BenQ W1070 User manual

Digital Projector
Quick Start Guide
W1070 W1080ST
W1080ST

Projection dimensions
W1070
Projection distance (mm)
lens position
(mm)
Diagonal
H (mm) W (mm)
Min distance
Average
Max distance
Inch mm (max.
zoom) (min. zoom)
Screen size Lowest/
Highest
Maximum zoom
Maximum zoom
Projection distance
Projection distance
Center of lens
Center of lens
H
H
W
W
Diagonal
Diagonal
Installation for a 16:9 ratio screen
The screen aspect ratio is 16:9 and the projected picture is 16:9
Lowest/Highest
lens position
Lowest/Highest
lens position
Floor Installation Ceiling Installation
Screen
Screen

W1080ST
The above numbers are approximate and may be slightly different from the actual measurements. Only the
recommended screen sizes are listed. If your screen size is not in the table above, please contact your dealer
for assistance.
Projection distance (mm)
lens position
(mm)
Diagonal
H (mm) W (mm)
Min distance
Average
Max distance
Inch mm (max.
zoom) (min. zoom)
Screen size Lowest/
Highest

W1070
Projection distance (mm)
lens
position
(mm)
Diagonal
H
(mm) (mm)
W
(mm)
Min
distance
Average
Max
distance
Inch mm (max.
zoom)
(min.
zoom)
Screen size Lowest/
Highest
Maximum zoom
Projection distance
Projection distance
Center of lens
Center of lens
H
H
W
W
Diagonal
Diagonal
Installation for a 4:3 ratio screen
The screen aspect ratio is 4:3 and the projected picture is 16:9
Lowest/Highest
lens position
Lowest/Highest
lens position
Floor Installation Ceiling Installation
Screen
Screen
height
Image height
Maximum zoom
Image height

W1080ST
Projection distance (mm)
lens
position
(mm)
Diagonal
H
(mm) (mm)
W
(mm)
Min
distance
Average
Max
distance
Inch mm (max.
zoom)
(min.
zoom)
Screen size Lowest/
Highest
height
The above numbers are approximate and may be slightly different from the actual measurements. Only the
recommended screen sizes are listed. If your screen size is not in the table above, please contact your dealer
for assistance.

Ceiling Mount Screws:
M4 (Max. L = 25 mm; Min L= 20 mm)
625.95 577.7 537.9
95.33
163.12 244.12
102.97
43.55
311.95
137
160
46.21 115
80

1
4
ON
2
5
3
2
1

1
2
3
1
OFF
2
X 2

Table of contents
English ........................................................................................... 13
Français ......................................................................................... 14
Deutsch ......................................................................................... 15
Italiano ........................................................................................... 16
Español .......................................................................................... 17
Português ......................................................................................18
Svenska .......................................................................................... 19
Русский ........................................................................................ 20
Nederlands ................................................................................... 21
Polski .............................................................................................. 22
Türkçe ........................................................................................... 23
Čeština .......................................................................................... 24
繁體中文 ...................................................................................... 26
................................................................................................... 25
...................................................................................... 27
............................................................................................ 28
............................................................................................ 29
.............................................................................................. 30

13
All specifications are subject to change without notice.
Optical
Resolution
1920 (H) x 1080 (V)
Display system
Single-chip DLPTM system
Lens F/Number
(W1070)
F = 2.59 to 2.87, f = 16.88 to 21.88 mm
(W1080ST)
F = 2.6 to 2.78, f = 10.2 to 12.24 mm
Lamp
240 W lamp
Electrical
Power supply
AC100–240V, 3.4 A, 50-60 Hz
(Automatic)
Power consumption
375 W (Max); < 0.5 W (Standby)
Mechanical
Weight
(W1070)
2.65 Kg (5.84 lbs)
(W1080ST)
2.85 Kg (6.28 lbs)
Output terminals
Speaker
(Stereo) 10 watt x 1
Audio signal output
PC audio jack x 1
Control
RS-232 serial control
9 pin x 1
IR receiver x 2
Mini B type USB x 1
12VDC (Max. 0.5 A) x 1
Input terminals
Computer input
RGB input
D-Sub 15-pin (female) x 1
Video signal input
S-VIDEO
Mini DIN 4-pin port x 1
VIDEO
RCA jack x 1
SD/HDTV signal input
Analog - Component RCA jack x 3
(through RGB input)
Digital - HDMI x 2
Audio signal input
Audio in
RCA audio jack (L/R) x 2
PC audio jack x 1
Environmental Requirements
Operating temperature
0°C–40°C at sea level
Operating relative humidity
10%–90% (without condensation)
Operating altitude
0–1499 m at 0°C–35°C
1500–3000 m at 0°C–30°C (with
High Altitude Mode on)
Specifications
(EN)
W1070-W1080ST-QSG-17L.fm Page 13 Wednesday, August 1, 2012 5:14 PM

