Sunjoy A102007300 User manual

Country of Origin: China Production Number: XXXXXXXXXX
ASSEMBLY INSTRUCTION
ITEM#：A102007300
WE HAVE YOU IN MIND, LET US SERVE YOU!
Questions? Issues?
CONTACT US
24 hours / 7 days a week
www.sunjoyonline.com
[e-mail]

2/ 35
Country of Origin: China
•This product is intended for domestic outdoor use only.
•The product should be placed on flat, horizontal ground.
•Ensure enough clearance around the product. Before assembling the product, find level
ground not less than 6' (1.8 m) away from any structures or obstructions, such as
fences, garages, houses, overhanging branches, laundry lines, or electrical wires.
•This gazebo is not to be regarded as part of a building/house structure. The gazebo is
to be anchored onto the ground for added safety. Do not assemble the gazebo onto
soil/earth ground. It is best advisable to have the gazebo built onto a wooden deck or
concrete ground for stability. If it is to be build onto a wooden deck/ground, do
ensure that the wooden deck/ground has a strong foundation. It is advisable to use
appropriate floor plugs (not provided) to anchor the gazebo onto the wooden/concrete
ground.
•Some structures may require two or more people to install safely. Check for
underground utilities before digging or driving stakes into the ground.
•During installation, follow all safety warnings provided with your tools, and use safety glasses.
•In case you set up more than one gazebo, keep a minimum distance of 10' (3 m)
between the gazebos.
•Any assembly or maintenance of the product must be carried out by adults only.
•Arrange necessary manpower when assembling or moving the product.
•Some parts may contain sharp edges. Wear protective gloves if necessary.
•Keep children and pets away while setting up the gazebo.
•Check all nuts and bolts periodically to ensure bolts/nuts are tightened.
•Repairing and replacing parts should be done by a qualified technician.
•This gazebo is intended for decorative and sunshade purposes only, and it is not
designed to withstand harsh weather, including high winds, rain, and snow.
•Do not light any fires inside or near the product!
•Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before
firemen allow you to do so.
•Do not hang heavy weights on the roof frame.
•Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
•Retain the original packaging to store the gazebo.
Important Safety Instructions
Warning! To reduce the risk of serious injury, read the following safety instructions
before assembling and using the gazebo.
Please check with your local governing authority/local municipal codes regarding
installation of structures before assembly.
Caution! Proper placement of your gazebo is essential.
Do not place the product underneath electrical lines.
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
Keep fingers away from the places where they can be pinched or trapped. Do
not attempt to assemble the gazebo if any parts are missing.

3/ 35
Country of Origin: China
Please read and understand this manual before any assembly. Before beginning assembly
of product, make sure all parts are present. Compare parts with packaging contents list.
•When assembling wooden parts, do not overtorque the bolts to avoid splitting the wood.
See image illustration.
•Place all parts from the box in a cleared area and position themon the floor in front of
you.
•Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete.
•Read each step carefully before beginning any assembly and make sure you understand
each step.
•Needed for assembly:（The following tools are not included）
IMPORTANT:

4/ 35
Country of Origin: China
EXPLODED DRAWING

5/ 35
Country of Origin: China
Parts List
Label
Part Number
Description
Qty
Part Image
08
P000200227
Post
4
03
P000400508
Lateral Left Beam
4
04
P000400509
Lateral Right Beam
4
05
P000400510
Inner Long Beam
4
06
P000400512
Inner Short Beam
(Short Side)
4
21
P000400960
Inner Short Beam
(Long Side)
4
10
P005000200
Arc Support 1
4
11
P005000201
Arc Support 2
4
A
P00610021603
Base Cap
4
B
P00010025803
Post Base
4
F
P00050024803
Lower Connector
For Slanting Beam
4
D
P00050025103
Lower Connector
For Middle Beam
4
CE
P00050157505
Big Top Corner
Connector
4
CG
P00050157302
Big Roof Short
Connector Tube
4
K
P00060197103
Big Roof Sloping
Beam
4

6/ 35
Country of Origin: China
L
P00060198303
Big Roof Middle
Beam
4
AF
P00570034503
Left Mosquito
Netting Rod
4
AG
P00570034603
Right Mosquito
Netting Rod
4
AU
P00050156502
Small Roof
Connector
1
CJ
P00060023602
Small Roof Oblique
Beam
4
R
P005800001
Hook
1
CK
P00060202102
Small Roof Panel
Flashing(Short Side)
4
CL
P00070022402
Small Roof Panel
(Left)
4
CM
P00070022602
Small Roof Panel
(Right)
4
CN
P00080009802
Small Roof Inclined
Beam Cap
4
AV
P00090015402
Small Top Cover
1
W
P00060198903
Big Roof Top
Beam(Upper)
8
Y
P00060199903
Big Roof Top
Beam(Middle)
8
AB
P00060201203
Big Roof Panel
Flashing(Short Side)1
4

7/ 35
Country of Origin: China
AC
P00060201602
Big Roof Panel
Flashing(Short Side)2
4
AM
P00070102103
Big Roof Big Panel
(Left)
4
AN
P00070102603
Big Roof Big
Panel (Right)
4
AP
P00070101403
Big Roof Small
Panel (Left Middle)
4
AQ
P00070101603
Big Roof Small
Panel (Right
Middle)
4
AR
P00070101003
Big Roof Small
Panel (Left)
4
AS
P00070101203
Big Roof Right
Small Panel
4
CP
P00080034402
Big Roof Slanting
Beam Cap 4

8/ 35
Country of Origin: China
Hardware Pack
Label
Part Number
Description
Qty
Add
Part Image
H1
H100010047
Bolt M6*20
196
10
H2
H100010073 Bolt M6*60 1
1
H3
H100010046 Bolt M6*40 12
1
H4
H010010449
Bolt M10*205
8
1
H5
H100010054
Bolt M8*25
24
2
H6
H100010055
Bolt M8*35
16
1
H7
H030050058
Screw
ST4.8*30
64
4
H8
H030050057
Screw
ST4.8*40
56
3
H9
H030030010
Screw ST8*35
16
1
H10
H030010031
Screw
ST9.5*80
8
1
H11
H050080007
Flat Washer
M8
16
1
H12
H050080008
Flat Washer
M10
24
2
H13
H040050026
Non-slip Nuts
M10
8
1

9/ 35
Country of Origin: China
H14
H040090004
T-Nut
M8*8
24
2
H15
H040090005
T-Nut
M8*20
16
1
H16
H090990002
M3 Drill
2
0
HS H070010003 Stake Φ8*180 8 0
HW1 H090010017 M6 Wrench 2 0
HW2 H090030005 Allen Key M8 1 0
HW3 H090010015 M10 Wrench 2 0
HH P00220034001 Black Plastic
Buckle 8 1

10 / 35
Country of Origin: China
