bf1 systems 1SYSTEM TPMS User manual

bf1systems 1SYSTEM TPMS
bf1systems 1SYSTEM TPMS User Manual V1_00
Page 1of 7
RD096110124
bf1systems 1SYSTEM TPMS User Guide
1 Modifications
Date
Modifications
Author
Version
Modified
Sheets
Approved
By
Date
Signed
05/02/2021
New Document
WL
1_00
2 Tableof Contents
1Modifications..........................................................................................................................................................................1
2Table of Contents..................................................................................................................................................................1
3System Contents...................................................................................................................................................................2
4Features and User Manual...................................................................................................................................................2
5Warranty ................................................................................................................................................................................2
6Technical Specification .........................................................................................................................................................2
7Installation..............................................................................................................................................................................3
8Regulatory Information..........................................................................................................................................................4

bf1systems 1SYSTEM TPMS
bf1systems 1SYSTEM TPMS User Manual V1_00
Page 2of 7
RD096110124
3 SystemContents
The TPMS system consists of four ECU’s (withintegrated Antenna), oneof whichis mounted in each wheel arch, the wheel
sensors are mounted into the wheel. Wheel sensor data is communicated via the ECU over the vehicles’ CAN bus.
A full vehicle system includes;
•4x 1SYSTEM Wheel Sensors
•4x 1SYSTEM ECU Antennas
Please note.
•Tyrevalves are sold and availabletopurchaseseparately and are not included as part of the wheel
sensorsupplied.
Supporting documentation;
•CAN Protocol, Pinout and dbc file
4 Featuresand UserManual
The features and the content of the user manual may change, please contact bf1systems for the latest version.
5 Warranty
Pleaserefer to the terms and conditions ofsale.
6 Technical Specification*
ECU:
Supply: 6.5 –18 VDC (limited to Maximum 3A)
Transmission Power: 1mW
Frequency: 2.4GHz –2.48GHz
Operating Temperature: 0°C to 105°C
Ingress Protection: IP6K7
Sensor:
Supply: Built-in battery 3V coin cell
Transmission Power: 1mW
Frequency: 2.4GHz –2.48GHz
Operating Temperature: 15°C to 125°C
*Please refer to the product datasheet for further details.

bf1systems 1SYSTEM TPMS
bf1systems 1SYSTEM TPMS User Manual V1_00
Page 3of 7
RD096110124
7 Installation
The system components should be securely fastened in place, see below;
ECU:
Fastener: M6 Cap Head with plain washer
Torque: 5Nm Max
Sensor*:
Fastener: Valve kit
Torque: 4.5Nm Max
*Please refer to the product installation guide for further details.

bf1systems 1SYSTEM TPMS
bf1systems 1SYSTEM TPMS User Manual V1_00
Page 4of 7
RD096110124
8 RegulatoryInformation
Europe
- DECLARATION OF CONFORMITY
The 1SYSTEM TPMS complies with current European directives.
The declarations of conformity of the various parts of the kit can be found and the end of this document.
USA
- STATEMENT
The device complies with Part 15 of the rules. Operation is subject to the following two conditions;
(1) It must not cause interference and
(2) The device must accept any radio-electric interference suffered, even if the interference is likely to compromise its
use.
- CAUTIONS
Modifications not authorised by the manufacturer may void the user’s authority to operate these devices.
- RF EXPOSURE STATEMENT
This equipment complies with the RF radiation exposure limits sets forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20cm between the radiator and any part of
your body.
Australia
- DECLARATION OF CONFORMITY

bf1systems 1SYSTEM TPMS
bf1systems 1SYSTEM TPMS User Manual V1_00
Page 5of 7
RD096110124
Europe

bf1systems 1SYSTEM TPMS
bf1systems 1SYSTEM TPMS User Manual V1_00
Page 6of 7
RD096110124
Europe

bf1systems 1SYSTEM TPMS
bf1systems 1SYSTEM TPMS User Manual V1_00
Page 7of 7
RD096110124
Australia
