SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
Best P.O. Box 140 Hartford, Wisconsin www.bestbybroan.com 800-558-1711
WC26E SERIES
RANGE HOODS
Aggressive, wedge-like design - directs heat and
moisture to the blower for exceptional capture.
FEATURES
• Italian design
• Wall mount
• Finish: 304 Stainless Steel #4 Brushed; brushed copper
• Widths: 36”, 42”, 48”
• Telescopic ue accommodates 8’ to 9’ ceilings
• 8-in. round duct connector/backdraft damper
• Halogen lighting (2 x 20 watt, Type JC 12V 20W G4
Base - bulbs included) with multilevels from bright
cooktop illumination to a low nighttime setting
• Advanced, electronic push-button controls feature delay
shutoff
• Use with exterior-mounted or attic-installed remote
blowers for different levels of exhaust capacity (see
specications)
• Delay timer control automatically shuts off range hood
after ten minutes
• Special control indicates when it’s time to clean the lter
• Dishwasher-safe lter features a quick-release latch and
decorative cover plate
• Heat SentryTM - automatically turns blower to high speed
when excess cooking heat is detected
• Light sensor automatically activates glass light
OPTIONS
• Replacement grease lters available (Part No.
SB08087295)
• Flue extensions for 10’ ceilings (Model AEWC26 series)
available in stainless steel or copper (36-7/8” long)
• Interior blower version (WC26ISeries) available,
providing 480 cfm exhaust
• 8-in. to 10-in. transition (Model 414)
SPECIFICATIONS
80C 99043775B
LANOITPOHTIW
SLEDOMREWOLB
REWOLB
MFC STLOV SPMA TCUD
6BE
foorrollaw
tnuom
etomer
srewolb
.xam006
021
34.0
sthgil(
)ylno
+
0.6
.xam
rewolb(
)ylno
tadnuor.ni-8
.dooheht
rewolbeeS
tcudrofsceps
.stnemeriuqer
9BE .xam009
21BE .xam0021
51BE .xam0051
3BLI
citta
dellatsni
enilni
srewolb
.xam082
6BLI .xam006
9BLI .xam008
11BLI .xam0011

Best P.O. Box 140 Hartford, Wisconsin www.bestbybroan.com 800-558-1711
L
L
C
5 "
1
16
WC26E SERIES WIRING
WC26E SERIES MOUNTING
WOOD CROSS SUPPORT
– SECURED TO FRAMING AND
LOCATED BEHIND DRYWALL
A. Minimum hood distance above cooktop must not be less than 22”. A maximum of 28” above the cooktop is
highly recommended for best capture of cooking impurities. Distances over 28” above the cooktop are at the
installer’s and user’s discretion - providing that ceiling height and ue length permit.
B. Requires optional 10-ft. ue extension - ducted Model AEWC26xB.
DRYWALL
FRAMING BEHIND
WOOD CROSS SUPPORT
MOUNTING BRACKET
LOCATION
(ABOVE 36” HIGH
COOKTOP)
CEILING HEIGHT MOUNTING DISTANCE ABOVE 36” HIGH COOKTOP (see note A)
22” 23” 24” 25” 26” 27” 28”
MOUNTING BRACKET LOCATION ABOVE 36” HIGH COOK TOP
8 FEET 41-1/4” 42-1/4” 43-1/4” 44-1/4”
9 FEET 41-1/4” 42-1/4” 43-1/4” 44-1/4” 45-1/4” 46-1/4” 47-1/4”
10 FEET (see note B) 41-1/4” 42-1/4” 43-1/4” 44-1/4” 45-1/4” 46-1/4” 47-1/4”
120 VOLT 60 HZ
2-WIRE PLUS GROUND
POWER SUPPLY
2-WIRE
PLUS GROUND
WIRE BOX
COVER
EXTERIOR OR
INLINE BLOWER
