Better Music Builder VM-62U Beta User manual

Passionate about Music
www.BetterMusicBuilder.com
Thank you for purchasing this unit. To
make full and effective use of this unit,
please read this Owner's Manual
carefully before operating it. Please
retain this manual for future reference.
UHF
Frequency Selectable
Professional UHF Wireless Microphone System
VM-62U
Operating Instructions
2-in-1 Base Module ***1 Receive Module with 2 Wireless Microphones System
®
Unlike any others ... that’s cost & value for you
®
ON
UH F WI RE LE S S SY ST EM V M - 6 2 U
662.500
MHz
090
CH
ON
UH F WI RE LE S S SY ST EM V M - 6 2 U
665.250
MHz
098
CH
IR
DUA L CH AN NEL R EC EI VE R
VM- 62U
UHF
MIC 1 V OL UM E
MIN M AX
MIC 2 V OL UM E
MIN M AX
2- IN -1 BA SE RE CE IV ER M ODU LE
AC T SC AN
PO WER
AC TSC AN
Bette r Music B uilde r
®®
Pa s s i o n a te ab o u t Mus i c
MHZ
CH
090
662.500
A
CH 098
665.250
FRE
MHZ
A
RF
AF
RF
AF

CONTENTS
INTRODUCTION................................................................................ 1
SYSTEM FEATURES.............................................................................1
PACKAGE ACCESSORIES...................................................................2
2-in-1 BASE MODULE........................................................................ 3
• Controls and Functions................................................................. 3~4
• Hardware Setup.............................................................................5~6
HAND-HELD MICROPHONE..............................................................7
• Controls and Functions................................................................. 7~8
OPERATION...................................................................................... 9
• How to Select Frequencies for the Receiver............................ 9~10
• How to Adjust Squelch.................................................................... 11
• How to Lock/unlock the Receiver...................................................11
• How to Lock/unlock the Microphone............................................11
• How to Insert/change Batteries of Microphone..........................12
• How to Adjust Radio Frequency of Microphone.........................13
• How to Turn On/Off Microphone.................................................13
• How to Interchange Microphone Head........................................13
TECHNICAL SPECIFICATION............................................................ 14
BODY-PACK MICROPHONE (Optional)...................................... 15~16
TROUBLESHOOTING................................................................. 17~18
APPENDIX................................................................................. 19~20
WARRANTY.....................................................................................21
hand-held
Base Module
Features
Package
Spec
Appendix
Warranty
Troubleshooting
Body-Pack
Intro
Operation

1
INTRODUCTION
Better Music Builder is proud to introduce the newest member in our UHF
wireless microphone systems: the VM-62U. It features a lighter design that
includes two hand-held microphones with built-in LCD panels, Wireless Infrared
Auto Sync System, and ultra long battery life.
Created for novices and professionals alike, VM-62U Wireless Microphone
improves your performance and simplifies your setup. Innovations such as the
Wireless Infrared Auto Sync System make setting up frequencies quick and
simple. Using the technology, the microphone automatically sets the same
frequency as the base module by syncing to create a complete interference free
and crystal clear microphone system. It features Clear Voice, delivering crystal
clearer sound quality that pro audio engineers trust. Gone are unpleasant
artifact noises wireless microphones are known to emit. What you get is a
cleaner, clearer sound at all audio levels.
The VM-62U Wireless Microphone is arguably the smartest microphone in the
market right now. The base module has a built-in automatic frequency search
capability that picks up the strongest signal in your current environment, saving
you time scrolling through channels hoping for the best signal.
With years of experience designing wireless microphone system, we at Better
Music Builder understand the problem with short battery life. Through intensive
research we have developed a better power management system to help
extend our wireless microphone battery life.
It is simply the best solution for home and professional karaoke performance.
SYSTEM FEATURES
1. Equipped with the latest wireless technology and UHF dual-channel in a
2-in-1 Base Module to pick up weak signals and prevent signal interference.
2. Clear LCD screen displaying Frequency, Channel, Audio Frequency, Radio
Frequency, Lock Setting, and Antenna Status.
3. Wireless Infrared Auto Sync System makes syncing a breeze.
4. Clear Voice delivering crystal clearer sound just like a wired microphone.
5. 100 selectable channels!
6. Ability to lock current settings.
7. Light weight mounting design for portability.
8. Adjustable antennas for better signal receiving.
9. AA battery usage for easy handling.
Features
Intro

