Citrus Press KH 25
Operating Instructions
IB_KH25_E6575_EN.qxd 02.08.2007 9:37 Uhr Seite 2

IB_KH25_E6575_EN.qxd 02.08.2007 9:37 Uhr Seite 3

q
y
r
e
w
t
i
o
u
a
s
IB_KH25_E6575_EN.qxd 02.08.2007 9:38 Uhr Seite 4

- 3 - 
Index Page
Intended use 4
Technical Data 4
Items supplied 4
Important safety instructions 4
Appliance description 5
Set-up and assembly of the appliance 5
Juice extraction 6
Emptying 6
Disassembly 6
Cleaning and Care 7
Storage 7
Disposal 7
Warranty & Service 7
Importer 7
Read the operating instructions carefully before using the appliance for the first time
and preserve this booklet for later reference. Pass the manual on to whoever might
acquire the appliance at a later date.
IB_KH25_E6575_EN.qxd 02.08.2007 9:38 Uhr Seite 3

- 4 -

Citrus Press KH 25
Intended use
The appliance is intended for the extrac-
tion of juices from citrus fruits such as
oranges and lemons. Only foodstuffs
may be processed with the appliance.
All other usages or modifications are
regarded as contrary to the operating
instructions and contain a great risk of
accidents.
The manufacturer accepts no liability
for damage(s) resulting from usage that
is contrary to these instructions.
Not for commercial use.
Technical Data
Mains voltage: 220-240 V~ 50 Hz
Rated output: 25 W
Items supplied
Citrus Press
Large squeezing cone
Small squeezing cone
Fruit pulp sieve (2 parts)
Operating instructions
Warranty card
Important safety instructions
To avoid potentially fatal electric shocks:
• The rating of the local power supply
must tally completely with the details
given on the rating plate of the appli-
ance.
• Arrange for defective power plugs
and/or cables to be replaced at once
by qualified technicians or our Customer
Service Department.
• Arrange for damaged or malfunctio-
ning appliances to be inspected and/or
repaired by a qualified specialist or
the Customer Service Department as
soon as possible.
• Do not expose the appliance to rain
and never use it in a humid or wet
environment. Ensure that the power
cable never becomes moist or wet
during operation.
To avoid the risks of fire and burn
injuries:
• This appliance is not suitable for
children or for those whose physical,
sensorial or intellectual faculties pre-
vent the safe usage of the appliance
without support or supervision. Chil-
dren should be supervised to ensure
that they do not play with the appli-
ance.
• Provide for a safe and slip-free posi-
tioning of the appliance.
• Ensure that the power plug is easily
accessible in the event of danger,
and that there is no danger of anyone
tripping over the power cable.
IB_KH25_E6575_EN.qxd 02.08.2007 9:38 Uhr Seite 4

- 5 - 
Using the appliance safely:
• In the event of danger, immediately
remove the power plug from the wall
socket.
• Never use the appliance for purposes
other than those for which it was
designed.
• Remove the power plug from the wall
socket when the appliance is not in
use, when you remove parts and
before cleaning the appliance.
• Do not use the appliance outdoors.
Appliance description
qLid
wLarge squeezing cone
eSmall squeezing cone
rUpper fruit pulp sieve
tFruit pulp regulator
yLower fruit pulp sieve
uJuice collector
iDrive axle
oPower cable with power plug
aAppliance plinth
sPower cable storage
Set-up and assembly of the appliance
Important: Ensure that the power
plug is not in the power socket before
assembling the appliance.
1. Unwind the power cable ocompletely
from the cable storage sand secure
it in the lateral recess on the appliance
plinth a.
2. Place the appliance plinth aon a level
and slip-free surface.
Note: Rinse all removable compo-
nents thoroughly before the first
usage of the appliance (see chapter
"Cleaning and care").
3. Place the juice collector uon the drive
axle iof the appliance plinth aand
turn it clockwise as far as it will go.
4. Place both parts of the fruit pulp sieve
r/yinto each other so that the fruit
pulp regulator tprotrudes through
the recess. Both parts must audibly
engage.
5. Place the assembled fruit pulp sieve
r/yon the juice collector u. The fruit
pulp regulator tmust lie on the grip
and catch in the rabbet on the grip.
6. Press the small squeezing cone eon
the drive axle iso that it engages.
Note: If you want to press oranges
or other larger fruits, place the large
squeezing cone wover the small
squeezing cone e. Ensure that the
lobes of the small squeezing cone e
engage in the recesses of the large
squeezing cone w.
7. Insert the power plug into a wall
power socket. The appliance is now
ready for use.
IB_KH25_E6575_EN.qxd 02.08.2007 9:38 Uhr Seite 5