14
Toutes les caractéristiques peuvent être modifiées sans notification préalable.
Caractéristiques optiques
Résolution
1920 (H) x 1080 (V)
Système d’affichage
Système à une puce DLPTM
Ouverture (nombre F)
(W1070)
F = 2,59 à 2,87, f = 16,88 à 21,88 mm
(W1080ST)
F = 2,6 à 2,78, f = 10,2 à 12,24 mm
Lampe
Lampe de 240 W
Caractéristiques électriques
Alimentation
100 à 240 V CA, 3,4 A, 50 à 60 Hz
(Automatique)
Consommation
375 W (max) ; < 0,5 W (veille)
Caractéristiques mécaniques
Poids
(W1070)
2,65 Kg (5,84 lb)
(W1080ST)
2,85 Kg (6,28 lb)
Prises de sortie
Haut-parleur
1 x 10 watts (stéréo)
Sortie de signal audio
1 prise audio PC
Commande
Contrôle série RS-232
1 à 9 broches
2 récepteurs IR
1 port USB type mini B
1 prise 12 V CC (max. 0,5 A)
Terminaux d’entrée
Entrée ordinateur
Entrée RVB
1 connecteur D-Sub 15 broches
(femelle)
Entrée signal vidéo
S-VIDEO
1 port mini DIN à 4 broches
VIDEO
1 prise RCA
Entrée de signal SD/HDTV
3 prises RCA analogique -
composantes (via entrée RVB)
2 numérique HDMI
Entrée de signal audio
Entrée audio
2 prises audio RCA (G/D)
1 prise audio PC
Caractéristiques
environnementales
Température de fonctionnement
0°C à 40°C, au niveau de la mer
Humidité relative en fonctionnement
10% à 90% (sans condensation)
Altitude de fonctionnement
0 à 1499 m à 0°C à 35°C
1500 à 3000 m à 0°C à 30°C (avec
Mode Haute altitude activé)
(FR)
Caractéristiques
W1070-W1080ST-QSG-17L.fm Page 14 Wednesday, August 1, 2012 5:14 PM

15
Alle Daten können ohne Bekanntmachung geändert werden.
Optische Daten
Auflösung
1920 (H) x 1080 (V)
Anzeigesystem
Einzel-Chip DLPTM System
F-Wert des Objektivs
(W1070)
F = 2,59 bis 2,87; f = 16,88 bis 21,88 mm
(W1080ST)
F = 2,6 bis 2,78; f = 10,2 bis 12,24 mm
Lampe
240 W-Lampe
Elektrische Anschlusswerte
Stromversorgung
AC100–240V, 3,4 A, 50-60 Hz
(Automatisch)
Stromverbrauch
375 W (Max); < 0,5 W (Standby)
Weitere Daten
Gewicht
(W1070)
2,65 Kg (5,84 lbs)
(W1080ST)
2,85 Kg (6,28 lbs)
Ausgänge
Lautsprecher
(Stereo) 10 Watt x 1
Audiosignalausgang
PC-Audio-Buchse x 1
Steuerung
Serielle RS-232-Steuerung
9-polig x 1
IR-Empfänger x 2
Mini-B-Typ-USB x 1
12VDC (Max 0,5 A) x 1
Eingänge
Computereingang
RGB-Eingang
15-polige D-Sub-Buchse x 1
Videosignaleingang
S-VIDEO
4-polige Mini-DIN 4-Buchse x 1
VIDEO
RCA-Buchse x 1
SD/HDTV-Eingangssignal
Analog - Component RCA-Buchse x 3
(über RGB-Eingang)
Digital - HDMI x 2
Audiosignaleingang
Audioeingang
RCA-Audiobuchse (L/R) x 2
PC-Audio-Buchse x 1
Umgebungsbedingungen
Betriebstemperatur
0°C–40°C auf Meereshöhe
Luftfeuchtigkeit bei Betrieb
10%-90% (nicht kondensierend)
Höhenlage bei Betrieb
0–1499 m bei 0°C–35°C
1500–3000 m bei 0°C–30°C (mit
Höhenmodus eingeschaltet)
Technische Daten
(DE)
W1070-W1080ST-QSG-17L.fm Page 15 Wednesday, August 1, 2012 5:14 PM