PACKAGE ACCESSORIES
The package comes with one 2-in-1 Base Module [Receiver], two handheld
microphones, two receiver antennas, one DC adaptor, one unbalance audio
cable, and four AA batteries.
Package
AUDIO CABLE (FOR MIXED OUTPUT): 1 UNIT
For better quality connections, a XLR
to XLR cable is highly recommended.
Recommend
AA
ALKALINE
BATTERY
AA
ALKALINE
BATTERY
AA
ALKALINE
BATTERY
AA
ALKALINE
BATTERY
AA (1.5V) BATTERY: 4 UNITS
DC POWER ADAPTOR: 1 UNIT
DC-POWER USAGE: This wireless
microphone system is designed specifically
for the North American market, which uses
120V for DC power. For usage in Asia or
Europe, please change it to 220V by an
adaptor with DC 14V output 500mA.
NOTE
AC T S CAN
MI C 1 VOL UME
MI N MA X
MI C 2 VOL UME
MI N MA X
AC TSC A N
2- IN-1 BA SE RE C EI V ER MO DUL E
FR E
MH Z
CH
090
662.500
A
CH 098
665.250
FR E
MH Z
A
RF
AF
RF
AF
Better Music Builder
®®
Pa s s i o n a t e a b o u t M us i c
PO W ER
IR
DU AL CH ANN EL RE CEI V ER
VM-62U
UHF
2-IN-1 BASE MODULE [RECEIVER]: 1 SET
HANDHELD MICROPHONE: SET of 2
UH F W IR E LE S S SY S T EM V M - 6 2 U
662.500
MH z
090
CH
UH F W IR E LE S S SY S T EM V M - 6 2 U
665.250
MH z
098
CH
2
RECEIVER
ANTENNA:
2 UNITS
10.2 inches
25.8 cm

AC T S CAN
MI C 1 VOL UME
MI N MA X
MI C 2 VOL UME
MI N MA X
AC TSC A N
2- IN-1 BA SE RE C EI V ER MO DUL E
FR E
MH Z
CH
090
662.500
A
CH 098
665.250
FR E
MH Z
A
RF
AF
RF
AF
Better Music Builder
®®
Pa s s i o n a t e a b o u t M us i c
PO W ER
IR
DU AL CH ANN EL RE CEI V ER
VM-62U
UHF
2-in-1 BASE MODULE [RECEIVER]
CONTROLS AND FUNCTIONS
FRONT PANEL:
1. MIC 1 VOLUME CONTROL: Controls Microphone 1 volume.
2. MIC 1 ACT BUTTON: Automatically matches the microphone’s frequency
to the receiver’s frequency. Holding the button for three seconds to manually
select the receiver’s frequency.
3. MIC 1 SCAN BUTTON: Automatically searches and sets the best
frequency for the receiver. Holding the button for three seconds to
lock/unlock settings.
4. IR PORT: Infrared port for the Wireless Infrared Auto Sync System. Pointing
the handheld microphone’s infrared port at the receiver’s infrared port to
allow communication.
5. LCD SCREEN: Displays system status.
6. MIC 2 SCAN BUTTON: Automatically searches and sets the best
frequency for the receiver. Holding the button for three seconds to
lock/unlock settings.
7. MIC 2 ACT BUTTON: Automatically matches the microphone’s frequency
to the receiver’s frequency. Holding the button for three seconds to manually
select the receiver’s frequency.
8. MIC 2 VOLUME CONTROL: Controls Microphone 2 volume.
9. POWER BUTTON: Turns the system on/off.
Base Module
1 2 3 4 6 7 8 95
3

