RASOR SW12M Mounting instructions

SW12M BENCH CUTTER
USE MANUAL

2
EN
COMPANY
ACKNOWLEDGMENT
Rasor®Elettromeccanica S.r.l. was established in Milan in 1946 by the two promoting partners
Spinelli and Ciminaghi. For more than sixty years it has been producing automatic cutting
systems, cutting units for textile applications and electric and pneumatic cutters.
Initially considered as a point of reference for cutting systems in the
textile applications, the Rasor®products are nowadays widely used in
other fields: chemical, automotive, nautical and sport sectors and in
furniture manufacturing.
Rasor®can rely on the professional continuity of three generations,
thanks to the precious support of the promoting partner, to his passion, dedication and
great experience of seventy years.
The main characteristic of Rasor®is that each working phase, starting from the manufacturing
of the product up to its packing and delivery is carried out in Rasor®premises by qualified
operators who have professionaly grown up following the spirit of the company and of its
founders. This ensures the high quality which Rasor® has always considered as essential
since the beginning of its activity.
Following the innovative spirit mentioned above, our company is constantly focused on the
improvement of the product quality, on the study and development of new materials and
technologies.
Dear Customer,
thank you for choosing a Rasor®Elettromeccanica S.r.l. product.
Rasor®has been a reference point in the field of cutting systems in the textile, clothing,
furniture, tailoring, sport, chemical, automotive, nautical and insulating material sectors for
years. Its production has been always synonymous with reliability attested by many of
satisfied customers.
Rasor®quality system supervises all the company activities in order to provide the Customer
with a service that meets its needs and expectations in terms of product quality, delivery
reliability and stock of finished products.
All the parts of the devices have been planned and produced to guarantee an optimum
performance. In order to keep the high quality level and the long reliabilty of the Rasor®
products, it is recommended to use only original spare parts and to contact the head
office for any maintenance work.

EN
3
1. GENERAL SAFETY RULES
This manual is an integral part of bench cutter SW12M and must be carefully
read before using it since it gives important indications with regards to its safe
installation, use and maintenance. Keep it with care.
Before using bench cutter SW12M, read carefully the following general safety
rules.
• PACKAGING.
After taking off the packaging make sure that the bench cutter is intact. In
case of doubt do not use it and contact an authorized service centre. Do not
leave pieces of packaging (plastic bags, foam polystyrene, boxes, etc.) within
the reach of children or disabled persons since they are potential sources of
danger.
• AVOID DANGEROUS ENVIRONMENTS.
Prevent the bench cutter SW12M components from coming in contact with
damp or wet surfaces.
•KEEPCHILDRENAWAY.
Unauthorized persons, in particular children, must be kept away from the
working area.
•FEEDCABLE.
Prevent the feed cable from coming in contact with hot objects, pointed
surfaces or sharp edges. Never pull the feed cable of the machine. It must
never be replaced by the user. If necessary contact professionally qualified
staff.
• KEEP THE WORKING AREA ALWAYS IN ORDER.
The workplace must always be kept in order and well lightened; liquids or oil
traces must not be present.
• ALWAYS USE BENCH CUTTERS SW12M PROPERLY.
Use the bench cutters only to carry out the works they have been designed
for; do not use them improperly.
• OBSERVE THE USE OF THE TOOLS.
Do not cut excessively thick materials and always check blade conditions.
• AVOID ACCIDENTAL STARTINGS.
Before connecting bench cutter SW12M, make sure that everything is installed
properly.
• CLOTHING.
Do not use large clothes or accessories that might get stuck in the moving
parts.
• GOGGLES AND PROTECTIVE METAL MESH GLOVES.
Always use goggles, protective metal mesh gloves approved by Rasor®during
use and maintenance operations (according to UNI EN 388:2004 standard).
•SPAREPARTS.
During maintenance and replacement operations use only original spare parts.
Blade maintenance must be only performed by Rasor®technicians.
• INSTALLATION.
Any installation that is not in conformity with these
specifications could jeopardize your safety and cancels the
warranty.

