Beyerdynamic RP-T User manual

UNITE RP | RP-T
BODYPACK RECEIVER
TASCHENEMPFÄNGER
QUICK START GUIDE
KURZANLEITUNG

4
This device complies with Pa 15 of the FCC Rules and
with Indury Canada licence-exempt RSS andard(s).
Operation is su ject to the following two conditions: (1)
this device may not cause harmful inteerence, and (2)
this device mu accept any inteerence received,
including inteerence that may cause undesired
operation.
Le présent appareil e conforme aux CNR d’Indurie
Canada applica les aux appareils radio exempts de
licence. L’exploitation e autorisée aux deux conditions
suivantes: (1) l’appareil ne doit pas produire de rouillage,
et (2) l’utilisateur de l’appareil doit accepter tout rouil-
lage radioélectrique su i, même si le rouillage e
suscepti le d’en compromettre le fonctionnement.
This equipment has een teed and found to comply
with the limits for a Class A digital device, pursuant to Pa
15 of the FCC Rules. These limits are designed to provide
reasona le protection again harmful inteerence
when the equipment is operated in a commercial envi-
ronment. This equipment generates, uses, and can radi-
ate radio frequency energy and, if not inalled and used
in accordance with the inruction manual, may cause
harmful inteerence to radio communications. Operation
of this equipment in a residential area is likely to cause
harmful inteerence in which case the user will e re-
quired to correct the inteerence at his own expense.
Changes or modifications made to this equipment not
expressly approved y Beyerdynamic may void the FCC
authorization to operate this equipment.

5
Ee produto eá homologado pela Anatel, de acordo
com os procedimentos regulamentados pela Resolução
n°. 242/2000 e atende aos requisites técnicos aplicados,
incluindo os limites de exposição da Taxa de A sorção
Específica referente a campos elétricos, magnéticos e
eletromagnéticos de radiofreqüência de acordo com as
Resoluções n°. 303/2002 e 533/2009.
This device is granted pursuant to the Japanese Radio
Law (電波法) and the Japanese Telecommunications
Business Law (電気通信事業法). This device should not e
modified (otherwise the granted designation num er will
ecome invalid).
The devices conforms to the EU guidelines
(EMC) 2014/30/EU
(LVD) 2014/35/EU
(RED) 2014/53/EU
as atteed y the CE mark.
FCC ID: OSDUNITEP
IC: 3628C-UNITEP
Japan: R: 202-SMG006
Radiofrequency radiation exposure Information:
For ody worn operation, this equipment has een teed
and meets the FCC RF exposure guidelines when used
with the Beyerdynamic accessories supplied or
designated for this product. Use of other accessories may
not ensure compliance with FCC RF exposure guidelines.

Unite RP | RP-T – Bodypack Receiver
6
Thank you for choosing the Unite RP odypack
receiver.
To ensure an optimum peormance, we would like
to give you a rief introduction on how to use this
odypack receiver.
The Unite RP odypack receiver was designed for
arrier-free use:
– raised sym ols on the front operating uttons for
the lind
– Braille on the side talk ack utton for the lind
– compati le with eyerdynamic induction loops
for the hard of hearing
For detailed operating inructions in your
language, please visit:
www. eyerdynamic.com/unite
1. Safety instructions
Genera
• Please READ this user manual efore the first use.
• Please KEEP this user manual.
• Please FOLLOW the specified operating and
safety instructions.
Disc aimer
• eyerdynamic Gm H & Co. KG will not e lia le
for any damage to the product or injury to
persons caused y negligent, improper, incorrect
or inappropriate operation of the product.

eng ish
Unite RP | RP-T – Bodypack Receiver
7
Danger to ife
• The supplied strap is only used for wearing the
device around the neck. If it is not used correctly,
the risk of strangulation may occur.
Vo ume
• When using headphones/headsets, make sure
that the volume is set to minimum. Adju the
volume only aer putting on the headphones/
headset.
Too high volumes and too long liening times
can damage your hearing. Hearing damage
always represents an irreversi le impairment of
hearing.
• Always pay attention to the volume. As a rule of
thum , the higher the volume, the shoer the
liening time. By law, the maximum allowed
value is 85 dB at a maximum liening time of
8 hours.
• Temporary symptoms that you have een
exposed to loud noise are:
– ringing or whiling in the ears
– high tones can no longer e perceived
Troub eshooting / repairs
• Never open the device yourself.
• Refer all service work to authorised professionals
only.