FRE
MHZ
CH
090
662.500
A
CH 098
665.250
FRE
MHZ
A
RF
AF
RF
AF
364110609500
Mod el No.: VM -62U
(UHF Microphone)
CALIFORNI A, UNITED STATES OF AMERICA
E-MAIL: i nfo@bette rmusic builder.c om
w w w . B e t t e r M u s i c B u i l d e r . c o m
ENGINEERED AND DE SIGN IN U.S.A.
SERIAL NO.
ANT ENN A-A ANT ENN A-BMIC 1 SQ UEL CH MIC 2 SQ UEL CH
DC 14V
DC-POWER
MIC 1 BA LA NCED MIC 2 BA LAN CED
TRUE DIV ERSIT Y
MIX
MIC 1 & 2
UNBA LA NCED
AUDI O OUT PUT
RISK OF ELECTR IC SHOCK
DO NOT OPEN
Taking apar t or modifyin g the
recei ver may lead to el ectric shock ,
fire, or d amage to the rec eiver and
will voi d your warrant y.
Better Mus ic Bu ilde r
®
®
16 17 18 19 20 21 22 23
4
LCD PANEL:
After turning on the “POWER” button, LCD screen will display the following:
10. MIC 1 Radio Frequency: Strength indicator of radio signal.
11. MIC 1 Audio Frequency: Strength indicator of incoming audio signal.
12. MIC 1 Frequency: Displays the current frequency.
13. MIC 1 Channel: Displays the current channel.
14. MIC 1 Lock/Unlock: Shows whether current settings are locked.
15. Antenna A/B: Displays the antenna in use. When one antenna
experiences noise or interference, the other antenna takes over.
REAR PANEL:
16. ANTENNA-A: Connect the antennas to the BNC socket.
17. MIC 1 SQUELCH CONTROL: Distance coverage adjustment.
18. MIXED OUTPUT: unbalanced 1/4" audio output for MIC 1 & MIC 2.
19. MIC 1 BALANCED OUTPUT: balanced XLR audio output.
20. MIC 2 BALANCED OUTPUT: balanced XLR audio output.
21. POWER SUPPLY: Removable adapter with DC14~22V 500mA.
22. MIC 2 SQUELCH CONTROL: Distance coverage adjustment.
23. ANTENNA-B: Connect the antennas to the BNC socket.
1210 11 13 14 15

XLR
Balanced Input
XLR
Balanced Input
XLR
Balanced Input
XLR
Balanced Input
1/4"
Unbalanced Input
1/4"
Unbalanced Input
1/4"
Unbalanced Input 1/4"
Unbalanced Input
364110609500
Mod el No.: VM -62U
(UHF Microphone)
CALIFORNI A, UNITED STATES OF AMERICA
E-MAIL: i nfo@bette rmusic builder.c om
w w w . B e t t e r M u s i c B u i l d e r . c o m
ENGINEERED AND DE SIGN IN U.S.A.
SERIAL NO.
ANT ENN A-A ANT ENN A-BMIC 1 SQ UEL CH MIC 2 SQ UEL CH
DC 14V
DC-POWER
MIC 1 BA LA NCED MIC 2 BA LAN CED
TRUE DIV ERSIT Y
MIX
MIC 1 & 2
UNBA LA NCED
AUDI O OUT PUT
RISK OF ELECTR IC SHOCK
DO NOT OPEN
Taking apar t or modifyin g the
recei ver may lead to el ectric shock ,
fire, or d amage to the rec eiver and
will voi d your warrant y.
Better Mus ic Bu ilde r
®
®
HARDWARE SETUP
HOW TO CONNECT AUDIO OUTPUT:
There are three rear outputs as shown in the below diagram:
MIXED OUTPUT is unbalanced audio output for MIC 1 & MIC 2 using 1/4”
connection. When using this output, MIC 1 and MIC 2 have to share a signal. To
produce different effects on each microphone, MIC 1 and MIC 2 need their own
signals which can be done by using XLR connections.
MIC 1 BALANCED OUTPUT is balanced audio output for MIC 1 using XLR
connection. When using this output, you can change MIC 1 effects without
affecting MIC 2 effects.
MIC 2 BALANCED OUTPUT is balanced audio output for MIC 2 using XLR
connection. When using this output, you can change MIC 2 effects without
affecting MIC 1 effects.
UHF WIRELESS SYSTEM DIAGRAM:
Set Up
We highly recommend using balanced XLR connections if the distance between the
microphone receiver and the mixer is more than 10 feet. The grounding of the balanced XLR
connection delivers better quality signal by reducing noise.
Recommend
MIC 1 HANDHELD MICROPHONE
UHFWIRELE SS SYSTEM VM-62U
662.500
MHz
090
CH
MIC 2 HANDHELD MICROPHONE
UHFWIRELE SS SYSTEM VM-62U
665.250
MHz
098
CH
BALANCED CONNECTION
5
364110609500
Mod el No.: VM -62U
(UHF Microphone)
CALIFORNI A, UNITED STATES OF AMERICA
E-MAIL: i nfo@bette rmusic builder.c om
w w w . B e t t e r M u s i c B u i l d e r . c o m
ENGINEERED AND DE SIGN IN U.S.A.
SERIAL NO.
ANT ENN A-A ANT ENN A-BMIC 1 SQ UEL CH MIC 2 SQ UEL CH
DC 14V
DC-POWER
MIC 1 BA LA NCED MIC 2 BA LAN CED
TRUE DIV ERSIT Y
MIX
MIC 1 & 2
UNBA LA NCED
AUDI O OUT PUT
RISK OF ELECTR IC SHOCK
DO NOT OPEN
Taking apar t or modifyin g the
recei ver may lead to el ectric shock ,
fire, or d amage to the rec eiver and
will voi d your warrant y.
Better Mus ic Bu ilde r
®
®
1
MIXED OUTPUT
(MIC 1 & 2 UNBALANCE) 2
MIC 1 BALANCED OUTPUT (BALANCED XLR)
MIC 2 BALANCED OUTPUT (BALANCED XLR)
3
AUDIO MIXER AMPLIFIER OR A KARAOKE UNIT INPUT TERMINAL
REAR VIEW

