Billion BiPAC 7402(G)X(L) Series User manual

Version Release: 6.24b.dm2
Last Revision July 04.2012
BiPAC 7402(G)X(L)
Series
3G/ADSL2+ (802.11g) (VPN)
Firewall Router
User Manual

1
T
Ta ab bl le e o of f C Co on nt te en nt ts s
Chapter 1: Introduction.............................................................................................................1
Introduction to your Router.......................................................................................................1
Features ...................................................................................................................................1
Chapter 2: Installing the Router................................................................................................4
Important note for using this router...........................................................................................4
Package Contents ....................................................................................................................4
The Front LEDs ........................................................................................................................5
The Rear Ports .........................................................................................................................6
Cabling .....................................................................................................................................7
Chapter 3: Basic Installation.....................................................................................................8
Connecting Your Router ...........................................................................................................9
Network configuration.............................................................................................................10
Configuring PCs in Windows 7 ...........................................................................................10
Configuring PCs in Windows Vista .....................................................................................12
Configuring PCs in Windows 2000 .....................................................................................15
Configuring PC in Windows 95/98/ME................................................................................16
Configuring PC in Windows NT4.0 .....................................................................................17
Factory Default Settings .........................................................................................................18
Information from your ISP ......................................................................................................19
Configuring with your Web Browser .......................................................................................20
Chapter 4: Configuration.........................................................................................................21
Status .....................................................................................................................................22
ADSL Status.......................................................................................................................22
3G Status............................................................................................................................23
EWAN Status......................................................................................................................24
iBurst Status .......................................................................................................................25
ARP Table...........................................................................................................................26
DHCP Table........................................................................................................................27
Routing Table......................................................................................................................28
NAT Sessions.....................................................................................................................29
UPnP Portmap....................................................................................................................29
PPTP Status .......................................................................................................................30
IPSec Status.......................................................................................................................30
L2TP Status........................................................................................................................31
Email Status........................................................................................................................31
Event Log ...........................................................................................................................32
Error Log.............................................................................................................................33
Diagnostic...........................................................................................................................34
Quick Start..............................................................................................................................35
Configuration..........................................................................................................................39
LAN - Local Area Network ..................................................................................................40
Bridge Interface...............................................................................................................40
Ethernet ..........................................................................................................................41
IP Alias ............................................................................................................................41
IPv6 Autoconfig ...............................................................................................................42
Ethernet Client Filter .......................................................................................................43
Wireless (Wireless Router only) ......................................................................................44
Wireless Security (Wireless Router only) ........................................................................46
Wireless Client / MAC Address Filter (Wireless Router only) ..........................................48

2
WPS (Wireless Router only) ...........................................................................................49
Port Setting .....................................................................................................................59
DHCP Server ..................................................................................................................60
WAN - Wide Area Network .................................................................................................61
WAN Interface.................................................................................................................61
WAN Profile.....................................................................................................................64
ADSL Mode.....................................................................................................................81
System................................................................................................................................82
Time Zone .......................................................................................................................82
Remote Access ...............................................................................................................83
Firmware Upgrade ..........................................................................................................84
Backup / Restore.............................................................................................................85
Restart Router.................................................................................................................86
User Management...........................................................................................................87
Mail Alert .........................................................................................................................89
Firewall and Access Control ...............................................................................................90
General Settings .............................................................................................................91
Packet Filter ....................................................................................................................92
Intrusion Detection ..........................................................................................................99
URL Filter ......................................................................................................................101
IM / P2P Blocking..........................................................................................................103
Firewall Log...................................................................................................................104
VPN - Virtual Private Networks.........................................................................................105
PPTP (Point-to-Point Tunneling Protocol) .....................................................................105
IPSec (IP Security Protocol).......................................................................................... 113
L2TP (Layer Two Tunneling Protocol) ...........................................................................122
QoS - Quality of Service...................................................................................................134
Prioritization ..................................................................................................................134
Outbound IP Throttling (LAN to WAN)...........................................................................136
Inbound IP Throttling (WAN to LAN) .............................................................................137
Virtual Server (known as Port Forwarding).......................................................................143
Add Virtual Server .........................................................................................................144
Edit DMZ Host...............................................................................................................146
Edit One-to-One NAT (Network Address Translation) ...................................................147
Wake on LAN....................................................................................................................150
Time Schedule..................................................................................................................151
Configuration of Time Schedule ....................................................................................152
Advanced..........................................................................................................................153
Static Route...................................................................................................................153
Static ARP .....................................................................................................................153
Dynamic DNS................................................................................................................153
Check Email..................................................................................................................155
Device Management .....................................................................................................156
IGMP.............................................................................................................................159
MLD ..............................................................................................................................159
VLAN Bridge .................................................................................................................160
Logout ..................................................................................................................................160
Chapter 5: Troubleshooting..................................................................................................161
Problems starting up the router ............................................................................................161
Problems with the WAN Interface.........................................................................................161
Problems with the LAN Interface..........................................................................................161
APPENDIX A: Product Support and Contact Information ..................................................162

