Better Homes and Gardens Hendrix BH48-084-899-03 User manual

THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2021-06-23 Rev. 0001-A
Hendrix TV Console
Stock # BH48-084-899-03
BH48-084-899-04
BH48-084-899-05
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
www.whalenstyle.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /

2
1. Please read the Assembly Instructions prior to assembling this product.
2. Remove all hardware from the box and sort by size.
3. Check to see that all hardware and parts are present BEFORE assembling.
4. Ask a friend to assist you with the assembly of this furniture.
5. To avoid damage, assemble the product on a sturdy, level and protective surface.
6. Please wait until all steps are completed before fully tightening bolts.
7. Make sure all screws and bolts are tightly fastened before the unit is used.
How to adjust the European adjustable hinges on doors
Shipping may cause doors to go out of alignment. If you find that the doors need to be adjusted slightly,
turn the appropriate screw as illustrated.
1. TO ADJUST DOOR FORWARD OR BACKWARD.
2. TO ADJUST DOOR TO RIGHT OR TO LEFT.
3. TO ADJUST DOOR UP OR DOWN.
SPECIAL NOTE
Please read the instruction sheets completely before assembly. Examine all packaging material
before discarding carton. Remove any remaining staples from the carton before discarding.
Remove all parts from carton and separate into groups as indicated on part list. Please ensure
all parts are included prior to assembly. Use of power tools to complete assembly is not
recommended.
GE NERA L I NFO R M ATI ON , T I PS A N D TRI C KS
This product is sold with two sets of Tipping Restraint Hardware Kit. You must install the Tipping Rest
raint
Hardware between the wall and the console
to prevent any accidents or damages. When properly installed,
this restraint can provide protection against the unexpected tipping of the unit due to small tremors, bumps or
climbing. The restraint is only a deterrent and is not a substitute for proper adult supervision. Use of tip-
over
restraints may only reduce, but not eliminate, the risk of tip-over.
1
2

3
IMPORTANT
Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and
non-abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual.
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED
OFF WITH DAMP CLOTH.
Insert the dowel at least half way by tapping lightly with a rubber mallet, IF NECESSARY.
CAM LOCK SYSTEM OPERATION
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw the Cam Bolt into the threaded inserts on the panel. Connect both panels together; making sure Cam
Bolt goes into the pre-drilled hole on the end of panel for Cam Lock.
2. Insert the Cam Lock into the pre-drilled large hole on the panel. Make sure the arrow on the face of Cam
Lock faces out and points towards Cam Bolt.
3. Take a Phillips screwdriver and rotate the Cam Lock clockwise to lock the Cam Bolt in place.
4. Plug the Cam Lock Cover into the cross slot of the Cam Lock to conceal the Cam.
You are now ready to assemble the KD unit.
XX
FINAL
1 2 43

4
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
A- Top Panel (Qty. 1) B- Fixed Shelf (Qty. 1) C- Left Side Panel (Qty. 1)
D- Right Side Panel (Qty. 1) E- Lower Partition Panel (Qty. 1) F- Bottom Panel (Qty. 1)
G- Left Side Molding (Qty. 1) H- Right Side Molding (Qty. 1) I- Top Front Stretcher (Qty. 1)
J- Base Front Stretcher (Qty. 1) K- Base Back Stretcher (Qty. 1) L- Base Side Stretcher (Qty. 2)
M- Upper Partition Panel (Qty. 1) N- Adjustable Shelf (Qty. 2) O- Left Door (Qty. 1) P- Right Door (Qty. 1)
Q- Stop Rail (Qty. 1) R- Back Panel (Qty. 1)

5
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
(1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel
(Qty. 32+1 extra) (Qty. 32+1 extra) (Qty. 39+2 extra)
(4) M4 x 38 mm Screw (5) M3.5 x 15 mm Screw (6) M3.5 x 12 mm Screw
(Qty. 10+1 extra) (Qty. 28+1 extra) (Qty. 4+1 extra)
(7) Handle (8) Rubber Bumper (9) Shelf Support
(Qty. 2) (Qty. 4+1 extra) (Qty. 8+1 extra)
(10) Cam Lock Cover Glue Touch-up Pen
(Qty. 20+1) (Qty. 2) (Qty. 1)
Tipping Restraint Hardware Kit (Qty.2)
(Included in plastic bag)
Tools required: Phillips screwdriver and hammer (not provided).

6
Assembly Instructions
NOTE: Please do not fully tighten all bolts/screws until you finish assembling all parts. Once assembled,
go back and fully tighten all bolts. This will make it easier during assembly of unit.
1. Unpack the unit and confirm that you have all the hardware and required parts listed. Assemble the unit
on a carpeted floor or the empty carton to avoid any scratch.
2. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A), Fixed Shelf (B),
Side Panels (C and D), Bottom Panel (F), Left and Right Side Moldings (G and H) and Base Front and
Back Stretchers (J and K) using a Phillips screwdriver.
A
B
F
D
C
G
H
J
K
2
② x 30

7
Assembly Instructions
3. Insert two 30 mm Wood Dowels (3) into the inner holes of the Left Side Panel (C). Tap in with a rubber
mallet, if necessary. Make sure that you use a small amount of glue with both ends of all dowels.
NOTE: It is very important to use a small amount of glue on both ends of dowels.
4. Align the drilled holes on the Left Side Molding (G) with the inserted Wood Dowels (3) on the Left
Side Panel (C), and then press them together. Attach the Left Side Molding (G) in place by engaging
two Cam Locks (1) (Refer to page 3 on Cam Lock system operation supplement).
5. Repeat the same procedure to combine Right Side Molding (H) with Right Side Panel (D).
Raw edge
Raw edge
①
x
4
③ x 4
C
D
G
H
C/D
3
1
G/H