IR
DUA L CHA NNEL RE CEI VER
VM-6 2U
UHF
MIC 1 V OLU ME
MIN MA X
MIC 2 V OLU ME
MIN MA X
2-I N-1 B ASE R ECEIV ER MO DUL E
ACT S CA N
POW ER
ACTSCA N
Better M usic Bui lder
®®
Pas s i o n a t e a b o u t M u s i c
MHZ
CH
090
662.500
A
CH 098
665.250
FRE
MHZ
A
RF
AF
RF
AF
6
364110609500
Mod el No.: VM -62U
(UHF Microphone)
CALIFORNI A, UNITED STATES OF AMERICA
E-MAIL: i nfo@bette rmusic builder.c om
w w w . B e t t e r M u s i c B u i l d e r . c o m
ENGINEERED AND DE SIGN IN U.S.A.
SERIAL NO.
ANT ENN A-A ANT ENN A-BSQU ELCH -1 SQU ELCH -2
DC 14V
DC-POWER
MIC 1 BA LA NCED MIC 2 BA LAN CED
TRUE DIV ERSIT Y
MIX
MIC 1 & 2
UNBA LA NCED
AUDI O OUT PUT
RISK OF ELECTR IC SHOCK
DO NOT OPEN
Taking apar t or modifyin g the
recei ver may lead to el ectric shock ,
fire, or d amage to the rec eiver and
will voi d your warrant y.
Better Mus ic Bu ilde r
®
®
HOW TO CONNECT DC-POWER:
For North America Market, use 120V, DC 14~22V 500mA adaptor. For market
outside North America, use 220V~ 240V DC adaptor with a maximum battery
capacity of 500mA.
OPTIONAL 19” RACK MOUNT KIT:
To put the system onto a mount-kit, please follow the diagram below. Our
special design feature allow it to be mounted on a DJ rack.
NOTE
Please make sure to use the right DC adaptor. Otherwise, it may damage the 2-in-1 Base
Module and the charger because their maximum battery capacity is different. The product
warranty will be voided if there is damage caused by using the wrong DC adaptor.
REAR VIEW
ANTENNA IS ADJUSTABLE
5.5 inches
19 inches
11.8 inches
Rack mount kit is not included in package.

7
Hand-held
HANDHELD MICROPHONE
CONTROLS AND FUNCTIONS
1. INTERCHANGEABLE MICROPHONE HEAD
2. LCD DIGITAL DISPLAY
3. POWER ON/OFF SWITCH BUTTON
4. IR PORT: Infrared port for the Wireless Infrared Auto Sync Technology.
Point the microphone’s infrared port at the receiver’s infrared port to allow
communication.
5. FREQUENCY SELECTION BUTTON: Press UP/DOWN button to select
frequency.
6. SET BUTTON: Press SET button to confirm frequency.
7. TRANSMISSION POWER LEVEL CONTROLLER
8. BATTERY SLOTS: Insert 2x1.5V AA battery or 2x1.2V rechargeable battery.
AA ALKALINE
BATTERY AA ALKALINE BATTERY
UHF W I R E L E S S S Y S T E M V M - 6 2 U
662.500
MH z
090
CH
1 2 3
IR
4
8
662.500
MH z
090
CH
DOWN UP
RF
H
L
SE T
VM-62U
UHF WI RE L ES S SY S TE M
FR EQ UEN CY: 5 20 ~682 MHz
BAT T ER Y SIZ E: 2 A A
En gin eer e d in U .S. A. FC C
75 6
1.5V AA 1.5V AA

8
LCD PANEL:
After turning on the “POWER”, the LCD screen will light up as below:
1. CHANNEL: Current value depends on your setting.
2. FREQUENCY: Current value depends on your setting.
3. RADIO FREQUENCY SIGNAL: Switch to High (10mW) to use a stronger
signal and Low (5mW) to use a weaker signal.
4. BATTERY STATUS: Indicates battery life.
BATTERY STATUS:
Indicates full battery on the microphone. The
engineering team of Better Music Builder uses
the latest technology to indicate the battery
status, so you can see the battery strength.
Indicates low battery on the microphone.
When the microphone LCD screen is blinking
or fading, its time to replace the batteries.
If the microphone cannot be turn on, please check the battery. It may be very low.
Typical new full battery life is 4~6 hours with our system, otherwise, the batteries might be
defective or near expiration date.
Batteries are not covered under our product warranty.
NOTE
Low Battery
Full Battery
LCD screen will blink
constantly when battery is
extremely low and about
to die.
OFF
090
CH
662.500
MHz
090
CH
662.500
MHz
090
CH
662.500
MHz
090
CH
1
2
3
4

