PM 60 / 80 MANUAL BOWL LIFT PARTS LIST
ITEM # DESCRIPTION PART NUMBER ITEM # DESCRIPTION PART NUMBER
1BOLT PM60/PM80-00001 57-1 SWITCH PLATE PM60/PM80-00057-1
2TOP NUT PM60/PM80-00002 58 MICROSWITCH-SFTY.GRD PM60/PM80-00058
3WASHER PM60/PM80-00003 59 MICROSWITCH PLATE PM60/PM80-00059
4BEARING PM60/PM80-00004 60 TRANSMISSION CASE PM60/PM80-00060
5NUT PM60/PM80-00005 61 SPEED CHANGE MECH. PM60/PM80-00061
6BOLT PM60/PM80-00006 62 SPEED CHANGE BALL PM60/PM80-00062
7NUT PM60/PM80-00007 63 SPEED CHANGE SPRING PM60/PM80-00063
8SHAFT COVER PM60/PM80-00008 64 CAM PM60/PM80-00064
9UPPER SPACER PM60/PM80-00009 65 LOCKING UNIT PM60/PM80-00065
10 WASHER PM60/PM80-00010 66 RUBBER RING PM60/PM80-00066
11 SLOW SPEED CLIP PM60/PM80-00011 67-1 PLATE PM60/PM80-00067-1
12 SLOW SPEED PIN PM60/PM80-00012 68 TIME SELECT SWITCH PM60/PM80-00068
13 SLOW SPEED GEAR 12T PM60/PM80-00013 69 TIMER PM60/PM80-00069
14 OUTER SLOW SPEED GEAR PM60/PM80-00014 70 EMERGENCY STOP PM60/PM80-00070
15 BEVEL GEAR PM60/PM80-00015 71 SPEED CHANGE BASE PM60/PM80-00071
16 UPPER CLUTCH GEAR PM60/PM80-00016 72 SPEED CHANGE ROD PM60/PM80-00072
17 BUSHING PM60/PM80-00017 73 SPEED CHANGE KNOB PM60/PM80-00073
18 SLEEVE CLUTCH PM60/PM80-00018 74 NUT PM60/PM80-00074
19 CENTER SHAFT PM60/PM80-00019 75 WASHER PM60/PM80-00075
20 KEYWAY PM60/PM80-00020 76 WORM PM60/PM80-00076
21 KEYWAY PM60/PM80-00021 77 OIL SEAL PM60/PM80-00077
22 KEYWAY PM60/PM80-00022 78 O RING PM60/PM80-00078
23 BUSHING PM60/PM80-00023 79 GASKET PM60/PM80-00079
24 LOWER CLUTCH GEAR PM60/PM80-00024 80 STATOR PM60/PM80-00080
25 LOWER SPACER PM60/PM80-00025 81 WASHER PM60/PM80-00081
26 BEARING (CTR. SHAFT) PM60/PM80-00026 82 BOLT PM60/PM80-00082
27 SEAL PM60/PM80-00027 83 INTERNAL GEAR PM60/PM80-00083
28 SNAP RING PM60/PM80-00028 84 SPRING WASHER PM60/PM80-00084
29 BEARING-TRNS.SHAFT PM60/PM80-00029 85 BOLT PM60/PM80-00085
30 TRANSMISSION SHAFT PM60/PM80-00030 86 BOLT PM60/PM80-00086
31 KEYWAY PM60/PM80-00031 87 SNAP RING PM60/PM80-00087
32 KEYWAY PM60/PM80-00032 88 BEATER SHAFT GEAR PM60/PM80-00088
33 GEAR PM60/PM80-00033 89 BEARING-BTR.SHAFT PM60/PM80-00089
34 SNAP RING PM60/PM80-00034 90 KEY WAY PM60/PM80-00090
35 GEAR PM60/PM80-00035 91 BEATER SHAFT PM60/PM80-00091
36 SNAP RING PM60/PM80-00036 92 BEATER SHAFT PIN PM60/PM80-00092
37 NUT PM60/PM80-00037 93 BEARING PM60/PM80-00093
38 YOKE SHIFT ROD PM60/PM80-00038 94 SEAL PM60/PM80-00094
39 NUT PM60/PM80-00039 95 BOTTOM NUT PM60/PM80-00095
40 SPRING PM60/PM80-00040 96 BOLT PM60/PM80-00096
41 PIN PM60/PM80-00041 97 SAFETY GUARD STOP PM60/PM80-00097
42 YOKE SHIFTER PM60/PM80-00042 98 SAFETY GUARD SCREW PM60/PM80-00098
