ILS
User Manual
Electric Heang Element
Gebrauchsanweisung — Elektroheizpatrone | Manual de usuario — Elemento calefactor
eléctrico |Mode d’emploi — Kit résistance électrique | Upute za upotrebu — Električni
grijač | Manuale d'uso — Elemento Elerico Riscaldante | Инструкция по применению
— Электронагреватель | NAVODILA ZA UPORABO — Električni grelec | Uputstva za
upotrebu — Električni grejač

3
EN
Electric radiator
Guide to safe installaon
and use.
1. Do not install the heater under an electrical socket point.
2. Your electric heater should be lled with a carefully
measured amount of liquid. In the case of loss of heat-
ing medium, or in any other case which demands its
supplementaon, contact your supplier.
3. The device is not equipped with an external tempera-
ture controller. Do not use the device in a small room
if unsupervised disabled or incapacitated individuals
are inside it. Only use the device if those individuals
are under constant supervision.
4. Electric heater is not a toy. Children under the age
of 3 should not be allowed within close proximity
of the device without the supervision of an adult.
Children aged 3 to 8 should only be allowed to oper-
ate the heater when it has been properly installed and

4
connected. The child must be under adult supervi-
sion or have been trained to safely operate the device
while understanding the risks.
5. Note: Some parts of the radiator can be very hot and
can cause burns. Pay special aenon to the presence
of children or people with disabilies.
6. If the device is used as a clothes and towel dryer, ensure
that the fabrics drying on it have only been washed in
water, avoiding contact with any harsh chemicals.
7. To ensure the safety of very small children, install
the electric dryer so that the lowest tube is at least
600 mm above the oor.
8. The device should only be installed by a qualied in-
staller in accordance with the applicable regulaons
regarding safety and all other regulaons.
9. All installaons to which the device is connected
should comply with regulaons applicable in the coun-
try of installaon and use.
10. Extension leads or electric plug adapters should not
be used in order to supply power to the heater.
11. The electric installaon to which the heater is perma-

5
EN
nently connected must have the right current dier-
enal and overcurrent relay (R.C.D.) of 30 mA.
An Omni-pole cut-out is required for disconnecng
the device on all poles, via joints posioned at least
3 mm apart.
12. The device equipped with a supplying cable without
plug can be installed in bathrooms in zone 1, as de-
ned by applicable law, subject to any addional regu-
laons concerning electrical installaons in wet areas.
Other versions of the device can be installed in Zone 2
or beyond.
13. The device is recommended for use solely as de-
scribed in the manual.
14. Ensure that the heater has been installed on a wall in
accordance with its installaon manual.
15. Please forward this instrucon manual to the end
user.

6
Zone 1
Zone 2

7
EN
Electric Heang
Element
Safety requirements
— installaon
1. Fing and connecon of the heang element should
only be performed by a qualied installer.
2. Connect the unit to a sound electrical installaon (see
the rangs on the heater).
3. Ensure that the power cord does not touch the hot
parts of the heang element or radiator.
4. Before installing or removing the device, make sure it
is disconnected from the power source.
5. Do not open the device — any interference with inter-
nal components will invalidate the warranty.
6. The heang element’s power output must not ex-
ceed the radiators power output for the parameters
75/65/20° C.

8
7. The pressure in the radiator should not exceed 10
atm. Make sure an air cushion is preserved in electric
radiators, in central heang systems leave one valve
open to prevent pressure build up due to the thermal
expansion of the liquid.
8. The device is intended for home use only.
9. Fing and Installaon of the device must be carried
out in accordance with all local regulaons for electri-
cal safety, including installaon in a permissible loca-
on only, maintaining bathroom electrical zones.

9
EN
Safety requirements — use
1. The heang element must be fully submerged in the
liquid during its operaon.
2. Regularly check the device for damage to ensure it is
safe to use.
3. If the power cord is damaged the device should not be
used. Unplug the device and contact the manufactur-
er or distributor.
4. Do not allow ooding into the heang element casing.
5. The heang element and radiator can heat up to high
temperatures. Please be cauous — avoid direct con-
tact with hot parts of equipment.
6. Do not open the heang element casing.
7. In the central heang system, always make sure that
one valve of the radiator remains open.
8. Ensure that minors under 8 years of age or those with
a physical or mental disability are supervised if operat-
ing the device.

