BJM Pumps J400 Instruction manual

Version 7-11-16
INSTALLATION, OPERATION & MAINTENANCE MANUAL
J & JX SERIES
SIDE DISCHARGE
Electric Submersible Pumps
Single Phase
115 & 230V
Three Phase
208V, 230V, 460V & 575V
UUCAST IRONUU
UUSINGLE PHASEUU
UUTHREE PHASEUU
J400
J750
J1500
J1500H
J08
J15
J22
J37
J55C
J75C
J15H
J22H
J37H
J55CH
J75CH
U316 STAINLESS STEELU
UUSINGLE PHASEUU
UUTHREE PHASEUU
JX400SS
JX750SS
JX1500SS
JX1500HSS
JX08SS
JX15SS
JX22SS
JX37SS
JX55CSS
JX75CSS
JX15HSS
JX22HSS
JX37HSS
JX55CHSS
JX75CHSS
Read this manual carefully before installing, operating or servicing these pump models.
UUObserve all safety information.UU Failure to comply with instructions may result in
personal injury and/or property damage. Please retain these instructions.

TABLE OF CONTENTS
INTRODUCTION.............................................................................................................................................................................................4
SAFETY..........................................................................................................................................................................................................5
INSPECTION..................................................................................................................................................................................................6
PRE-INSTALLATION INSPECTION............................................................................................................................................................ 6
OIL FILL QUANTITY/TYPE......................................................................................................................................................................... 7
PUMP INSTALLATION............................................................................................................................................................................... 8
POSITIONING THE PUMP......................................................................................................................................................................... 8
PUMP ROTATION...................................................................................................................................................................................... 9
PUMP OPERATION...................................................................................................................................................................................10
TYPICAL MANUAL DEWATERING-EFFLUENT INSTALLATION .................................................................................................................10
TYPICAL AUTOMATIC DEWATERING-EFFLUENT INSTALLATION ...........................................................................................................11
INTENDED METHODS OF CONNECTION...................................................................................................................................................12
SINGLE PHASE WIRING INSTRUCTIONS...............................................................................................................................................13
THREE PHASE WIRING INSTRUCTIONS................................................................................................................................................13
TROUBLE SHOOTING .................................................................................................................................................................................14
PUMP WILL NOT RUN..............................................................................................................................................................................14
PUMP RUNS BUT DOES NOT DELIVER RATED CAPACITY........................................................................................................................5
SERVICING YOUR SUBMERSIBLE PUMP................................................................................................................................................ 5
MAINTAINING YOUR PUMP...................................................................................................................................................................... 5
CHANGING SEAL OIL................................................................................................................................................................................ 5
EXPLODED VIEW OF J400, JX400SS..........................................................................................................................................................15
EXPLODED VIEW OF J750, J1500, J1500H.................................................................................................................................................16
EXPLODED VIEW OF J08, J15, J15H..........................................................................................................................................................17
EXPLODED VIEW OF J22, J22H, J37, J37H,...............................................................................................................................................18
EXPLODED VIEW OF J55C, JX55CSS, J55CH, JX55CHSS, J75C, JX75CSS, J75CH, JX75CHSS ............................................................19
EXPLODED VIEW OF JX750SS, JX1500SS, JX1500HSS (PRECISION CAST MODELS)...........................................................................20
EXPLODED VIEW OF JX08SS, JX15SS, JX15HSS (PRECISION CAST MODELS) ....................................................................................21
EXPLODED VIEW OF JX22SS, JX37SS (PRECISION CAST MODELS)......................................................................................................22
J SERIES PARTS LIST.................................................................................................................................................................................23
JX PRECISION CAST PARTS LIST..............................................................................................................................................................25
SINGLE PHASE WIRING DIAGRAM 115V & 230V W/O GOVERNOR SWITCH...........................................................................................27
MODELS J400, JX400SS.....................................................................................................................................................................27
MODELS J750, JX750, J1500, JX1500H, JX1500HSS.........................................................................................................................28
THREE PHASE WIRING DIAGRAM .............................................................................................................................................................29
208V..........................................................................................................................................................................................................29
MODELS J08, JX08SS, J15, JX15SS, J15H, JX15HSS, J22, JX22SS, J22H, JX22HSS, J37. JX37SS, J37H, J37HSS, J55C, J55CSS,
J55CH, J55CHSS, J75C, JX75CSS, J75CH, J75CHSS........................................................................................................................29
230V..........................................................................................................................................................................................................30
MODELS J08, JX08SS, J15, JX15SS, J15H, JX15HSS, J22, JX22SS, J22H, JX22HSS, J37. JX37SS, J37H, J37HSS, J55C, J55CSS,
J55CH, J55CHSS, J75C, JX75CSS, J75CH, J75CHSS........................................................................................................................30
460V..........................................................................................................................................................................................................31
MODELS J08, JX08SS, J15, JX15SS, J15H, JX15HSS, J22, JX22SS, J22H, JX22HSS, J37, JX37SS, J37H,J37HSS, J55C, J55CSS,
J55CH, J55CHSS, J75C, JX75CSS, J75CH, J75CHSS........................................................................................................................31
575V..........................................................................................................................................................................................................32
MODELS J08, JX08SS, J15, JX15SS, J15H, JX15HSS, J22, JX22SS, J22H, JX22HSS, J37. JX37SS, J37H, J37HSS, J55C, J55CSS,
J55CH, J55CHSS, J75C, JX75CSS, J75CH, J75CHSS........................................................................................................................32
SEAL MINDER®...........................................................................................................................................................................................33
WARRANTY AND LIMITATION OF LIABILITY..............................................................................................................................................35
START-UP REPORT FORM.........................................................................................................................................................................36
NOTES:.........................................................................................................................................................................................................39