4
EN
Customer Care Technical Service
WARNING
Informative letter
For any information, please contact
® ELETTROMECCANICA S.r.l.
Via V. Caldesi, 6; 20161, MILANO (MI) - ITALY
Tel: [phone]; Fax: [phone]
e-mail: [e-mail]
web: www.rasor-cutters.com
WARNING
RASOR
The installer and the maintenance man must know the content of this manual. Although
the main features of the machine described in this manual are not subject to change,
Rasor®Elettromeccanica S.r.l. reserves the right to modify the components, details
and accessories it deems necessary to improve the machine or to meet manufacturing
or commercial requirements at any time and without being obliged to update this
manual immediately.
ALL RIGHTS ARE RESERVED ACCORDING TO THE
INTERNATIONAL COPYRIGHT CONVENTIONS,
The reproduction of any part of this manual, in any form, is forbidden without
the prior written authorization of Rasor®Elettromeccanica S.r.l.
The content of this guide can be modified without prior notice. Great care has
been taken in collecting and checking the documentation contained in this
manual to make it as complete and comprehensible as possible.
Nothing contained in this manual can be considered as a warranty, either
expressed or implied - including, not in a restrictive way, the suitability warranty
for any special purpose. Nothing contained in this manual can be interpreted as a
modification or confirmation of the terms of any purchase contract.
Rasor®Elettromeccanica S.r.l. machines have not been conceived to work in areas at risk of
explosions and at high risk of fire and they cannot cut wet or damp materials. Moreover, they
cannot work in case of rain.
In case of damage or malfunction, table cutter SW12M must not be used until the Customer
Care Technical Service has repaired them.
The original configuration of the bech cutter must not be changed at all.
On receiving the machine make sure the supply corresponds to what has been ordered.
In case of non-compliance immediately inform Rasor®.
Also make sure the bench cutter has not been damaged during transport.

EN
5
2. TRANSPORT AND PACKAGING
2
2
3. PLATE DATA
3
READ
THE
INSTRUCTION
MANUAL
DO NOT
REMOVE
THE
SAFETY
DEVICES
HIGH
VOLTAGE
SHEARING
RISK
USE
METAL
GLOVES
USE
GOGGLES
1
1
Class II double insulation
Serial number
Year of production
Model
Electric data
4
5
SW12M
220 230 50 60 2.5 350
550
The bench cutter is delivered in a cardboard box, inside which there are various options.
The code of the ordered product and its serial number are indicated outside the package
(see picture 1). The following accessories are contained in a bag inside the package:
1) Poligonal blade;
2) Wrench for blade nut disassembly.
3) Shuko cable without plug;
4) Fuse;
5) Drift for blade disassembly.
The manufacturer's identification and CE STANDARD 2006/42/CE conformity plate (see picture
below) is located on the front part of the bench cutter.
The plate must not be removed at all, even if the machine is resold. Always refer to the serial
number (written on the plate itself) when contacting the manufacturer.
Several safety warnings are printed on a card which is applied to the cutter feeding cable;
such warnings must be strictly followed by everyone dealing with the machine. The company
is not to be held responsible for damage to property or accidents to people which might
occur if the above-mentioned warnings are not observed. In such a case, the operator is the
only person responsible.

