BGS 9027
Tire Cart, 200 kg
INTENDED USE
This tire cart can be used to transport four tires or four combinations of tires and rims, taking into
account the maximum permissible load. Use this tire cart only for the stated purpose. Any other use
can lead to damage, injuries and void the warranty.
SAFETY INFORMATION
•Do not use the device if parts are broken, bent, cracked or otherwise damaged.
•If the device is damaged in any way or does not function properly, it must no longer be used
and must be removed from the work area.
•If the device has been subjected to a shock load, it may only be used again after being
checked by an authorized person. An annual inspection by a qualified person is recommended.
•Use this device only for the work specified in the “Purpose” chapter.
•Make sure that the max. Load capacity (including the wheels to be transported) is not
exceeded. The max. Load capacity is listed in the “Specifications” chapter.
•Be careful with uneven ground, there is a risk of tipping over!
•The device can tip over if not all wheels of the device are in contact with the ground during
loading.
•Move the product carefully, especially if there are wheels on it.
•Check the product for damage before using it. A damaged device must not be used.
•Do not stand on the device and do not transport people or animals on it.
•Do not let children play with the device and its packaging. Keep children away from the device!
This device is not suitable for use by children.
SPECIFICATIONS
Load capacity: max. 200 kg
Total width: 610 mm
Total height: 1385 mm
Total depth: 695 mm
Weight: 20.5 kg
For other dimensions see chapter “Dimensions” below
IMPORTANT
Read the operating instructions and all safety instructions contained
therein carefully before using the product. Use the product correctly,
with care and only according to the intended purpose. Non-
compliance of the safety instructions may lead to damage, personal
injury and to termination of the warranty. Keep these operating
instructions in a safe and dry location for future reference. Enclose
the operating instructions with the product when handing over to third
parties.

BGS technic KG
Bandwirkerstr. 3
D-42929 Wermelskirchen
Tel.: [phone]
Fax.: [phone]
[e-mail]
www.bgstechnic.com
© BGS technic KG, Copying and further use not allowed
DIMENSIONS
A
: Clamp arm opening
Min.:
440 ±10 mm
Max.: 7
30 +20/-10 mm
B
: Clamp arm diameter
Min.: 560
±10 mm
Max.: 750 +20/
-10 mm
SCOPE OF DELIVERY
No. Descriptions Qty
1
1 Main Frame
2 Left Clamp Arm 1
3 Right Clamp Arm 1
4 Axle 1
6 Spring Ø10x1.6 2
7 Spacer 6
9 Hex Bolt M8x1.25x25 6
10 Flat Washer 10.5x20x2.0 12
11 Hex Nut M8x1.25 6
12 Nylon Plug M8x1.25x15 2
MOUNTING
Mount axle/wheel assembly and hook it with spring to frame (fig.1+2).
Assemble the left and right clamp arms (fig.3+4).
MAINTENANCE / SERVICING
•Lubricate the joints and guides of levers, axles and wheels with oil at least twice a year.
•Clean the product with a soft cloth and for example washing-up liquid when required; aggressive
cleaning agents can damage the surfaces.