1
Chapter 1: Introduction
Introduction to your Router
Welcome to the 3G/ADSL2+ (802.11g) (VPN) Firewall Router. The router is an “all-in-one” ADSL router,
combining an ADSL modem, ADSL router and Ethernet network switch functionalities, providing
everything you need to get the machines on your network connected to the Internet over your ADSL
broadband connection. With features such as an ADSL Quick-Start wizard and DHCP Server, you can be
online in no time at all and with a minimum of fuss and configuration, catering for first-time users to the
guru requiring advanced features and control over their Internet connection and network.
Features
Express Internet Access
The router complies with ADSL worldwide standards. It supports downstream rate up to 12/24 Mbps
with ADSL2/2+, 8Mbps with ADSL. Users enjoy not only high-speed ADSL services but also
broadband multimedia applications such as interactive gaming, video streaming and real-time
audio much easier and faster than ever. It is compliant with Multi-Mode standard (ANSI T1.413,
Issue 2; G.dmt (ITU G.992.1); G.lite (ITU G.992.2); G.hs (ITU G994.1); G.dmt.bis (ITU G.992.3);
G.dmt.bis.plus (ITU G.992.5)).
Virtual Private Network (VPN) (VPN model only)
It allows user to make a tunnel with a remote site directly to secure the data transmission among
the connection. User can use embedded PPTP and L2TP client/server, IKE and IPSec which are
supported by this router to make a VPN connection or users can run the PPTP client in PC and the
router already provides IPSec and PPTP pass through function to establish a VPN connection if the
user likes to run the PPTP client in his local computer.
3G
With 3G-based Internet connection (requires an additional 3G USB modem), user can access
internet through 3G - whether you're seated at your desk or taking a cross-country train trip.
EWAN
Besides using 3G/ADSL to get connected to the Internet, the router offers its Ethernet port 1 as a
WAN port to be used to connect to Cable Modems and fiber optic lines. This alternative, yet faster
method to connect to the internet will provide users more flexibility to get online.
Dual WAN
Dual WAN is a new way of getting connected to the internet which is to use each two of the
3G/ADSL/EWAN to deal with the unexpected case and balance traffic load. That is a way of
improving greatly the robustness.
802.11g Wireless AP with WPA Support (Wireless Router only)
With integrated 802.11g Wireless Access Point in the router, the device offers a quick and easy
access among wired network, wireless network and broadband connection (ADSL) with single
device simplicity, and as a result, mobility to the users. In addition to 54 Mbps 802.11g data rate, it
also interoperates backward with existing 802.11b equipment. The Wi-Fi Protected Access (WPA1
and WPA2) and Wired Equivalent Privacy (WEP) supported features enhance the security level of
data protection and access control via Wireless LAN.
Fast Ethernet Switch
A 4-port 10/100Mbps fast Ethernet switch is built in with automatic switching between MDI and
MDI-X for 10Base-T and 100Base-TX ports. An Ethernet straight or crossover cable can be used
directly for auto detection.

