Better Homes and Gardens BHF1025004004 User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2021-06-08 Rev. 0001-A
Farmhouse Writing Desk
St ck # BHF1025004004
ADULT ASSEMBLY RE UIRED
If y u have any questi ns regarding assembly r if parts are missing, DO NOT return this item t the
st re where it was purchased. Please call ur cust mer service number and have y ur instructi ns
and parts list ready t pr vide the m del name, part name r fact ry number:
866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., M nday - Friday
Or visit ur web site 24 h urs a day, 7 days a week f r pr duct assistance at
www.whalenstyle.com
Or e-mail y ur request t [e-mail]
LOT NUMBER:
DATE PURCHASE
D
:
/
/

2
MANUFACTURER: Whalen Furniture Manufacturing
CATALOG: Farmh use Writing Desk
St ck # BHF1025004004
UALITY GUARANTEE
We are c nfident that y u will be delighted with y ur Whalen Furniture purchase.
Sh uld this pr duct be defective in w rkmanship r materials r fail under n rmal use, we will repair r replace
it f r up t ne (1) year fr m date f purchase. Every Whalen Furniture pr duct is designed t meet y ur
highest expectati ns. We guarantee that y u will immediately see the value f ur fine furniture.
This warranty gives y u specific legal rights and y u may als have ther rights which vary fr m State t State.
Whalen Furniture Manufacturing
1578 Air Wing R ad, San Dieg , CA 92154, USA
Cust mer Service: 866-942-5362
8:30 a.m. - 4:30 p.m., PST, M nday t Friday
www.whalenstyle.com
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S
THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE MAXIMUM
WEIGHTS INDICATED. USE WITH LOAD HEAVIER THAN THE MAXIMUM WEIGHTS
INDIC
AT
ED MAY RESULT IN INSTABILITY
,
CAUSING POSSIBLE INJURY.
MAXIMUM LOAD 200 lb. (90.7 kg)
MAXIMUM LOAD 10 lb. (4.53 kg)

3
IMPORTANT
Bef re y u begin: Open, identify and c unt all parts pri r t assembly. Lay ut parts n a flat and
n n-abrasive surface. Y u will need the parts identified n page 6 f this instructi n manual.
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED OFF
WITH DAMP CLOTH.
Insert D wel at least halfway by tapping lightly with a rubber mallet, IF NECESSARY.
CAM LOCK SYSTEM OPERATION
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw the Cam B lt int the pre-drilled small h les n the panel. C nnect b th panels t gether; making sure
the Cam B lt g es int the pre-drilled h le at the end f the panel with the Cam L ck.
2. Insert the Cam L ck int the pre-drilled large h le in the panel. Make sure the arr w n the Cam L ck is
p inted t wards the Cam B lt.
3. Once the Cam B lt is c nnected inside the Cam L ck, take a Phillips screwdriver (n t included) and
tighten the Cam L ck cl ckwise.
4. Plug the Cam L ck C ver int the cr ss sl t f the Cam L cks t c nceal the cam.
Y u are n w ready t assemble the KD unit.
X
X
FINAL
1 2 43

4
FURNITURE POWER DISTRIBUTION CENTER
IMPORTANT SAFETY INSTRUCTIONS
Carefully read all instructions installing and operating fixture
IF YOU HAVE ANY UESTIONS REGARDING THE PROPER INSTALLATION
CONSULT A UALIFIED ELECTRICIAN.
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR
INJURY TO PERSONS, PLEASE FOLLOW THE NEXT:
 Use nly insulated staples r plastic ties (n t included) t secure the c rds.
 R ute and secure c rds s that they will n t be pinched r damaged when the desk is pushed up against
the wall.
 Make sure c rd is n t pinched between desk and fl r.
 Use the unit ind rs nly.
 D n t use an extensi n c rd t c nnect this unit t a wall utlet.
 Use p wer strip with integral ver-current pr tecti n t supply ther electrical devices r access ries in
desk.
 This unit must be plugged int a pr perly gr unded utlet.
 The s cket utlet sh uld be installed near the equipment and sh uld be easily accessible.
 Maximum l ad f c nnected equipment cann t exceed a t tal f 12 amps and 120 v lts.
 D n t pen r disassemble this unit f r any reas n.
SAVE THESE INSTRUCTIONS

