Billion BiPAC 5200S RC Series User manual

BiPAC 5200S RC Series
ADSL2+ Modem/Router
Quick Start Guide

Billion BiPAC 5200S RC Series ADSL2+ Modem/Router
1
Package Contents
BiPAC 5210S RC / 5200S RC / 5200S RD ADSL2+ Modem/Router
CD containing the on-line manual, QSG, utility software
RJ-11 ADSL/ telephone cable
Ethernet (CAT-5 LAN) cable
USB cable (for 5210S RC only)
Power adapter
This Quick Start Guide
Splitter/ Micro-filter (Optional)
Attention
Warning
PLEASE READ THE QUICK START GUIDE AND FOLLOW THE
STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU
INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE.
IF YOU NEED MORE INFORMATION ON THIS SOFTWARE
CONFIGURATION, PLEASE REFER TO THE USER MANUAL ON THE
CD-ROM.

Do not use the
router
in high humidit
y or high temperatures.
Do not use the same power source for the router as other
equipment.
Do not open or repair the case yourself. If the router is too hot,
turn off the power immediately and have it repaired at a qualified
service center.

Avoid using th
is
product
and all
accessories
outdoors.

Place the router on a stable surface.
Only use the power adapter that comes with the package. Using a
different voltage rating power adaptor may damage the router.

Quick Start Guide
2
Hardware Overview
BiPAC 5210S RC
The Front LEDs
The Rear Ports
Connect the supplied RJ
-
11
(“telephone”) cable to this
port when connecting to the
ADSL / telephone network.
Lit when
the device
is connected to the
PC and is working
properly.
Lit when
successfully
connected to an ADSL
DSLAM ( “linesync” )
After the device is powered on, press it
to reset the device or restore to factory
default settings. 0-3 seconds: reset the
device; 6 seconds above: restore to
factory default settings (this is used
when you cannot login to the router, e.g.
forgot the password)
C
onnect
a
UTP Ethernet
cable (Cat-5 or Cat-5e)
to the Ethernet port
when connecting to a
PC or an office/home
network of 10Mbps or
100Mbps.
Lit red when WAN fails
to get IP address. Lit
green when WAN gets
the IP address.
Lit when connected to an
Ethernet device. Lit green
for 10M or 100M. Blinking
when data is Transmitted /
Received.
Lit red when power is
ON. Lit green when
the system is ready.
User can connect to PC
using an alternative USB
cable through this port.
Connect the
supplied power
adapter to this jack.
Power
On/Off
switch.

Billion BiPAC 5200S RC Series ADSL2+ Modem/Router
3
Hardware Overview
BiPAC 5200S RC/RD
The Front LEDs
The Rear Ports
Power On/Off
switch.
(Only available
for
5200S
RD
)
Connect the supplied
RJ-11 (“telephone”)
cable to this port when
connecting to the
ADSL/telephone network.
Lit red when power is
ON. Lit green when the
system is ready..
Lit red when WAN fails to
get
IP address. Lit green when
WAN gets the IP address.
Lit when connected to an
Ethernet device. Lit green for
10M and 100M. Blinking when
data is Transmitted / Received.
Lit when successfully
connected to an ADSL
DSLAM (“linesync”).
Connect
an UTP Ethernet
cable (Cat-5 or Cat-5e) to
the Ethernet port when
connecting to a PC or an
office/home network of 10
Mbps or 100 Mbps.
After the device is powered on, press it
to reset the device or restore to factory
default settings. 0-3 seconds: reset the
device; 6 seconds above: restore to
factory default settings (this is used
when you cannot login to the router, e.g.
forgot the password).
Connect the
supplied power
adapter to this jack.

Quick Start Guide
4
Hardware Connection
BiPAC 5210S RC
BiPAC 5200S RC
BiPAC 5200S RD

Billion BiPAC 5200S RC Series ADSL2+ Modem/Router
5
Hardware Installation
1. Power Connection
Plug the supplied power adapter into
the wall jack and the other side to the router.
Please note that the plug type may differ according to country.
2. LAN Connection
Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the
other side to the PC’s Ethernet interface.
3. ADSL Connection
Connect the supplied RJ-11 phone cable to the router’s ADSL port, and the other
side to the phone jack on the wall.
4. USB Connection (BiPAC 5210S RC only)
Users can connect to PC with an alternative USB cable through this port.
Note: For USB installation, please find USB driver in the CD.

Quick Start Guide
6
5. Splitter/ Micro-filter Connection
Splitter / Micro-filters are important for ADSL installation, they help ensure that
high-frequency signals are directed to the ADSL modem, and low-frequency
signals are directed to the telephone or other analog voice-channel device to
prevent inter-modulation distortion and get good speeds and stable ADSL sync
rate
a) Splitter connection
If the installation has only a single telephone and a single ADSL modem, then a
splitter can be employed.
b) Micro-filter connection
If the installation has several telephones or other analog devices, then an internal
micro-filter can be employed at each analog device.
Setup Utility
After you complete the hardware installation insert CD into the CD Drive to run the setup utility.
The setup utility will auto-run. Follow the step-by-step configuration wizard & it will guide you to
setting up the basic network configuration.

Billion BiPAC 5200S RC Series ADSL2+ Modem/Router
7
Connecting to the Router
1. Open the web browser and type http://192.168.1.254 in the browser's address box. This
number is the default IP address for this router. Press Enter.
2. A username and password window will appear. The default username is “admin”,
password is “admin”. Press OK to proceed.
3. You will get a status report web page and main menu screen.
Please see the relevant sections of user manual for detailed instructions on how to
configure your router.
Troubleshooting
1. None of the LEDs are on when you turn on the router.
Check the connection between the adapter and the router. If the error persists, you may have
a hardware problem. In this case you should contact technical support.
2. Can’t ping any PCs on the LAN.
Check the Ethernet LEDs on the front panel. The LED should be on for a port that has a PC
connected. If it is off, check the cables between your router and the PC. Make sure you have
uninstalled any software firewall for troubleshooting. Verify that the IP address and the subnet
mask are consistent between the router and the workstations.
3. Frequent loss of ADSL linesync (disconnections).
Ensure that all other devices connected to the same telephone line as your router (e.g.
telephones, fax machines, analogue modems) have a line filter connected between them and
the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified
and licensed electrician), and ensure that all line filters are correctly installed and the right
way around. Missing line filters or line filters installed the wrong way around can cause
problems with your ADSL connection, including causing frequent disconnections. If you have
a back-to-base alarm system you should contact your security provider for a technician to
make any necessary changes.
Product Support and Contact Information
Most problems can be solved by referring to the Troubleshooting section in the User Manual.
If you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer
where you purchased this product.
Contact Billion
WORLDWIDE:
http://www.billion.com
Billion Product Registration
Billion is committed to before and after sales customer services. You will get the most out of your Billion's products
after registration. Please register online at http://www.billion.com/register to receive valuable services and support
from us.
5200S RC Series V101EN (AAMPIMBIL5200SRCX1)
