Beyerdynamic NE 600 D Configuration guide

NE 600
UHF Diversity Receiver
APPLICATIONS
The NE 600 UHF diversity receiver with PLL synthesizer technology
is suitable for a variety of applications: For example for musicians or
actors on stage, presenters and moderators in meetings, sports
events, hotels, universities and houses of worship. The reciever is
available in two versions as one-channel (NE 600 S) or two-channel
receiver (NE 600 D) with integrated antenna splitter and mix output.
The NE 600 operates in the frequency range from 506 to 530 MHz,
668 to 692 MHz, 774 to 798 MHz, 790 to 814 MHz and 841 to
865 MHz. Within these frequency ranges one of 16 pre-programmed
frequencies can be selected. The Scan function is used to start an
automatic search for interference-free frequencies. The found
frequency is transmitted to the transmitter with the ACT function
(Automatic Channel Targeting). The frequency presets can also be
selected manually. LEDs display all operating parameters such as
RF and AF level or the selected frequency preset. A sophisticated,
adjustable squelch system monitors the operating and level states
of the system. The pilotone-controlled AF-mute suppresses noise
and mutes the receiver when the appropriate transmitter is switched
off. The Opus 600 system features reliability, easy handling,
superior operating time of the transmitter battery and flexibility due
to interchangeable microphone capsules. The one-channel receiver
is also available in pre-configured sets with a rugged soft case.
FEATURES
• UHF diversity receiver with PLL synthesizer technology as
one-channel (NE 600 S) or,
two-channel version (NE 600 D)
• Suitable for 19" rack mounting, 1 U
Front view
• On/off switch with power on LED
• Scan button
• Channel display
• RF level indicator
• AF level indicator
• ACT button
Rear view
• Removable TNC antennae
• Antenna inputs (TNC sockets) with power supply for
antenna amplifiers
• AF output, 3-pin XLR, balanced
• AF output, 1/4" jack (6.35 mm), unbalanced
• Mic/Line level switch
• Adjustable squelch
beyerdynamic GmbH & Co. KG
Theresienstr. 8 | 74072 Heilbronn – Germany
Tel. [phone] / 617 - 0 | Fax [phone] / 617 - 224
[email protected] | www.beyerdynamic.de
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Contents subject to change without notice. E1/NE 600 (05.09)
1 of 3
NE 600 S
NE 600 D

NE 600
beyerdynamic GmbH & Co. KG
Theresienstr. 8 | 74072 Heilbronn – Germany
Tel. [phone] / 617 - 0 | Fax [phone] / 617 - 224
[email protected] | www.beyerdynamic.de
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Contents subject to change without notice. E1/NE 600 (05.09)
2 of 3
OPTIONAL ACCESSORIES
Antenna splitter
ZAS 800 Antenna splitter, active, 19" housing,
incl. cable set,
740 - 764 MHz . . . . . . . . . . . . . . . . . Order # 467.073
ZAS 800 same as above, but 774 - 798 MHz* . . Order # 473.081
ZAS 800 same as above, but 790 - 814 MHz** . Order # 491.667
ZAS 800 same as above, but 841 - 865 MHz** . Order # 491.675
Antennae
AT 70 A/B Set
UHF antenna set for NE 900,
incl. 2 x AT 70 B TNC antenna amplifiers,
2 x AT 70 TNC antenna and
2 x MS 10 mounting kit. . . . . . . . . . . Order # 459.976
FBC 71 Cable rear-to-front for NE 900,
ZAS 800 . . . . . . . . . . . . . . . . . . . . . . Order # 469.823
FB 71 Mounting bracket, metal,
for mounting one NE 600 S receiver
into a 19" rack, 1 U. . . . . . . . . . . . . . Order # 469.793
FB 72 Mounting bracket, metal,
for mounting two NE 600 S receivers
or one NE 600 D receiver
into a 19" rack, 1 U. . . . . . . . . . . . . . Order # 469.807
VERSIONS
NE 600 D Two-channel true diversity receiver,
506 - 530 MHz . . . . . . . . . . . . . . . . . Order # 701.246
NE 600 D same as above, but 668 - 692 MHz . . . Order # 701.254
NE 600 D same as above, but 774 - 798 MHz* . . Order # 701.262
NE 600 D same as above, but 790 - 814 MHz** . Order # 701.327
NE 600 D same as above, but 841 - 865 MHz** . Order # 701.270
NE 600 S One-channel true diversity receiver,
506 - 530 MHz . . . . . . . . . . . . . . . . . Order # 700.894
NE 600 S same as above, but 668 - 692 MHz . . . Order # 700.908
NE 600 S same as above, but 774 - 798 MHz* . . Order # 700.916
NE 600 S same as above, but 790 - 814 MHz** . Order # 700.319
NE 600 S same as above, but 841 - 865 MHz** . Order # 700.924
SETS
Opus 660 Set consisting of:
NE 600 S one-channel receiver and
SDM 660 microphone,
incl. soft case, batteries,
mounting brackets and
power supply unit, 506 - 530 MHz . . . Order # 700.622
same as above, but 668 - 692 MHz . . . Order # 700.673
same as above, but 774 - 798 MHz* . . Order # 700.746
same as above, but 790 - 814 MHz** . Order # 700.797
same as above, but 841 - 865 MHz** . Order # 700.843
Opus 669 Set consisting of:
NE 600 S one-channel receiver and
SDM 669 microphone,
incl. soft case, batteries,
mounting brackets and
power supply unit, 506 - 530 MHz . . . Order # 700.630
same as above, but 668 - 692 MHz . . . Order # 700.681
same as above, but 774 - 798 MHz* . . Order # 700.754
same as above, but 790 - 814 MHz** . Order # 700.800
same as above, but 841 - 865 MHz** . Order # 700.851
Opus 681 Set consisting of:
NE 600 S one-channel receiver and
SEM 681 microphone,
incl. soft case, batteries,
mounting brackets and
power supply unit, 506 - 530 MHz . . . Order # 700.649
same as above, but 668 - 692 MHz . . . Order # 700.703
same as above, but 774 - 798 MHz* . . Order # 700.762
same as above, but 790 - 814 MHz** . Order # 700.819
same as above, but 841 - 865 MHz** . Order # 700.878
Opus 600 Set consisting of:
NE 600 S one-channel receiver and
TS 600 beltpack transmitter,
incl. soft case, batteries,
mounting brackets and
power supply unit, 506 - 530 MHz . . . Order # 701.106
ame as above, but 668 - 692 MHz. . . . Order # 701.114
same as above, but 774 - 798 MHz* . . Order # 701.122
same as above, but 790 - 814 MHz** . Order # 701.130
same as above, but 841 - 865 MHz** . Order # 701.149
*Not for use in the USA **Not for use in the USA or Canada