ACT SCAN
MIC 1 VOLUME
MIN MAX
MIC 2 VOLUME
MIN MAX
ACTSCAN
2-IN-1 BAS E RECEIV ER MODUL E
FRE
MHZ
CH
090
774.750
A
CH 098
776.750
FRE
MHZ
A
RF
AF
RF
AF
Better Music Builder
®®
Passion a te abo u t Mus i c
POWER
IR
DUAL CHANN EL RECEI VER
VM-62U UHF
9
OPERATION
HOW TO SELECT FREQUENCIES FOR THE RECEIVER
The 2-in-1 Base Module comes with two handheld microphones and the
microphones are preset with 100 frequency channels. The frequency can be
selected either automatically or manually.
1. AUTOMATIC FREQUENCY SELECT
STEP 1: Press and release the SCAN button on the receiver. It will automatically
search and set the strongest frequency for the receiver.
Operation
STEP 2: Once the frequency has
been set on the receiver, point
the microphone infrared port (IR)
directly at the receiver infrared
port (IR).
STEP 3: Press and release the ACT button on the receiver. It will automatically set
the microphone frequency the same as the receiver frequency.
ACT S CAN
MIC 1 VO LUME
MIN MA X
MIC 2 VO LUME
MIN MA X
ACT
SCAN
2-IN -1 BASE RE CEIVE R MODULE
FRE
MHZ
CH
090
662.500
A
CH
098
665.250
FRE
MHZ
A
RF
AF
RF
AF
Better Mus ic Builder
®®
Pass i o n a t e abo ut Musi c
POW ER
IR
DUAL C HANNEL REC EIVER
VM-62U
UHF
M
a
t
chin
g
Fr
e
q
u
e
nci
e
s
D
is
ta
n
c
e
:
3-inch
IR
FR E
If the SCAN button is
pressed and held for more than
three seconds, the frequency will
be locked .
NOTE
ACT SCAN
MIC 1 VOLUME
MIN MAX
MIC 2 VOLUME
MIN MAX
ACTSCAN
2-IN-1 BAS E RECEIV ER MODUL E
FRE
MHZ
CH
090
774.750
A
CH 098
776.750
FRE
MHZ
A
RF
AF
RF
AF
Better Music Builder
®®
Passion a te abo u t Mus i c
POWER
IR
DUAL CHANN EL RECEI VER
VM-62U UHF
ACTSCAN
CH 098
665.250
FRE
MHZ
A
RF
AF
MICROPHONE AND RECEIVER
FREQUENCY MATCHED
IR
IR
665.250
MHz
098
CH
2- IN -1 BASE REC EI V E R MODULE
MH Z
CH
090
662.500
A
CH 098
665.250
FR E
MH Z
A
RF
AF
RF
AF

10
Please make sure that the other hand-held microphone is turned off when adjusting the
frequency on one microphone.
Each unit is fully tested and qualified by the manufacturer. However, due to the nature of wireless
connection, interference may occur because of local environments and/or radio signals emitted
by other wireless devices within the household.
If MIC 1 or MIC 2 is actively picking up RF and/or AF signal when the handheld microphone is
turned off, this is an indication that the frequency is being used by some other active device within
a 200 feet radius. Therefore, selecting a different frequency is highly recommended.
NOTE
2. MANUAL FREQUENCY SELECT
STEP 1: Press and hold the ACT button on the receiver for three seconds until the
frequency starts flashing, and then release the button.
STEP 2: While it is flashing, press the ACT or SCAN button on the receiver to
choose the desired frequency. After choosing the desired frequency, wait until it
stops flashing.
STEP 3: Press the UP or DOWN button on the microphone to match the receiver
frequency and then press the SET button on the microphone to confirm. When
the microphone frequency matches the receiver frequency, the receiver’s RF bars
will show.
3 SECONDS
662.500
MHz
090
CH
DOWN UP
RF
H
L
SET
VM-62U
UHF WIREL ESS SYST EM
FREQUEN CY: 520~68 2 MHz
BATTERY S IZE: 2A A
Engine ered in U .S.A. F CC
665.250
MHz
090
CH
DOWN UP
SET
ACT SCAN
MIC 1 VOLUME
MIN MAX
MIC 2 VOLUME
MIN MAX
ACTSCAN
2-IN-1 BAS E RECEIV ER MODUL E
FRE
MHZ
CH
090
774.750
A
CH 098
776.750
FRE
MHZ
A
RF
AF
RF
AF
Better Music Builder
®®
Passion a te abo u t Mus i c
POWER
IR
DUAL CHANN EL RECEI VER
VM-62U UHF
CH 098
665.250
FRE
MHZ
A
RF
AF
SCAN ACT
ACT SCAN
MIC 1 VOLUME
MIN MAX
MIC 2 VOLUME
MIN MAX
ACTSCAN
2-IN-1 BAS E RECEIV ER MODUL E
FRE
MHZ
CH
090
774.750
A
CH 098
776.750
FRE
MHZ
A
RF
AF
RF
AF
Better Music Builder
®®
Passion a te abo u t Mus i c
POWER
IR
DUAL CHANN EL RECEI VER
VM-62U UHF
ACTSCAN
CH 098
665.250
FRE
MHZ
A
RF
AF