6
EN
4. PRODUCT DESCRIPTION
The fixtures described in this manual is a bench cutter model SW12M which is used in order to cut
strong fabrics. By cutting with the blade and the counterblade always in contact and thanks to
the steel upper quality of the blade supplied, SW12M cutter guarantees the clear separation
without frayings of the two borders of the cut material. The fixture is extremely versatile, light and
precise in the cutting operation. Thanks to the use of a sliding bearing base and an effective
cutting system with a poligonal blade, it is possible to use the bench cutter to cut profiles not only
in the textile and tannage sector, but also in several industrial sectors such as to cut polymers,
thermoacoustic insulators, padding, neoprene, filters, synthetic fabrics and similar fabrics, moquette
and internal parts of cars and ships, glass and carbon fibres. The blade diameter (120mm) and the
motor power (180 Watt) gives to this bench cutter remarkable cutting capacity in terms of
thickness (up to 5 cm). The wide sliding bearing base allows the operator to slide the cutter on
the table without efforts. A sharpener assembled on the cutter heads allows whetting the blade
at any moment without disassembling it. After carrying out this operation, it is possible to start
cutting again. A high power motor, perfectly balanced, with a high number of revolutions and
totally free of maintenance, reduces the vibrations to the minimum, thus making the bench cutter
SW12M complies with Legislative Decree No. 187 dated 19/8/2005, which adopts European
Directive No. 2002/44/CE concerning the risks deriving from mechanical vibrations.The mechanical
parts are made of high resistance steel and bronze and require lubrication after several working
hours.
1
23
4
11
7
8
10
5
6
12
13
14
15
9
16
1 Swit ch pro vided w ith lig ht 9 Poligo nal blad e
2 Motor cover 10 Foot
3 Connector socket 11 Greaser
4 Motor frame 12 Safety catch to enable the
st art ing lever
5 Sharpener push but ton 13 Cont rol lever
6 Motor support 14 Handle
7 Movable front protection 15 Complementary foot
8Roller platform covered with
Teflon®16 Counterblade
Device components

EN
7
7. FIELD OF APPLICATION
6. NOISE LEVEL
5. TECHNICAL FEATURES
The technical data are only indicative and they can be changed without notice.
NOTE
It is advisable for bench cutter SW12M’s owners to verify the compliance with the standard
concerning safety of workers: Italian legislative decree N.277 ITEM IV (DATED 15-08-91).
The use of ear protecting devices is compulsory.
The maximum acoustic pressure level emitted by bench cutter SW12M is about 60 dB (A).
Noise tests have been carried out in compliance with Standard ISO 11202 (1995). The
device noise levels, measured at different distances (without any sound wave filtering
system), vary in the extent of few db (A).
Bench cutter SW12M has been designed, manufactured and assembled to cut every kind of
fabrics or materials, with the exception of metal, plastic or wood, by means of rotary poligonal
blades.
This equipment must not work:
- in areas prone to explosions;
- in presence of fine dust or corrosive gases;
- on wet or damp materials;
- to cut plastic, metal and wooden materials.
It is forbidden to use bench cutter SW12M for purposes different from the above-mentioned
ones.
8 side blade Ø 120 mm, in H.S.S. steel
12 side blade Ø 120 mm, in H.S.S. steel
Circular blade Ø 120 mm, in Extra steel
8 side blade Ø 120 mm, in H.S.S. steel
covered with TIN
12 side blade Ø 120 mm, in H.S.S. steel
covered with TIN
8 side blade Ø 120 mm, in H.S.S. steel
covered with Teflon
8 side blade Ø 120 mm, in hard integral
metal
Features of the available blades
12SHSS
12CSW
12SMD
12DHSSTN
12SHSSTN
12DHSS
12DHSSTF
120 mm with hard metal counter
blade
550 rev/min
about 50 mm
Monophase 220 V - 350 W
2,5 A
3,300 Kg
4,400 Kg
1,5 mt
LUX 200
< 2,5 m/s2
0 ~ 55°C
10 ~ 95% without condensate
Cutting working depth
Motor power
Weight (with feeding cable)
Bench cutter SW12M features
Blade diameter
Blade speed
Max. Absorption
Temperature
Humidity
Weight with package
Electric cable lenght
Minimum luminosity for working
o
p
erations
Vibrations at the start up