NE 600
beyerdynamic GmbH & Co. KG
Theresienstr. 8 | 74072 Heilbronn – Germany
Tel. [phone] / 617 - 0 | Fax [phone] / 617 - 224
[email protected] | www.beyerdynamic.de
For further distributors worldwide, please go to www.beyerdynamic.com
Non-contractual illustrations. Contents subject to change without notice. E1/NE 600 (05.09)
3 of 3
TECHNICAL SPECIFICATIONS
Operating principle . . . . . . . . . . . . . . . . . True diversity receiver
(UHF)
Frequency range . . . . . . . . . . . . . . . . . . . 506 - 530 MHz
668 - 692 MHz
774 - 798 MHz*
790 - 814 MHz**
841 - 865 MHz**
Power consumption . . . . . . . . . . . . . . . . NE 600 S: 6 W
NE 600 D: 15 W
Power consumption
in stand-by mode . . . . . . . . . . . . . . . . . . NE 600 S: 1.5 W
NE 600 D: 2.5 W
Switching bandwidth . . . . . . . . . . . . . . . 24 MHz
Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . 2 µV
Antenna connection . . . . . . . . . . . . . . . . 2 x TNC
Nominal deviation. . . . . . . . . . . . . . . . . . ± 40 kHz
Output level . . . . . . . . . . . . . . . . . . . . . .
1.2 V
Compander system. . . . . . . . . . . . . . . . . . NE572
Signal-to-noise ratio . . . . . . . . . . . . . . . . > 110 dB(A)
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . < 0.5% at 1 kHz
Squelch . . . . . . . . . . . . . . . . . . . . . . . . . 2 µV - 1 mV, adjustable
Power supply . . . . . . . . . . . . . . . . . . . . . 12 V - 15 V DC
Mains . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 V - 240 V AC
Dimensions
NE 600 S (L x B x H) . . . . . . . . . . . . . . . . 210 x 235 x 43 mm
NE 600 D (L x B x H) . . . . . . . . . . . . . . . . 420 x 204 x 44 mm
Weight
NE 600 S . . . . . . . . . . . . . . . . . . . . . . . . 1.1 kg (without power
supply unit)
NE 600 D . . . . . . . . . . . . . . . . . . . . . . . . 2.2 kg
Minimum distance of the profiles
when mounting into a 19" rack . . . . . . . 446 mm
*Not for use in the USA **Not for use in the USA or Canada
