Bissell ESSENTIAL PROHEAT 1887 User manual

PROHEAT™
ESSENTIAL
Models 1887, 1887T
Product Overview
1. Spray Trigger
2. Quick Release™
Cord Wrap
3. Upper Handle
4. Tool Storage
(select models)
5. Carry Handle
6. Tank Carry Handle
7. 2-in-1 Water Tank
8. ReadyTools™ Dial
9. Removable Nozzle
10.DirtLifter® PowerBrush
11. Belt Access Door
(underside of machine)
12. EdgeSweep® Brushes
Go online for a comprehensive walkthrough
of your new purchase!
This guide has everything you need to get ready for first use,
including setting up, using and maintaining your machine,
but online you’ll find additional resources like tips and
troubleshooting, videos, product registration, parts, and more.
Go to support.BISSELL.com.
1
3
5
4
6
7
8
9
10 11
12
2
Warranty..........................................................................2
What’s in the Box?.....................................................3
Assembly.........................................................................3
Cleaning Formulas.....................................................4
Filling the 2-in-1 Water Tank .................................5
Cleaning Your Carpet...............................................6
Using the Ready Tools.............................................7
Emptying the 2-in-1 Water Tank.........................8
After-Cleaning Care..................................................9
Storing Your Machine.............................................10
Troubleshooting........................................................10

2BISSELL.com
IMPORTANT SAFETY INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
»Connect to a properly grounded outlet only. See
grounding instructions. Do not modify the 3-prong
grounded plug.
»Do not leave appliance when it is plugged in. Unplug
from outlet when not in use and before servicing.
»Use indoors only.
»Do not allow to be used as a toy. Close attention is
necessary when used by or near children.
»Do not use for any purpose other than described in this
user guide. Use only manufacturer’s recommended
attachments.
»Do not use with damaged cord or plug. If appliance is not
working as it should, or has been dropped, damaged, left
outdoors, or dropped into water, have it repaired at an
authorized service center.
»Do not pull or carry by cord, use cord as a handle, close a
door on cord, or pull cord around sharp edges or corners.
»Do not run appliance over cord. Keep cord away from
heated surfaces.
»Do not unplug by pulling on cord. To unplug, grasp the
plug, not the cord.
»Do not handle plug or appliance with wet hands.
»Do not put any object into openings. Do not use with any
opening blocked; keep openings free of dust, lint, hair,
and anything that may reduce air flow.
»Keep hair, loose clothing, fingers, and all parts of body
away from openings and moving parts.
»Turn OFF all controls before plugging or unplugging
appliance.
»Use extra care when cleaning on stairs.
»Do not use to pick up flammable or combustible
materials (lighter fluid, gasoline, kerosene, etc.) or use in
areas where they may be present.
»Do not use appliance in an enclosed space filled with
vapors given off by oil-based paint, paint thinner, some
moth-proofing substances, flammable dust, or other
explosive or toxic vapors.
»Do not use to pick up toxic material (chlorine bleach,
ammonia, drain cleaner, etc.).
»Do not pick up anything that is burning or smoking, such
as cigarettes, matches or hot ashes.
»Do not pick up hard or sharp objects such as glass, nails,
screws, coins, etc.
»Do not use without filters in place.
»Use only BISSELL® cleaning products intended for use
with this appliance to prevent internal component
damage. See the Cleaning Formula section of this guide.
»Do not immerse. Use only on surfaces moistened by the
cleaning process.
»Keep appliance on a level surface.
»Do not carry the appliance while in use.
»Always install float before any wet pick-up operation.
»Unplug before connecting TurboBrush® Tool.
»Plastic film can be dangerous. To avoid danger of
suffocation, keep away from children.
READ ALL INSTRUCTIONS BEFORE USING YOUR APPLIANCE.
When using an electrical appliance, basic precautions should be observed, including the following:
SAVE THESE INSTRUCTIONS
THIS MODEL IS FOR HOUSEHOLD USE ONLY.
COMMERCIAL USE OF THIS UNIT VOIDS THE MANUFACTURER’S WARRANTY.
WARNING
Improper connection of the equipment-grounding conductor can result
in a risk of electrical shock. Check with a qualified electrician or service
person if you aren’t sure if the outlet is properly grounded. DO NOT MODIFY
THE PLUG. If it will not fit the outlet, have a proper outlet installed by a
qualified electrician. This appliance is designed for use on a nominal 120-volt
circuit, and has a grounding attachment plug that looks like the plug in the
illustration. Make certain that the appliance is connected to an outlet having
the same configuration as the plug. No plug adapter should be used with
this appliance.
GROUNDING INSTRUCTIONS
This appliance must be connected to a grounded
wiring system. If it should malfunction or break
down, grounding provides a safe path of least
resistance for electrical current, reducing the risk
of electrical shock. The cord for this appliance
has an equipment-grounding conductor and a
grounding plug. It must only be plugged into an
outlet that is properly installed and grounded in accordance with all local
codes and ordinances.
Grounded
Outlets
Grounding
Pin
Warranty
2-Year limited warranty, may vary by state. Visit support.BISSELL.com or call 1-800-237-7691
for complete warranty information.