4
INTRODUCTION
This Installation, Operation and Maintenance manual provides important information on safety
and the proper inspection, disassembly, assembly and testing of the BJM Pumps® J & JX
Series submersible pump. This manual also contains information to optimize performance and
longevity of your BJM Pumps submersible pump.
The submersible J Series pumps are designed to pump water and municipal/industrial
effluent wastewater. The JX Series pumps are designed to pump corrosive liquids in
concentrations chemically compatible with 316SS and FKM. The J & JX Series pumps are
not explosion proof. They are not designed to pump volatile or flammable liquids.
Note: Consult chemical resistance chart for compatibility between pump materials and
liquid before operating pump.
If you have any questions regarding the inspection, disassembly, assembly or testing please
contact your BJM Pumps distributor, or BJM Pumps, LLC.
BJM Pumps, LLC
123 Spencer Plain Rd.
Old Saybrook, CT 06475, USA
Fax: [phone]
Phone: [phone]
Phone: [phone]
Information, including pump data sheets and performance curves, is also available on
our web site: HHUUwww.bjmpumps.comUU
For assistance with your electric power source, please contact a certified electrician.
Please pay attention to the following alert notifications. They are used to notify
operators and maintenance personnel to pay special attention to procedures, to avoid
causing damage to the equipment, and to avoid situations that could be dangerous to
personnel.
NOTE: Instructions to aid in installation, operation, and maintenance or which
clarify a procedure.
Immediate hazards that WILL result in severe personal injury or
death. These instructions describe the procedure required and the injury which will
result from failure to follow the procedure.
Hazards or unsafe practices that COULD result in severe personal
injury or death. These instructions describe the procedure required, and the injury which
could result from failure to follow the procedure.
Hazards or unsafe practices which COULD result in personal injury
or product or property damage. These instructions describe the procedure required and
the possible damage which could result from failure to follow the procedure.

5
SAFETY
Pump installations are seldom identical. Each installation and application can vary due
to many different factors. It is the owner/service mechanics responsibility to repair,
service, and test to ensure that the pump integrity is not compromised according to this
manual.
Risk of electric shock –this pump has not been investigated for use
in swimming pool areas.
Do not pump flammable, inflammable or volatile liquids. UUDeath
or serious injury will result.
Before attempting to open or service the pump:
1) Familiarize yourself with this manual.
2) Unplug or disconnect the pump power cable to ensure that the pump will remain
inoperative.
3) Allow the pump to cool if overheated.
Do not operate the pump with a worn or damaged electric power
cable. Death or serious injury could occur.
Never attempt to alter the length or repair any power cable with a
splice. The pump motor and pump motor and cable must be completely waterproof.
Damage to the pump or personal injury may result from alterations.
After the pump has been installed, make sure that the pump and all
piping are secure before operation.
Do not lift the pump by the power cable piping or discharge hose.
Attach proper lifting equipment to the lifting handle (or lifting rings) fitted to the pump. Do
not suspend the pump by the power cable.
Obtain the services of a qualified electrician to troubleshoot, test
and/or service the electrical components of this pump.
Pumps and related equipment must be installed and operated
according to all national, local and industry standards.