8
EN
8. USE WARNINGS
WARNING
3
9. ELECTRIC CONNECTION
We recommend following the indications below in order to always work in safety conditions.
•All the operations must be carried out complying strictly with the safety rules of the
country where the device is to be installed.
•It is STRICTLY FORBIDDEN to smoke during the installation or adjustment operations of
the bench cutter.
•The Customer undertakes to comply with and make his staff observe all the rules and
regulations in force concerning safety, prevention of accidents and health in the work
place. Therefore, the Customer assumes the responsibility to strictly follow all the rules and
regulations in force, as well as the special provisions in force in sport and public installations
the Customer declares to know after receiving all the relative necessary information.
•The bench cutter works also without their safety protective device. This protective device
must NEVER be removed.
•Always check the resistance of the material to be cut and the kind of blade which is being
used.
•The Customer shall equip his own personnel with all the individual safety protections for
the execution of the works, as well as with the ones which might be prescribed by the
Manufacturer due to specific danger conditions of the plant or of the area where the
personnel must work.
•Only one operator must use the bench cutter always standing behind the guide handle.
Do not make any adjustment while the blade is working or while the electric plug is
connected.
•Always pay attention to the electric cable position to prevent it from being cut or damaged
by the blade.
•It is allowed to assemble bench cutter SW12M on machines O.E.M. on condition that their
original structure is not modified. Otherwise, the intervention must be certified by Rasor®.
Firstly make sure that the lines are able to feed the cutter correctly, in compliance
with the safety rules (for the feature required see par. 5).
We suggest installing a magnetothermic safety device before the cutter and check
that the ground circuit is effective. Before working on the feeding cable pull the
plug out. Check that electric connections and protections correspond to the driving
force and the plate data values (voltage and current), required
by the different electric circuits. Possible faulty ground
connections make the working conditions unsafe. Possible
damages are not charged to Rasor®. By referring to the EC 11-
27/1 standard all the works carried out by means of electric
current must be performed by a staff, who has been provided
with all the devices required by the above-mentioned
standard. For the works carried out under voltage, it is
necessary that the employer certifies the suitability, against
formative processes. As the cutter SW12M is supplied without
plug, the user must use a plug homologated in the country in
which the cutter is used. In the European Countries a Shuko plug
is required (see picture 3). The electric cable is equipped with
yellow and green grounding. Never change the lenght of the cable
supplied.

EN
9
10. RESIDUAL RISKS
11. USE
Even though the bench cutter is safe, operators must pay attention to preserve their and
other people’s safety.


At the end of the working operations, the motor could be very hot.

The cutting blade can work even when the protective device is disassembled.
To use the bench cutter manually, proceed as follows:
1) Lay the material to be cut on a table;
2) Connect the cutter to the electric feeding (see picture 4);
3) Put the material on the cutting foot;
4) Adjust the front mobile protection according to the thickness of the material to be cut;
5) Enable the switch; once it has been enabled, it lights with a green light (see picture 5);
6) Press the starting lever after having moved the safety catch (see picture 6);
7) Push the bench cutter to the desired direction, by trying to put the material in front
of itself as stretched as possible, preventing it from curling in the front part of the
cutter. To work, the cutter must be placed on a surface and must slide by means of
the rolls placed under the sliding platform.
NOTE:
The thrust on the bench cutter must be as uniform as possible. To carry out linear cuts with
precision (and to follow predetermined paths), we also recommend using the arrow point
(see point “A” in picture 7).
5
4
67
A


