materials rather than disposing of them as waste. Sort the
tools, hoses, and packaging in specific categories and take to the local recycling
centre or dispose of in an environmentally safe way.
•

7

1282 406
PNEUMATIC COIL FRAMING NAILER
8
Do not disconnect or reconnect the air hose with the tool pressed or with a
fastener in the guide. The tool may fire when it is reconnected to the air
supply.
•
TOOL SPECIFIC WARNINGS
DANGER Potential hazard that will result in serious injury or death.
Keep hands and other parts of the body away from the nail guide during use.
Keep hands and feet and all other parts of the body at least 8” (20cm) away
from the firing head.
Objects in the workpiece can cause serious injury if they cause the fasteners
to be deflected or to be driven away from the point of entry.
Do not drive fasteners on top of a fastener. The fastener may ricochet,
causing serious personal injury.
Do not drive fasteners on scaoldings, ladders, or such similar construction.
Use only fasteners of the proper size and gauge, as specified in this manual.
Do not drive fasteners close to the edge of the workpiece. The workpiece may
split which could allow the fastener to fly free or ricochet and cause serious
personal injury.
•
•
•
•
•
•
WARNING Potential hazard that could result in serious injury or death.

9
KNOW YOUR
PNEUMATIC COIL FRAMING NAILER
Exhaust Vent
Air Quick Coupler
Trigger
Depth
Adjustment wheel
Lock o switch
Magazine
Canister latch
Workpiece Contact

ASSEMBLY AND OPERATION
1282 406
PNEUMATIC COIL FRAMING NAILER
10
GUIDELINES FOR PROPER USE AND OPERATION
Be sure to use a proper air compressor with air-powered tools. The compressor
should be able to supply a minimal air delivery of 5.8 CFM @ 90 PSI to ensure the
compressor can run continuously with the pneumatic coil framing nailer.
COMPATIBLE COMPRESSORS
Air Compressor
Size & Power
>0.6g/cm3<1/2" (38 mm) T nails
≥1/2" (38 mm) T nails
<1/2" (38 mm) T nails
≥1/2" (38 mm) T nails
90 psi
110 psi
70 psi
100 psi
≤0.6g/cm3
Wood density Nail size Compressor air pressure
4 - 5 Gallons Light duty and
intermittent use
Light duty and
intermittent use
Light duty and
intermittent use
6 - 11 Gallons Light duty and
intermittent use
Medium duty and
intermittent use
Medium duty and
intermittent use
15+ Gallons Medium duty and
intermittent use
Heavy-duty and
continuous use
Heavy duty and
continuous use
1 1/2–2 HP 2 1/2 HP 3+ HP

11
Always use clean, dry, regulated, compressed air at 6.3 to 7.5 bar (90 to 110 PSI)
Do not exceed the maximum or minimum pressures. Operating the tool at the wrong
pressure (too low or too high ) will cause excessive noise or rapid wear of tool.
AIR SYSTEM
Full Head Framing Nails 1-3/4” to 3-1/2” Long (Flat wire welded)
(Fastener size & Nail length: Drives (Dia.2.87-3.7mm) and length (45mm,50mm,
65mm,70mm,75mm,83mm,90mm) wire welded coil nails). Magazine capacity:
225 pcs.
ACCEPTABLE FASTNERS
DESCRIPTION/FEATURES
Features:
No. Description No. Description
Pneumatic coil framing nailer
Quick connector
Quick coupler
Air hose
Lubricator
Regulator (0 to 8.5 bar)
Filter
Cut-o valve
Air compressor
1
2
3
4
5
6
7
8
9
Rugged magazine, Drives 225 nails continuously in contact actuation mode.
Multi-directional exhaust
Comfortable rubber grip.
Equipped with dust cover and body protector.
•
•
•
•
Applications
Making pallets, drums, and export wooden boxes
Crating
Making wooden fence
Heavy-duty packaging
General construction applications including siding, decking, and sheathing
•
•
•
•
•

1282 406
PNEUMATIC COIL FRAMING NAILER
12
The Framing Nailer has two firing modes: Single-Sequential actuation for single firing,
or Contact / bump actuation for repetitive, fast firing of nails.
Each mode requires a dierent method of operation:
Single Firing: To operate the tool in this manner, first position the Workpiece Contact
on the work surface, WITHOUT PULLING THE TRIGGER. Depress the Workpiece
Contact until the Workpiece contact (nose of tool) touches the work surface and then
pull the trigger to drive a fastener. Do not press the tool against the work with extra
force. Instead allow the tool to recoil o the work surface to avoid a second,
unwanted fastener. Remove your finger from the trigger.
Contact or Bumping actuation mechanism: To operate the tool in this manner, hold
the tool with the Workpiece Contact pointing towards but not touching the work
surface. Pull the trigger and then tap (bump) the Workpiece Contact against the
work surface using a bouncing motion. Each depression of the Workpiece Contact
will cause a fastener to be driven.
FIRING MODES
WARNING! Never free-fire the tool at high pressure.
because a nail will be driven when the firing head contacts any surface.
WARNING Extreme care should be taken