Unite RP | RP-T – Bodypack Receiver
8
C eaning
• Only clean the device with a dry or slightly damp
cloth. Never use solvents, as these will damage
the surface.
Rechargeab e battery
• The odypack receiver is operated with the
following attery type: BAT-3707, lithium-ion, 3.7 V,
1.88 Ah, 6.96 Wh (order no. 727.679)
• Use only a USB 2.0/3.0 compliant 5V power supply
to charge the attery pack via the integrated
USB type-C port (power consumption is max.
500 mA).
• High temperatures, paicularly in association
with a high charging atus, result in irreversi le
damage of the attery pack.
• If you are not intending to use the attery for an
extended period or are planning to put it into
orage, it is advisa le to lower the attery’s
charging level to around 50% and to ore it at
temperatures of maximum 30 °C.
• In order to ensure safe transpo y land, sea
and air, the attery pack used for the odypack
receiver is teed according to the UN 38.3
transpo regulation for lithium-ion atteries.
• Misuse or improper use could damage the
attery pack. In extreme cases, there is a risk of
explosion, heat, fire, smoke or gas.
• Never expose the attery pack to excessive heat
such as sunshine, fire or the like.
• Do not expose the attery pack to mechanical
shock.

eng ish
Unite RP | RP-T – Bodypack Receiver
9
• Charge the attery pack efore initial use.
• Use the specified chargers for charging the
attery pack.
• Avoid complete draining of the attery. This
could damage the attery and shorten its
service life.
• If you do not use the receiver for several months,
the atteries should e charged at least twice a
year to prevent deterioration in performance
due to self-discharge.
• Clean the charging contacts of the receiver with
a clean dry cloth, if they ecome dirty.
• Do not short-circuit the attery.
• The charging contacts could cause property
damage, njuries or fire damage if they come into
contact with conductive materials such as
jewellery, keys or chains. This can lead to a
closed electric circuit and, therefore, to the
material overheating. To avoid this kind of
unintentional electric circuit, the charging
contacts must e handled with care. This is
especially important if the receiver is transported
in a ag or another container containing other
metallic o jects.
Moisture / heat sources
• Keep the attery pack clean and dry. Never
expose the device to rain or high humidity. Do
not install it in the immediate vicinity of
swimming pools, shower facilities, damp ase-
ments or other areas with unusually high air
humidity.

Unite RP | RP-T – Bodypack Receiver
10
• Never place o jects filled with water (e.g. vases
or drinking glasses) on the device. Liquids in the
devices may cause a short circuit.
• Never install or operate the device in the
immediate vicinity of radiators, lighting systems
or other heat-generating devices.
Disposa
At the end of its operating life this
product may not e disposed of along
with normal household waste. Please
take it to a designated recycling point for
electric and electronic appliances. This is
indicated y the sym ol on the product,
the operating instructions or
the packaging.
Simp ified EU dec aration of conformity
eyerdynamic here y declares that the wireless
transmission device complies with the EU Directive
2014/53/EU (RED). The complete text of the EU
declaration of conformity is availa le online at the
following address:
http://www. eyerdynamic.com/cod
2. Supp ied accessories
• Unite RP or RP-T odypack receiver with mounted
elt clip
• Quick Start Guide
• Neck strap
• Two spare caps for the talk ack utton

eng ish
Unite RP | RP-T – Bodypack Receiver
11














3. Operating e ements
3.1 Device
Display
The display indicates the channel name, attery
status and different menus.
On/Off and menu utton
Use the on/off utton to turn the receiver on or
off. To switch off the device, hold down the
utton for 5 seconds. In order to activate the
main menu, hold down the utton for 2 seconds.
Use the menu utton to confirm settings.

