SIP 06724 User manual

16
FOR HELP OR ADVISE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR
SIP DIRECTLY ON:
TEL: [phone]
EMAIL: [e-mail] or [e-mail]
www.sip-group.com
Ref: 180913
Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip and
place into the appropriate recycling bin.
1
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference
06724
190 mm
Air Hammer Kit

2
15
Declaration of Conformity
We
SIP (Industrial Products) Ltd
Gelders Hall Road
Shepshed
Loughborough
Leicestershire
LE12 9NH
England
As the manufacturer's authorised representative within the EC
declare that the
190 mm air hammer Kit - SIP Part. No. 06724
Conforms to the requirements of the following directive(s), as indicated.
2006/42/EC Machinery Directive
Signed: …………………………………...
Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd
Date: 06/01/2013.
And the relevant harmonised standard(s)
DECLARATION OF CONFORMITY

14
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Hammer Body AI05-00530 9. Throttle Spring AI05-00128
2. Trigger Pin (3×16) AI05-00121 10. Air Inlet AI05-00129
3. Regulator Valve Pin (3×17.5) AI05-00122 11. Upper valve case AI05-00130
4. O-ring 8×1.8 AI05-00123 12. Valve disc AI05-00130
5. Regulator AI05-00124 13. Lower valve case AI05-00130
6. Trigger AI05-00125 14 - 15 Piston kit AI05-00531
7. Pin AI05-00126 16. Spring Retainer AI05-00135
8. Pin Seat AI05-00127 N/A Chisel set AI05-00533
PARTS LIST
3
Page No. Description
4. Safety Instructions
6. Contents and Accessories
7. Getting to Know Your Air Air hammer
8. Technical Specifications
8. Guarantee
9. Operating Instructions
11. Maintenance
12. Troubleshooting
13. Exploded Drawing
14. Parts List
15. Declaration of Conformity
CONTENTS

4
IMPORTANT: Please read the following instructions carefully, failure to do so could
lead to serious personal injury and / or damage to the air hammer.
When using your air hammer, basic safety precautions should always be followed to
reduce the risk of personal injury and / or damage to the air hammer.
Read all of these instructions before operating the air hammer and save this user
manual for future reference.
The air hammer should not be modified or used for any application other than that for
which it was designed.
This air tool is designed to be used as a hand held, hand controlled tool for air ham-
mering and similar applications.
If you are unsure of its relative applications do not hesitate to contact us and we will
be more than happy to advise you.
Before operating the air hammer always check no parts are broken and that no parts
are missing.
Always operate the air hammer safely and correctly.
KNOW YOUR AIR HAMMER: Read and understand the owner's manual and labels af-
fixed to the air hammer. Learn its applications and limitations, as well as the potential
hazards specific to it.
KEEP CHILDREN AND UNTRAINED PERSONNEL AWAY FROM THE WORK AREA: All visitors
should be kept at a safe distance from the work area; never allow untrained persons
to operate the air hammer.
STAY ALERT: Always watch what you are doing and use common sense.
HAVE YOUR AIR HAMMER REPAIRED BY A QUALIFIED PERSON: The air hammer is in ac-
cordance with the relevant safety requirements. Repairs should only be carried out by
qualified persons using original spare parts, otherwise this may result in considerable
danger to the user and void the warranty.
DANGER! Check that the air hammer is in sound condition and good working order;
Take immediate action to repair or replace damaged parts.
DO NOT dismantle or tamper with the air hammer, as this may be dangerous and will
invalidate the warranty.
If a problem with the air hammer is experienced or suspected stop using the air
hammer immediately and contact your distributor for repair.
Regularly inspect and lubricate the air hammer, ensuring that it is in good working
order and condition.
Always ensure that the work area is clean and tidy, free from unrelated materials and
has adequate lighting.
Clean and stow the air hammer correctly.
Failure to follow the warnings in this manual, may result in personal injury and/or prop-
erty damage.
DO ensure that only compressed air is used to supply the air tool.
The compressed air supply MUST be at a suitable regulated pressure. Pipe work, reg-
SAFETY INSTRUCTIONS
13
EXPLODED DRAWING