5
Furniture P wer Distributi n Unit User Guide
Please read this user guide bef re installing and using y ur p wer distributi n Center.
INTRODUCTION
The integrated p wer and USB center ffer 480 Mbps
high transmissi n rate and can c nnect up t tw devices,
such as a digital camera, MP3 player, cell ph ne r
wireless m use.
SPECIFICATIONS
cULus listed, rated f r: 120 V AC, 12 A, 60 HZ
NOTES
 T reach USB 2.1 high speed, y ur c mputer r h st
adapter card must supp rt USB 2.1. This hub is als
backwards c mpatible with USB 1.1.
 When using the hub with a c mputer that has a
versi n 1.1 USB interface, all f the devices attached
t the hub will run at USB 1.1 speed.
NOTE: This equipment has been tested and f und t
c mply with the limits f r a Class B digital device,
pursuant t part 15 f the FCC Rules. These limits are
designed t pr vide reas nable pr tecti n against harmful
interference in a residential installati n. This equipment
generates, uses and can radiate radi frequency energy and,
if n t installed and used in acc rdance with the instructi ns,
may cause harmful interference t radi c mmunicati ns.
H wever, there is n guarantee that interference will n t
ccur in a particular installati n.
If this equipment d es cause harmful interference t radi
r televisi n recepti n, which can be determined by turning
the equipment ff and n, the user is enc uraged t try t
c rrect the interference by ne r m re f the f ll wing
measures:
 Re rient r rel cate the receiving antenna.
 Increase the separati n between the equipment and receiver.
 C nnect the equipment int an utlet n a circuit
different fr m that t which the receiver is c nnected.
 C nsult the dealer r an experienced radi /TV
technician f r help.
This device c mplies with Part 15 f the FCC Rules.
Operati n is subject t the f ll wing tw c nditi ns: (1)
This device may n t cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
perati n.
CAN ICES-3 (B)/NMB-3(B)
This Class B digital apparatus c mplies with Canadian
ICES-003.
Whalen Furniture Manufacturing
1578 Air Wing R ad, San Dieg , CA 92154, USA
866-942-5362
WARNINGS
! Y ur hub aut matically shuts ff any p rt with a l w
r excessive current.
! If USB Hub Current Limit Exceeded appears n y ur
screen, disc nnect the affected USB device, click
Reset n the screen, and rec nnect the device.
! If ne f y ur hub p rts is disabled, but USB Hub
Current Limit Exceeded d es n t appear:
 Disc nnect and rec nnect the affected device.
 If the p rt still d es n t w rk, disc nnect the hub
and the device, and then rec nnect.
! Keep y ur deskt p hub dry; if it gets wet, wipe it dry
immediately.
! D n t m dify r tamper with y ur deskt p hub’s
internal c mp nents. It may cause a malfuncti n and
invalidate its warranty.
! M dificati ns n t appr ved by the party resp nsible
f r c mpliance c uld v id user’s auth rity t perate
the equipment.
Pr duct: Furniture P wer Distributi n Unit
M del N : GEO101U-050200U
C mpany: Whalen Furniture Manufacturing

6
Parts and Hardware List
Please read c mpletely thr ugh the instructi ns and verify that all listed parts and hardware are present
bef re beginning assembly.
A- Desk T p (1) B- Left Fr nt Leg (1) C- Right Fr nt Leg (1) D- Left Rear Leg (1)
E- Right Rear Leg (1) F- Side Stretcher (2) G- Back Stretcher (1) H- P wer Adapter (1)
(1) Cam L ck (2) Cam B lt (3) M8 x 30 mm W d D wel
(6+1 extra) (6+1 extra) (6+1 extra)
(4) 1/4” x 57 mm B lt (5) L ck Washer (6) Flat Washer
(Qty. 8+1 extra) (Qty. 8+1 extra) (Qty. 8+1 extra)
(7) Cam L ck C ver (8) M12 x 40 mm W d D wel 4 mm Hex Wrench
(Qty. 6+1 extra) (Qty. 4+1 extra) (Qty. 1)
Glue (Qty. 1) T uch-up Pen (Qty. 1)
T ls required: Hex wrench (pr vided) and Phillips screwdriver (n t pr vided).

7
Assembly Instructions
1. Unpack the unit and c nfirm that y u have all the hardware and required parts. Assemble the unit n a
carpeted fl r r the empty cart n t av id any scratch.
2. Securely screw the Cam B lts (2) int the designated small h les n the Legs (B, C, D and E) using a
Phillips screwdriver. DO NOT ver tighten the cam b lts.
② x 6
B
C
D
E
2
DO NOT fully tighten the b lts r nuts initially until all the b lts r nuts are
ready t assemble. T av id causing damages t the thread, DO NOT ver-tighten the nuts r b lts.

