INSTALLATION MANUAL FOR THE
ATLANTIS BACK ENTRY
Thank you for purchasing an Atlantis. We take great pride in our products and the toilet
you have purchased has been designed and manufactured to the highest standards.
Please read through the manual carefully and make sure that you understand the
installation process.
Please check the toilet carefully, to see if there are any irregularities or damages
before you begin. This is a precaution to ensure that the toilet has not been damaged
in handling and transport. After the toilet has been installed no claim for visual
defects will be considered.
Whilst we pride ourselves in producing the best product, we at BETTA Sanitaryware
cannot take responsibility for damages that may occur during the installation
process.
4 Dobson Street, Chamdor, Krugersdorp 1740
www.ceramic.co.za
Tel: [phone]
4 1
‘THROUGH LEGENDARY DESIGN COMES LUXURIOUS BATHROOMS’.
The Atlantis suite is captured with clear lines and striking form. The
Sleekness and elegance of its timeless style, will create a sophisticated
and luxurious bathroom space to rival any European standards.
PAN WEIGHT: 29kg
CISTERN WEIGHT: 11.5Kg
Floor mounted with screw xations.
Wash-down type,“P”“S”trap outlet,
close rim ush.
SOFT CLOSE SEAT COVER

90
180
275
170
750
210
220
180
FIXATION BRACKETS
TECHNICAL DRAWINGS
810
420
Finish the frame. The outside of the frame is often tiled to create a cohesive bathroom design.
“P”TRAP & “S”TRAP
The Atlantis has the option of using a “P” Trap
or “S”Trap pipe.
WATER INLET AND PIPE
BACK ENTRY
WATER INLET
STEP 2
23
STEP 1
STEP 3
Please make sure
your water inlet,
outlet pipe
and pan xation
are as to the specied
measurements.
BACK ENTRY
WATER INLET
Cable must be on
the right hand side
as shown.
31
44
Wirquin back
entry installed
mechanism
(Atlantis cistern).
All the
mechanism are
set for 3/4.5L
ushing.
210
105
210
90
160
105
210
“P”Trap
“S”Trap
Please note that
the water inlet pipe
is only on the left
hand side.