6
INSPECTION
Review all safety information before servicing pump.
The following are recommended installation practices/procedures for the pump. If there
are questions in regards to your specific application, contact your local BJM Pumps
distributor or BJM Pumps, LLC.
PRE-INSTALLATION INSPECTION
1) Check the pump for damage that may have occurred during shipment.
2) Inspect the pump for any cracks, dents, damaged threads, etc.
3) Check power cord (and Seal Minder® cord, if installed) for any cuts or damage.
4) Check for, and tighten any hardware that appears loose.
5) Carefully read all tags, decals and markings on the pump.
If anything appears to be abnormal, contact your BJM Pumps distributor or BJM
Pumps, LLC. If damaged, the pump may need to be repaired before use. Do not install
or use the pump until appropriate action has been taken.
Lubrication:
No additional lubrication is necessary. The shaft seal and bearings are fully lubricated
from the factory. Seal oil should be checked once per year. See table below.

7
Note: For EPDM seals propylene glycol is used in the seal chamber
OIL FILL QUANTITY/TYPE
Qty. oil in seal chamber
Models
U.S. fl. oz.
C.C.
Type of oil
J400
5.1
150
ISO 32 NSF Food Mineral Grade
J750
9
265
ISO 32 NSF Food Mineral Grade
J1500
9
265
ISO 32 NSF Food Mineral Grade
J08
9
265
ISO 32 NSF Food Mineral Grade
J15
9
265
ISO 32 NSF Food Mineral Grade
J22
10.8
320
ISO 32 NSF Food Mineral Grade
J37
10.8
320
ISO 32 NSF Food Mineral Grade
J55C
45.6
1350
ISO 32 NSF Food Mineral Grade
J75C
45.6
1350
ISO 32 NSF Food Mineral Grade
Qty. oil in seal chamber
Models
U.S. fl. oz.
C.C.
U.S. fl. oz.
J1500H
9
265
ISO 32 NSF Food Mineral Grade
J15H
9
265
ISO 32 NSF Food Mineral Grade
J22H
10.8
320
ISO 32 NSF Food Mineral Grade
J37H
10.8
320
ISO 32 NSF Food Mineral Grade
J55CH
45.6
1350
ISO 32 NSF Food Mineral Grade
J75CH
45.6
1350
ISO 32 NSF Food Mineral Grade
Qty. oil in seal chamber
Models
U.S. fl. oz.
C.C.
Type of oil
JX400SS
5.1
150
ISO 32 NSF Food Mineral Grade
JX750SS
10.1
300
ISO 32 NSF Food Mineral Grade
JX1500SS
10.1
300
ISO 32 NSF Food Mineral Grade
JX08SS
10.1
300
ISO 32 NSF Food Mineral Grade
JX15SS
10.1
300
ISO 32 NSF Food Mineral Grade
JX22SS
13.5
400
ISO 32 NSF Food Mineral Grade
JX37SS
13.5
400
ISO 32 NSF Food Mineral Grade
JX55CSS
45.6
1350
ISO 32 NSF Food Mineral Grade
JX75CSS
45.6
1350
ISO 32 NSF Food Mineral Grade
Qty. oil in seal chamber
Models
U.S. fl. oz.
C.C.
Type of oil
JX1500HSS
10.1
300
ISO 32 NSF Food Mineral Grade
JX15HSS
10.1
300
ISO 32 NSF Food Mineral Grade
JX22HSS
13.5
400
ISO 32 NSF Food Mineral Grade
JX37HSS
13.5
400
ISO 32 NSF Food Mineral Grade
JX55CHSS
45.6
1350
ISO 32 NSF Food Mineral Grade
JX75CHSS
45.6
1350
ISO 32 NSF Food Mineral Grade

8
PUMP INSTALLATION
J & JX Series pumps have been evaluated for use with water or water based solutions.
Please contact the manufacturer for additional information.
Risk of electric shock. Pump models; J400, JX400, J750 &
JX750 (115v) are supplied with a grounding conductor and grounding-type attachment
plug. Pump models 230V single phase pumps and all three phase pumps do not come
with electric plug connectors. To reduce the risk of electric shock, be certain that it is
connected only to a properly grounded, grounding-type receptacle.
Lifting:
Attach a rope or lifting chain (not included) to the handle (or lifting rings) on the top of
the pump.
Do not lift the pump by the power cable or discharge hose/piping.
Proper lifting equipment (rope/chain) must be used.
POSITIONING THE PUMP
BJM Pumps, J & JX Series pumps are designed to operate fully or partially submerged.
Do not run the pump dry. Refer to data sheet for minimum submersion depth for your
particular model. Data sheets can be obtained online at HHUUwww.bjmpumps.comUUHH or by
calling BJM Pumps, LLC at 860-399-5937. As a general rule, J and JX Series side
discharge pumps can pump down to a level above the suction screen. Pumping lower
than screen will permit air to enter the pump and cavitate, lose prime or become air
bound.
Do not run the pump dry.
Pump liquid should not exceed a maximum temperature of 104°F.
Never place the pump on loose or soft ground. The pump may sink, preventing
water from reaching the impeller. Place on a solid surface or suspend the pump
with a lifting rope/chain. The J & JX Series pumps are provided with a suction
strainer to prevent large solids from clogging the impeller. Any spherical solids
which pass through the strainer should pass through the pump.
For maximum pumping capacity, use the proper size non-collapsible hose or rigid
piping. A check valve may be installed after the discharge to prevent back flow
when the pump is shut off.