Unite RP | RP-T – Bodypack Receiver
12
Status indicator light
– during operation:
Indicator ight Operating status
Off Device is switched off
Flashing yellow
slowly
• Ready to operate and
attery status > 10 %
• Out of range from
transmitter
Yellow Only for RP-T:
Connection esta lished
and attery status > 10 %
Green • RP:
Connection esta lished
and attery status > 10 %
• RP-T:
Connection esta lished,
talk ack is running and
attery status > 10 %
Flashing red slowly Low attery level < 10 %
Red • Device is starting
• Firmware update is
running
Flashing red rapidly Critical error

eng ish
Unite RP | RP-T – Bodypack Receiver
13
– in the charger:
Multifunction utton
With this utton you can enter the channel
selection menu and select a channel. If you are
in a menu, you can scroll through the menu to
make various settings.
Volume utton
Use this utton to adjust the volume of any
connected headphone/headset/induction loop.
Use this utton to adjust the volume of any
connected headphones/headsets/induction
Indicator ight Charging status
Off Device is switched off
Flashing green
slowly
Charging 0 - 100%
Green Battery is charged
Flashing yellow
slowly
Pairing information is
eing copied from the
transmitter/charger
Yellow for
10 seconds
Device information is
copied successfully to
device
Flashes red slowly
for 10 seconds
Paring error
Flashing green/yel-
low rapidly
Device is eing localised
Flashing red rapidly Charging error

Unite RP | RP-T – Bodypack Receiver
14
loops. With “+” the volume is increased, with “-”
the volume is reduced.
Important: Please note the safety inructions
regarding the volume.
Talk ack utton (on y with RP-T)
With this utton you can ask the tour guide a
question via the integrated microphone or the
microphone of a connected headset.
Neck strap attachment
Attach the supplied neck strap y pushing the
pins at the end of the neck strap into the
fastening holes. For safety reasons, the fastening
will detach when pulled strongly.
Integrated microphone (on y with RP-T)
The integrated microphone is used for short
queries to the tour guide. Maintain a distance of
10 cm from the microphone when speaking. For a
est possi le audio transmission we recommend
using an external headset
RP: Headphone/induction loop connector
RP-T: Headphone/headset/induction loop
connector
USB port, Type C
You can use this connector to charge the inte-
grated attery pack via a USB power adapter.
Furthermore, you can connect the odypack
receiver to the USB Type C port on a Unite
charger to charge it or to pair it with other
devices.
Belt clip
The elt clip allows you to attach the device to
clothing such as a waist and or elt.

eng ish
Unite RP | RP-T – Bodypack Receiver
15
Charging contacts
The uilt-in attery is charged via the charging
contacts when the device is inserted into the
charger. Make sure to insert the device fully into
the charging slot of a Unite charger so that the
charging contacts have proper contact.
Type la el
The type la el provides information a out the
name, article num er, certification num ers,
hardware version, serial num er and production
date.
3.2 Disp ay
The main screen ( elow) is displayed when the
odypack receiver is switched on and ready for
operation.
Display of all active speakers (Master, 1st slave, 2nd
slave)
Display of current type of speaker (the ar
indicates 1st slave or 2nd slave)
Current channel name
RP-T on y:
Headset connected
Talk ack function activated
Display of remaining attery capacity



 

Unite RP | RP-T – Bodypack Receiver
16
4. Genera operation
•Important: Before using the odypack receiver
for the first time, you must charge the uilt-in
attery. Please use an appropriate Unite
charger.
• Connect a headphone or induction loop to jack
socket .
With the RP-T variant you can also connect a
headset instead of headphones.
• Hold down the on/off utton  to switch on the
receiver.
• Use the volume utton  to adjust the volume of
the headphone/headset/induction loop.
• All devices are supplied with the group ID 256
and fixed audio encryption allowing quick and
easy initial use.
• If you require several device groups or an audio
transmission even more secure against
unauthorised listening and to avoid listening y
other Unite users using Unite devices, follow the
steps in chapter 5 of the Unite TP odypack
transmitter quick start guide to create a new
pairing.
The transmitter and receiver can only
communicate if the settings mentioned in this
chapter match. Transmitters cannot
communicate with receivers that do not have
the same pairing information. This is shown in the
following diagram:

eng ish
Unite RP | RP-T – Bodypack Receiver
17
4.1 How to se ect an audio channe
• If there are several transmitters in one group you
can select the channel of the appropriate
transmitter on the receiver. Use the multifunction
utton on the receiver to select the desired
channel and confirm your selection y riefly
pressing the menu utton .
TP
Group ID 256
Name 1
A
Group ID 256
Name 1
A
Group ID 1
Name 2
TP
TP
B

