Birlea Corfu Bunk Bed User manual

We suggest you spend a short time reading through this
leaflet and then follow the simple step by step instructions.
It is important for you to follow the instruction carefully.
Assembling the bed without following the instructions
might cause the bed to collapse and lead to fatal injuries.
To ensure an easier assembly, we strongly advise that all fittings
are only finger tightened during initial assembly. Only upon
completion of the assembly, should all fixing points be
fully tightened.
Do not use this bed if any parts are missing, damage or worn.
Retain these instruction for future reference.
In case for any claims, please retain this product original packing
HARDWARE LIST
PARTS LIST
What is included in this pack?
What is included in this pack?
IMPORTANT!
Before you start, here is some helpful advice Health & Safety
1.
2.
3.
4.
5.
6.
DO NOT JUMP ON THIS BED!.
DO NOT use this bed unless all fixings are tightly secured.
Periodically check all bolts, screws & fixings to ensure they
are tightly secured.
Always use on a level and even surface.
Warning! if this bed is on a laminated floor, you must place
some protection under all legs to stop the bed from moving.
If this is not adhered to, there is no guarantee if the
bed collapses.
Always use on a level and even surface.
Be aware of the danger of young children (under 6) falling
from the upper bunk. It is not advisable for children under
6 years of age to sleep on the top bunk.
Recommended thickness of mattress is max 200mm.
Caution! Children might strangle in items such as ropes,
strings, cords harnesses & belts strings attached to or
hang on the bunk bed.
Warning! Children can become trapped between the bed &
the wall. To avoid risk of serious injuries, please aware of the
distance between the top safety barrier & the wall.
This bunk bed is comply to EN 747 - 1 & 2 [2012]
1.
2.
3.
4.
5.
7.
8.
9.
10.
11.
12.
How do I care for this Corfu Bunk Bed?
Keep away any sharp object from the metal part of
the bed.
1.
M4 Allen Key (Small) - 2pcs
M5 Allen Key (Big) - 1pc
NAME NO Q'TY
Upper Frame
Bottom Frame
01
03
02
01
Bottom Base
Top Base
02
04
02
01
Back Rail 05 01
Front Rail 06 01
Ladder 07 01
Frame Connector 08 04
Page 1 of 3
11032014(R-8)
M8 Metal
Square Nut
M6 x 45mm
JCBC Screw
M8 x 95mm
JCBC Screw
M6 x 15mm
JCN Nut
M6 x 80mm
JCBC Screw
M6 x 35mm
JCBC Screw
M6 Cap Nut
19mm M6 Flat
Round Washer
B203 - 50mm Black
Round Stopper
NAME FIGURE QTY. NO.
A
B
C
D
E
F
G
H
I
08
08
04
04
09
04
02
02
04
PP22 (2") - 50mm
Beige Round Cap J04
B018 : Black
Round Stud K10
Instructions for assembly and installation
Corfu Bunk Bed
Birlea Furniture
FURNITUREFURNITURE
RR
Vendor Code: S000053
Bottom Base
Top Base
1
2 3
456
78

How do I assemble the Corfu Bunk Bed?
Step 1.
Step 2.
Step 3.
Step 4.
Insert the 50mm Black Round Stopper (I) to the Bottom Frame (2).
Slot in the Bottom Base (3) to the bracket of the Bottom Frame (2).
Place the Frame Connector (8) between the Upper & Bottom Frame (1) & (2) by facing hole to hole as shown in view AA & AB
Secure the Frame Connector (8) with M6 x 45mm JCBC Screw (C) & M6 x 15mm JCN Nut (D) for the back 2 bedpost as attached
(View AB). Insert Black Round Stud (K) into the front two bedpost hole as shown in (View AA).
Slot in the Top Base (4) to the bracket of the Upper Frame (1) and secure with M8 Metal Square Nut (A) and
M8 x 95mm JCBC Screw (B) at the four corner ends. Also secure the bottom base with M8 Metal Square Nut (A) & M8 x 95mm JCBC
Screw (B) at the four corner ends. But do not tighten the screws of the base yet before assembling the Side Rail in Step 6.
Upper Frame
Bottom
Frame
Caution:
Do not tighten the screws of the
Base yet before assembling the
Side Rail bar (Step 5 & 6)
Bottom Base
Top Base
Sticker
'Top Base'
Please Note:
Part C and D only
connects the back
two bedposts,
use the rounded stud
part K for the front post.
STEP 2
1
2
ISticker
'Bottom Base'
I
C
D
D
C
I
B
B
A
A
K
K
ABAB
AA AB
88
88
BottomBase
I
3
Frame Connector
with hole
Frame
Connector
STEP 1
STEP 3
AA
AA
AB
AB
Shorter neck for upper frame
Longer neck
for bottom frame
Small
Allen Key
8
2
8
1
2
1
4
3
13
2
2
Big Allen
Key
Big Allen
Key
Top Base
3
Bottom Base
STEP 4
Page 2 of 3
11032014(R-8)
Vendor Code: S000053

E
How do I assemble the Corfu Bunk Bed?
Step 5.
Step 6.
Step 7.
Step 8.
Bottom Base
Top Base
Bottom Base
Top Base
Bottom Base
Top Base
Bottom Base
Top Base
5 6
7
7
4
E
E
EE
E
F
JJJJ
J
F
H
H
G
G
F
F
E
E
Please insert B018 - Black Round Stud
into those 10mm extra holes
Small
Allen
Key
Small
Allen
Key
Small Allen
Key
E
Secure the horizontal tube of the Back Rail (5) to the upper Frame (1) with M6 x 80mm JCBC Screw (E).
Secure the Back Rail (5) to the Top Base with M6 x 80mm JCBC Screw (E).
Secure the horizontal tube of the Front Rail (6) to the Upper Frame (1) with M6 x 80mm JCBC Screw (E).
Secure the Front Rail (6) to the Top Base with M6 x 80mm JCBC Screw (E).
Assemble the Ladder (7) by using M6 x 35mm JCBC Screw (F), 19mm M6 Flat Round Washer (H) and M6 Cap Nut (G)
Lastly, insert the Beige Round Cap (J) onto the Upper Frame (1).
ASSEMBLY
1
Use this step as the 1st ladder
step to climb up the bed
11
1
1
STEP 5 STEP 6
STEP 7
STEP 8
Page 3 of 3
11032014(R-8)
Vendor Code: S000053