11
HOW TO ADJUST SQUELCH
The SQUELCH knob on the back of the receiver adjusts the distance range
between the microphone and the receiver. Use a plastic screwdriver to make the
squelch adjustment at the button. A higher level of squelch allows the usage of
microphone further away from the receiver. However, the drawback of using a
higher level of squelch is the increased chance of interference.
HOW TO LOCK/UNLOCK THE RECEIVER
Press and hold the SCAN button on the receiver for more than three seconds to
lock/unlock the frequency on the receiver.
HOW TO LOCK/UNLOCK THE MICROPHONE
STEP 1: Press and release the SET button on the microphone to see “LOC
ON/LOC OFF” on the LCD screen.
STEP 2: Press the UP/DOWN button to either lock or unlock the
frequency/channel of the microphone.
STEP 3: Press the SET button to confirm. Press the SET button again to return to
the main menu.
ACT SCAN
MIC 1 VOLUME
MIN MAX
MIC 2 VOLUME
MIN MAX
ACTSCAN
2-IN-1 BAS E RECEIV ER MODUL E
FRE
MHZ
CH
090
774.750
A
CH 098
776.750
FRE
MHZ
A
RF
AF
RF
AF
Better Music Builder
®®
Passion a te abo u t Mus i c
POWER
IR
DUAL CHANN EL RECEI VER
VM-62U UHF
3 SECONDS
LOCK

UNLOCK
662.500
MHz
090
CH
DOWN UP
RF
H
L
SET
VM-62U
UHF WIREL ESS SYST EM
FREQUEN CY: 520~68 2 MHz
BATTERY S IZE: 2A A
Engine ered in U .S.A. F CC
locoff
090
CH
DOWN UP
SET
364110609500
ModelNo .: VM-62U
(UHFMicrop hone)
CALIFORNIA,UNITED STATES OF AMERICA
E-MAIL:info@bettermus icbuilder.com
www.Be t terMus i c B u i l d e r . c o m
ENGINEEREDANDDESIGN IN U.S.A.
SERIALNO.
ANTENNA-A ANTENNA-BSQUELCH-1 SQUELCH-2
DC14V
DC-POWER
MIC1 BALAN CED MIC 2 BAL ANCED
TRUEDIV ERSITY
MIX
MIC1 & 2
UNBALANCED
AUDIO OUTPU T
RISKOFELECTRIC SHOCK
DONOTOPEN
Takingapartor modi fying the
receivermay lead to elect ric shock,
fire,ordamage t o the receive r and
willvoidyou r warranty.
BetterM usic Builder
®
®
SQUELCH-1
PLASTIC SCREWDRIVER

12
AA ALKALINE
BATTERY AA ALKALINE BATTERY
Good
AA ALKALINE
BATTERY AA
ALKALINE
BATTERY
No Good
1.5V AA 1.5V AA
AA
ALKALINE
BATTERY
1.5V AA 1.5V AA
IR
1.5V AA 1.5V AA
IR
HOW TO INSERT/CHANGE BATTERIES OF MICROPHONE
STEP 1: Twist open battery cover.
STEP 2: Use one hand to hold onto the top of the Microphone, and the other
hand to slide 2x1.5V AA batteries into battery slot. Be careful not to drop
Microphone while inserting batteries.
Make sure to follow the polarity of the battery according to the battery
slots.
STEP 3: Twist back battery cover.