10
EN
12. BLADE SHARPENING
13. LUBRICATION
After many hours of a continuative use of the bench
cutter, or if it would not be able to cut anymore, it is
necessary to sharp the blade.
To carry out this operation, start the blade and press
sharpener “2” located on it 3-4 seconds (by pressing
push button “1”, as shown in picture 8).
Repeat the operation 2-3 times.
If the sharpening operation is not effective, check the
wear of emery grinding wheel “3” (see picture 9).
If grinding wheel “3” is too worn or dirty, replace it.
14. MOTOR BRUSH REPLACEMENT
Every 3-4 working hours, it is necessary to lubricate the
pair of gears. To carry out this operation, remove
protective plug “A” located on the motor support of the
bench cutter and fill it with lubricating grease Rasor. Screw
plug “A” again few turns. Screw plug “A” some turns
every 2-3 working hours (see picture 10).
WARNING
The blade must never be dirty with grease or oil.
Worn motor brushes could create a cutter malfunction (no starting, intermittent start,
etc.), therefore it should be better to verify their wear periodically.
Open the motor cover by unscrewing 4 screws “4” on the cutter head (see picture 11).
Remove the metal contacts that close the brushes with a slotted screwdriver (see picture
12). Remove the brushes and check their wear: if the graphite has a lenght shorter than 15
mm or it is uneven, replace it (see picture 13).
Close the metal contacts again by making sure that they adhere well to the metal part of
the brush. Finally close the motor cover again.
8
1
2
9
3
10
A
11 12
4
13

EN
11
15. BLADE REPLACEMENT
1
14
3
2
If the blade is no more able to cut (even after repeating the
sharpening operation several times) it is necessary to replace
it. To carry out this operation, use wrench “1” and drift “3”
locking the blade (shown in picture 14).
To replace the blade, proceed as follows:
1) Use some protective gloves in compliance with
Legislative Decree 242 dated 19 March 1996 (use of
personal protection devices);
2) Remove the fixed rear safety protection “A” (see
picture 15) by unscrewing the three cross screws “C”,
“D” and “E” by means of a screwdriver (not supplied
by the manufacturer) as shown in picture 16.
Remove the mobile front safety protection “B” (see
picture 15) by unscrewing pin “F” and removing the
two washers “G” as shown in picture 16.
3) Insert drift “3” (see picture 14) into hole “H”, so as
to lock the blade (the hole on the blade must
correspond to the one on the structure).
4) Use butterfly wrench “1” to unscrew nut “L” and
remove blade “M” (see picture 17).
5 ) Replace the worn blade with the new one “2”, being
careful to center the blade on the shaft, in the correct
position, and remember to assemble it with the side
with the writing Rasor positioned towards the external
side of the bench cutter.
6) Assemble all the components again and carry out
the sharpening.
15
BA
16
E
G
H
M
1
L17
F
CD

12
EN
17. SPARE PARTS / EXPLODED VIEW
16. TROUBLESHOOTING


SOLUTION
Check that the blade and the counterblade contact with
each other
Check the kind of fabric
Sharpen the blade
Check the fabric thickness
Check the compatibility between blade and fabric
Make sure that the motor turns correctly
Reduce the feeding speed
Check the counterblade integrity
Carry out the lubrication
Disassemble the blade and remove the material residues
Check the wear of the pair of gears
Check the protection fuse
Check the electric connections
Check the motor brushes
Check the feeding cable
The cutter starts slowly, workd intermittently or
it does not start