10
9. The device is not a toy. Keep it out of the reach of
children.
10. The device must be disconnected from the mains dur-
ing cleaning and maintenance.
11. Cleaning equipment by children under 8 years of age
is only permied under appropriate supervision.

11
EN
Detailed informaon about the dierent
ways of installing or removing the radia-
tor heang element are available from the
manufacturer or importer (see footnotes at
the end of the manual). Below we list some
basic requirements and principles which
must be followed to ensure long term re-
liable operaon.
To ensure safe operaon, the power rat-
ing of the heang element should always
be lower than that of the radiator for
75/65/20° C parameters. We recommend-
ed to select heang element with the pow-
er output around 80% to a maximum of
100% of the radiator output the heang el-
ement is to be installed in.
Before installaon or rst use:
1. Read the chapter Safety requirements
—Installaon.
2. Fit the heang element using the cor-
rect spanner (size 22).
3. The heang element must be installed
at the boom of the radiator, perpen-
dicular to the radiator pipes, preserving
space for proper circulaon of the heat-
ing medium.
4. Use a suitable heang medium for ll-
ing the electric radiator (water, special
products based on water and glycol for
use in central heating, oil complying
with the requirements of the manufac-
turer of radiator and heang element).
Installaon or removal

12
5. Do not switch the heang element on if
it is not fully immersed in radiator heat-
ing medium.
6. Make sure an adequate air cushion is
present to protect against excessive pres-
sure build up in the heater (in dual-fuel
radiator always leave one of the valves
open).
7. Follow the subsequent guidelines when
connecng the electrical installaon:
a. Brown wire — live connecon to the
circuit (L).
b. Blue wire — connect to neutral (N)
8. Before lling the radiator with heang
medium, make sure that heang ele-
ment is fitted properly to guarantee
that it is water ght.
Notes prior to removal:
1. Before dismantling permanently discon-
nect the heang element from the mains
ensure that the radiator is not hot.
2. Be aware. A radiator lled with liquid can
be very heavy. When moving the radia-
tor, ensure that you take the necessary
safety precauons.
3. Before disassembly, close the appropriate
valves and drain the radiator to avoid any
damage being caused by water remain-
ing inside the radiator (close the appro-
priate valves, drain the radiator, etc.)
Product disposal
This product should not be disposed of
as general waste but should be brought
to the appropriate collecon point for re-
cycling of electric and electronic devices.
This informaon is provided by the sign on
the product, user manual and packaging.
Informaon on the appropriate point for
used devices can be provided by Your local
distributor or manufacturer of the product.
Thank You for Your eort towards environ-
ment protecon.
Maintenance
• Before performing maintenance, always
unplug the unit from the mains system.
• Periodically check the uid level in the
radiator and ensure the heating ele-
ment is completely submerged.
• Clean the product with a dry or damp
cloth. If necessary, use a very small
amount of detergent, ensuring that it
contains no solvents or abrasives.

13
EN
Manual
Specicaon
Power: 230 V / 50 Hz
Class of protecon: II
Ingress protecon: IP x5
Type of heang element: PTC
Connecon type: — Straight cable with plug — PW — type Y
— Spiral cable with plug — SW — type Y
— Straight cable without plug* — PB — type Y
Radiator tapping: thread G 1/2"
The maximum pressure al-
lowed in the radiator:
1.0 MPa
Rated power: 100 200 300 400 500 600 800 1000 1200 W
Length of el. heang element: 165 220 260 350 350 465 600 670 810 mm
* Device intended to be connected permanently to the system (it must be possible to
disconnect the device on both polarity points (an air gap of a min. 3 mm)
Purpose
The heang element is an electric device
intended solely for installaon in radiators
(standalone or connected to the central
heang system) to serve as space heaters,
or clothes and towels dryer.