12
TROUBLESHOOTING
PROBLEMS POSSIBLE CAUSES REMEDIES
Tool runs at normal speed
but struggles under load.
Motor parts worn.
Piston sticking due to lack
of lubricant.
Check / have the parts checked and re-
pair / replace as necessary.
Check that the piston is well greased; add
grease where necessary.
NOTE: Heat usually indicates insufficient
grease in gears. Severe operating condi-
tions may require more frequent lubrica-
tion.
Tool runs slowly. Air flows
slightly from exhaust.
Inlet filter restricted.
Motor parts jammed with
dirt particles.
Air flow blocked by dirt.
Check air inlet filter for blockage.
Pour air tool lubricating oil into air inlet,
operate tool in short bursts quickly reversing
rotation back and forth where applicable.
Repeat above as needed. If this fails return
to service centre.
Tools will not run. Air flows
freely from exhaust.
Piston Jamming Pour air tool lubricating oil into air inlet,
operate tool in short bursts.
Tap motor housing gently with plastic mal-
let.
If tool remains jammed return to service
centre.
Tool will not shut off.
‘O’ rings throttle valve dis-
lodged from seat inlet
valve.
Replace ‘O’ ring or return to service centre.
Note: Repairs should be carried out by a qualified person.
If any of the following symptoms occurs during your operation, stop using the tool immediately, or serious
personal injury could result. Only a qualified person or an authorised service centre should perform repairs
of the tool. Disconnect from the air supply before attempting repairs or adjustments. When replacing O-
rings etc. lubricate with air tool oil before assembly.
5
ulators, hoses, isolation valves and connection devices MUST be suitable for the in-
tended application correctly installed and maintained in good condition by a com-
petent person.
Appropriate Personal protective equipment MUST be worn and MUST be designed to
protect against all hazards created. Severe permanent injury can result from using
inappropriate or insufficient protective equipment - eyes in particular are at risk.
Long hair MUST be tied back; loose clothing MUST NOT be worn. There is a severe risk
of these being drawn in or trapped by the moving parts of the air tool.
Open or damaged compressed air lines present a significant ‘whip’ hazard; isolate
the problem hose from the air supply and repair / replace the hose immediately.
This air tool is electrically conductive DO NOT allow them to come into contact with
any source of electrical supply.
After use wait for the air tool to STOP completely before putting it aside.
When putting the air tool aside you MUST ensure that it placed in a stable position. To
avoid inadvertent operation DO NOT place the air tool where it can be knocked or
moved accidentally either directly or by the air connection hose.
If the air tool is not required or the air supply is interrupted, disconnect the air tool
from the air supply and place in secure storage to prevent unauthorised use.
Ensure the air valve (or trigger) is in the “off” position before connecting to the air sup-
ply.
Disconnect the air hammer from the air supply before making adjustments, chang-
ing chisels etc. and before servicing the tool.
Always keep your air tool clean and lubricated. Daily lubrication is essential to avoid
internal corrosion and possible failure.
Do not overload the tool. Allow the tool to operate at its optimum speed for maxi-
mum efficiency.
Do not increase the air pressure above the manufacturers recommended level, as
excessive pressure can cause the tool casing to split. This can also create excessive
wear on moving parts and possible failure.
Always ensure that the work-piece is firmly secured leaving both hands free to control
the air hammer.
Always wear safety goggles or glasses during operation.
Do not wear watches, rings, bracelets or loose clothing when using air tools.
Use as light weight a hose as possible from the tool to the wall or compressor cou-
pling.
In the interests of safety and possible damage to the tool/operator, always ensure
that the air hammer has stopped before putting it down after use.
Always ensure that the accessories such as chisels are rated / designed for use with
this air hammer as well as the required application, and are correctly and securely
fastened before connecting the tool to the air supply.
Do not carry or move the air hammer by its air hose.
Never allow the tool to come into contact with harsh solvents such as petrol.
SAFETY INSTRUCTIONS….cont

6
CAUTION: The warnings and cautions mentioned in this user manual can not
cover all possible conditions and situations that may occur. It must be under-
stood by the operator that common sense and caution are factors which can-
not be built into this product, but must be applied.
We recommend wearing ear protection - particularly during extended
periods of operation.
We recommend wearing a face mask or respiratory equipment when
using any air tool; particularly during drilling, sanding, grinding, sawing or
other operations likely to cause airborne particles.
Always wear approved safety goggles / glasses when using or maintain-
ing any air tool, everyday eyeglasses have only impact resistant lenses,
they are not safety glasses.
Note: If any of the above are missing or damaged, contact your distributor
immediately.
190 mm air hammer Instruction Manual Quick Coupler (Euro type)
Retaining Spring Small Bottle of Oil 5 x Chisels
SAFETY INSTRUCTIONS….cont
CONTENTS AND ACCESSORIES
11
DO NOT use the tool if it is, or has parts that are worn, damaged or missing; re-
move from service and have the parts repaired / replaced using original spare
parts.
Ensure that the air tool is lubricated daily with an inline lubricator, or a few drops
of air tool oil dripped into the air inlet.
Clean the air tool after each use.
Check hose and fittings for wear or damage before each use.
Drain the air tank / receiver of the compressor daily; water in the air line will
damage the air hammer.
In the event that it becomes necessary to store the tool for an extended period
of time (overnight, weekend, etc.), it should receive a generous amount of lubri-
cation at that time. The tool should be run for approximately 30 seconds to en-
sure oil has been evenly distributed throughout the tool.
The tool should be stored in a clean and dry environment.
Disconnect the air tool from the air supply before changing accessories,
servicing or performing maintenance. Replace or repair damaged parts.
Use genuine parts only, non-authorised parts may be dangerous and will
invalidate the warranty.
MAINTENANCE
OPERATING INSTRUCTIONS….cont
OPERATING THE AIR HAMMER
Once the bit is fitted and secure:
Connect the air hammer to the air supply via the air inlet (4).
Use the built in regulator (5) to set the correct air flow.
Press the air trigger (3) and the air hammer will operate.
Release the air trigger (3) and the air hammer will stop.
Note: Never start the air hammer with the chisel touching the work-piece.
Allow the air hammer to reach full speed before starting the operation.
Note: To remove the retaining spring; press against the lower spring tab to
remove the spring and the upper spring tab to refit the spring.