Unite RP | RP-T – Bodypack Receiver
18
5. Technica specifications
DECT RF frequency range . . . . . 1880 - 1930 MHz,
depending on the country
DECT transmission power. . . . . . up to 250 mW (peak),
depending on the country
DECT operating range . . . . . . . . . up to 300 m outside
(line of sight);
the actual operating
range depends upon the
RF output settings, the
surroundings, the signal
a sorption, signal
reflection and signal
interference
Audio andwidth
Low quality (SD) . . . . . . . . . . . . . . 200 Hz - 7 kHz (-3 dB)
High quality (HD) . . . . . . . . . . . . . 100 Hz - 14 kHz (-3 dB)
Operating mode. . . . . . . . . . . . . . . Broadcast and/or
full-duplex on all routes
Encryption . . . . . . . . . . . . . . . . . . . . . AES-256 it encryption
Headphone/headset/
induction loop connector . . . . . 4-pin mini jack, 3.5 mm,
CTIA Standard
Integrated microphone. . . . . . . . yes
Display . . . . . . . . . . . . . . . . . . . . . . . . monochrome white OLED
display with high contrast
Max. num er of
open microphones . . . . . . . . . . . . 3 (individual level control
for each microphone)
Battery . . . . . . . . . . . . . . . . . . . . . . . . lithium-ion attery pack,
replacea le y service
staff only

eng ish
Unite RP | RP-T – Bodypack Receiver
19
Battery monitoring . . . . . . . . . . . . Battery status of
remaining capacity via
OLED display
Operating time
of attery pack. . . . . . . . . . . . . . . . > 15 hrs., typ.
Side-tone and
microphone gain . . . . . . . . . . . . . . individually adjusta le
USB Type C connector . . . . . . . . . USB 2.0/3.0 standard,
compati le to 5 V power
supplies only,
power consumption
max. 500 mA
Strap anchor points . . . . . . . . . . . availa le, neck strap
remova le
Dimensions (W x H x D) . . . . . . . . . 58 x 102 x 15.5 mm
Weight (incl. attery) . . . . . . . . . . 105 g
Temperature range
Operation. . . . . . . . . . . . . . . . . . . . -10 to +40 °C
Storage . . . . . . . . . . . . . . . . . . . . . . -20 to +70 °C
Relative humidity . . . . . . . . . . . . . . 0 to 90%
6. Service
When servicing is required, please contact an authorised
professional or directly:
eyerdynamic Service- and Logistik Center
E-mail: service@ eyerdynamic.de
Never open the device yourself, as this will invalidate all
warranty claims.

Unite RP | RP-T – Taschenempfänger
20
Vielen Dank für Ihr Verauen und dass Sie sich für den
Kauf des Taschenempfängers Unite RP entschieden
ha en.
Für ein emögliches Erge nis möchten wir Ihnen eine
kurze Einführung ge en, wie Sie den Taschenempfänger
verwenden können.
Der Taschenempfänger Unite RP wurde für eine
arrierefreie Benutzung konzipie:
– erha ene Sym ole auf den vorderen Bedientaen für
Blinde
– Brailleschri auf der seitlichen Talk ack-Tae für
Blinde
– Unterützung von eyerdynamic Induktionsschleifen
für Schwerhörige
Eine ausführliche Bedienungsanleitung in Ihrer Sprache
finden Sie unter www. eyerdynamic.com/unite
1. Sicherheitsinformationen
A gemein
• LESEN Sie die Bedienungsanleitung vor der ersten In e-
trie nahme.
• BEWAHREN Sie diese Bedienungsanleitung auf.
• BEFOLGEN Sie die aufgeführten Bedienungs- und
Sicherheitshinweise.
Haftungsaussch uss
• Die Firma eyerdynamic Gm H & Co. KG ü ernimmt
keine Haftung für Schäden am Produkt oder Verletzun-
gen von Personen aufgrund unachtsamer, unsachge-