43 SNAP RING PM60/PM80-00043 99 SAFETY GUARD PM60/PM80-00099
44 BEARING (WORM GEAR) PM60/PM80-00044 100 SPLASH GUARD PM60/PM80-00100
45 KEYWAY PM60/PM80-00045 101 BOLT PM60/PM80-00101
46 WORM GEAR SHAFT PM60/PM80-00046 102 S/S BOWL PM60/PM80-00102
47 BRASS WORM GEAR PM60/PM80-00047 103 FLAT BEATER PM60/PM80-00103
48 SNAP RING PM60/PM80-00048 104 HOOK PM60/PM80-00104
49 TOP COVER (FIBER) PM60/PM80-00049 105 S/S WHIP PM60/PM80-00105
50 ATTCH HUB PLUG PM60/PM80-00050 106 POWER SWITCH PM60/PM80-00106
51 ATTCH HUB SCREW PM60/PM80-00051 110 MICROSWITCH PM60/PM80-00110
52 ATTACHMENT HUB PM60/PM80-00052 111 FIBER BOARD PM60/PM80-00111
53 THUMB SCREW PM60/PM80-00053 112 APRON PM60/PM80-00112
54 BEARING PM60/PM80-00054 113 BOLT PM60/PM80-00113
55 BEVEL DRIVE GEAR PM60/PM80-00055 114 PEDESTAL PM60/PM80-00114
56 GREEN ON SWITCH PM60/PM80-00056-A 115 VENT PM60/PM80-00115
56-1 RED OFF SWITCH PM60/PM80-00056-B 116 BOLT PM60/PM80-00116

PM 60 / 80 MANUAL BOWL LIFT PARTS LIST
ITEM # DESCRIPTION PART NUMBER
117 C-CLIP PM60/PM80-00117
118 GEAR PM60/PM80-00118
119 KEY WAY PM60/PM80-00119
120 HANDLE SHAFT PM60/PM80-00120
121 BEARING PM60/PM80-00124
122 LIFT HOLDING PM60/PM80-00122
123 BOLT PM60/PM80-00123
124 BEARING PM60/PM80-00124
125 C-CLIP PM60/PM80-00125
126 WHEEL PM60/PM80-00126
127 HANDLE PM60/PM80-00127
128 SCREW PM60/PM80-00128
129 GEAR PM60/PM80-00129
130 DRIVE UNIT PM60/PM80-00130
131 BRASS NUT PM60/PM80-00131
132 DRIVE UNIT PM60/PM80-00132
133 KEY WAY PM60/PM80-00133
134 THREAD SHAFT PM60/PM80-00134
135 STOPPER PM60/PM80-00135
136 BOLT PM60/PM80-00136
137 BOLT PM60/PM80-00137
138 BOWL LIFT BRACKET PM60/PM80-00138
139 THREAD NUT PM60/PM80-00139
140 BOLT PM60/PM80-00140
141 PIN PM60/PM80-00141
142 GUIDE PM60/PM80-00142
143 SLIDE WAYS PM60/PM80-00143
144 SPRING WASHER PM60/PM80-00144
145 BOLT PM60/PM80-00145
146 KNOB PM60/PM80-00146
147 BOWL CLAMP ROD PM60/PM80-00147
148 BOWL CLAMP PM60/PM80-00148
149 BOWL SUPPORT PM60/PM80-00149
150 TRANSFORMER PM60/PM80-00150
151 RELAY PM60/PM80-00151
159 BEARING PM60/PM80-00159
160 BRASS BUSHING PM60/PM80-00160
161 BRASS BUSHING PM60/PM80-00161
162 LIFTING APRON PM60/PM80-00162
167 INGREDIENT CHUTE PM60PM80-00167
169 HARNESS PM60/PM80-00169
170 WIRE/PLUG PM60/PM80-00170
172 PLANETARY PM60/PM80-00172
173 BOWL SUPPORT PIN PM60/PM80-00173
174 BOLT PM60/PM80-00174
175 NUT PM60/PM80-00175
176 BOLT PM60/PM80-00176
177 PIN PM60/PM80-00177
178 SPRING WASHER PM60/PM80-00178
179 NUT PM60/PM80-00179
180 SCREW PM60/PM80-00180
181 STOP, BOWL SUPPORT PM60/PM80-00181
182 NUT PM60/PM80-00182

PM 60 / 80 ELECTRIC BOWL LIFT PARTS LIST