UH F WIR ELES S SY ST EM V M - 6 2 U
662.500
MHz
090
CH
13
HOW TO ADJUST RADIO FREQUENCY OF MICROPHONE
Adjust the signal of the radio frequency using the RF switch on the handheld
microphone. Switch to High (10mW) to use a stronger signal and Low (5mW)
to use a weaker signal. However, the drawback of using a stronger signal is
the increased chance of interference.
HOW TO TURN ON/OFF MICROPHONE
TURN ON: Push the power switch up to turn microphone’s power ON.
Microphone’s LED screen will displays Frequency, Channel, Radio Frequency
and Battery Status.
TURN OFF: Push the power switch down to turn microphone’s power OFF.
Microphone’s LED screen will be off.
After turning on the microphone’s power on, there might be a need to adjust
the frequency to match the receiver’s frequency.
HOW TO INTERCHANGE MICROPHONE HEAD
1
2
INTERCHANGEABLE
MICROPHONE HEAD
Replacement parts (such as the
microphone head as shown on the
left) can be purchased from any of
our authorized dealers.
NOTE
If the microphone cannot be turn on, please check the battery. It may be very low.
Typical new full battery life is 4~6 hours with our system, otherwise, the batteries might be
defective or near expiration date.
NOTE
662.500
MHz
090
CH
DOWN UP
RF
H
L
SET
VM-62U
UHF WIREL ESS SYST EM
FREQUEN CY: 520~68 2 MHz
BATTERY S IZE: 2A A
Engine ered in U .S.A. F CC
662.500
MHz
090
CH
RF
H
L

14
TECHNICAL SPECIFICATION
A. TECHNICAL FEATURE OF THE 2-IN-1 BASE MODULE:
1. Channel: 100 Channels
2. Frequency Range: UHF 520~682 MHz
3. Signal to Noise Ratio: > 90dB
4. Total Harmonic Distortion: < 0.05%
5. Band Width: < 200kHz
6. Frequency Response: 35Hz~20kHz +/-3dB
7. Dynamic Range: > 100dB
8. Valid Distance: 0.50m
9. Audio Output Level: Unbalanced Out: 0~+/-400mV
Balanced Out: 0~+/-200mV
10. Power Supply: DC 14V~22V with 500mA~1000mA, AC 120V (For 220V,
you may need to change to a 220V~240V DC adaptor)
11. Consume Power: 5 Watts
12. Receiver Dimensions (WxHxD): 11.8 x 1.9 x 7.1 (inches) / 30 x 4.8 x 18 (cm)
13. Package Dimensions (WxHxD): 16.9 x 13.8 x 3 (inches) / 43 x 35 x 7.5 (cm)
14. Shipping Weight: 5.6 lbs / 2.5 kg
B. TECHNICAL FEATURE OF THE MICROPHONE:
1. Transmitter Power: 5mW and 10mW
2. Osillation Mode: PLL
3. Image Controlment: >50dB
4. Adjust Frequency Deviation: <75kHz
5. Channel Switch Mode: Coding Switch
6. Power Supply: DC 2.4V~4.8V
7. Battery Voltage: 2 x AA 1.5V Alkaline Battery
8. Continuous Using: 8 Hours (GP) 2 x AA 1.5V Battery
9. Microphone Dimensions (WxH): 10.4 x 2.2 (inches) / 26.5 x 5.5 (cm)
C. THIS SYSTEM INCLUDES THE FOLLOW:
• 2-in-1 Base Module: 1 Set • DC-Power Adaptor: 1 Unit
• Handheld Microphone: 2 Sets • Audio Cable: 1 Unit
• Antenna: 2 Units • Instructional Manual: 1 Unit
• AA 1.5V Battery: 4 Units
Spec

15
BODY-PACK MICROPHONE SYSTEM
SPECIFICATION (Optional)
NAMES & FUNCTION:
Body-Pack Microphone System (including Lavalier Mic. and Headset Mic.)
Optional
Side-face
Apical Panel
1. Antenna Jack
2. Power/Mute indicator
3. Power Switch
4. Microphone Input Jack
1 2 3 4
Body-pack Microphone Top View
Optional
Headset Mic.
(Accessories)
1/4” to mini 3-pin lavalier cable
Lavalier Mic.
(Accessories)
1/4” to mini 3-pin lavalier cable
Optional
Outside Picture
1. Antenna
2. 4-pin Microphone Input Jack
3. LCD Digital Display
4. IR Port: Receives infrared beam
to synchronize frequencies. IR
when using multiple systems,
only one microphone port should
be exposed at a time
5. Battery Cover
6. Tie-Clip
7. Microphone Extension Jack
Inside Picture
1. Power/Mute indicator
• Green: Ready
• Amber: Mute Open
• Flashing Red: IR is transmission in
process
• Glowing Red: Low battery power
• Pulsing Red: Battery dead
(microphone cannot be turned off
until batteries are changed)
2. Power ON/OFF/mute switch
Button: Press and hold the
microphone for 3 seconds to turn
power ON/OFF. Press and
release to mute or un-mute the
microphone.
3. Adjustment switch
4. Battery Slot
7
1
2
3
4
5
6
Optional
2
1
4
3
Optional
Body-Pack

