stilum sedis1 User guide

© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved. State: 11/2012 · S. 1
Mounting instruction seat „sedis1“
Item-No. 571011401
Skizze 1: Gesamtansicht „sedis1“

© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved. State: 11/2012 · S. 2
Mounting instruction seat „sedis1“
Item-No. 571011401
Diagram 2: Side view „sedis1“
Diagram 3: Top view „sedis1“
1. Select the location.
2. Carry out excavation work for two foundations as shown in Diagram 2.
Note: the bench is availabe with an installation depth of 450 mm or can
be installed on solid surfaces like concrete or asphalt.
3. Concrete foundation acc. the specied dimensions (LxBxH 600 x 600 x 400
mm) build with centrally mounted, horizontal reinforcement. It shed the sup-
plied anchor bolts with the foundation that the upper angle frame is horizontal
and ush with the foundation surface.
4. During the setting time of 10-14 days, depending on weather conditions and
foundation size, lock the play equipment.
5. After the setting period clean the surface of the foundation, place the
pre-mounted play equipment onto it and screw the base plate of the seat
onto the foundation anchor.
6. Seal the foundation with surface material and compress.
7. Do not allow children to use the equipment before the installation has been
nished.
-0,3
+0,3
BLATT:
OHNE SCHRIFTLICHE ZUSTIMMUNG DER CONRADI + KAISER GMBH DARF DIESE TECHNISCHE UNTERLAGE WEDER VERVIELFÄLTIGT
NOCH DRITTEN MITGETEILT ODER ZUGÄNGLICH GEMACHT WERDEN NOCH IN SONSTIGER WEISE MISSBRÄEUCHLICH VERWENDET
WERDEN. ZUWIDERHANDLUNGEN WERDEN URHEBERRECHTLICH VERFOLGT.
VON:
WERKSTUECKKANTEN
NACH DIN 6784
OBERFLAECHEN NACH
DIN ISO 1302 REIHE 2
ZUL. ABWEICHUNG
DIN 2768 - mH
MAßSTAB:
WERKSTOFF / ROHMAß:
DATUM: NAME:
GEZ:
GEPR:
FREIG:
BENENNUNG:
ZG-NR:
KUNDE:
Gewerbegebiet Larsheck
56271 Kleinmaischeid
Deutschland
500
600
400
450
500
950
Kennzeichnung
Einbautiefe
1
1
1:1
1
4 32
A
E
D
C
B
F
Sedis 1 DS
1
1
1:10
1
4 32
A
E
D
C
B
F
-0,3
+0,3
BLATT:
OHNE SCHRIFTLICHE ZUSTIMMUNG DER CONRADI + KAISER GMBH DARF DIESE TECHNISCHE UNTERLAGE WEDER VERVIELFÄLTIGT
NOCH DRITTEN MITGETEILT ODER ZUGÄNGLICH GEMACHT WERDEN NOCH IN SONSTIGER WEISE MISSBRÄEUCHLICH VERWENDET
WERDEN. ZUWIDERHANDLUNGEN WERDEN URHEBERRECHTLICH VERFOLGT.
VON:
WERKSTUECKKANTEN
NACH DIN 6784
OBERFLAECHEN NACH
DIN ISO 1302 REIHE 2
ZUL. ABWEICHUNG
DIN 2768 - mH
MAßSTAB:
WERKSTOFF / ROHMAß:
DATUM: NAME:
GEZ:
GEPR:
FREIG:
BENENNUNG:
ZG-NR:
KUNDE:
Gewerbegebiet Larsheck
56271 Kleinmaischeid
Deutschland
Reinforcement plan: Concrete foundation with rein-
forcement
Main foundation: BSt 500S
Ever 4 stirrups Ø 8 mm lengthwise and cross
Concrete cover h´= 3 cm
Concrete quality class C20/25

© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved. State: 11/2012 · S. 3
Mounting instruction seat „sedis1“
Item-No. 571011401
Attention: If the play equipment has been incompletely installed or partly dis-
mantled when carrying out maintenance and repair work, this may lead to par-
ticular risks of injury for the user. For this reason, make clearly visible that the
equipment shall not be used in such cases.
NOTE: Play equipment, which contain components made of stainless steel
should not come with „normal“ steel parts in contact. Those steel parts may rub
off and leave small steel particles in combination with moisture brown rust stains.
If such corrosion occur on stainless steel parts, they are ne with an abrasive
(240 grit) to remove.
Please take care when transporting and setting up the fact that the components
are made of stainless steel with no „normal“ steel parts in contact.
In order to preserve a good visual appearance of your stilum playground equip-
ment over a long period one should take care of maintenance of the stainless
surface even despite of their corrosion resistance.
Especially areas, which can not be reached by rainfall should be frequently clea-
ned from dirt and deposits due to air pollution and dirt caused by the atmosphere.
Light soiling can easily be romoved by using a high pressure cleaner.
For persistent deposits use a clean cloth moistened with a special liquid cleaner
(e.g. on phosphoric acid) and rinse off with clear water after a short application
time. During cleaning with mild abrasive components, only wipe over stainless
steel surface in polishing direction.
For heavily soiled surfaces, polishes can be used (e.g. for cleaning chrome on
cars) or for greasy and oily dirt alcoholic cleaning agents and solvents (e.g. ethyl
alcohol, isopropyl alcohol or acetone).
However, it should be noted that the dissolved soiling is not spread over the sur-
face again.
Do not use any chlorid or hydrochloric containing cleaning products nor scouring
powder, bleaching - or silver polish cleaner. Cleaning intervals depend on type
and degree of soiling as well as on demands made on optical characteristics.
Therefore cleaning is advisable at intervals of six to twelve months – whereby in
the case of strong soiling it is appropriate to clean the playground equipment at
intervals of 3 to six months.