PROBLEM
The cutter is noisy
The fabric is not cut or it gets stuck between the
blade and the counterblade
CODE DESCRIPT ION CODE DESCRIPT ION CODE DESCRIPTION CODE DESCRIPT ION
12SHSS 8-SIDE BLADE Ø 120 mm, H.S.S. STEEL SW121900 COMPLETE PAIR OF GEAR SW127500 BEARING ADJUSTMENT T 102900 HANDLE SWITCH WITH LIGHT, OLD TYPE
SW104102 OILER RING SW122000 LOWER MOTOR CAP SW127501 BEARING ADJUSTMENT FIXING GRAIN T 102902 HANDLE PUSH BUTTON, OLD TYPE
SW104103 OILER RING SPRING SW1229M UPPER MOTOR CAP SW127600 CLOSE CAP T 102903 LEVER PUSH BUTTON
SW107101 COMPLEMENT FOOT SW123800 STEEL STRUCTURE SW127700 COUNTERBLADE SPRING T 102904 CAP SWITCH WITHOUT LIGHT
SW107701 COUNTERBLADE SPRING FIXING SCREW SW123900 STRUCTURE FIXING S CREW SW127800 PLATFORM SECTOR T 102904L CAP SWITCH WITH LIGHT
SW1078M COMPLEMENT SECTOR SW124000 STRUCTURE SUPPORT SCREW SW128600 Ø 30x10x6 EMERY, MEIUM GRAINED T 102906 RATCHET AND LEVER FIXING PIN
SW107900 COUNTERBLADE HOLDER FIXING SCREW SW124100 FIX REAR PROTECTION SW1286CPL COMPLETE EMERY UNIT, MEDIUM GRAINED T 102908 SWITCH LEVER
SW108000 COUNTERBLADE HOLDER SW124101 3x10 MA SCREW REAR GUARD FIXING T 100102 MOTOR CAP WITH SLOT T 102908CPL COMPLETE LEVER
SW108100 WIDIA COUNTERBLADE SW124102 3x5 MA SCREW REAR GUARD FIXING T 100200 MOTOR CAP FIXING SCREW T 102909 LEVER RATCHET
SW108200 COUNTERBLADE FIXING SCREW SW1241CPL REAR PROTECTION SET T 100201 SOCKET SCREW T 102910 RATCHET SPRING
SW108700 EMERY PIN SW124400 FRONT PROTECTION GUARD T 100300 ADJUSTMENT LOCKING SCREW T1029F31 3.15 FUSE FOR FEEDING CIRCUIT
SW108800 EMERY SPRING Ø 11 mm SW124402 FRONT PROTECTION FIXING S CREW T 100600 MOTOR BRUSHES T 103000 HA NDLE S W IT CH/ PUS H BUT T ON F IXING
SCREW
SW108900 SHARPENER BUSH SW1244CPL FRONT PROTECTION SET T 100700 BRUSH HOLDER T 104700 GREASER CAP
SW109000 EMERY SPRING Ø 6 mm SW1255M COMPLETE MOTOR SUPPORT T 100800 BRUSH HOLDER CLIP T 104800 GREASER
SW109100 EMERY CAP SW125600 SUB-BLADE RING T 100900 BRUSH HOLDER FIXING SCREW T 105200 MOTOR SUPPORT FIXING BOLT
SW109200 EMERY CAP FIXING SCREW SW126101 BLADEGUIDE SERIES >2001 T 101500 FAN T 105300 WAS HER
SW109300 WASHER SW126102 REFERENCE PIN T 101801 ELASTIC PIN T 106400 BEARING PIN
SW120400 MOTOR BEARING ADJUSTMENT SW126103 GEAR RING FIXING SCREW T 102001 UPPER CAP FIXING SCREW T 106800 ROLLER FIXING SCREW
SW120500 CORRUGATED THRUST BEARING PAIR SW126201-1P GEAR RING T 102100 LOWER CAP FIXING SCREW T 107000 PLATFORM FIXING SCREW
SW121000 MOTOR BEARING L9 SW126300 RING NUT FIXING THE BLADE T 102200L MOTOR FRAME WITH MEGNETS T 107500 BLADE AS S EMBLING/DIS ASS EMBLING
WRENCH
SW121200 ANTI-GREASE WASHER SW126500 PLATFORM ROLLER BEARING T 102201 PAIR OF PERMANENT MAGNETS T 107600 DRIFT LOCKING THE BLADE
SW1213P COMPLETE ROTOR 220 V - 350 W SW126501 BEARING WASHER T 102300L HANDLE SECTOR T 107900 LUBRICATING GREASE
SW121600 MOTOR BEARING L12 SW1265CPL SLIDING ROLLER SET T 102400 HANDLE SECTOR FIXING SCREW T104501 PAIR OF ROUNDED WASHERS
SW121700 ELASTIC RING SW127201 GEAR BEARING R6 T 102701 L-PLUG WITH FROMMET T105400 ANTI-FRICTION WASHER
SW121800-1P WORM SCREW - MOD. 1,25 1P SW1274M SIMPLE PLATFORM T 102702 SOCKET SCREW T107000 PLATFORM AND SECTOR FIXING SCREW
SW121801CPL-1P COMPLETE PAIR OF GEAR -MOD. 1,25 1P SW1274MCPL COMPLETE PLATFORM T 1027CPL FEEDING CABLE WITHOUT PIN