13
Please read and observe the operation and safety instructions before using the
tool. Basic safety measures should always be strictly followed to protect against
damage to the equipment and personal injury to the user or other people working
in the vicinity of operation.
Preparing a tool for first time operation
Ensure that the pressure supplied by the compressed air system does not exceed
the maximum allowable pressure of the fastener driving tool. Set the air pressure
initially to the lower value of the recommended allowable pressure.
Empty the magazine to prevent a fastener from being ejected when connected to
the compressor.
Connect the fastener driving tool to the compressed air supply using suitable
pressure hose equipped with quick-action connectors.
Check for proper functioning by applying the Workpiece contact of the tool to a
piece of wood or wooden material and actuating the trigger once or twice.
Connection to the compressed air system
PREPARING THE TOOL FOR USE
•
•
•
•
•
DANGER! Potential hazard that will result in serious injury or loss of life.
• Disconnect the tool from the compressed air source before loading nails.
• Do not point the tool towards the operator or other people while changing nails.
• Do not hold the tool with the trigger pressed while changing or loading the
nail. Failure to comply will lead to serious injury or loss of life.
Disconnect the tool (1) from the air supply (2) (fig A).
Loading nails
1.
fig A fig B
12
1

1282 406
PNEUMATIC COIL FRAMING NAILER
14
Take hold of the pneumatic coil framing nailer with one hand and use the other
hand to press the latch (1) on the magazine and slide it down (fig B), then open to
the left and the magazine open to the right (fig C)
2.
Insert a coil of nails into the magazine. Ensure the points of the nails are facing
down. Be sure to insert the heads of the nails into the channel. Close (push) the
magazine (1) until it locks into place. (Fig C).
3.
Plug in compressor, turn it on and set the pressure regulator to 90psi, attach one
end of the air hose to the compressor and the other end of the air hose (1) to the
tool (2). Use plumber’s tape to avoid air leak (fig D).
4.
Test the driving depth using a sample piece of wood before working on the
workpiece.
5.
12
fig C fig D
1
Note: Refer to the graphic imprinted
below the trigger and adjust the firing
depth accordingly.
For varying materials, the nail depth
can be tool- free adjusted with the
depth adjustment wheel (fig E)
•
Adjusting nail depth
fig E

15
Turn the depth adjustment wheel (1) clockwise (with the discharge area of the tool
facing away from the operator) (fig F).
Increasing nail depth
The coil framing nailer has a lock o switch (1) and the tool cannot be operated
unless it is in the ON position. (fig H).
Flip the lock-o switch (1) down, to allow the tool to operate (fig I).
Methods of operation
Turn the depth adjustment wheel (1) counter-clockwise (with the discharge area of
the tool facing away from the operator) (fig G).
Note: If the nail is not going deep enough, adjust the pressure of the regulator
accordingly.
Decreasing nail depth
fig F fig G
fig H fig I
11
Lock up
11

1282 406
PNEUMATIC COIL FRAMING NAILER
16
• Always handle nails and package carefully. If nails are dropped, collating plastic
may be broken.
After nailing:
1) Disconnect air hose from the nailer:
2) Remove all nails from the nailer:
3) Supply 5-10 drops of pneumatic tool lubricant into the air plug on the nailer:
4) Open the valve on the air compressor tank to drain any moisture.
NOTE:
Connection to the compressed air system
Ensure that the pressure supplied by the compressed air system does not exceed
the maximum allowable pressure of the tool. Set the air pressure initially to the
lower value of the recommended allowable pressure (see product specification
data). Empty the magazine to prevent a fastener from being ejected at the next
stage of work in the event that internal parts of the tool are not in the starting
position following maintenance and repair work or transportation. Connect the tool
to the compressed air supply using suitable pressure hose equipped with
quick-action connectors. Check for proper functioning by applying the muzzle of
the tool to a piece of wood or wooden material and actuating the trigger once or
twice.
Only those fasteners specified under product specifications (see fastener) may be
used.
When filling the magazine, hold the tool so that the muzzle is not pointing towards
the operator or any other person or animals.
Filling the magazine
•
•
The compressed air connectors of tool and the hoses should be protected against
contamination, the ingress of coarse dust chips, sand etc., will result in leaks and
damage to the tool and the couplings.
Disconnect the tool from the compressed air source before loading fasteners.
Do not point the tool towards the operator or other people while changing
fasteners.
Do not hold the tool with the trigger depressed while changing the fasteners.
Failure to comply will lead to serious injury or loss of life.
DANGER! Potential hazard that could result in serious injury or loss of life.
•
•
•
Potential hazard that may result in moderate injury or damage to equipment.
Operate the tool with the utmost care when connected with the air
compressor.
Failure to comply may result in moderate injury or damage to equipment.
WARNING! Potential hazard that could result in serious injury or loss of life.
CAUTION!

