PRODUCT DESCRIPTION
The Apprimo Touch 8i is an 8" control panel for any room
that requires a more complex level of control, while still
being a stylish and discreet interface that fits in any type of
interior design.
Apprimo
Touch 8i Control Panel
Installation and Operation Guide
Table Mount Wall Mount (accessory)
CONTENTS
Touch 8 control panel with attached Table Mount
FEATURES
• 8" capacitive touch LCD interface
• Scratch-resistant glass
• Display brightness can adjust automatically to the
ambient light level
• Customizable user interface to fit customers’ control
requirements and corporate identity
• PoE powered (IEEE 802.3at Class 3, 15W) for simple,
single CAT5e/CAT6 cable installation
Apprimo Touch 8i
(with table mount attached)
Reset Pin
3 m (10 ft) Cat5 cable
Reset Pin Cat5 Cable

page 2 Installation and Operation Guide Apprimo Touch 8
3
PRODUCT INSTALLATION
Table Installation
1. Remove cover from the bottom of the table mount.
2. Insert network cable into port on the back of the
control panel.
3. Reattach the cover routing the cable through the
notch in the latch and stand.
4. Follow on-screen prompts to complete the installation.
21
4
5

Apprimo Touch 8 Installation and Operation Guide page 3
Wall Mount Installation
The control panel can be mounted to the wall with or
without a gang box. Most gang box styles are supported.
1. The center of the control panel would typically be
located between 102 – 165 cm (40" – 65") above the
nished oor. Route Cat 5e/6 cable to the location.
There is a channel on the base plate and a knockout
on the angled plate for cable routing if installing on a
solid wall.
Note: Follow local guidelines for accessible wall controls.
Installations complying with US ADA guidelines the top of
the panel should not exceed 122 cm (48") from the oor.
Remove table mount from the control panel
2. Remove cover from the rear of the table mount.
3. Remove screw holding table mount to control panel.
4. Remove mount by sliding it down and then lifting up.
ACCESSORIES (OPTIONAL)
165 cm
(65")
122 cm
(48")
102 cm
(40")
2 3
4
1

page 4 Installation and Operation Guide Apprimo Touch 8
5 5
6 6
7 7
Wall Mount Installation (continued)
Install wall plate
5. Attach wall plate directly to the wall with screw anchors
or screw it to a gang box (most gang box styles are
supported). Orient the plate with the arrows pointing up.
ACCESSORIES (OPTIONAL)
Both Flat and Angle wall mounting options are shown below. The Angle Mount
has a notch to route the cable through if mounted on a solid wall.
6. Attach wall mount base to control panel - t clips in control panel back (a),
and slide up (b).
7. Secure base with a screw.
abab
Flat Wall Mount
(Apprimo Touch 8-WMF)
Angled Wall Mount
(Apprimo Touch 8-WMA)
70 mm
(2.75")
140 mm
(5.5")

Apprimo Touch 8 Installation and Operation Guide page 5
Wall Mount Installation (continued)
8. Insert network cable into port on the back of the control
panel.
9. Mount the panel on the wall plate by hanging it on the
top tabs then rotating in and clipping into the bottom tab.
Ensure the tab is fully engaged (see circled views).
8
9
ACCESSORIES (OPTIONAL)
Center tab latched
Center tab latched
Flat Wall Mount
8
9
Angled Wall Mount

A: 9300 S.W. Gemini Drive Beaverton, OR 97008 USA W: www.biamp.com
30AUG2022
CONTACT US
Email: [email protected]
Web: support.biamp.com
Warranty: biamp.com/legal/warranty-information
Safety & Compliance: biamp.com/compliance
OPERATION
A simple touch will wake up the control panel. It provides a
method of interacting with or controlling the room system.
The interface and on-screen prompts make use of the
control panel simple.
Note: Additional options can be enabled upon setup, including
user proximity to "wake up" the panel.
Maintenance
Cleaning: Use a soft cloth (microfiber recommended)
to clean the glass and cabinet. Do not use abrasives or
solvent-based cleaning products. If necessary, use a
specially formulated screen cleaner on a soft cloth to wipe
any smears off the control panel. Wipe with a dry cloth to
remove any residual moisture.
Settings: Insert reset pin into the designated hole in the
top of the control panel rear. A simple press will bring up
the device settings screen.
Note: Inserting the pin in the other hole will initiate a device
reboot.
Device Reboot Settings