14
Operaon
2h dryer mode
Power on/o
Heang power regulaon
Pressing the buon switches on the de-
vice, aer which, the element will begin to
heat. By turning itself on and o regularly,
the device regulates the heang output of
the radiator to an average output, as set by
the user within 30-100% of nominal heang
output of the device.
The design of the device (PTC heang el-
ement) protects the user from harm via
burning, by automacally liming radiator
temperature to 60° C, regardless of the cur-
rent seng (provided that the heat output
of the element has been correctly matched
with the heat output of the radiator).
The design of the device as well as physical
characteriscs of heang medium inside
the radiator inuence the way in which heat
is distributed throughout radiator — tem-
perature of the pipes at the boom of the
radiator (especially the two located at the
very boom of it), may be lower than the
temperature of the remaining parts of the
radiator — this is a normal phenomenon.
Seng of required heang output:
In order to obtain the required room tem-
perature, please set the right heang level
of the device (buons / ). It is possible to
set 1 of 5 heang levels: 30-40-60-80-100%
of the nominal heang output.
Selecon of every subsequent level is indi-
cated by switching on subsequent diodes.
TIMER Funcon
TIMER function allows programming of
the device to heat for 2 hours with a dif-
ferent heat output, for instance in order to
dry a towel. Aer this period of me the
device automacally returns to the seng
from before the 2-hour dryer acvaon.
TIMER is turned on by pressing the but-
ton (also when the device is o). The de-
vice will start working with the heat output

15
EN
currently set. Sengs can be modied as
required while the device is working (but-
tons and ).
If the device was o before the mer mode
was acvated, it will turn o automacally
on terminaon of t he mer.
If the device was set to i.e. seng 2 before
the mer mode was acvated, and is then
modied to i.e. seng 4, the device will re-
turn to seng 2 aer 2 hours.
Aenon: if the device is on and sengs
are not modied on acvaon of TIMER,
sengs will not change aer 2 hours. It will
sll operate on the same seng.
Press button at any time to stop the
TIMER mode. Turning the device o and
back on with the buon will also deac-
vate the funcon.
ANTI-FREEZE FUNCTION
(An-freeze protecon)
When the device is o and the tempera-
ture around temperature sensor drops to
below 6° C, the device will switch on au-
tomacally. This is to prevent the heang
medium inside the radiator from freezing.
Acvang An-freeze mode is indicated by
ashing of the centre diode.
TROUBLESHOOTING
Problem Possible cause Problem soluon
Device is connected to
electricity, no diodes are
on
Connecon problem
Check the mains connec-
on, check if the power
supply is correct
Device heats despite hav-
ing been turned o with
{on/o} buon
Electronics problem
Disconnect the device
completely from electricity
and wait unl the radiator
cools down. Turn the de-
vice back on
If the problem persists, please contact your local distributor.

16
Warranty terms & condions
1. The subject of this warranty is
a BIAL d.o.o. electric heang element
with control head. The product name
and characteriscs are specied on the
packaging.
2. By accepng the device on purchase,
the Client conrms that the product is
of full value. The Client should imme-
diately inform the Seller of any discov-
ered faults — otherwise it will be un-
derstood that the Product was faultless
at the me of purchase. This refers es-
pecially to any faults or damages of the
control panel case.
3. The Warranty for period for the Product
is 24 months from the date of purchase,
but no longer than 36 months from the
date of producon.
4. Any claims made will be processed on
producon of the warranty card and the
evidence of purchase. The manufactur-
er has the right to reject any claim on the
grounds of failure to present any of the
above documents.
5. This warranty does not cover any faults
that are due to:
— incorrect (not in accordance with
the manual) installation, use or
disassembly,
— incorrect use of the heating ele-
ment (i.e. for any purpose that is not
specied by the Manufacturer as in-
tended for this type of product),
— Product being handled by unauthor-
ized persons,
— Fault’s or damages caused by the
Client aer having purchased and
accepted the Product.
6. The Central Heang system should be
ed with lock-shield valves, enabling
disassembly of the radiator or the heat-
ing element and its control head with-
out the necessity of emptying the
whole system of the heang agent. Any
problems or expenses arising from the
absence of lock-shield valves in your in-
stallaon cannot be used as grounds for
any claims against BIAL.
7. The aached Product Manual is an in-
tegral element of the Warranty. Please
read it carefully prior to the installaon
and use of the Product.
8. The Manufacturer is obliged to remove
any producon fault within 14 working
days of receipt of the faulty device at the
Manufacturer’s premises.
9. Should the repair be impossible, then
the manufacturer is obliged to replace
the faulty Product with a new, full-value
unit of idencal parameters.