ITEM # DESCRIPTION PART NUMBER ITEM # DESCRIPTION PART NUMBER
1BOLT PM60/PM80-00001 55 BEVEL DRIVE GEAR PM60/PM80-00055
2TOP NUT PM60/PM80-00002 57 SWITCH PLATE PM60/PM80-00057
3WASHER PM60/PM80-00003 58 MICROSWITCH-SFTY.GRD PM60/PM80-00058
4BEARING PM60/PM80-00004 59 MICROSWITCH PLATE PM60/PM80-00059
5NUT PM60/PM80-00005 60 TRANSMISSION CASE PM60/PM80-00060
6BOLT PM60/PM80-00006 61 SPEED CHANGE MECH. PM60/PM80-00061
8SHAFT COVER PM60/PM80-00008 62 SPEED CHANGE BALL PM60/PM80-00062
9UPPER SPACER PM60/PM80-00009 63 SPEED CHANGE SPRING PM60/PM80-00063
10 WASHER PM60/PM80-00010 64 CAM PM60/PM80-00064
11 SLOW SPEED CLIP PM60/PM80-00011 65 LOCKING UNIT PM60/PM80-00065
12 SLOW SPEED PIN PM60/PM80-00012 66 RUBBER RING PM60/PM80-00066
13 SLOW SPEED GEAR 12T PM60/PM80-00013 67 PLATE PM60/PM80-00067
14 OUTER SLOW SPEED GEAR PM60/PM80-00014 70 EMERGENCY STOP PM60/PM80-00070
15 BEVEL GEAR PM60/PM80-00015 71 SPEED CHANGE BASE PM60/PM80-00071
16 UPPER CLUTCH GEAR PM60/PM80-00016 72 SPEED CHANGE ROD PM60/PM80-00072
17 BUSHING PM60/PM80-00017 73 SPEED CHANGE KNOB PM60/PM80-00073
18 SLEEVE CLUTCH PM60/PM80-00018 74 NUT PM60/PM80-00074
19 CENTER SHAFT PM60/PM80-00019 75 WASHER PM60/PM80-00075
20 KEYWAY PM60/PM80-00020 76 WORM PM60/PM80-00076
21 KEYWAY PM60/PM80-00021 77 OIL SEAL PM60/PM80-00077
22 KEYWAY PM60/PM80-00022 78 O RING PM60/PM80-00078
23 BUSHING PM60/PM80-00023 79 GASKET PM60/PM80-00079
24 LOWER CLUTCH GEAR PM60/PM80-00024 80 STATOR PM60/PM80-00080
25 LOWER SPACER PM60/PM80-00025 81 WASHER PM60/PM80-00081
26 BEARING (CTR. SHAFT) PM60/PM80-00026 82 BOLT PM60/PM80-00082
27 SEAL PM60/PM80-00027 83 INTERNAL GEAR PM60/PM80-00083
29 BEARING-TRNS.SHAFT PM60/PM80-00029 84 SPRING WASHER PM60/PM80-00084
30 TRANSMISSION SHAFT PM60/PM80-00030 85 BOLT PM60/PM80-00085
31 KEYWAY PM60/PM80-00031 86 BOLT PM60/PM80-00086
32 KEYWAY PM60/PM80-00032 87 SNAP RING PM60/PM80-00087
33 GEAR PM60/PM80-00033 88 BEATER SHAFT GEAR PM60/PM80-00088
34 SNAP RING PM60/PM80-00034 89 BEARING-BTR.SHAFT PM60/PM80-00089
35 GEAR PM60/PM80-00035 90 KEY WAY PM60/PM80-00090
36 SNAP RING PM60/PM80-00036 91 BEATER SHAFT PM60/PM80-00091
37 SNAP RING PM60/PM80-00037 92 BEATER SHAFT PIN PM60/PM80-00092
38 YOKE SHIFT ROD PM60/PM80-00038 93 BEARING PM60/PM80-00093
39 NUT PM60/PM80-00039 94 SEAL PM60/PM80-00094
40 SPRING PM60/PM80-00040 95 BOTTOM NUT PM60/PM80-00095
41 PIN PM60/PM80-00041 96 BOLT PM60/PM80-00096
42 YOKE SHIFTER PM60/PM80-00042 97 SAFETY GUARD STOP PM60/PM80-00097
44 BEARING (WORM GEAR) PM60/PM80-00044 98 SAFETY GUARD SCREW PM60/PM80-00098
45 KEYWAY PM60/PM80-00045 99 SAFETY GUARD PM60/PM80-00099