SW126201-1P
SW1255M
SW126101
SW121500
SW122000
dal 1946
®
T 100102
SW127600
T 105300
SW124402
SW1244CPL SW124400
T104700
SW127201
SW121900
SW121000
T 105200
T105400
SW121200
SW127500
T 107500
T 102900
T 103000 T 103000
T 102100
T 100800
SW127501
T 107600
T 102902
T 103000T 103000
T 102908
T 1027 CPL
T 107900
T 102910
T 102906
T 102909
T 102906
T 102904L
T 102702
T 102904
T 102908CPL
T 100600
T 100900
T 102200L
T 100700
T 100300
T 100900
T104501
T104501
SW120500
SW120400
S W 12 29M
T1029F31
T 102701
SW124102
12SHSS
SW126102 SW124101
SW126103
SW124101
SW1241CPL
SW126300
SW127201
SW124100
SW104103
SW104102
SW125600
T 101801
SW121700
SW121600
T 102201
T 100201
SW121801CPL-1P
SW126201-1P
SW121800-1P
T 106800
SW127700
SW107701
SW107900
SW127800
T107000 SW126500
T 106400
SW126501
SW1265CPL
SW108100
SW107101
SW108200
SW10800
SW109100
SW1286CPL
SW109000
SW109200
SW109300
T104800
T 100200
T 102001
T 102903
T 102300L
T 102400
SW1213P - V220-240V
S W 12 78M
SW108900
SW108800
SW108700
SW128600
SW123900
SW123800
SW124000
S W 12 74M
SW1274MCPL

WARRANTY
Rasor®Elettromeccanica S.r.l. bench cutter has a 12 month warranty from the date indicated
on the last page of this manual, except in case of different written agreements.
The warranty covers all manufacturing and material defects. Replacement and repair operations
are covered only if carried out by our company and at our workshop.
The material to be repaired must be sent CARRIAGE FREE.
Once the machine has been repaired, it will be sent CARRIAGE FORWARD to the customer.
The warranty covers neither technicians' intervention on site nor the machine disassembly
from the installation place.
If for practical reasons, one of our technicians is sent to the premises, the customer will be
charged the costs plus the travelling expenses.
The warranty does not include:
failure caused by wrong use or assembly,
failure caused by external agents,
failure caused by lack of maintenance or neglicence;
blades and parts subject to wear.
WARRANTY FORFEITURE:
In case of arrearage or other breaches of contract,
Whenever changes or repairs are carried out on our cutters without our prior
authorization,
Whenever the serial number is tampered with or cancelled,
Whenever the damage is caused by improper use, bad treatment, bumps, falls and
other causes not due to normal working conditions,
Whenever the unit seems tampered with, dismantled or previously repaired by
unauthorized staff,
In case the bench cutters are used for purposes that are different from the ones
described in this manual.
All repair operations carried out under warranty do not interrupt its duration.
All disputes will be settled in the court of justice of Milan (Italy).
We thank you in advance for the attention you will pay to this manual and we invite you to
inform us of any change you deem necessary to improve it and make it more complete.

RASOR ELETTROMECCANICA SRL
Via Vincenzo Caldesi 6
20161 Milan ∙ Italy
ph. [phone]
fax [phone]
[e-mail]
www.rasor-cutters.com
FOLLOW US:
