Betstco FHM FH-EFGCH Series Application guide


www. Betstco.com
541-895-3083 M-F 7am-4pm PST
83371 Melton Rd, Creswell OR 97426


FH-EFGCH Hydraulic Offset Series



Hydraulic Assembly Kit Instructions
A
A
B
B
CC
DD
Once you have the connecting brackets installed correctly, attach the cylinder seat bracket to the flail mower
using the second to the last set of holes from the right side of the mower.
www.BETSTCO.com Phone:[phone] Toll Free: 877-876-7895 Email: [e-mail] 83371 Metlon Rd, Creswell, OR 97426

Next install the hydraulic kit to the mower. All bolts should be installed through the splints and from underside
of the mower housing so that the nuts are on top. Install the cylinder so that the piston rod is attached to the
cylinder seat bracket and the cylinder barrel is attached to the main hydraulic slide bracket.
Run both hydraulic hoses through the slot in the slide bracket.
www.BETSTCO.com Phone:[phone] Toll Free: 877-876-7895 Email: [e-mail] 83371 Metlon Rd, Creswell, OR 97426

Torque Values Chart
5.8 8.8 10.9
Grade 2 Grade 5 Grade 8 Class 5.8 Class 8.8 Class 10.9
in-tpi 1 N · m ft-lb 3N · m ft-lb N · m ft-lb mm x pitch N · m ft-lb N · m ft-lb N · m ft-lb

SafetyLabels
A

B
C
