Beyond Square 153754 User manual

USE AND CARE GUIDE
12 INCHES SQUARE PANEL DOWNLIGHT
Beyond LED Technology | Stone Mountain, GA, [phone] | www.beyondledtechnology.com,

2 www.beyondledtechnology.com
Table of Contents
Table of Contents................................... 2
Safety Information.................................. 2
Warranty.......................................... 2
Installation ...................................... 3-4
Safety Information
For your safety, always remember to:
□Turn o the power supply at the fuse or circuit breaker box
□
reliable starting.
□Double-check all connections to be sure they are
tight and correct.
□Wear rubber soled shoes and work on a sturdy
wooden ladder.
□Account for small parts and destroy packing material, as these
may be hazardous to children.
circuit breaker. It is also designed to be installed in accordance with
local electrical codes. If you are unsure about your wiring, consult a
electrical code.
WARNING: RISK OFSHOCK. House electric current can
causepainful shock or serious injury unless handled properly.
CAUTION: Turn o themain power at the circuitbreaker
NOTICE: All electrical connections must be in accordance with local
and National Electrical Code (N.E.C.) standards. If you are unfamiliar
with proper electrical wiring connections obtain the services of a
sure that no parts are missing by referencing the illustrations on the
installation instructions.
Warranty
This product is warranted to be free from defects in workmanship and materials for up to 5 years from date of purchase. If it fails to do so,
please contact Beyondledtechnology at [email protected] or call 1(866) 786-1117 for instructions on replacement.
Do not return the product to the store.
circuits. Suitable for damp locations. Before installing
-
-
trical wiring experience, please refer to a do-it-your -
-
tions must be in accordance with Local and National
Electrical Code (NEC) Standards. Reliable operating
level dimming, increase light level. Compatible with
most dimmers including Leviton 6681-IW, Lutron
S-600P and Lutron DVCL-153. Dimmable to 10% with
most dimmers.
FCC STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation. Note: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on,
the user is encouraged to try to correct the interference by one or more of
the following measures: Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver. Connect the
equipment into an outlet on a circuit dierent from that to which the
receiver is connected. Consult the dealer or an experienced radio/ TV
technician for help.

3 www.beyondledtechnology.com
5”-6” In. Recessed Can Installation
1Turning O the Power
□Turn the power OFF at the switch and
fusebox or the circuit breaker.
□Remove the existing trim installed in the
recessed housing.
□Fix bracket & E26 base to the light as per
diagram
□Connect the two terminals together (See Fig. 2).
3 Connecting the terminals
Connect the orangeconnectors
Fig. 3
Fig. 1
□Install the E26 adapter (DD) into the socket (See Fig. 1).
2 Installing the adapter
Fig. 2
Fig. 5
5□Gently push the cture in to the recessed housing (See Fig. 4)
□
□
4Adjusting the torsion springs
5”
6”
Move the torsion spring from the6 in.
position to the 5 in. position
FF
Fig. 4
When installing trim into a 5 in. recessed housing, the
torsion spring (FF) must be moved. Unscrew the torsion
spring (FF) from the 6 in. position and move it to the 5 in.
position (See Fig. 3).

□Fix bracket on terminal box.
4 www.beyondledtechnology.com
J-Box Installation
1 Turning O the Power
□Turn the power OFF at the switch and fusebox or the circuit
breaker.
□Remove the existing trim installed in the recessed housing.
3
□Secure the xture to the mounting
bracket by pressing the xture into the
mounting bracket until the clips on the
xture engage together. Make sure the
xture is rmly locked into place.
□Fixing bracket on terminal box
2 Identifying the wires & Installing the
mounting bracket
□Identify the wiring: (black - line voltage, white - neutral
and green - ground)
□Use the wire nuts (JJ) to connect the stripped wires with
male connector (EE) to the two wires coming from the
J-box (black - line voltage, white - neutral).
□Determine if the ground wire is inside the J-box. If
not, then secure the ground wire (FF) provided to the
mounting bracket (BB)
EE
BB
JJ
FF
