Better Homes and Gardens Canton BHS0025004002 User manual

Canton Media Console
MODEL # BHS0025004002
ADULT ASSEMBLY REQUIRED
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions
and parts list ready to provide the model name, part name or factory number:
866-942-5362
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
www.whalenstyle.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2020-08-25 Rev. 0001-B

2
MANUFACTURER: Whalen Furniture Manufacturing
CATALOG: Canton Media Console
MODEL # BHS0025004002
How to adjust the European adjustable hinges on doors
Shipping may cause doors to go out of alignment. If you find that the doors need to be adjusted slightly,
turn the appropriate screw, as illustrated.
1. TO ADJUST DOOR FORWARD OR BACKWARD.
2. TO ADJUST DOOR TO RIGHT OR TO LEFT.
3. TO ADJUST DOOR UP OR DOWN.
M A X I M U M R E C O M M E N D E D W E I G H T L O A D S
FITS UP TO MOST 177.8 cm / 70”
DIAGONAL FLAT PANEL TVs
MAXIMUM LOAD 61.2 kg / 135 lb
THIS UNIT IS NOT INTENDED FOR USE WITH CRT TVS. USE ONLY WITH FLAT
PANEL TVS AND AUDIO/VIDEO EQUIPMENT MEETING RECOMMENDED SIZE AND WEIGHT
LIMITS. NEVER USE WITH LARGER/HEAVIER THAN RECOMMENDED FLAT PANEL TVS OR
EQUIPMENT. TO AVOID INSTABILITY, PLACE FLAT PANEL TV IN THE CENTER OF THE UNIT; THE
BASE OF THE TELEVISION MUST BE ABLE TO REST ON THE SUPPORTING SURFACE OF THE
UNIT WITHOUT OVER-HANGING THE EDGES. IMPROPERLY POSITIONED FLAT PANEL TVS, OR
FLAT PANEL TVS INCLUDING OTHER EQUIPMENT THAT EXCEED RECOMMENDED SIZE AND
WEIGHT LIMITS COULD FALL OFF OR BREAK THE UNIT, CAUSING POSSIBLE SERIOUS INJURY.
FOR USE WITH TELEVISIONS WEIGHING 135 LBS (61.2 KG) OR LESS. USE WITH HEAVIER
TELEVISIONS MAY RESULT IN INSTABILITY CAUSING TIP OVER RESULTING IN DEATH OR
SERIOUS INJURY.
MAXIMUM LOAD 22.7 kg / 50 lb
PLACE TV BEHIND THE STOPPER
12
3

3
Important
Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non-
abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual.
NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH DOWELS. EXCESS GLUE CAN BE WIPED
OFF WITH DAMP CLOTH.
Insert the Dowel at least half way by tapping lightly with a rubber mallet, IF NECESSARY.
CAM LOCK SYSTEM OPERATION
HOW THE KNOCK DOWN (KD) ASSEMBLY SYSTEM WORKS
1. Screw the Cam Bolt into the threaded inserts on the panel. Connect both panels together; making sure Cam
Bolt goes into the pre-drilled hole on the end of panel for Cam Lock.
2. Insert the Cam Lock into the pre-drilled large hole on the panel. Make sure the arrow on the face of Cam
Lock faces out and points towards Cam Bolt.
3. Take a Phillips screwdriver and rotate the Cam Lock clockwise to lock the Cam Bolt in place.
4. Plug the Cam Lock Cover into the cross slot of the Cam Lock to conceal the Cam.
You are now ready to assemble the console.
XX
FINAL
1 2 43

4
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
A- Top Panel (Qty. 1) B- Left Side Panel (Qty. 1) C- Right Side Panel (Qty. 1)
D- Left Partition Panel (Qty. 1) E- Right Partition Panel (Qty. 1) F- Middle Stile (Qty. 2)
G- Bottom Panel (Qty. 1) H- Bottom Front Stretcher (Qty. 1) I- Bottom Back Stretcher (Qty. 1)
J- Door (Qty. 2) K- Small Adjustable Shelf (Qty. 4) L- Large Adjustable Shelf (Qty. 2)
M- Back Panel (Qty. 1) N- Stop Rail (Qty. 1) O- Bottom Support (Qty. 1)