16
Tutte le specifiche sono soggette a modifiche senza preavviso.
Parte ottica
Risoluzione
1920 (O) x 1080 (V)
Sistema di visualizzazione
Sistema DLPTM a chip singolo
Numero/F dell'obiettivo
(W1070)
F = 2,59 a 2,87, f = 16,88 a 21,88 mm
(W1080ST)
F = 2,6 a 2,78, f = 10,2 a 12,24 mm
Lampada
Lampada da 240 W
Parte elettrica
Alimentazione
CA 100–240V, 3,4 A, 50-60 Hz
(Automatico)
Consumo energetico
375 W (massimo); < 0,5 W (standby)
Parte meccanica
Peso
(W1070)
2,65 Kg (5,84 lbs)
(W1080ST)
2,85 Kg (6,28 lbs)
Terminali aoutput
Altoparlante
(Stereo) 10 watt x 1
Uscita segnale audio
Jack audio per PC x 1
Controllo
Controllo seriale RS-232
9 pin x 1
Ricevitore infrarossi x 2
Mini USB tipo B x 1
12VDC (Massimo 0,5 A) x 1
Terminali di input
Input da computer
Input RGB
D-Sub da 15-pin (femmina) x 1
Input da segnale video
S-VIDEO
Porta mini DIN a 4 pin x 1
VIDEO
Jack RCA x 1
Input segnale SD/HDTV
Jack RCA analogico – component x 3
(tramite input RGB)
Digitale - HDMI x 2
Input segnale audio
Audio in
Jack audio RCA (L/R) x 2
Jack audio per PC x 1
Requisiti ambientali
Temperatura operativa
0°C–40°C sul livello del mare
Umidità relativa operativa
10%–90% (senza condensa)
Altitudine operativa
0–1499 m a 0°C–35°C
1500–3000 m a 0°C–30°C (con
Modalità altitudine elevata)
(IT)
Specifiche tecniche
W1070-W1080ST-QSG-17L.fm Page 16 Wednesday, August 1, 2012 5:14 PM

17
Todas las especificaciones están sujetas a cambio sin previo aviso.
Óptico
Resolución
1920 (H) x 1080 (V)
Sistema ópticoSistema DLP
TM de un sólo chip
Lente F/Número
(W1070)
F = 2,59 a 2,87, f = 16,88 a 21,88 mm
(W1080ST)
F = 2,6 a 2,78, f = 10,2 a 12,24 mm
Lámpara
Lámpara de 240 W
Especificaciones eléctricas
Fuente de alimentación
100 – 240 V de CA, 3,4 A, 50-60 Hz
(automático)
Consumo
375 W (máx); < 0,5 W (modo de espera)
Especificaciones mecánicas
Peso
(W1070)
2,65 Kg (5,84 lbs)
(W1080ST)
2,85 Kg (6,28 lbs)
Terminales de salida
Altavoz
(Estéreo) 10 vatios x 1
Salida de señal de audio
Clavija de audio de PC x 1
Control
Control de serie RS-232
9 patillas x 1
Receptor de infrarrojos (IR) x 2
USB tipo mini B x 1
12 V de CC (máx. 0,5 A) x 1
Terminales de entrada
Entrada de ordenador
Entrada RGB
D-Sub de 15 patillas (hembra) x 1
Entrada de señal de vídeo
S-VÍDEO
Puerto Mini DIN de 4 patillas x 1
VÍDEO
Clavija RCA x 1
Entrada de señal de SD/HDTV
Analógico - clavija RCA de
componente x 3
(a través de entrada RGB)
Digital - HDMI x 2
Entrada de señal de audio
Entrada de audio
Clavija de audio de RCA (I/D) x 2
Clavija de audio de PC x 1
Requisitos medioambientales
Temperatura de funcionamiento
0°C–40°C al nivel del mar
Humedad relativa de funcionamiento
10%-90% (sin condensación)
Altitud de funcionamiento
0–1499 m a 0°C–35°C
1.500–3.000 m a 0°C–30°C (con
el Modo altitud elevada activado)
Especificaciones
(ES)
W1070-W1080ST-QSG-17L.fm Page 17 Wednesday, August 1, 2012 5:14 PM

