BERNSTEIN Dusch basic User manual

OPERATORS MANUEL - II / 2018
Dusch basic BERNSTEIN Shower Toilet

2
Dusch basic BERNSTEIN Shower Toilet
LIABILITY DISCLOSURE
SAFETY INSTRUCTIONS
The supplier is not liable for damages caused by negligence in the following areas:
1. This is an electronic device and must be grounded!
2. Persons with disabilities or small children should not be allowed to use this product without supervision.
3. This product is an electrical device, please pay attention to a proper installation.
Make sure there is proper ventilation.
1. Do not insert or remove any electrical plug with wet hands. Electrical shock may occur.
2. Do not damage the power cord and the plug.
 Otherwisethereisariskofelectricshock,shortcircuitandre.
3. Do not use a damaged electrical plug, cord or a loose plug-in. Any negligence could result
 inelectricalshock,re,shortcircuitordamagetoyourproductmayoccur.
4. An electrical installation should be installed professionally. Any negligence could result in
 electricshock,shortcircuit,reordamagetoyourdevice.
5. Do not disassemble any device without expert knowledge. Any negligence could result in
 electricshock,shortcircuit,reordamagetoyourdevice.
6. Donotallowanyuidsofanykindtocomeincontactwiththeelectricalcomponents.   
 Anynegligencecouldresultinelectricshock,shortcircuit,reordamagetoyourdevice.
7. Caution!Pleasepayattentiontothewaterowdirection.Negligencecancauseirreparable  
damage to your device.
8. Don not bend, twist or bend the steel water hose, this could cause a leak.

3
Rear Wash
Lady Wash
Adjustable Water temperature settings
Adjustable Flow Rate
NozzelSelfcleaning
NozzelManuallycleaning
Night-light
SoftClosingSeatandCover
Body Knob with Breathing Lamp
Rimless toilet
Installation of the toilet
WaterSupplyconnector
Rated Voltage
Power
Lenght of Power cord
WaterSupplypressure
WaterSupplytemperature
Ambient temperature
Waterproof rating
Flow rate
Water temperature
Wash Cycle time
HeatingModel
MaximumHeaterpower
Safetydevice
BackowPrevention
OtherSafetydevice
Netweight
Dimension
Wash
Hygiene
Wash Device
●
●
5Settings(Standard3)
5Settings(Standard3)
●
●
●
●
●
●
Wall-hung
G 3/8“
AC220-240V,50/60Hz
950 W
1,80 m
0,07-0,75MPa(0,7-7,5bar)
4°C - 35°C
4°C - 40°C
IPX4
350 ~ 650 mL/min
31°C - 39°C
3 minutes
Tank
1200 W
Thermal fuses, Level switch, Thermostat
Air Gap
Residual current devices
32 kg
B 384 x T 593 x H 380 mm
TECHNICAL SPECIFICATIONS

4
Dusch basic BERNSTEIN Shower Toilet
TECHNICAL DRAWINGS

5
OVERVIEW
Seateddetector
Cover
Nightlight
Rear Wash
Ladywash
Breathing lamp
Knob
WCSeat
WC Corpus

6
Dusch basic BERNSTEIN Shower Toilet
STOP OPERATION
ADJUSTING WATER FLOW RATE
ADJUSTING WATER TEMPERATURE
BREATHING LAMP SETTING
You can operate by rotating the knob. Rotate the knob in the clockwise direction to activate Ladywash and the
anticlockwise direction for Rear Wash. It will stop after 3 minutes.
In the process of Rear Wash or Ladywash, press the knob it will stop washing.
In the process of Rear Wash or Ladywash you can operate by
rotatingtheknob.Theowratewillincreaseintheclockwise
direction and decrease in the anticlockwise direction.
Always on by default. Open the cover and be seated, without washing, then always
press the knob for 6 seconds. The breathing lamp will be lighted off. It will be lighted
up again when pressing then knob for 6 seconds.
In the process of Rear Wash or Ladywash. Always press the knob and rotate it. The water temperature will be
increased in the clockwise direction and be decreased in the anticlockwise direction.
Note: While Rear Wash or Ladywash, it will wash at the xed position for about 10 seconds and movable wash
for about 18 seconds, then regain to the xed position until to the end.
Ladywash
REAR WASH / LADYWASH
lIn the „seat-down“ position
Rear Wash Ladywash
Rear Wash
NIGHT LIGHT
Always on mode for the night light by default. Open the cover and seat then rotate the knob in the anticlockwise
direction. The night light will be on the deferent mode just as „close“,“always on“,“smart“.
NOTE: The „smart“ mode refers that the night light will light up in a dark environment and light off in a bright
environment.

7
SELF-CLEAN THE TANK
POWER STANDBY SETTING
Notusedformorethan72hours,whentheuseroperatesthewashing,itwillopentheself-cleaningforabout 
30 seconds. All the buttons are invalid during the self-cleaning and it will return to normal after the self-cleaning.
In the state without seating. Keep pressing the knob for more than 6 seconds, it
will go into power standby mode. Press again the knob for more than 6 seconds to
restart it.
NOZZLE CLEANING
Thezozzlewillbecleanedbeforewashingandafterwashing.
The operation of manual cleaning is as follows.
Openthecoverandseatthenrotatetheknobintheclockwisedirection.Thenthenozzlewillextendwithcleaning
water. It will return after 5 minutes or press the stop button.

8
Dusch basic BERNSTEIN Shower Toilet
Lesrenseignementsgurantdanscettenoticedemontagenesontcommuniquésqu’àtitred’informationetpeuventêtre
misàjoursanspréavis.Touteslesguresetdessinsprésentsdanscesinstructionssontuniquementàtitred’illustration
etn’ontaucunevaleurd‘actualité.
Thisinstructionsshouldonlybeconsideredasastandardmanual.Modicationsappliedtoupdatedversionofthe
product might not be mentioned inside this document. In this case, please just use the manual as a reference. The
companyreservesmodicationrights.
Ilseguentemanualeèsolounaguidastandard.Nelcasoincuidovesseroesserepresentierrori,dovutiaeventuali
modichepostumedelprodotto,sipregadiconsiderareilmanualeunicamentecomeriferimentoperilmontaggio.
L´aziendasiriservaildirittodimodica.
ERKLÄRUNG
STATEMENT
EXPLICATIONS
DICHIARAZIONE
DieBedienungsanleitungdientnuralsReferenz.DieseAnleitungkannabweichendeAngabenenthalten.  
DiebeschriebenenProduktekönnenjederzeitaktualisiertwerden.DieZeichnungenindieserAnleitungdienennurzur
Darstellung und haben keinen Anspruch auf Aktualität.