10
OPERATING INSTRUCTIONS….cont
CAUTION: If a filter/regulator/lubricator is not installed on the air system,
air operated tools should be lubricated at least once a day or after 2
hours work with 2 to 6 drops of oil, depending on the work environment,
directly through the male fitting in the tool housing.
LUBRICATION
An automatic in-line filter-regulator-lubricator is recommended (Fig.1) as it in-
creases tool life and keeps the tool in sustained operation. The in-line lubricator
should be regularly checked and filled with air tool oil.
Proper adjustment of the in-line lubricator is performed by placing a sheet of
paper next to the exhaust ports and holding the throttle open approximately 30
seconds. The lubricator is properly set when a light stain of oil collects on the
paper. Excessive amounts of oil should be avoided.
In the event that it becomes necessary to store the tool for an extended period
of time (overnight, weekend, etc.), it should receive a generous amount of lubri-
cation at that time. The tool should be run for approximately 30 seconds to en-
sure oil has been evenly distributed throughout the tool. The tool should be
stored in a clean and dry environment.
It is most important that the tool be properly lubricated by keeping the air line
lubricator filled and correctly adjusted. Without proper lubrication the tool will not
work properly and parts will wear prematurely.
Use the proper lubricant in the air line lubricator. The lubricator should be of low
air flow or changing air flow type, and should be kept filled to the correct level.
Use only recommended lubricants, specially made for pneumatic applications.
Substitutes may harm the rubber compounds in the tools O-rings and other rub-
ber parts.
FITTING A CHISEL
Remove the retaining spring (2) (if fitted) by turning it anti-clockwise.
Slide the desired chisel into the air hammer.
Fit the retaining spring over the chisel (as shown below).
Turn the spring clockwise to secure the chisel.
7
Ref. No. Description
1. Chisel
2. Retaining Spring
3. Trigger
4. Air Inlet
5. Air Regulator
1
3
5
4
2
GETTING TO KNOW YOUR AIR HAMMER

8
SIP Part No. 06724
Chisel Length 190mm
Blows Per Minute 3500
Average Air Consumption 2.3 cfm (65 l/min)
Operating Pressure 6.3 bar (90 psi)
Air Inlet 1/4” bsp
Sound Pressure (LpA) * 84.2 dB(A)
Sound Power (LwA) * 95.2 dB(A)
Vibration ** 14.0 m/s2
Guarantee:
This SIP air hammer is covered by a 12 month parts and labour warranty covering fail-
ure due to manufacturers defects. This does not cover failure due to misuse or operat-
ing the air hammer outside the scope of this manual - any claims deemed to be out-
side the scope of the warranty may be subject to charges Including, but not limited to
parts, labour and carriage costs.
The warranty does not cover consumable parts such as chisels.
Failure to lubricate your air tool will shorten its working life and reduce performance.
The warranty does not cover rusting air tools and tools that failed due to the lack of
lubrication.
Note: Proof of purchase will be required before any warranty can be hon-
oured.
TECHNICAL SPECIFICATIONS
GUARANTEE
* Measured in accordance with ISO 15744:2008.
** Measured in accordance with EN 28662-1, EN 28662-5 and EN ISO 8662-9; level of uncertainty 7.4%.
9
1. Ensure the air drill trigger (3) is not depressed before connecting to the air sup-
ply.
2. You will require an air pressure of 90psi, and an air flow according to specifica-
tion.
3. WARNING! Ensure the air supply is clean and does not exceed 90psi while oper-
ating the air hammer. Too high an air pressure and unclean air will shorten the
product life due to excessive wear, and may be dangerous causing damage
and/or personal injury.
4. Drain the air tank daily; water in the air line will damage the air hammer.
5. Recommended hook-up procedure is shown in fig 1.
6. Line pressure should be increased to compensate for unusually long air hoses
(over 8 metres). The minimum hose diameter should be 3/8” I.D. and fittings
must have the highest flow rate that can be fitted to the tool.
7. Keep hose away from heat, oil and sharp edges. Check hose for wear, and
make certain that all connections are air tight secure.
This 190 mm air hammer is designed with a durable lightweight housing. It has a built
in air regulator for precise start-up and control, forward facing exhaust to reduce noise
and direct air flow away from the operators face. It is the ergonomic choice.
Tool
Compressor
Quick Connector Quick Connector
Quick Coupler Quick CouplerAir Hose
Regulator
Lubricator
Filter
Cut Off Valve
Fig. 1
DESCRIPTION
AIR SUPPLY
OPERATING INSTRUCTIONS