18
Todas as especificações estão sujeitas a alteração sem aviso prévio.
Ópticas
Resolução
1920 (H) x 1080 (V)
Sistema de ecrã
Sistema DLPTM de um só chip
Número F da lente
(W1070)
F = 2,59 a 2,87, f = 16,88 a 21,88 mm
(W1080ST)
F = 2,6 a 2,78, f = 10,2 a 12,24 mm
Lâmpada
Lâmpada de 240 W
Eléctricas
Fonte de alimentação
AC 100-240V, 3,4 A, 50-60 Hz
(Automático)
Consumo de energia
375 W (Máx); < 0,5 W (Em espera)
Mecânicas
Peso
(W1070)
2,65 Kg (5,84 lbs)
(W1080ST)
2,85 Kg (6,28 lbs)
Terminais de saída
Altifalante
(Estéreo) 10 watt x 1
Saída de sinal áudio
Tomada áudio PC x 1
Controlo
Controlo de série RS-232
9 pinos x 1
Receptor IR x 2
USB tipo Mini B x 1
12VDC (Máx. 0,5 A) x 1
Te r m i n a i s d e e n t r a d a
Entrada para computador
Entrada RGB
D-Sub 15 pinos (fêmea) x 1
Entrada de sinal vídeo
S-VIDEO
porta mini DIN 4-pinos x 1
VIDEO
Tomada RCA x 1
Entrada de sinal SD/HDTV
Tomada Analógico - Component RCA x 3
(através de entrada RGB)
Digital - HDMI x 2
Entrada de sinal áudio
Entrada áudio
Tomada RCA áudio (L/R) x 2
Tomada áudio PC x 1
Requisitos Ambientais
Temperatura de funcionamento
0°C–40°C ao nível do mar
Humidade de funcionamento
10%–90% (sem condensação)
Altitude de funcionamento
0–1499 m a 0°C–35°C
1500-3.000 m a 0°C-30°C (com
Modo Grande Altitude ligado)
(PT)
Especificações
W1070-W1080ST-QSG-17L.fm Page 18 Wednesday, August 1, 2012 5:14 PM

19
Alla specifikationer kan ändras utan föregående meddelande.
Optik
Upplösning
1920 (H) x 1080 (V)
Visningssystem
DLPTM-system med enkel krets
Linsens f-nummer
(W1070)
F = 2,59 till 2,87, f = 16,88 till 21,88 mm
(W1080ST)
F = 2,6 till 2,78, f = 10,2 till 12,24 mm
Lampa
240 W lampa
El
Strömtillförsel
AC 100–240 V, 3,4 A, 50-60 Hz
(automatiskt)
Strömförbrukning
375 W (max); < 0,5 W (viloläge)
Mekanik
Vikt
(W1070)
2,65 Kg (5,84 lbs)
(W1080ST)
2,85 Kg (6,28 lbs)
Uttag
Högtalare
(Stereo) 10 watt x 1
Ljudsignalsutgång
Datorljuduttag x 1
Kontroll
RS-232-seriekontroll
9 stift x 1
IR-mottagare x 2
USB av typ Mini B x 1
12VDC (Max. 0,5 A) x 1
Ingångskontakter
Datoringång
RGB-ingång
D-Sub (hona) med 15 stift x 1
Videosignalingång
S-VIDEO
4-stifts mini-DIN-port x 1
VIDEO
RCA-jack x 1
SD/HDTV-signalingång
Analogt - komponent-RCA-jack x 3
(via RGB-ingång)
Digital - HDMI x 2
Ljudsignalingång
Ljudingång
RCA-ljuduttag (L/R) x 2
Datorljuduttag x 1
Miljökrav
Driftstemperatur
0°C - 40°C vid havsnivå
Relativ luftfuktighet vid drift
10% - 90% (icke-kondenserande)
Driftshöjd
0 -1499 meter vid 0°C - 35°C
1500 -3000 meter vid 0°C - 30°C (med
höghöjdsläge på)
Specifikationer
(SV)
W1070-W1080ST-QSG-17L.fm Page 19 Wednesday, August 1, 2012 5:14 PM
