BiPAC 7404V series
VoIP/(802.11g) ADSL2+
(VPN) Firewall Router
Quick Start Guide

VoIP/(802.11g) ADSL2+ (VPN) Firewall Router
1
For more detailed instructions on con
f
i
g
urin
g
and usin
g
th
e
Billion VoIP/(802.11g) ADSL2+ (VPN) Firewall
R
outer, please
refer to the on-line manual.
Package Contents
VoIP/(802.11g) ADSL2+ (VPN) Firewall Router
CD-ROM containing the online manual
RJ-11 ADSL/telephone Cable
Ethernet (CAT-5 LAN) Cable
Console Kit (RJ45-RS232)
A detachable antenna
AC-DC power adapter (12VDC, 1.2A)
This Quick Start Guide
 Do not use this router in high humidity or high temperatures.
 Do not use the same power source for this router as other
equipment.
 Do not open or repair the case yourself. If this router is too hot,
turn off the power immediately and have it repaired at a qualified
service center.
 Avoid using this product and all accessories outdoors.
Warning
 Place this router on a stable surface.
 Only use th
different voltage rating pow
e power adapter that comes with the package. Using a
er adaptor may damage this router.
A
ttention

Quick Start Guide
The Front LEDs
LED Meaning
1 PWR Lit when power is ON.
2 SYS Lit when the system is ready.
3 – 6 Lit when connected to an Ethernet device. Green for 100Mbps; Orange for 10Mbps.
LAN Port
1X — 4X
(RJ-45 connector) Blinking when data is Transmitted / Received.
7 WLAN Lit green when the wireless connection is established.
(Wireless Router only) Flashes when sending/receiving data.
8 – 9 Phone 1X — 2X
(RJ-11 connector) Lit green when the phone is off-hook.
10 LINE
(Router with LINE port only) Lit when the inbound and outbound calls transmitted
through PSTN.
12
VoIP Port Lit when the SIP Registration is OK.
1X — 2X
(RJ-11 connector) Green for Phone 1; Orange for Phone 2.
13 ADSL/PPP
Lit Green when successfully connected to an ADSL DSLAM
(“linesync”).
Lit Orange when there is a PPPoA / PPPoE connection.
2

VoIP/(802.11g) ADSL2+ (VPN) Firewall Router
The Rear Ports
5 3
6 1
8 7
3
2
4
The LAN 4 can be connected to the computer and console cable. You need a special
console kit in this package to connect the LAN cable of Port 4 when connecting to a PC’s
RS-232 port (9-pin serial port).
Port Meaning
1 Power Switch Power ON/OFF switch
2 PWR Connect the supplied power adapter to this jack.
3 RESET
After the device is powered on, press it to reset the device or
restore to factory default settings.
1-3 seconds: reset the device
6 seconds above, and power off, power on the device: restore to
factory default settings (this is used when you can not login to
the router, e.g. forgot the password)
4 LAN 1X — 4X
(RJ-45 connector)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the
four LAN ports when connecting to a PC or an office/home
network of 10Mbps or 100Mbps.
5
Phone
1X ─2X
(RJ-11 connector)
Connect RJ-11 cable to this port when connecting to an analog
phone set.
6 LINE (Router with LINE port
only)
Connect RJ-11 cable to this port when connecting to the
telephone wall jack.
7 ADSL Connect the supplied RJ-11 (“telephone”) cable to this port
when connecting to the ADSL/telephone network.
Antenna Connect the detachable antenna to this port.
8 (Wireless Router only)

Quick Start Guide
Connecting Your ADSL Router
1. Connect this router to a LAN (Local Area Network) and the ADSL/telephone (ADSL) network.
2. Power on the device.
3. Make sure the PWR and SYS LEDs are lit steadily and that the LAN LED is lit.
4. Connect an RJ11 cable to VoIP port when connecting to an analog phone set.
5. Connect RJ-11 cable to LINE Port when connecting to the telephone wall jack
Connect more
computers
Analog Phone
ADSL
Splitter
ADSL Phone
Line
Switching/
HUB
4

VoIP/(802.11g) ADSL2+ (VPN) Firewall Router
Configuring PC in Windows XP
1. Go to Start / Control Panel (in Classic
View). In the Control Panel, double-click on
Network Connections
2. Double-click Local Area Connection.
3. In the Local Area Connection Status
window, click Properties.
4. Select Internet Protocol (TCP/IP) and click
Properties.
5. Select the Obtain an IP address
automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
5

Quick Start Guide
Configuring PC in Windows 2000
1. Go to Start / Settings / Control Panel. In the
Control Panel, double-click on Network and
Dial-up Connections.
2. Double-click Local Area Connection.
3. In the Local Area Connection Status
window click Properties.
4. Select Internet Protocol (TCP/IP) and click
Properties.
5. Select the Obtain an IP address
automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
6

VoIP/(802.11g) ADSL2+ (VPN) Firewall Router
Configuring PC in Windows 98/Me
1. Go to Start / Settings / Control Panel. In
the Control Panel, double-click on Network
and choose the Configuration tab.
2. Select TCP/IP ->
NE2000 Compatible, or the name of your
Network Interface Card (NIC) in your PC.
3. Select the Obtain an IP address
automatically radio button.
4. Then select the DNS Configuration tab.
5. Select the Disable DNS radio button and
click OK to finish the configuration.
7

Quick Start Guide
Configuring PC in Windows NT4.0
1. Go to Start / Settings / Control Panel. In the
Control Panel, double-click on Network and
choose the Protocols tab.
2. Select TCP/IP Protocol and click Properties.
3. Select the Obtain an IP address from a
DHCP server radio button and click OK.
8

VoIP/(802.11g) ADSL2+ (VPN) Firewall Router
Configuring Your ADSL Router
To configure this device, you must have IE 5.0 / Netscape 4.5 or
above installed
Verifying Your Local Network Connection with the Device
To see if this ADSL Router is
visible on the local network, go
to Start / Run.In the Run dialog
box, type “ping 192.168.1.254”
then press OK.
A command prompt window will
pop out. If your ping is
successful which means your
local network is able to reach to
the device, then the command
prompt window will close up
automatically.
Connection fails, when you see
“Request timed out” in the
command prompt window. You
may need to check your set up.
9

Quick Start Guide
Connecting to the Router
1. Open the web browser and type
http://192.168.1.254 in the browser’s
address box. This number is the default IP
address for this router. Press Enter.
2. A username and password window will
appear. The default username and
password are admin and admin. Press
OK to proceed.
3. You will get a status report web page and main menu screen.
10
N
avigation panel

VoIP/(802.11g) ADSL2+ (VPN) Firewall Router
At the main menu screen, the left navigation panel where bookmarks are provided links you directly to
the desired setup page, including:
 Status (ARP Table, Wireless Association (Wireless Router only), Routing Table, DHCP Table,
PPTP Status, IPSec Status, L2TP Status (Only the 7404VGO has VPN features), Email Status, VoIP
Status, Event Log, Error Log, NAT Sessions, Diagnostic and UPnP Portmap)
 Quick Start
 Configuration (LAN, WAN, System, Firewall, VPN (Only the 7404VGO has VPN features),
VoIP, QoS, Virtual Server, Time Schedule and Advanced)
 Save Config to FLASH
 Language (provides user interface in English and French languages).
Please see the relevant sections of on-line manual for detailed instructions on how to
configure your router.
Product Support and Contact Information
Most problems can be solved by referring to the Troubleshooting section in the User’s Manual.If you
cannot resolve the problem with the Troubleshooting chapter, please contact the dealer where you
purchased this product.