2
Multi-Protocol to Establish a Connection
It supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5), RFC 1483 encapsulation over
ATM (bridged or routed), PPP over Ethernet (RFC 2516), and IPoA (RFC1577) to establish a
connection with the ISP. The product also supports VC-based and LLC-based multiplexing.
Quick Installation Wizard
It supports a WEB GUI page to install this device quickly. With this wizard, end users can enter the
information easily which they get from their ISP, then surf the Internet immediately.
Universal Plug and Play (UPnP) and UPnP NAT Traversal
This protocol is used to enable simple and robust connectivity among stand-alone devices and PCs
from many different vendors. It makes network simple and affordable for users. UPnP architecture
leverages TCP/IP and the Web to enable seamless proximity networking in addition to control and
data transfer among networked devices. With this feature enabled, users can now connect to Net
meeting or MSN Messenger seamlessly.
Network Address Translation (NAT)
Allows multi-users to access outside resources such as the Internet simultaneously with one IP
address/one Internet access account. Many application layer gateway (ALG) are supported such as
web browser, ICQ, FTP, Telnet, E-mail, News, Net2phone, Ping, NetMeeting, IP phone and others.
SOHO Firewall Security with DoS and SPI
Along with the built-in NAT natural firewall feature, the router also provides advanced hacker
pattern-filtering protection. It can automatically detect and block Denial of Service (DoS) attacks.
The router is built with Stateful Packet Inspection (SPI) to determine if a data packet is allowed
through the firewall to the private LAN.
Domain Name System (DNS) Relay
It provides an easy way to map the domain name (a friendly name for users such as
www.yahoo.com) and IP address. When a local machine sets its DNS server with this router’s IP
address, every DNS conversion request packet from the PC to this router will be forwarded to the
real DNS in the outside network.
Dynamic Domain Name System (DDNS)
The Dynamic DNS service allows you to alias a dynamic IP address to a static hostname. This
dynamic IP address is the WAN IP address. For example, to use the service, you must first apply for
an account from a DDNS service like http://www.dyndns.org/. More than 5 DDNS servers are
supported.
Quality of Service (QoS)
QoS gives you full control over which types of outgoing data traffic should be given priority by the
router, ensuring important data like gaming packets, customer information, or management
information move through the router ay lightning speed, even under heavy load. The QoS features
are configurable by source IP address, destination IP address, protocol, and port. You can throttle
the speed at which different types of outgoing data pass through the router, to ensure P2P users
don’t saturate upload bandwidth, or office browsing doesn’t bring client web serving to a halt. In
addition, or alternatively, you can simply change the priority of different types of upload data and let
the router sort out the actual speeds.
IPv6 supported
Internet Protocol version 6 (IPv6) is a version of the Internet Protocol that is designed to succeed
IPv4.
IPv6 has a vastly larger address space than IPv4. This results from the use of a 128-bit address,
whereas IPv4 uses only 32 bits. The new address space thus supports 2128 (about 3.4×1038)
addresses. This expansion provides flexibility in allocating addresses and routing traffic and
eliminates the primary need for network address translation (NAT), which gained widespread
deployment as an effort to alleviate IPv4 address exhaustion.
IPv6 also implements new features that simplify aspects of address assignment (stateless address
autoconfiguration) and network renumbering (prefix and router announcements) when changing

3
Internet connectivity providers. The IPv6 subnet size has been standardized by fixing the size of the
host identifier portion of an address to 64 bits to facilitate an automatic mechanism for forming the
host identifier from Link Layer media addressing information (MAC address).
Network security is integrated into the design of the IPv6 architecture. Internet Protocol Security
(IPsec) was originally developed for IPv6, but found widespread optional deployment first in IPv4
(into which it was back-engineered). The IPv6 specifications mandate IPsec implementation as a
fundamental interoperability requirement.
Virtual Server (“port forwarding”)
Users can specify some services to be visible from outside users. The router can detect incoming
service requests and forward either a single port or a range of ports to the specific local computer to
handle it. For example, a user can assign a PC in the LAN acting as a WEB server inside and
expose it to the outside network. Outside users can browse inside web servers directly while it is
protected by NAT. A DMZ host setting is also provided to a local computer exposed to the outside
network, Internet.
Rich Packet Filtering
Not only filters the packet based on IP address, but also based on Port numbers. It will filter packets
from and to the Internet, and also provides a higher level of security control.
Dynamic Host Configuration Protocol (DHCP) Client and Server
In the WAN site, the DHCP client can get an IP address from the Internet Service Provider (ISP)
automatically. In the LAN site, the DHCP server can allocate a range of client IP addresses and
distribute them including IP address, subnet mask as well as DNS IP address to local computers. It
provides an easy way to manage the local IP network.
Static and RIP1/2 Routing
It has routing capability and supports easy static routing table or RIP1/2 routing protocol.
Simple Network Management Protocol (SNMP)
It is an easy way to remotely manage the router via SNMP.
Web based GUI
It supports web based GUI for configuration and management. It is user-friendly and comes with
on-line help. It also supports remote management capability for remote users to configure and
manage this product.
Firmware Upgradeable
Device can be upgraded to the latest firmware through the WEB based GUI.
Rich Management Interfaces
It supports flexible management interfaces with local console port, LAN port, and WAN port. Users
can use terminal applications through the console port to configure and manage the device, or
Telnet, WEB GUI, and SNMP through LAN or WAN ports to configure and manage the device.

