BISLEY Glide V2 User manual

Glide V2 Assembly Instructions
Level the unit
One Left and one Right handed unit.
Place inner sides together matching front and tops and level units using adjustable feet

Glide V2 Assembly Instructions
Fitting the top
Screw 2x No.8 Dome head screws into
the holes at each corner
Place the over-sailing top assembly
across the two cabinets.

Glide V2 Assembly Instructions
Fitting the top
With the Aluminium track at the front.
Locate the keyhole cut-outs over the screws
Lower the top and push it back flush
with the front as far as it goes

Glide V2 Assembly Instructions
Fitting the top
M6 x 14mm Pan head screws
Fix top down with screws. Fit hanging
rails at same time using these fixings.
(not shown)

Glide V2 Assembly Instructions
Fitting the top
Use all screws provided in both carcases.

Glide V2 Assembly Instructions
Fitting bottom plinth rail.
Place the rail at an angle to the front edge of the carcase base, line up the ob-
round cut-outs to the screw threads and press home.

Glide V2 Assembly Instructions
Fitting Bottom Plinth Rail
Use supplied No.8 x 3/8 pan head
screws.
Screw in securely in pre-drilled
positions.

Glide V2 Assembly Instructions
Fitting Base Channel Cover
Fit supplied Base Channel Covers to sit over the screw heads, covers are
handed

Glide V2 Assembly Instructions
Fitting Doors
Check there is 2x top running gear in
the outer top channel and 2x in the
inner channel
The Outer door (LH) has a lock fixed in the
right hand edge opposite the handle.

Glide V2 Assembly Instructions
Fitting Doors
Fit the Inner Door (RH) first, place the base sliders into the rear bottom channel.
Top running gear has spring clips to the sides so will ‘snap fit’ when located
correctly into the doors top fixings.

Glide V2 Assembly Instructions
Fitting Doors
Tighten off the centre screws in the upper running gear.
Fit the Outer Door in the same way, locating the bottom running rear into the front channel

Glide V2 Assembly Instructions
Fitting Door Stop Bracket
Door Stop Bracket
Screw into position with 2x screws
supplied

Height at which door can run, can be adjusted by turning this screw.
Glide V2 Assembly Instructions
Door Adjustment

Glide V2 Assembly Instructions
Door Adjustment
Soft Closing can be adjusted
by the repositioning of this
component within the top
track, using an Allen key to
loosen the grub screw.

Glide V2 Assembly Instructions
Finished Unit.