8
Assembly Instructions
6. Glue two Wood Dowels (3) into the top inner holes of the Lower Partition Panel (E) and attach to the
Fixed Shelf (B) by engaging two Cam Locks (1).
B
E
B
E
1
3
① x 2
③ x 2

9
Assembly Instructions
7. Glue six Wood Dowels (3) into the inner holes of the Fixed Shelf (B) and Top Front Stretcher (I) at both
ends. DO NOT insert the Wood Dowels into the Cam Bolt holes.
8. Align and attach the Fixed Shelf (B) to the Left Side Panel (C) by engaging two Cam Locks (1).
9. Attach the Top Front Stretcher (I) to the Left Side Molding (G) as shown.
10. Repeat this procedure to attach the Right Side Panel (D) at the opposite end.
C
D
H
G
B
I
B
C/D
1
3
① x 4 ③ x 6

10
Assembly Instructions
11. Glue four Wood Dowels (3) into the drilled holes on the both ends of the Base Side Stretchers (L).
12. Align and attach Base Side Stretchers (L) between the Base Front Stretcher (J) and Base Back Stretcher
(K) by engaging four Cam Locks (1).
3
K
J
3
3
3
1
1
1
1
L
L
① x 4
③ x 4

11
Assembly Instructions
13. Glue eight Wood Dowels (3) into the inner holes on the Bottom Panel (F).
14. Align and attach Base Stretchers (J, K and L) to the Bottom Panel (F) in place by engaging ten Cam
Locks (1).
F
J
K
L
L
F
33
1
L
J/K
① x 10
③ x 8

12
Assembly Instructions
15. Glue six Wood Dowels (3) into the bottom inner holes of both Side Panels (C and D) and Lower
Partition Panel (E).
16. Position the Bottom Panel (F) onto the inserted Wood Dowels (3) and fasten it in place with six 38 mm
Screws (4).
F
C
E
D
C/D/E
4
3
F
③ x 6
④ x 6

13
Assembly Instructions
17. Stand the assembled unit upright.
18. Securely screw two Cam Bolts (2) onto the Fixed Shelf (B).
2
B
② x 2

14
Assembly Instructions
19. Glue one Wood Dowel (3) into the bottom inner hole of the Upper Partition Panel (M) and attach it to
the Fixed Shelf (B) by engaging two Cam Locks (1).
B
M
M
B
3
1
① x 2
③ x 1

15
Assembly Instructions
20. Glue eight Wood Dowels (3) into the top inner holes of the Side Panels (C and D), Upper Partition
Panel (M) and Top Front Stretcher (I).
21. Align and attach the Top Panel (A) to the Side Panels (C and D) and Upper Partition Panel (M) by
engaging six Cam Locks (1).
22. Fasten the Top Panel (A) to the Top Front Stretcher (I) with four 38 mm Screws (4).
C
D
A
M
I
I
C/D
3
4
1
①
x
6
③ x 8
④ x 4

16
Assembly Instructions
23. Now, go back and tighten all Cam Locks and Screws. Make sure that all the parts are tight and there are
no gaps between the pieces. This will help keep the unit square.
24. Turn the previous assembly at its front edges.
25. Unfold the Back Panel (R) and lay it to the back edges of the assembled unit. Make sure that the
overlaps on the panels are even all the way around. Attach the Back Panel (R) in place with the 15 mm
Washer Head Screws (5).
NOTE: We recommend attaching back panel with the screws at the corners first.
R
R
5
R
DF
⑤ x 28

17
Assembly Instructions
26. Using the pilot holes as a guide, attach one Handle (7) to each Door (O and P) with two 12 mm Screws
(6).
O
P
7
6
7
6
⑥ x 4
⑦ x 2

18
Assembly Instructions
27. Stand the unit upright.
28. Pick up Left Door (O) and attach the extended Hinge Arms to the Hinge Bases installed on the Left Side
Panel (C). Loosen the bolt on the back of Hinge Base for an easy fit. Align and insert the “U” slot on
Hinge Arm under the bolt head on the back of Hinge Base. Make sure that both door hinges engage and
function properly. Tighten the bolt on the Hinge Base to lock the hinges in place.
29. Repeat the same procedure to attach the Right Door (P) to the Right Side Panel (D).
30. Open and close the doors to make sure they are aligned and shut correctly. If necessary, adjust the
screws for a good fit. Refer to the hinge sticker on door for adjustment.
1
O/P
C/D
C
D
O
P
O/P
C/D

19
Assembly Instructions
31. With the doors open, insert four Shelf Supports (9) into the holes at your desired height inside each
compartment. Make sure you place the 4 Shelf Supports (9) in the same level so that shelf is not tilted.
32. Tilt and rest the Adjustable Shelves (N) onto the Shelf Supports (9).
C
D
E
N
N
N
9
9
⑨ x 8

20
Assembly Instructions
s
33. Peel off the Rubber Bumpers (8) from the bumper cards and stick them at the outer corners of the Doors
(O and P) where they meet the Lower Partition Panel (E).
34. Plug the Cam Lock Covers (10) onto the visible Cams Locks to conceal the cams.
C
D
E
10
88
⑧ x 4
⑩ x 20