Chapter 2: Installing the router 4
Chapter 2: Installing the Router
Important note for using this router
Package Contents
3G/ADSL2+ (802.11g) (VPN) Firewall Router
CD containing the online manual
RJ-11 ADSL/telephone Cable
Ethernet Cable
Console tool kit
Power adapter
A detachable antenna
Quick Start Guide

Chapter 2: Installing the router 5
The Front LEDs

LED Meaning
1 Power Both red and green LEDs lit together when power is ON.
Lit red means system failure. Restart the device or contact support.
Lit green when the device is ready.
2 LAN Port
1X - 4X
(RJ-45 connector)
Lit when one of LAN ports connected to an Ethernet device.
The speed of transmission hits 100Mbps appears Green; The speed of
transmission hits 10Mbps appears Orange.
Blinking when data is Transmitted / Received.
3 USB Lit when the device connected to a USB device.
Flash when the device is sending/receiving data.
4 Wireless(Wireless
Router only)
Lit green when the wireless connection is established.
Flashes when the device is sending/receiving data.
Flash once per second while wi-fi protected setup is in progress.
5 Mail Lit green when there are emails in the Inbox.
6 DSL Lit Green when the device is successfully connected to an ADSL
DSLAM. (“line sync”).
7 Internet
Lit red when WAN port fails to get IP address.
Lit green when WAN port gets IP address successfully.
Lit off when the device is in bridge mode or when WAN connection is
absent.

Chapter 2: Installing the router 6
The Ethernet Port # 4 can be used as a console port. You need a special
console tool which already includes in the package to connect with LAN
port 4 and PC’s RS-232 port (9-pin serial port).
The Rear Ports
Port
M
eaning
1 Antenna
(Wireless Router only) Connect the detachable antenna to this port.
2 DSL Connect the supplied RJ-11 (“telephone”) cable on this port
when connecting to the ADSL/telephone network.
3 USB Connect the USB cable on this port.
4
LAN
1X - 4X
(RJ-45 connector)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the
LAN ports when connecting to a PC or an office/home network
of 10Mbps or 100Mbps.
Caution: Port 4 can be either a LAN or Console port at a time
but not both.
5 WPS (Wireless Router only) Push WPS button for less than 5 sec to trigger Wi-Fi Protected
Setup function; push WPS button for more than 5 sec to
enable/disable WLAN Service.
6 RESET
To be sure the device is being turned on. Press RESET button
for:
1-3 seconds: quick reset the device.
6 seconds above, and power off, power on the device:
restore to factory default settings. (Cannot login to the router or
forgot your Username/Password. Press the button for more
than 6 seconds).
Caution: After pressing the RESET button for more than 6
seconds, to be sure you power cycle the device again.
7 Power Connect the supplied power adapter to this jack.
8 Power Switch Power ON/OFF switch

Chapter 2: Installing the router 7
Cabling
One of the most common causes of problems is the bad cabling or ADSL line(s). Make sure that all
connected devices are turned on. On the front of the product is a bank of LEDs. Verify that the LAN Link
and ADSL line LEDs are lit. If they are not, verify that you are using the proper cables.
Ensure that all other devices connected to the same telephone line as your router (e.g. telephones, fax
machines, analogue modems) have a line filter connected between them and the wall socket (unless you
are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and ensure
that all line filters are correctly installed and the right way around. Missing line filters or line filters installed
the wrong way around can cause problems with your ADSL connection, including causing frequent
disconnections.