5
Parts and Hardware List
Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
(1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel
(Qty. 28+1 extra) (Qty. 28+1 extra) (Qty. 27+1 extra)
(4) M4 x 50 mm Screw (5) M3.5 x 15 mm Pan Head Screw (6) Triangle metal plate
(Qty. 4+1 extra) (Qty. 8+1 extra) (Qty. 2)
(7) Floor leveler (8) M3.5 x 15 mm Washer Head Screw (9) Door stopper
(Qty. 2) (Qty. 24+1 extra) (Qty. 2)
(10) Shelf Support (11) M3.5 x 15 mm Flat Head Screw (12) Knob
(Qty. 24+1 extra) (Qty. 28+1 extra) (Qty. 2)
(13) Knob Bolt (14) Door Hinge (15) M3.5 x 15 mm Zinc Screw
(Qty. 2) (Qty. 4) (Qty. 24+1 extra)
(16) Cam Lock Cover (17) M4 x 38 mm Screw
(Qty. 8+1 extra) (Qty. 2+1 extra)
Glue (Qty. 1) Touch-up Pen (Qty. 1) Tipping Restraint Hardware Kit (Qty. 2)
(Included in plastic bag)
Tools required: Phillips screwdriver and rubber mallet (not provided).

6
Assembly Instructions
1. Unpack the unit and confirm that you have all the hardware and required parts. Assemble the unit on a
carpeted floor or the empty carton to avoid any scratch.
2. Securely screw the Cam Bolts (2) into the designated small holes on the Side Panels (B and C), the
Bottom Panel (G), the Bottom Front Stretcher (H) and the Middle Stiles (F) using a Phillips screwdriver.
DO NOT over tighten the cam bolts.
② x 20
B
C
G
F
F
H
2

7
Assembly Instructions
3. Glue the 30 mm Wood Dowels (3) into side holes of the Partition Panels (D and E).
③ x 4
D
E
3
3
3
3

8
D
F
1
Assembly Instructions
4. Align and attach one Middle Stile (F) to the Left Partition Panel (D) by engaging 3 Cam Locks (1)
(Refer to page 3 on Cam Lock system operation supplement).
① x 3

9
E
F
1
Assembly Instructions
5. Repeat the same procedure to combine the other Middle Stile (F) to the Right Partition Panel (E).
① x 3

10
Assembly Instructions
6. Glue the 30 mm Wood Dowels (3) into side holes of Bottom Panel (G), Partition Panels (D and E),
Bottom Support (O) and Bottom Stretchers (H and I).
③ x 19
3
O
G
D
E
H
I
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3

11
Assembly Instructions
7. Align and attach the Bottom Front Stretcher (H) to the Bottom Panel (G) by engaging 4 Cam Locks (1).
G
H
1
G
① x 4

12
Assembly Instructions
8. Align and attach the Bottom Support (O) to the Bottom Front Stretcher (H) by engaging one Cam Lock (1).
G
H
O1
① x 1

13
Assembly Instructions
9. Align and attach the Bottom Back Stretcher (I) to the Bottom Panel (G) by engaging 3 Cam Locks (1).
GH
II1
G
① x 3

14
Assembly Instructions
10. Fasten the Bottom Back Stretcher (I) to the Bottom Support (O) with two 38 mm Wood Screws (17).
x 2
G
I
H
17

15
Assembly Instructions
11. Attach the Partition Panels (D and E) to the Bottom Panel (G) with four 50 mm Wood Screws (4).
④ x 4
G
D
E
4
4
4
4
I
H

16
Assembly Instructions
12. Glue the 30 mm Wood Dowels (3) into side holes of the Side Panels (B and C).
③ x 4
B
C
3
3
3
3

17
Assembly Instructions
13. Align the large holes on Left Side Panel (B) with the inserted Wood Dowels (3) on the assembled base.
Firmly press them together and fasten it in place by engaging 3 Cam Locks (1).
14. Repeat the previous step to attach Right Side Panel (C) at the other end.
① x 6
B
C
G
D
E
1
G
B/C

18
Assembly Instructions
15. Securely screw the Cam Bolts (2) into the designated small holes on the Top Panel (A) using a Phillips
screwdriver.
A
2
② x 8

19
Assembly Instructions
16. Using the pilot holes as a guide, fasten 2 door stoppers (9) to the Top Panel (A) with four 15 mm Flat Head
Screws (11).
A
A
11 9
11
⑨ x 2
x 4

20
Assembly Instructions
17. Ask for assistance to position the Top Panel (A) onto the inserted Wood Dowels (3). Attach the Top Panel
(A) in place by engaging 8 Cam Locks (1).
① x 8
A
B
G
C
D
E
1