8
Assembly Instructions
3. Glue the 30 mm W d D wels (3) int the side h les f the Stretchers (F and G).
G
F
3
3
3
3
F
3
3
③ x 6

9
Assembly Instructions
4. Orient and attach ne Side Stretcher (F) between the Legs (B and D) by engaging 2 Cam L cks (1)
(Refer t page 3 n Cam L ck system perati n supplement).
① x 2
B
D
F
1
1

10
Assembly Instructions
5. Repeat the same pr cedure t attach the ther Side Stretcher (F) between the Legs (C and E).
C
E
F
1
1
① x 2

11
Assembly Instructions
6. Glue ne 40 mm W d D wel (8) int the t p h le f each Legs (B, C, D and E).
D
B
C
E
8
8
8
8
⑧ x 4

12
Assembly Instructions
7. Attach Left Leg assembly t the left c rners f the Desk T p Apr n (A) with f ur B lts (4) and f ur
Washers (5 and 6).
NOTE: DO NOT fully tighten all the b lts until the desk has been adjusted and level all the legs s that
they d n t w bble. Once adjusted, g back and tighten while making sure that the unit remains level.
⑤ x 4 ⑥ x 4
B
D
A
B/D
A
4
56
④ x 4

13
G
A
B
D
C
E
E
G
1
C/E
A
4
5
6
Assembly Instructions
8. Attach the Back Stretcher (G) t the Left Rear Leg (D) by inserting the w d d wel int the drilled h le.
Make sure that the cam l ck h les face inward.
9. Align and attach the Right Leg assembly t the Desk T p (A) while inserting the installed w d d wel
n the end f the Back Stretcher (G) int the drilled h le n the Right Rear Leg (E).
10. Insert f ur 57 mm B lts (4) with the Washers (5 and 6) thr ugh the c rner bl cks and screw int the
Legs (C and E).
11. Fasten the Back Stretcher (G) int place by engaging 2 Cam L cks (1).
⑤ x 4 ⑥ x 4
④ x 4
① x 2

14
Assembly Instructions
12. Stand the assembled unit upright.
13. Plug the Cam L ck C vers (7) nt the visible Cams L cks t c nceal the cams.
14. C nnect the pr vided AC/DC Adapter (H) with the USB hub pre-installed n the right apr n f the
Desk T p (A) t gether. Insert the tw -pr ng plug int an utlet t supply p wer f r the USB hub.
15. If necessary, adjust the installed Fl r Levelers at the b tt m f the legs t level the unit.
⑦
x
6
7
A
H
H
C
B
D
E

15
Care and Maintenance
 Use a s ft, clean cl th that will n t scratch the surface when dusting.
 Use f furniture p lish is n t necessary. Sh uld y u ch se t use p lish, test first in an
inc nspicu us area.
 Using s lvents f any kind n y ur furniture may damage y ur furniture’s finish.
 Never use water t clean y ur furniture as it may cause damage t the finish.
 Always use c asters under beverage glasses and fl werp ts.
 Liquid spills sh uld be rem ved immediately. Using a s ft, clean cl th, bl t the spill gently. Av id
rubbing.
 Always use pr tective pads under h t dishes and plates. Heat can cause chemical changes that may
create sp tting within the furniture finish.
 Stains r marks fr m cray ns r ink markers will be difficult t rem ve.
 In the event that y ur furniture is stained r therwise damaged during use, we rec mmend that
y u call a pr fessi nal t repair y ur furniture.
 Check b lts/screws peri dically and tighten them if necessary.
Further Advice about Wood Furniture Care
It is best t keep y ur furniture in a climate-c ntr lled envir nment. Extreme temperature and
humidity changes can cause fading, warping, shrinking and splitting f w d. It is advised t keep
furniture away fr m direct sunlight as sun may damage the finish.
Pr per care and cleaning at h me will extend the life f y ur purchase. F ll wing these imp rtant and
helpful tips will enhance y ur furniture as it ages.
A t uch-up pen has been pr vided t minimize the small nicks r scratches that may ccur during
assembly r shipping.
We h pe y u enj y y ur purchase f r many years.
Thank y u f r y ur purchase!

ESTE INSTRUCTIVO CONTIENE INFORMACION IMPORTANTE DE SEGURIDAD.
POR FAVOR LEA Y MANTENGA PARA USO FUTURO.
Fecha 2021-06-08 Rev. 0001-A
Escritorio Farmhouse
M del # BHF1025004004
ENSAMBLE POR ADULTO REQUERIDO
Si tienen alguna pregunta acerca del ensamble si alguna parte está faltante, n ret rne esté pr duct a
la tienda d nde l c mpr . P r fav r llame a nuestr departament de ayuda al cliente teniend su
instructiv y lista de partes para pr veer el m del , n mbre de parte el númer de fábrica:
866-942-5362
H ra estándar del Pacífic : 8:30 a.m. - 4:30 p.m., de Lunes a Viernes
O visite nuestra página de Internet 24 h ras al día, 7 días a la semana para asistencia
www whalenstyle com
O mande un c rre electrónic a parts@whalenfurniture com
NÚMERO de LOTE:
FECHA de COMPRA
:
/
/

