10. The start stop switch and the grind engage lever are located on the right side of the machine when facing the
grinding bowl. The start stop switch will activate the mixer paddles. The start stop switch will also activate the
grinding auger only when the grind lever is in the "engaged" position. To deactivate the grinding operation move
the grind lever to the "disengaged" position. The tank and hopper cover interlock switches are located in the
motor compartment. When the safety cover is raised the machine will stop operation.
PRE-OPERATION AND AUGER ROTATION CHECK
ROTATION MUST ONLY BE CHECKED WITH THE
GRINDING AUGER REMOVED, otherwise serious irreparable
damage may occur to grinding components.
11. Turn the toggle hand/foot selector switch to the hand position and engage the grind lever to activate the grinding
auger. Push the green start button. CHECK THE ROTATION OF THE AUGER DRIVE SHAFT; ROTATION
MUST BE COUNTER-CLOCKWISE as indicated by the rotation decal affixed to the grinding bowl.
12. If machine runs clockwise (backwards), it must be rewired to correct rotation, otherwise serious irreparable
damage may occur to the grinding components.
13. Check operation of optional footswitch provided as needed. Plug footswitch cord into fitting located on the same
side as the operation controls. Move toggle selector to foot. The machine will operate with pressure on the
footswitch treadle. Releasing the treadle stops the machine. The footswitch operates the mix and grind
together.
14. Insert auger assembly into grinding bowl, place knife (sharp edges out) onto the square end of the auger
assembly. The breaker plate slides over the worm knife drive pin, and is held from rotating by pins in the grinder
bowl. Install the retaining ring.
ONLY HAND TIGHTEN RETAINING RING
For best results, use knife and plate as a set. Do not operate machine
for any period of time without product in the grinding bowl. This will
cause heating and dulling of the knife and plate.
15. Check placement of all warning labels and be sure anyone who is to operate this MINI-32 MIXER GRINDER has
read and fully understands the operators manual. Machine is now ready for trained operators to process
product.
16. Use meat deflector attached to grinding bowl to eliminate meat splatter.
17. Contact your local distributor if you have any questions or problems with the installation or operation of this
machine.