9
PUMP ROTATION
Two ways to check the correct pump rotation:
1. By looking at the impeller; the rotation of the impeller should be counter
clockwise as shown in the picture below.
2. By looking from the top of the pump. Since the impeller cannot be seen, the best
way to check the rotation is to check the kick back motion of the pump when the
pump just starts. The kick back motion of the pump should be counter clockwise
as shown in the picture below.

10
PUMP OPERATION
This pump is designed to handle dirty water that contains some
solids. It is not designed to pump volatile or flammable liquids. Do not attempt to pump
any liquids which may damage the pump or endanger personnel as a result of pump
failure.
Do not operate this pump where explosive vapors or
flammable material exist. Death or Serious injury will result.
TYPICAL MANUAL DEWATERING-EFFLUENT INSTALLATION
NOTE: Maximum recommended starts should not exceed 10 times per hour.
All J & JX models are provided with a 33” (10m) power cord (exception; J1500, JX1500,
J1500H) are supplied with a 50’ (15m) power cord. UUNEVERUU splice the power cable due
to safety and warranty considerations. Always keep the plug end dry.
Note: 230V, single phase and 208V, 230V, 460V & 575V three phase units do not
have a plug and have to be provided separately.
Do not alter the length or repair any power cable with a splice. The
pump motor and cable must be completely waterproof. Damage to the pump or
personal injury may result from alterations.
For manual operation: 115 volt: plug the power cable into any 115 volt grounded
receptacle. 208, 230, 460 & 575 volt: Attach the proper plug, connect directly to the
power source or control box. Check the direction of the rotation. Tilt the pump and start
it. It should twist in the opposite direction of the arrow (on pump). It is recommended
that a Ground Fault Interrupter (GFI) type receptacle (or equivalent) be used.

11
Single phase pumps always use a three-prong grounded
receptacle. It is recommended that a Ground Fault Interrupter (GFI) type receptacle (or
equivalent) be used.
STOPPING
To stop the pump (manual and automatic mode), unplug it from the power source, turn
off the breaker, or turn the power source off (generator).
TYPICAL AUTOMATIC DEWATERING-EFFLUENT INSTALLATION
NOTE: Maximum recommended starts should not exceed 10 times per hour.
Float switches (wired into the pump motor or piggy-back style) are available from the
factory as an option.
Note: 208, 230V 460V & 575V pumps do not have a plug installed.
Three phase pumps need a separate control box with float(s) for automatic
operation.

12
STOPPING
To stop the pump (manual and automatic mode), unplug it from the power source, turn
off the breaker, or turn the power source off
(generator).
Typical 3 phase manual control 1
INTENDED METHODS OF CONNECTION
Use with approved motor control that matches motor input in full
load amperes. “UTILLISER UN DÉMARREAR APPROUVÉ CONVENANT AU
COURANT Á PLEINE CHARGE DU MOTEUR.”
BJM Pumps has been evaluated for use with water or water based solutions. Please
contact the manufacturer for additional information.

13
SINGLE PHASE WIRING INSTRUCTIONS
FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP
FROM ITS POWER SOURCE BEFORE HANDLING. Single phase pumps are supplied
with a three prong grounded plug to help protect you against the possibility of electrical
shock. DO NOT UNDER ANY CIRCUMSTANCES REMOVE THE GROUND PIN. The
three prong plug must be inserted into a mating three prong grounded receptacle. IF
the installation does not have such a receptacle it must be changed to the proper type,
wired and grounded in accordance with the National Electrical Code and all applicable
local codes and ordinances
“Risk of electrical shock” Do not remove power supply cord and
strain relief or connect conduit directly to the pump.
Installation and checking of electrical circuits and hardware should
be performed by a qualified licensed electrician.
THREE PHASE WIRING INSTRUCTIONS
FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP
FROM ITS POWER SOURCE BEFORE HANDLING.
Typical 3 phase Auto Control 1