17
WARNING! Potential hazard that could result in serious injury or loss of life.
Disconnect the air hose from the tool and remove the non-jammed nails
from the tool before clearing a jammed nail.
The nails are under pressure and failure to comply could cause them to be
fired out of the tool causing serious injury.
Operate the release latch and pull it back to open the movable cover.
Use pliers or any appropriate tool to remove the jammed nails.
Close the movable cover and verify that it relatches in place.
Reload the nails into the tool magazine.
Reconnect the air hose to the tool’s air inlet.
Test fire 3 to 5 nails into a piece of scrap wood in order to ensure a proper
operation.
•
•
•
•
•
•
•
•
WARNING! Potential hazard that could result in serious injury or loss of life.
Do not point the tool towards the operator or other people. Serious personal
injury could result if these instructions are not followed.
•
To clear a jammed nail
Disconnect the tool from the air supply line.
Remove the nails that are stored in the tool’s magazine.
Clearing a jammed nail
If it is necessary to store the tool for an extended period of time, apply a generous
amount of lubrication before storing. The tool should be allowed to run for
approximately 30 seconds after lubricating, in order to ensure that the lubrication is
uniformly distributed throughout the tool.
Storage
•

MAINTENANCE
Lubrication: If the tool and the compressor are not equipped with an in-line
lubrication system, fill 2 to 6 drops of pneumatic tool oil into the air inlet before e
ach use or after every 2 hours of continuous use depending in the characteristic
of work piece or type of fasteners.
Air-operated tools must be inspected periodically, and worn or broken parts must
be replaced to ensure that the tool is operating safely and eciently.
Inspect and replace worn or damaged O-rings, seals, etc. Tighten all screws and
caps.
Frequently in order to help prevent personal injury. Keep the magazine of the tool
clean and free of any dirt or abrasive particles.
TROUBLESHOOTING
SYMPTOM POSSIBLE SOLUTIONS
Air leak near top of
tool or in trigger
area
Air leak near
bottom of tool.
1. O-rings in trigger valve is
damaged.
2. Trigger valve head are
damage.
3. Trigger valve stem, seal, or
O-rings are damaged.
1. Check and replace O-ring.
2. Check and replace.
3. Check and replace trigger valve stem,
seal, or O-ring
1. Loose screws.
2. Worn or damaged O-ring or
bumper.
1. Tighten screws.
2. Check and replace O-ring or bumper.
WARNING! If any of the following symptoms appear while the tool is in use,
turn it o and disconnect it from the air supply immediately. Failure to comply
will lead to serious injury or loss of life.
Disconnect the tool from the air supply before making any adjustments.
Repairs must be performed by a qualified service technician only.
Note: Do not store the tool anywhere temperatures will fall below freezing.
DANGER! Disconnect the tool from the air compressor before maintenance/-
service, adjusting, cleaning jams, reloading, and when it is not in use. Repairs
must be performed by a qualified service technician only. Failure to comply
will lead to serious injury or loss of life.
1282 406
PNEUMATIC COIL FRAMING NAILER
18
The following chart lists common issues and solutions. Please read it carefully and
follow all instructions carefully.

19
SYMPTOM POSSIBLE SOLUTIONS
Blade driving
fastener too
deep.
Tool does not
operate well:
cannot
drive fastener
or operate
sluggishly.
1. Worn bumper
2. Air pressure is too high.
1. Replace bumper
2. Adjust the air pressure.
Tool skips
fasteners.
1. Worn bumper or damaged
spring.
2. Dirt in front plate.
3. Dirt or damage prevents
fasteners from moving freely
in magazine.
4. Worn or dry O-ring on piston
or lack of lubrication.
5. Cylinder cover seal leaking.
1. Repalce bumper or pusher spring.
2. Clean drive channel on front plate.
3. Magazine needs to be cleaned.
4. O-rings need to be replaced. And
lubricate.
5. Replace sealing washer.
Tool jams. 1. Incorrect or damaged
fasteners.
2. Damaged or worn driver guide.
3. Magazine or nose screw loose.
4. Magazine is dirty.
1. Change and use correct fastener.
2. Check and replace the driver.
3. Tighten the magazine.
4. Clean the magazine.
1. Inadequate air supply.
2. Inadequate lubrication
3. Worn or damaged O-rings or
seals.
4. Exhaust port in cylinder head
is blocked.
1. Verify adequate air supply.
2. Place 2 or 6 drops of oil into air inlet.
3. Check and replace O-rings or seal.
4. Replace damaged internal parts.
Air leak between
body and cylinder
cap.
1. Loose screws.
2. Worn or damaged O-ring or
seals.
1. Tighten screw.
2. Check and replace O-ring or bumper.
