Birlea URBAN TV UNIT RUSTIC User manual

URBAN TV UNIT RUSTIC
IMPORTANT : READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE OR
USE YOUR URBAN TV UNIT RUSTIC.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
ASSEMBLY:
Assembly should be carried out with this item laying flat, not standing upright.
Assemble on a soft, clean surface to prevent damages.
To erase the numbers printed on the pieces, use the rubber inside the accessories pack.
HEALTH & SAFETY:
DO NOT use this product if any parts are missing, damaged or worn.
DO NOT use this product unless all fixings are secured.
Always use on a level, even surface.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the product as this will cause damage.
Always lift the product with two people to reposition.
Keep any sharp objects away from the product.
1
ASSEMBLY INSTRUCTIONS
www.birlea.com Page of 6
Vendor: S000350

Page of 6
Vendor: S000350
Parts List Hardware List
Part Descripion Qty Part Description Qty
01 1
Top panel
02
03
04
05
06
07
08
09
Bottom panel
Center Panel (Right)
Shelf Panel
Door Panel (Right)
1
1
1
1
1
1
1
Center Panel (Left)
Side panel ( Left )
Side panel ( Right )
A2
Cam lock
Minifix screw
B
Plastic cap
M8 x 30mm Wood Dowel
C
D
E
F
G
H
I
J
M6 x 50mm CSK Cap Wood screw
M3.5 x 16mm C.B Screw
8
8
8
16
8
16
Handle 100.96. BLM
Allen key M4 1
2
Handle screw M4 x 19mm 4
JCBC screw M6 x 30mm 12
Stud 192 8
8
Stud 192 screw
A1
A3
2
K
L1
10
11
12
Metal Frame Side 2
** You will need a small mallet and a
screwdriver for assembly.
** Some screws and wooden dowel
Metal Frame Middle 2
Back Panel 1
Door Panel (Left) 1
7/8 Hinges 4
Metal Shelf Support 4
01
08
06
04 11
10
09
02
12
11
03
05
07
F
F
L2
JCBC screw M6 x 40mm 4
Stopper (2 Pin) 2M

Page of 6
Vendor: S000350
Step 1: Prepare these parts for assembly using hardware parts A1, A2, B, E, F, G, J and M.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
3
E
E
J
03
04
06
05
09 10
Step 2: Attach panel (3), (4), (5) and (6) to panel (1) using hardware A1, A2 and A3 with a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
A1
A1
A3
A2
04
06
05
03
01
FF
B
BB
BB
B
B
B
B
B
B
B
B
B
B
B
A1
A1 A1
A1
A1
A1
A1
A1
01 A2
A2
A2
A2
A2
A2
A2
A2
M
M
G
G
G
G

Page of 6
Vendor: S000350
Step 3: Insert panel (8) along the slot.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
4
Step 4: Attach panel (2) to panel (3), (4), (5) and (6) using hardware C and D.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 5: Attach hardware L1 into panel (1), (2), (3) and (4) using hardware L2 with a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
08
04
06
05
03
02
08
03 01
04
06
05
L1
L2
08
03
04
02
C
D
01
02

Page of 6
Vendor: S000350
5
Step 6: Attach Metal Frame Middle (12) to panel (2) using hardware D and H.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
D
12
11
D
11
D
I
12
11
11
08
12
03 H
12
12
02
03
08
04
01
H
K
01
04
06
05
03
02
Step 7: Attach Metal Frame Side (11) to panel (3) and (4) using hardware D and H.
Attach Metal Frame Side (11) to Metal Frame Middle (12) using hardware D and I.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Step 8: Insert hardware K into mounting positions on panel (5) and (6).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
02
04

Page of 6
Vendor: S000350
Step 9: Insert panel (7) between panel (5) and (6).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
6
JE
E
Vertical
Adjustment
Horizontal
Adjustment
Depth
Adjustment
01
09
03
05
07
06
10
04
02
J
J
01
07
06
03
02
04
05
Step 10: Attach panel (9) and (10) to panel (3) and (4) using hardware E with a screwdriver (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
Additional Information:
· For complete product information, images and dimension diagrams please visit the website
www.birlea.com
· If you have any issues with your item please contact the retailer directly you purchased it from
who will be able to resolve any issues with Birlea.
· Why don't you send us photos of your assembled furniture to [email protected]om to be shared in
our #birleahome feature on instagram.