17
DE
Elektroheizkörper
Sichere Montage und Verwen-
dung
1. Der Heizkörper darf nicht direkt unterhalb oder über
die Steckdose monert werden.
2. Der Heizkörper muss mit einer genau abgemessenen
Menge Flüssigkeit befüllt werden (siehe Kapitel „Mon-
tage und Demontage“). Bei Leckage oder zu niedri-
gem Stand des Heizmediums im Heizkörper setzen Sie
sich bie mit Ihrem Händler in Verbindung.
3. Dieses Gerät ist nicht mit Raumtemperaturregler aus-
gestaet. Daher ist die Benutzung in kleinen Räumen,
in denen sich Menschen mit eingeschränkter Fähigkeit
zum selbständigen Verlassen des Raumes benden,
nicht zulässig. (Ausnahme: Ständige Aufsicht durch ei-
nen Erwachsenen).
4. Der Elektroheizkörper ist kein Spielzeug. Kinder unter
3 Jahren sollten sich nicht in der Nähe des Heizkörpers
aualten. Kinder im Alter von 3 bis 8 Jahren dürfen

18
den Heizkörper nur unter Aufsicht von Erwachsenen
selbständig bedienen oder nach einer Einweisung über
den sicheren Gebrauch sowie alle damit verbundenen
Gefahren. Dies gilt jedoch nur, wenn das Gerät vorher
fachgerecht installiert und angeschlossen wurde.
5. Achtung: Einige Heizkörperelemente können relav
heiß werden. Bie beachten Sie dies besonders bei der
Anwesenheit von Kindern oder behinderten Menschen.
6. Wenn das Gerät als Wäsche — oder Handtuchtrock-
ner eingesetzt wird, verwenden Sie nur Stoe die zu-
vor ausschließlich in Wasser gereinigt wurden.
7. Aus Sicherheitsgründen (Rücksicht auf Kleinkinder)
sollte das unterste Rohr des Wäsche- oder Handtucht-
rockners mindestens 60 cm über dem Boden sein.
8. Das Gerät sollte nur durch einen qualizierten Fach-
mann installiert werden, unter Beachtung aller gül-
gen Sicherheitsnormen und Vorschrien.
9. Alle Anlagen an denen das Gerät angeschlossen wird
muss den aktuell gülgen Normen und Vorschrien
des Landes entsprechen.
10. Zum Anschluss der Heizpatrone dürfen keine Verlän-
gerungskabel oder Adapter verwendet werden.

19
DE
11. Stellen Sie sicher, dass der Stromkreis der elektrischen
Anlage, an der die Heizpatrone angeschlossen werden
soll, über einen passenden Überspannungsschutz-
schalter und eine Fehlerstromschutzeinrichtung (RCD)
mit einer Empndlichkeit von 30 mA verfügt.
Obligatorisch ist ebenso ein Schalter, der die Trennung
des Gerätes auf allen Polen mit Kontakten um je 3 mm
ermöglicht.
12. Die mit dem Symbol PB markierte Geräteversion kann
im Badezimmer in der durch die angemessenen Vor-
schrien denierten Zone 1 installiert werden, jedoch
unter einhalten der gesonderten Vorschrien über
elektrische Anlagen im Nassbereich.
Alle anderen Geräteversionen können in Zone 2 oder
außerhalb installiert werden.
13. Verwenden Sie das Gerät zweckgemäß und überein-
smmend mit der Betriebsanleitung.
14. Versichern Sie sich, ob der Heizkörper gemäß Betriebs-
anleitung richg auf der Wand monert wurde.
15. Bie leiten Sie dieses Informaonsmaterial an den
Endbenutzer weiter.

20
Zone 1
Zone 2