14
“Risk of electrical shock” Do not remove power supply cord and
strain relief or connect conduit directly to the pump.
Installation and checking of electrical circuits and hardware should
be performed by a qualified licensed electrician.
To automatically operate a non-automatic three phase pump, a control panel is
required. UUFollow the instructions provided with the panel to wire the system.U U For
automatic three phase pumps see automatic three phase wiring diagram.
Before installing a pump, check the pump rotation to insure that wiring has been
connected properly to power source, and that the green lead of power cord (See wiring
diagram), is connected to a valid ground, momentarily energize the pump, observing the
directions of kick back due to starting torque. Rotation is correct if kick back is in the
opposite direction of rotation arrow on the pump casing. If rotation is not correct,
switching of any two power leads other than ground will provide the proper rotation.
Three phase pumps have integral motor overload protection. It is recommended that all
three phase pumps using a motor starting device also incorporate motor overload
protection. Pumps must be installed in accordance with the National Electrical Code
and all applicable local codes and ordinances. Pumps are not to be installed in locations
classified as hazardous in accordance with National Electrical Code, ANSI/NFPA 70.
Connect pump to a junction box, outlet box, control box, enclosure with a wiring
compartment that meets NEC and local electrical codes. The provision for supply
connection shall reduce the risk of water entry during temporary, limited submersion
and shall comply with the applicable requirements of the Standard for Enclosures for
Electrical Equipment, UL 50, or the standard for Metallic Outlet Boxes, UL 514A, and
the standard for Motor-Operated Water Pumps. UL 778.
TROUBLE SHOOTING
Disconnect the power source to the pump BEFORE attempting
any type of trouble shooting, service or repair.
PUMP WILL NOT RUN
1. Check power supply (fuses, breaker).
Reset power.
2. Blocked impeller. Remove strainer,
check and clean.
3. Defective cable or incorrect wiring.
4. Strainer clogged. Check and clean as
necessary.
5. Float switch tangled/obstructed.
Clean and free float switch from
obstruction.
6. Float switch defective. Replace float
switch.
7. Pump overheated or temperature of
liquid exceeds pump operating
temperature.

5
UUWarning: Pump will restart automatically when motor over-heat protection switch
cools.
PUMP RUNS BUT DOES NOT DELIVER RATED CAPACITY
1. Discharge line clogged, restricted or
hose kinked. Check discharge
hose/pipe.
2. Worn impeller and/or suction cover.
Inspect and replace as necessary.
3. Pump overloaded due to liquid pumped
being too thick.
4. Pumping air. Check liquid level and
position of pump.
5. Excessive voltage drops due to long
cables.
6. Three phase only; pump running
backwards, check rotation.
SERVICING YOUR SUBMERSIBLE PUMP
Pump should be disconnected from the electric power supply before proceeding to do
any service or maintenance.
To service or repair your pump, please contact your local BJM Pumps distributor.
Service should only be performed by a qualified electrician.
MAINTAINING YOUR PUMP
Pump should be disconnected from the electric power supply before proceeding to
do any service or maintenance.
Pump should be inspected at regular intervals.
More frequent inspections are required if the pump is used in a harsh environment.
Preventative maintenance should be performed to reduce the chance of premature
failure.
Worn impellers and lip seals should be replaced.
Cut or cracked power cords must be replaced. (Never operate a pump with a cut,
cracked or damaged power cord.)
Seal oil should be checked once per year.
Maintenance should always be done when taking a pump out of service before
storage. 1) Clean pump of dirt and other build up.
2) Check condition of oil around the shaft seals.
3) Check hydraulic parts: check for wear.
4) Inspect power cable. Make sure that it is free of nicks or cuts.
CHANGING SEAL OIL
Changing the seal oil in the J & JX Series pumps is very easy.
1) Make sure that the pump cable is
disconnected from the power source.
2) Lay the pump down on its side.
3) Remove the screws that hold the
bottom plate in place.
4) Remove bottom plate.
5) Remove screws holding the suction
cover.
6) Remove the suction cover.
7) Remove the impeller.
8) Remove the inspection screw for the oil
chamber (pos#50-08). Pour out a small

5
sample of the oil. If it is milky white, or
contains water, then the oil and
possible, the mechanical seal, should
be changed. If an oil change is needed:
9) Remove the screws that hold the oil
chamber cover in place & remove the
oil.
10)Replace the mechanical seal if
necessary.
11)Replace the oil.
12)Assemble the pump.

15
EXPLODED VIEW OF J400, JX400SS

16
EXPLODED VIEW OF J750, J1500, J1500H

17
EXPLODED VIEW OF J08, J15, J15H

18
EXPLODED VIEW OF J22, J22H, J37, J37H

19
EXPLODED VIEW OF J55C, JX55CSS, J55CH, JX55CHSS, J75C, JX75CSS, J75CH,
JX75CHSS