16
HOW TO INSERT BODY-PACK MICROPHONE BATTERIES
HOW TO WEAR BODY-PACK MICROPHONE
The microphone can be buckled to the belt or the guitar band. For best result,
the microphone should be pushed down until the belt is close to the base of
microphone.
ADJUSTMENT GAIN
Three gain settings are available.
Choose the appropriate setting for your
instrument.
• MIC: for the microphone adjustment
• 0: Guitar with passive pickups
• -10: Guitar with active pickups
MICROPHONE BODY-PACK
REAR VIEW
A
AA ALK ALINE
BATTERY
AA
ALKALINE
BATTERY
AA ALKALINE
BATTERY
Good
CLOSE
OPEN
STEP 1: Open battery cover.
STEP 2: Insert 2 AA batteries. 2
alkaline batteries are expected to
use for about 8 hours.
Make sure that you insert batteries
correctly, as shown in picture. When
the microphone body-pack light
glows red, the batteries should be
changed immediately.
12
MICROPHONE BODY-PACK
REAR VIEW
B

17
TROUBLESHOOTING
CAUTION: Before troubleshooting any symptoms make sure the
equipments are in the “OFF” position.
1. SYMPTOM: NO SOUND COMING FROM MICROPHONE
A. CAUSE: There is no indication of signal.
a. Turn microphone to “OFF” position. Check if batteries are inserted correctly.
b. If batteries are inserted correctly, but there is no power, insert new batteries
c. Make sure the microphone and receiver are in the same channel
d. The volume may be turned to a low level.
B. CAUSE: The receiver is unpowered.
Make sure the power adapter is connected properly and there is power
coming from the power outlet.
C. CAUSE: There is no indication of AF signal.
Turn off the receiver and make sure it is properly connected to the mixer or
amplifier. If it is, slowly turn the volume higher.
D. CAUSE: There is no indication of RF signal.
If there is no indication of RF signal there may be interference between the
receiver and the microphone. Change the channel between the microphone
and receiver otherwise; Adjust the antenna of the receiver and/or move away
objects between receiver and the microphone .
2. SYMPTOM: ONE OR MORE OF THE MICROPHONE IS NOT WORKING,
CHECK THE SOLUTIONS FOR CAUSES A~D ABOVE.
3. SYMPTOM: RANDOM NOISE COMING OUT FROM MICROPHONE
CAUSE: There are interference within your area.
1. Change the channel between the microphone and receiver.
2. Stand further away from your speaker.
Troubleshooting

18
4. SYMPTOM: THE MICROPHONE SUDDENLY HAS NO SOUND AND THE
RECEIVER LCD LIGHT IS OFF.
Make sure the AC power adapter is securely plugged into the electrical outlet
and into the DC input connector on the rear panel of the receiver. Make sure
the AC electrical outlet works and is supplying the proper voltage.
5. SYMPTOM: THE MICROPHONE SUDDENLY HAS NO SOUND BUT THE
RECEIVER SHOWS RF SIGNAL.
CAUSE: The microphone out lead is damaged or disconnected.
To fix it, open the microphone head cover to check on the microphone out
lead and re-connect the wire by wielding. If it does not work, replace the
microphone out lead.
6. SYMPTOM: THE MICROPHONE DISTORTION LEVEL IS INCREASING
GRADUALLY.
CAUSE: The microphone batteries are running out.
Replace the microphone batteries.
7. SYMPTOM: POOR SIGNAL
CAUSE: When the 2-in-1 Base Module and microphone are placed in different
rooms made of concrete wall. This would cause poor signal.
Your audio equipment is close to the police, fire or radio stations. In this case,
a different frequency channel MUST be selected. Both the microphone and
the 2-in-1 Base Module must change to a matching frequency.
8. SYMPTOM: THE FREQUENCY OF THE MICROPHONE IS DIFFERENT
FROM THE 2-in-1 Base Module.
The microphone’s frequency must match with 2-in-1 Base Module’s frequency.
