Better Homes and Gardens DOVER BH17-084-098-28 User manual

1PB
model# BH17-084-098-28
model# BH17-084-098-27
Lot#_________Date________
Customer Service:
1.877.436.7290
[email protected]
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
gray
ivory
Manufactured By:
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
Assembly Instructions
DOVER
4 SHELF BOOKCASE

2
TOP PANEL
LEFT SIDE FRAME
RIGHT SIDE FRAME
BOTTOM PANEL
LOWER FRONT RAIL
LOWER BACK RAIL
FRONT RAIL
REAR RAIL
BACK PANEL
FIXED SHELF [X3]
BOTTOM FRONT PANEL
A
B
C
D
E
F
G
H
I
J
K
Before you begin:
1. Check for damaged or missing parts.
2. Use the carton as a working surface to prevent product damage during assembly.
TOOLS NEEDED
Hammer Flat Head Screwdriver Phillips Head Screwdriver
PARTS LIST

2 3
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
5. Bolt
x3
3. Cam
x30
1. Wood Dowel
x32
2. Cam Bolt
x30
6. Lock Washer
x3
4. 15mm Pan Head
Screw
x19
7. Washer
x5

44
HARDWARE LIST
CAUTION:
1. Make sure the screws go through the pre-drilled holes properly.
2. Do not over tighten bolts.
8. Allen Wrench
x1
9. Wall Anchor
x1
11. 19mm Pan Head
Screw
x1
12. Wall Strap
x1
10. Wall Screw
x1
13. 20mm Wood Dowel
x4
14. Cam Cover
x10

44 5
3
1 2
4 5
180º
HOW TO USE THE CAM LOCK SYSTEM

6
x4 x4 x4
STEP 1
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 5 for instructions on how to use the cam lock system.
1. Wood
D o w e l
2. Cam Bolt 3. Cam
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

6 7
x10 x10 x10
STEP 2
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 5 for instructions on how to use the cam lock system.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
D o w e l
2. Cam Bolt 3. Cam

8
x10 x10 x10
STEP 3
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
D o w e l
2. Cam Bolt 3. Cam
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 5 for instructions on how to use the cam lock system.

8 9
x4
x3
x1
x3x3
STEP 4
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Make sure the bolts go through the pre-drilled holes properly.
3. Do not over tighten bolts.
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
5. Bolt
8. Allen
Wrench
7. Washer6. Lock
Washer
13. 20mm
Wood Dowel

10
x8 x6 x6
STEP 5
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
1. Wood
D o w e l
2. Cam Bolt 3. Cam
1. Carefully tap small wooden dowels into place. Leave 1/2”of the dowels sticking out.
2. Screw-In cam bolts must be screwed down ush.
3. Refer to page 5 for instructions on how to use the cam lock system.

10 11
x19
STEP 6
1. Make sure the screws go through pre-drilled holes properly.
2. Do not over tighten screws.
4. 15mm Pan
Head Screw
hole for anti-tip strap
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
Begin by installing all of the screws along one
edge of the back panel. Next, using a square
or tape measure, make sure that the case is
square. (if using a tape measure, the distance
from one corner, diagonally to the other corner
should be the same in both directions.) Install
the remaining screws, starting with the corners.

1212
x1x1x1x1
x2
9
10
7
11
7
12
STEP 7
11. 19mm
Pan Head
Screw
10. Wall
Screw
12. Wall
Strap
7. Washer
9. Wall
Anchor
position against wall
mark position of strap hole on wall
drill 1/4”hole
tap in wall anchor
fasten anti-tip strap with wall
screw provided
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

12 1312
x10
STEP 8
1. Place cam covers over visible holes.
14. C a m
Cover
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.

