Bernafon PRIO 106 BTE DM User manual

PRIO
106 BTE DM
Behind-the-ear hearing instruments
INSTRUCTIONS
FOR USE

Summary
Operating Instructions for
PRIO 106 BTE (Behind-the-Ear) Hearing Instruments
Features 3
Inserting/Removing Instrument 4
with SPIRA flex Sound Tube
ON/OFF 7
Volume Control Indicator 8
Push Button 8
Battery Indicator 10
Battery Replacement 10
Battery Information 12
Direct Audio Input Adapter 14
Tracker Data Logging 16
Safety Guidelines 17
International Warranty 19
Push Button Configuration 21

2
The following hearing instrument is covered in this
operating instruction
PRIO 106 BTE DM
Congratulations on the purchase of your new hearing
instruments. These advanced devices are fully digital
and have been adjusted by your hearing care
professional with the aid of a computer and specially
developed software.
Please follow these instructions when using and caring
for your new hearing instruments. These guidelines
will help you to achieve the best possible results from
your instruments and to once again enjoy the sounds
of life … your family, friends and environment.
Important
Please read the entire content of these instructions
as well as the attached “Guide for Better Hearing”
before using your hearing instruments.

1 Push button
2 Microphone
2a Second microphone
3 Adapter
4 SPIRA flex Sound Tube
5 Sound outlet
6 Dome
7 Concha Clip
8 Battery drawer
9 Direct Audio Input
Description of features with SPIRA flex Sound Tube
2
7
8
6
9
4
5
3
1
2a
3

4
Inserting your hearing instrument
with a SPIRA flex Sound Tube
Inserting your SPIRA flex sound tube correctly
every time, takes practice, patience and perseverance.
• Lift the hearing instrument up and position it behind
your ear.
• Grasp the bend of the tube
between your thumb and index
finger. The dome should be poin-
ting towards the ear canal ope-
ning. Gently push the dome into
your ear canal until the sound
tube sits flush against the side of
your head.
• Position the concha clip into the
indentation above your ear lobe
using your index finger.
Look in a mirror. If the sound tube
is sticking out from your ear, the
dome has not been placed correctly
into the ear canal. If the concha clip is
visibly sticking out from your ear, it has
not been positioned correctly.

5
Removing your hearing instrument
with a SPIRA flex Sound Tube
To remove the SPIRA flex sound tube, grasp the bend
of the sound tube between your thumb and index finger.
Gently pull the sound tube and dome out of your ear.
Important
Do not take the sound tube and dome out of your
ear by pulling the hearing instrument. This might
disconnect the instrument from the sound tube or
cause damage to the sound tube.
Exchanging the sound tube and dome
The sound tube and dome should be changed
if they become stiff or brittle.
Wash and dry your hands before exchanging
the sound tube in order to prevent moisture
or debris from being pushed into
the sound tube adapter.
Exchanging the SPIRA flex
Sound Tube
1. The sound tube
simply snaps off the
hearing instrument's
adapter.

6
2. Attach the new sound tube
by pushing the sound tube
into the hearing instrument's
adapter.
Exchanging the dome
1. Remove the dome by grasping the dome between
your thumb and index finger.
2. Attach the new dome by pushing the dome as far
as possible onto the sound tube. When attached
correctly, it should touch the plastic ring on the
sound tube.
Important
The dome must be properly attached to the sound tube
before inserting it in your ear. Failure to follow the
instructions could result in injury.
Warning
If the dome is not correctly attached and falls off
in the ear canal, please see your medical practitioner.

7
ON/OFF function
ON:
Close the battery door completely.
The hearing instrument will make
one long beep.
OFF:
Open the battery door slightly with
your finger until a click is felt.
It is also possible to turn off the
hearing instruments by placing
the base on a flat surface and then
gently pressing and dragging the
hearing instrument as illustrated.
This action will open the battery
door slightly and turn the hearing
instrument off.
Note: Never force the battery drawer open or closed.

8
Volume Control Indicator
Your hearing instrument will beep continuously
every time you reach the programmed maximum
or minimum levels. This is only applicable with a
Remote Control, which is available as an option.
Push Button function
Your hearing instrument can be programmed
with up to 2 different listening programs.
Use the push button to change
between these programs.
When the hearing instrument is
turned on it will automatically
be in Program 1.
Your hearing instrument will beep in
the following sequence when you move
between programs:
Move into Program 1: One Beep
Move into Program 2: Two Beeps
Repeat this action to cycle through the programs.

9
To see how your hearing instrument push button
operates with a Direct Audio Input adapter, see page
14. To see how your hearing instruments are program-
med see page 21.
Mute function
Press the push button and hold for 2 to 3 seconds
to mute the hearing instrument. Give a short press
to the push button to unmute. The hearing instrument
will revert to its current program.

10
Battery Indicator
When the battery is about to run out the instrument
will beep at regular intervals. This warning indicates
that the battery should be replaced immediately.
Battery Replacement
•
Your hearing instrument uses a size 312 battery.
To insert a new battery
• Useyourfingernailtogentlyswing
the battery drawer fully open, but
do not force it.
• Takeouttheusedbattery.
• Removethecoloredstickerfrom
the new battery (if applicable).
• Placethebatteryintothedra-
wer with the flat, smooth side
facing up (+ sign) as shown in
the drawing.
• Closebatterydrawersecurely.