46 WORM GEAR SHAFT PM60/PM80-00046 100 SPLASH GUARD PM60/PM80-00100
47 BRASS WORM GEAR PM60/PM80-00047 101 BOLT PM60/PM80-00101
48 SNAP RING PM60/PM80-00048 102 S/S BOWL PM60/PM80-00102
49 TOP COVER (FIBER) PM60/PM80-00049 103 FLAT BEATER PM60/PM80-00103
50 ATTCH HUB PLUG PM60/PM80-00050 104 HOOK PM60/PM80-00104
51 ATTCH. HUB SCREW PM60/PM80-00051 105 S/S WHIP PM60/PM80-00105
52 ATTACHMENT HUB PM60/PM80-00052 106 POWER SWITCH PM60/PM80-00106
53 THUMB SCREW PM60/PM80-00053 107 LOCKING HANDLE PM60/PM80-00107

PM 60 / 80 ELECTRIC BOWL LIFT PARTS LIST
ITEM # DESCRIPTION PART NUMBER ITEM # DESCRIPTION PART NUMBER
108 CONTROL PANEL PM60/PM80-00108 166 SCREW PM60/PM80-00166
109 SCREW PM60/PM80-00109 167 INGREDIENTS SLEEVE PM60/PM80-00167
110 MICROSWITCH PM60/PM80-00110 168 CONTROL PANEL SCREW PM60/PM80-00168
111 FIBER BOARD PM60/PM80-00111 169 PLUG HARNESS PM60/PM80-00169
112 APRON PM60/PM80-00112 170 WIRE PLUG PM60/PM80-00170
113 BOLT PM60/PM80-00113 171 RING PM60/PM80-00171
114 PEDESTAL PM60/PM80-00114 172 PLANETARY PM60/PM80-00172
115 VENT PM60/PM80-00115 173 BOWL SUPPORT PIN PM60/PM80-00173
116 BOLT PM60/PM80-00116 174 BOLT PM60/PM80-00174
128 CHAIN GEAR PM60/PM80-00128 176 BOLT PM60/PM80-00176
130 DRIVE UNIT PM60/PM80-00130 177 PIN PM60/PM80-00177
131 BRASS NUT PM60/PM80-00131 178 SPRING WASHER PM60/PM80-00178
132 DRIVE UNIT PM60/PM80-00132 179 BOLT PM60/PM80-00179
133 KEY WAY PM60/PM80-00133 180 BOLT PM60/PM80-00180
134 THREAD SHAFT PM60/PM80-00134 181 BOWL BRACKET PM60/PM80-00181
135 STOPPER PM60/PM80-00135 182 RING PM60/PM80-00182
136 BOLT PM60/PM80-00136
137 BOLT PM60/PM80-00137
138 BRACKET PM60/PM80-00138
139 THREAD NUT PM60/PM80-00139
140 BOLT PM60/PM80-00140
141 PIN PM60/PM80-00141
142 GUIDE LEFT PM60/PM80-00142
142-1 GUIDE RIGHT PM60/PM80-00142-1
143 SLIDE WAYS LEFT PM60/PM80-00143
143-1 SLIDE WAYS RIGHT PM60/PM80-00143-1
144 SPRING WASHER PM60/PM80-00144
145 BOLT PM60/PM80-00145
146 KNOB PM60/PM80-00146
147 BOWL CLAMP ROD PM60/PM80-00147
148 BOWL CLAMP LEFT PM60/PM80-00148
148-1 BOWL CLAMP RIGHT PM60/PM80-00148-1
149 BOWL SUPPORT PM60/PM80-00149
150 CHAIN GEAR PIN PM60/PM80-00150
151 CHAIN GEAR PM60/PM80-00151
151-1 MOTOR PIN PM60/PM80-00151-1
152 CHAIN PM60/PM80-00152
153 SCREW PM60/PM80-00153
154 RING PM60/PM80-00154
155 WASHER PM60/PM80-00155
156 ELECTRONIC LIFT MOTOR PM60/PM80-00156
157 SCREW PM60/PM80-00157
158 MOUNTING BRACKET PM60/PM80-00158
159 BEARING PM60/PM80-00159
160 BRASS BUSHING PM60/PM80-00160
161 BRASS BUSHING PM60/PM80-00161
162 LIFTING APRON PM60/PM80-00162
163 SCREW PM60/PM80-00163
164 SWITCH BRACKET PM60/PM80-00164
165 ELECTRICAL SWITCH PM60/PM80-00165