14
25lbs. / 11.3 kg.
20lbs. per shelf/
9.1 kg. por repisa
!WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Install tip-over restraint provided.
• Place heaviest items in the lowest drawers.
• Do not set TV’s or other heavy objects on top
of this product, unless the product is
specifically designed to accommodate them.
• Never allow children to climb or hang on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
(OR)
• Do not defeat or remove the drawer interlock
system.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
This is a permanent label. Do not remove.
WARNING: Do not exceed the maximum load capacity. Exceeding the maximum load capacity may result in
collapse and possible injury.
Furniture Care Instructions:
Dust with clean, lint-free cloth.
Use furniture spray polish as needed.
Customer Service:
877.436.7290
[email protected]
Your complete satisfaction is our number 1 priority. Our product is designed and manufactured to meet the
highest quality of standards. In the event that you have assembly questions, or parts are missing or damaged,
our customer service department would appreciate the opportunity to assist you.
This product carries a one (1) year warranty against defects in workmanship and materials. Defective product
will be replaced free of charge within the stated warranty period, when returned by the original purchaser with
proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse. Please
contact our Customer Service at 1-877-436-7290 to obtain information on warranty performance. This warranty
gives you specic legal rights and you may also have other rights which vary from State to State.

1PB
model# BH17-084-098-28
model# BH17-084-098-27
Lot#_________Fecha_______
Servicio al Cliente:
1.877.436.7290
[email protected]
ESTE MANUAL DE INSTRUCCIONES CONTIENE INFORMACIÓN IMPORTANTE DE SEGURIDAD.
POR FAVOR LEA Y GUARDE PARA REFERENCIA FUTURA.
gris
marl
Fabricado Por :
BDDMI
1321 Tyler St NE, Minneapolis, MN 55413
LIBRERO DE 4 REPISAS
DOVER
Instrucciones de Ensamble

2
Antes de comenzar:
1. Compruebe si hay piezas dañadas o faltantes.
2. Utilice la caja de cartón como supercie de trabajo para evitar daños al producto durante el montaje.
Martillo Destornillador de Cabeza Plana Destornillador Phillips
HERRAMIENTAS NECESARIAS
LISTA DE PARTES
PANEL SUPERIOR
ENSAMBLE DEL LADO IZQUIERDO
ENSAMBLE DEL LADO DERECHO
PANEL INFERIOR
RIEL FRONTAL INFERIOR
RIEL POSTERIOR INFERIOR
RIEL FRONTAL
RIEL POSTERIOR
PANEL POSTERIOR
REPISA FIJA [X3]
PANEL FRONTAL INFERIOR
A
B
C
D
E
F
G
H
I
J
K

2 3
LISTA DE ARTÍCULOS DE FERRETERÍA
PRECAUCIÓN:
1. Cerciórese que los tornillos pasen por los agujeros pretaladrados de manera apropiada.
2. No sobreapriete los tornillos.
5. Perno
x3
3. Leva
x30
1. Clavija de Madera
x32
2. Tornillo de Leva
x30
6. Arandela Fijadora
x3
4. 15mm Tornillo Largo
de Cabeza de Noria
x19
7. Arandela
x5

44
LISTA DE ARTÍCULOS DE FERRETERÍA
PRECAUCIÓN:
1. Cerciórese que los tornillos pasen por los agujeros pretaladrados de manera apropiada.
2. No sobreapriete los tornillos.
8. Llava Allen
x1
9. Taquete de Pared
x1
11. 19mm Tornillo Largo
de Cabeza de Noria
x1
12. Cincha de Pared
x1
10. Tornillo de Pared
x1
13. 20mm Clavija de
Madera
x4
14. Cubierta del
Tornillo
x10

44 5
3
1 2
4 5
180º
COMO USAR EL SISTEMA FIJADOR DE LEVA

6
x4 x4 x4
PASO 1
1. Con cuidado golpee las clavijas de madera en su lugar. Deje un saliente de 1.27 cm (½”) en las clavijas.
2. Los tornillos de leva deben de estar atornillados al ras.
3. Reérase a la página 5 para instrucciones para como usar el sistema de levas.
1. Clavija de
Madera
2. Tornillo
de Leva
3. Leva
NO ESTÁ A ESCALA. CONSULTE LA PÁGINA 3 FOR HARDWARE DE TAMAÑO REAL.
