Bissell BG10 10N2 Series User manual

2. Safety Instructions
3. Product View
4. Operations
5. Operations
6. Troubleshooting

2 www.astonize.com 780.701.5112
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should be
observed, including the following:
READ ALL INSTRUCTIONS BEFORE USING YOUR COMMERCIAL
DEEP CLEANER-BG10.
WARNING:
To reduce the risk of fire, electric shock, or injury:
• Do not immerse.
• Use only on surfaces moistened by cleaning process.
• Always connect to a properly grounded outlet.
• See Grounding Instructions.
• Unplug from outlet when not in use and before conducting
maintenance or troubleshooting.
• Do not leave machine when it is plugged in.
• Do not service machine when it is plugged in.
• Do not use with damaged cord or plug.
• If appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped into water,
have it repaired at an authorized Service Center.
• Use indoors only.
• Do not pull or carry by cord, use cord as a handle,
close door on cord, pull cord around sharp corners or
edges, run appliance over cord, or expose cord to heated
surfaces.
• Unplug by grasping the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into appliance openings, use with
blocked opening, or restrict air flow.
• Do not expose hair, loose clothing, fingers or body parts
to openings or moving parts.
• Do not pick up hot or burning objects.
• Do not pick up flammable or combustible materials (lighter
fluid, gasoline, kerosene, etc.) or use in the presence of
explosive liquids or vapor.
• Do not use appliance in an enclosed space filled with vapors
given off by oil base paint, paint thinner, some moth proofing
substances, flammable dust, or other explosive or toxic
vapors.
• Do not pick up toxic material
(chlorine bleach, ammonia, drain cleaner, gasoline, etc.).
• Do not modify the 3-prong grounded plug.
• Do not allow to be used as a toy.
• Do not use for any purpose other than described in this user’s
guide.
• Do not unplug by pulling on the cord.
• Use only manufacturer’s recommended attachments.
• Always install float before any wet pick up operation.
• Use only cleaning products formulated by BISSELL for use
in this appliance to prevent internal component damage. See
the cleaning fluid section of this guide.
• Keep openings free of dust, lint, hair, etc.
• Do not point attachment nozzle at people or animals
• Keep appliance on a level surface.
• Do not use without intake screen filter in place.
• Turn off all controls before unplugging.
• Unplug before attaching the TurboBrush®.
• Be extra careful when cleaning stairs.
• Close attention is necessary when used by or near children.
SAVE THESE INSTRUCTIONS.
THIS MODEL IS FOR COMMERCIAL USE.
GROUNDING INSTRUCTIONS
This appliance must be connected to a grounded wiring system. If
it should malfunction or break down, grounding provides a safe
path of least resistance for electrical current, reducing the risk of
electrical shock. The cord for this appli-ance has an equipment-
grounding con-ductor and a grounding plug. It must only be
plugged into an outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING:
Improper connection of the equipment-grounding conductor
can result in a risk of electrical shock. Check with a qualified
electrician or service person if you aren’t sure if the outlet is
properly grounded. DO NOT MODIFY THE PLUG. If it will not fit
the outlet, have a proper outlet installed by a qualified electrician.
This appliance is designed for use on a nomi-nal 120-volt circuit,
and has a grounding attachment plug that looks like the plug in the
drawing above. Make certain that the appliance is connected to an
outlet hav-ing the same configuration as the plug. No plug ad

3 www.astonize.com 780.701.5112
Product View
WARNING:
To reduce the risk of fire and electric shock due to internal component damage, use only BISSELL cleaning fluids intended for use
with the deep cleaner. Non-BISSELL cleaning solutions may harm the machine.