2
FABRICANTE: Whalen Furniture Manufacturing
CATALOGO: Escrit ri Farmh use
MODELO # BHF1025004004
GARANTÍA DE CALIDAD
N s tr s estam s segur s que usted se enc ntrará feliz c n la c mpra de esté pr duct de Whalen Furniture.
Si esté pr duct tiene algun defect de ensamble material, si tiene alguna falla en us n rmal, n s tr s
l repararem s l re-emplazarem s hasta p r un añ a partir de la fecha de c mpra. T d pr duct de
Whalen Furniture es diseñad para alcanzar sus espectativas más altas. N s tr s le garantizam s que
inmediatamente p drá ver el val r de nuestra mercancia de la más alta calidad.
Está garantia le pr p rci na derech s legales especific s y talvez tenga tr s derech s que varian de estad a
estad .
Whalen Furniture Manufacturing
1578 Air Wing R ad, San Dieg , CA 92154, USA
Servici al cliente: 866-942-5362
H ra estándar del Pacífic : 8:30 a.m. - 4:30 p.m., de Lunes a Viernes
www whalenstyle com
MÁ X I M O P E SO R E C O M E N D A D O
ESTA UNIDAD DEBE UTILIZARSE CON LOS PESOS MÁXIMOS
INDICADOS. SI SE EXCEDE EL PESO MÁXIMO, PODRIA RESULTAR EN UNA
INESTABILIDAD DE LA UNIDAD CAUSANDO POSIBLES LESIONES
.
CARGA MÁXIMA 200 lb. (90.7 kg)
CARGA MÁXIMA 10 lb. (4.53 kg)

3
IMPORTANTE
Antes de comenzar: Abra, identifique y cuente t das las partes antes del ensamble. C l que las piezas s bre
una superficie plana y n abrasiva. Tendrá que las partes identificadas en la página 6 de este manual de
instrucci nes.
NOTA: ES MUY IMPORTANTE PARA EL USO DE PEGAMENTO CON LAS CLAVIJAS DE MADERA.
EL. EXCESO DE PEGAMENTO SE PUEDE LIMPIAR CON UN PAÑO HÚMEDO.
Inserte la clavija p r l men s a la mitad del camin g lpeand ligeramente c n un maz de pegament , SI ES
NECESARIO.
SISTEMA DE OPERACIÓN DE TUERCA DE FIJACIÓN
1. Fijar l s pern s de fijación en l s rifici s pequeñ s. C nectar amb s paneles, cerci ránd se que l s
pern s de fijación entren bien y que est s queden en l s rifici s al final del panel c n tuercas de fijación.
2. Inserte las tuercas de fijación en l s rifici s grandes del panel. Hacer que la flecha en la tuerca este
apuntand hacia la entrada del pern de fijación.
3. Una vez que el pern esté c nectad dentr , t me un dest rnillad r de cruz y apriete la tuerca en dirección
de las manecillas del rel j.
4. C l que la tapa de la tuerca de fijación s bre la misma en la ranura de cruz, ver detalle.
Esta list para ensamblar la unidad.
XX
1 2 43
Pegamento
Final

4
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
SOBRE EL CENTRO DE DISTRIBUCION DE PODER
DEL MUEBLE
Lea cuidadosamente las instrucciones de instalación y operación
SI TIENE DUDAS SOBRE LA INSTALACIÓN CORRECTA CONSULTE A UN
ELECTRICISTA CALIFICADO
PARA REDUCIR EL RIESGO DE FUEGO, DESCARGA
ELECTRICA O LESIONES A PERSONAS, POR FAVOR SIGA LO SIGUIENTE:
 S l use grapas insuladas ligaduras de plástic (n incluidas) para asegurar l s cables.
 Encamine y asegure cables para que n estén apretad s dañad s cuand el escrit ri esté empujad
c ntra la pared.
 Asegurar que el cable n esté apretad entre el escrit ri y el pis .
 S l usar la unidad en interi res.
 N usar un cable de extensión para c nectar esta unidad a una t ma en la pared.
 Usar la Fuente de p der c n pr tección integral c ntra s bre C rrientes para pr veer electricidad a tr s
disp sitiv s eléctric y acces ri s en el escrit ri .
 Esta unidad debe estar enchufada en una t ma que esté c nectada a tierra.
 La t ma de c rriente debe estar instalada cerca del equip y debería ser fácil de acceder.
 La carga máxima del equip c nectad n debe exceder un t tal de 12 amperes y 120 v lte s.
 N abrir desarmar esta unidad p r cualquier razón.
GUARDE ESTA INSTRUCCIONES