BISSELL.com 3
Base Handle Screws Tool Holders Tough Stain
Tool
Spraying
Crevice Tool
Trial-Size
BIS S E L L®
Formula
What’s in the Box?
Standard accessories may vary by model.To identify what should be included with your purchase,
please refer to the “Carton Contents” list located on the carton top flap.
Assembly
Go to support.BISSELL.com for assembly videos.
1. Slide Upper Handle onto
lower base and secure with
two long screws (taped to
Upper Handle) into marked
holes.
2. Attach upper hose/cord
wrap to the back of the handle
by inserting hook into the
slot and pressing up until it’s
seated flush with the back of
the machine. Use 1 short screw
to secure the bottom of the
wrap to the machine.
3. Attach lower hose/cord
wrap by inserting the hook into
the slot and pressing up until
it’s seated flush with the back
of the machine. Use 2 short
screws to secure the bottom
hose/cord wrap.
4. Wrap hose around both
hose/cord wraps. Secure it by
inserting the trigger hose grip
into opening on the grip holder
on the upper hose/cord wrap.
5. Wrap cord around lower
and upper hose/cord wraps.
Secure plug to cord with clip
on plug.
6. Attach included tools to the
appropriate storage locations
on the machine (varies by
model).
Required for Assembly
Phillips-head Screwdriver

4BISSELL.com
Cleaning Formulas
Find more formulas at BISSELL.com.
WARNING
»To reduce the risk of fire and electric shock due to internal component damage, use only BISSELL cleaning formula intended for
use with this machine.
»To reduce the risk of fire and electric shock when cleaning a hard floor, the BISSELL bare floor tool must be used and is only to be
used with BISSELL Hard Floor Solutions formula intended for use with this appliance.
Clean + Refresh
Powerful cleaning and odor
elimination with Febreze
freshness
PET Stain & Odor
Removes tough pet stains
Includes StainProtect™to
protect against future
stains
PRO MAX
Clean + Protect
Our most powerful formula
for tough, ground-in dirt
& stains
Includes StainProtect to
protect against future
stains
PET PRO OXY Urine
Eliminator
Our best formula for pet
urine stains & odors
Includes StainProtect to
protect against future
stains
Certain trademarks used under license from The Procter & Gamble Company or its affiliates.
Keep plenty of BISSELL® formulas on hand so you can clean whenever it fits your schedule. Always
use genuine BISSELL formulas in your machine. Other formulas may harm the machine and void the
warranty. Do not use Hard Floor Formula on area rugs or carpet.
OXY Boost
Removes old, set-in
stains
PRO MAX Boost
Add to formula for
2X deep cleaning
power
PET OXY Boost
Removes pet stains
and odors
PET Stain
Pretreat
Removes tough pet
stains & odors with
Enzyme Action
PET PRO OXY
Stain Destroyer
Removes tough pet
stains & odors with
OXY
Pretreat
Pretreat spots and stains to improve
carpet cleaning performance.
Boost
Add Boost carpet cleaning formula enhancers to
any formula to increase its effectiveness.

BISSELL.com 5
Note: Fill with warm (140°F/60°C MAX) tap water and add the appropriate BISSELL® formula. Do not
use boiling water. Do not heat water or tank in microwave.
1. Use Tank Carry Handle to
remove tank from the machine
and bring it to the sink.
2. Pull up on the bottom edge
of the latch on the tank to
remove the lid.
3. Pull up on bladder fill cover
that says “Fill Here”.
4. Fill tank with warm
(60°C/140°F MAX) tap water
to the water fill line. Do not
boil or microwave water as it
can destroy the tank.
5. Fill the provided measuring
cup with formula to the fill line
and pour into the bladder.
6. Push down on bladder fill
cover to close.
7. Replace the tank lid and latch. 8. Place tank into machine
base and seat firmly into place.
Filling the 2-in-1 Water Tank
More of a visual person? We’ve got video instructions for this step at support.BISSELL.com.