4 www.astonize.com 780.701.5112
Operations
Before you clean:
1. Move furniture to another area if cleaning the entire room
(optional.)
2. Vacuum area with a dry vacuum cleaner thoroughly before
deep cleaning.
3. Plan your cleaning route to leave an exit path. It is best to
begin cleaning in the corner farthest from your exit.
Carpet cleaning:
1. Remove dirty water tank. Pull dirty water tank handle to
upright position and lift up to remove dirty water tank.
2. Lift clean water tank from the base of machine.
A. Unscrew cap on top of the clean water tank. Fill tank to
FILL line with clean, hot tap water.
B. Measure BISSELL formula using cap on tank. Fill cap to
line twice for each full tank of water. Always use genuine
BISSELL formulas to maximize cleaning and for the safety
of your machine
C. Screw cap back onto clean water tank and place tank
onto base of the machine.
3. Replace dirty water tank securely on top of the clean water
tank and push handle back to lock into place.
4. Plug into a proper outlet and turn the power switch to the
ON ( I ) position.
5. Detent handle by pushing down on the green lever on the
back of the machine while pulling back.
6. Cleaning strokes. While pressing the trigger, make one
slow forward wet pass and another back. Let the formula
and DirtLifter PowerBrushes do the work for you.
Note: Your machine is equipped with a circuit breaker
that will automatically shut off the brush if a large or
loose object is caught in the brush roll. If that happens,
be sure to unplug your machine, remove the foreign
object and then plug machine in to reset the circuit
breaker.
ATTENTION:
Some Berber carpets have a tendency to fuzz with wear.
Repeated strokes in the same area with an ordinary vacuum
or deep cleaner may aggravate this condition.
1.
2.
2C.
3.
5.
1.
2A.
3.

5 www.astonize.com 780.701.5112
Operations
Carpet cleaning continued:
7. Cleaning strokes. Release the trigger and make one slow
forward and backward pass over the same area to remove
any residual dirty water and aid in drying. Repeat cleaning
passes until solution being pulled up appears clean. Continue
passes without pressing the trigger until you can’t see any
more water being pulled up.
8. Remove the dirty water tank by pulling the handle to the
upright position and lift up. Carry the tank like a bucket to
a utility sink or outside where you will dispose of the dirty
water.
9. Unlatch the top of the tank from the bottom by pushing the
handle all the way forward and lifting the top off. Pour dirty
water into the sink.
Note: You may notice hair and debris deposits
on the carpet or in the tank that were loosened
by the cleaning action (especially with newer car
pets that have never been deep cleaned before).
This debris should be picked up and thrown away.
10. Fill the clean water tank with clean hot tap water and follow
instructions 2 - 7 to continue cleaning.
CAUTION:
Do not overwet. Take care not to run over loose objects or edges of area rugs. Stalling brush may result in premature belt failure.
8.
9.
9.

6 www.astonize.com 780.701.5112
Troubleshooting
Reduce Spray or No Spray
Possible Causes
1. Water tank may be empty.
2. Tank may not be seated completely.
3. Pump may have lost prime.
4. Debris filter on base is clogged.
DirtLifter® PowerBrush does not turn
Possible Causes
1. The belt is off or broken.
2. The unit is in the upright position.
3. Circuit breaker on machine may have tripped.
Cleaner not picking up solution
Possible Causes
1. Tanks may not be seated properly.
2. Clean water tank is empty.
3. Dirty water tank has picked up the maximum amount of dirty
water the red float door has closed.
4. Red float “door” in the tank may have closed as a result of
bumping an object or moving machine back and forth too
quickly.
5. Front nozzle of machine is clogged.
6. Upper body filter is clogged.
Remedies
1. Fill clean tank with hot tap water.
2. Turn power OFF (0). Remove and reseat tank.
3. Turn power OFF (0) and then back ON (I). Wait one minute,
then depress trigger.
4. Use hand to remove debris.
Remedies
1. Turn power OFF ( O ) and unplug unit from outlet. Follow
instructions on page 14.
2. TBrushes only rotate when unit is reclined using the
detent pedal.
3. Turn the machine OFF ( O ) and unplug from outlet. Check
to see if foreign object is caught in brush roll. Remove
object. Plug machine in to reset circuit breaker.
Remedies
1. Pick up both the clean and dirty water tanks and reseat
them so they fit snuggly on the unit.
2. Check fluid levels in clean water tank and refill if necessary.
3. Empty dirty water tank. Refill clean water tank with water
and formula. Place both tanks back onto unit.
4. Turn the machine OFF(0), allowing red float door to release
into the open position,. Turn the unit back ON (I) to continue
cleaning. Be sure your forward and backward strokes are
completed at a slower pace.
5. Use fingers to remove any debris from this area.
6. Use fingers to remove any debris from this area.
WARNING:
To reduce the risk of fire, electric shock, or injury,turn power OFF and disconnect plug from electrical outlet before performing
maintenance or troubleshooting.
Other maintenance or service not included in the manual should be performed by an
authorized service representative.
Thank you for choosing Astonize Carpet Cleaner Rental.
Please do not return this product to the store.
For any questions please call 780-701-5112 or visit Astonize.com.