- 6 -

Juice extraction
1. Adjust the fruit pulp regulator t, by
sliding it, so that the slits in the fruit
pulp sieve r/ylie exactly above each
other if you wish to have fruit juice
with fruit pulp. Adjust the fruit pulp
regulator t, by sliding it, so that the
slits in the fruit pulp sieve r/yare not
lying above each other if you do not
wish to have fruit juice with fruit pulp.
2. Cut the fruits in half
(orange, lemon etc.)
3. Press the halved fruit lightly onto the
squeezing cone w/e. The appliance
switches itself on automatically as
soon as the squeezing cone w/eis
pressed down.
4. Apply pressure at various parts of the
fruit rind with your fingers. Thereby
the juice will be evenly squeezed out
of the fruit.
5. When no more juice flows from the fru-
it, stop applying pressure to the squee-
zing cone w/e. The appliance stops.
6. Press the squeezing cone w/edown
repeatedly to loosen it, until it turns
in the opposite direction.
7. When no more juice flows from the
fruit, stop applying pressure to the
squeezing cone w/e. The appliance
stops. Remove the fruit skin from the
squeezing cone w/e.
8. Continue similarly with further fruit-
halves until you have squeezed out
the desired volume of fruit juice. The
current volume squeezed can be read
off from the scale on the side of the
juice collector u.
Note: When pressing out juice, do not
exceed the 600 ml volume marking
on the scale of the juice collector u.
Emptying
Important: Remove the power plug
from the wall socket when you empty
the fruit pulp sieve or the juice collec-
tor u.
• Turn the juice collector uanti-clock-
wise until the perceptible resistance
desists. You can now lift it from the
drive axle iand pour the juice out.
Disassembly
If you wish to disassemble the Citrus Press,
e.g. for the cleaning of it, proceed as
follows:
1. Remove the power plug from the wall
socket o.
2. Remove the squeezing cone w/e.
3. Remove the fruit pulp sieve r/y.
Press the hook on the underside of the
upper fruit pulp sieve rinwards. At the
same time exert light pressure on the
fruit pulp sieve t. The components
allow themselves to be pressed apart.
4. Turn the juice collector uanti-clock-
wise until the perceptible resistance
desists. You can now lift it from the
drive axle a.
IB_KH25_E6575_EN.qxd 02.08.2007 9:38 Uhr Seite 6

- 7 - 
Cleaning and Care
Important: Always remove the
power plug from the wall socket
before cleaning the appliance.
Important: To avoid receiving an
electrical shock, NEVER submerse
the appliance plinth ain water
or other fluids.
• Disassemble the Citrus Press as described
in the chapter "Disassembly".
• Clean the appliance plinth aonly with
a slightly moistened cloth.
• Clean all other removable parts in a
warm mild-detergent solution and
dry them carefully.
• To clean the fruit pulp sieve r/y,
take it apart and clean it with a dish-
washing brush under running water.
Note: Do not use aggressive deter-
gents to clean the appliance.
The appliance and its components
may not be cleaned in a dishwasher
or in boiling water.
Storage
If you do not intend to use the appliance
for an extended period, wrap the power
cable oaround the power cable storage
s, directing the end of the cable through
the lateral recess on the appliance plinth a.
Assemble the appliance completely and
close the lid.
Store the appliance at a clean and dry
location.
Disposal
Do not dispose of the appliance
in your normal domestic waste.
Observe the currently applicable regula-
tions. In case of doubt, please contact
your waste disposal centre.
Dispose of the packaging materials
in an environmentally responsible
manner.
Warranty & Service
The warranty conditions and the service
address can be found on the supplied
warranty card.
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
D-44867 BOCHUM
www.kompernass.com