11
Optional tamper-proof battery drawer
for increased safety
With the battery drawer in
the closed position, insert
a small screwdriver into
the small screw as shown.
Turn it 90 degrees to lock or
unlock the battery drawer.
Note: Do not force the battery drawer open or closed,
excessive strain may deform it.

12
Battery information
• Batterylifewillvarywithconditionsofuse.Ask your
hearing care professional for more information.
• Alwayskeepsparebatteriesonhand.Theseare
available from your hearing care professional.
• Ausedbatteryshouldbereplacedimmediately.
• Ifyouarenotgoingtouseyourhearinginstruments
for a few days, remove the batteries.
• Onlyusebatteriesrecommendedbyyourhearing
care professional, since poor quality batteries can
produce a harmful substance.
• Atbedtime,orattimeswhenyouarenotwearing
your hearing instrument, fully open the battery drawer.
This may help to conserve battery power and reduce
the impact of moisture.
• Any moisture found on a battery should be wiped off
immediately, with a soft cloth.

13
• Usedbatteriesshouldbereturnedtoyourbattery
supplier or hearing care professional for disposal.
• Neverdisposeofbatteriesbyburningthem.
There is a risk that they may explode and cause
injury.
•
Never dispose of batteries with household waste.
They cause environmental pollution.
Note: Always remove zinc-air-batteries before drying
your hearing instrument with the help
of a drying kit.
Drying out zinc-air batteries shortens their life time.

14
Direct Audio Input (DAI 4) adapter
Direct Audio Input (DAI)
Direct Audio Input (DAI) enables the hearing instrument
to receive signals directly from external sources such
as T.V., personal stereo, etc.
Mounting of the DAI 4 adapter
Open the battery door. Slide the DAI adapter onto
the hearing instrument as shown. Make sure the DAI
adapter is securely positioned. Once the DAI adapter
is on the hearing instrument, close the battery door
and connect the DAI cords.
To remove the DAI 4 adapter: Open the battery door.
Slide the DAI adapter off the instrument. Close the
battery door.

15
DAI 4
The hearing instrument will mix the signals from the
DAI adapter with the microphones so that you can
listen to both sources. The hearing instrument will beep
twice in this mode: one lower frequency beep followed
by a higher frequency beep.
It is possible to switch from this combined setting by
pressing the push button so that the hearing instrument
is only amplifying the signal from the DAI adapter. The
hearing instrument will beep three times in this mode:
one lower frequency beep followed by two higher fre-
quency beeps.
If the push button is pressed again, only the sound from
the hearing instrument microphones will be ampli fied.
The hearing instrument will beep once in this mode.

16
Note: The second program will not function with the
DAI adapter in place. To access this
function remove
the DAI adapter from the hearing instrument.
Note: The safety of hearing instruments with DAI
(Direct Audio Input) is determined by the external
signal source. When the DAI is connected to an
electrically powered device, the equipment must
comply with EN 60601-1-1, EN 60065 or equivalent
safety standards.
Tracker Data Logging
Tracker stores information relating to the use of your
hearing instruments such as changes made to
the
overall volume (only if the optional Remote Control is
used) and the push button. This information can be
used by the hearing care professional to further adjust
your hearing device to your individual needs.
If you do not want this feature to be active, please ask
your hearing care professional, to switch it off.

17
Safety Guidelines
Hearing instruments and batteries can be dangerous if
swallowed or improperly used. Such actions can result
in severe injury, permanent hearing loss or even fatality.
Familiarize yourself completely with the following
general warnings and the full contents of this booklet
before using your hearing instruments.
• Hearinginstrumentsshouldbeusedonlyasdirected
and adjusted by your trained hearing care professional.
Misuse or improper adjustments can result in sudden
and permanent hearing loss.
•
Never allow others to wear your hearing instruments,
because they are adjusted for your hearing require-
ments and may permanently damage another person’s
hearing.
• A slap to your ear while wearing the instrument could
be harmful. Avoid wearing your hearing instrument
while playing contact sports (e.g. rugby, football etc.).
• Hearing instruments, their parts and batteries should
be kept out of reach of anyone who might swallow
these items or otherwise cause themselves injury.

18
• Discardbatteriesandkeepthemoutofsightof
infants, small children, pets or persons of mental
incapacity.
•
Clean your hearing instruments and their parts on a
regular basis only with products that are recommended
by your hearing care professional. Microorganisms
from unclean instruments may cause skin irritations.
• Becarefulwithleakingbatteryliquid,asitisa
hazardous substance.
• Nevertrytorechargenon-rechargeablebatteries.
• Neverchangethebatteryoradjustthecontrols
of the hearing instrument in front of infants,
small children and persons of mental incapacity.
• Neverputyourhearinginstrumentorbatteries
in your mouth, they could easily be swallowed.
• Keepbatteriesawayfrommedications.
Batteries are easily mistaken for pills.
• Incaseabatteryorhearinginstrumentisswallowed,
see a doctor immediately.
• Beawareofthepossibilitythatyourinstruments
may stop functioning without notice.
Keepthisinmindwhileyoucirculateintraffic
or otherwise depend on warning sounds.
