Black & Decker BDP2600 User manual

VEA EL ESPAÑOL EN LA CONTRAPORTADA.
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO
Y PÓLIZA DE GARANTÍA. ADVERTENCIA: LÉASE ESTE
INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
INSTRUCTION MANUAL
Pressure Washer
Catalog Number BDP2600
Th a n k y o u f o r c h o o s i n g Bl a c k & De c k e r !
goT o w w w .Bl a c k a n D De c k e r .c o m /ne w ow n e r
T o r e g i s T e r y o u r n e w p r o D u c T .
Cat No. BDP2600 Part No. N051884 Rev. 1
Copyright © 2010 Black & Decker
SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE.

2- ENG
SAFETY GUIDELINES - DEFINITIONS
This manual contains information that is important for you to know and under-
stand. This information relates to protecting YOUR SAFETY and PREVENTING
EQUIPMENT PROBLEMS. To help you recognize this information, we use the sym-
bols below. Please read the manual and pay attention to these symbols.
DANGER: Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION:Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury which, if not avoided,
may result in property damage.
CONSUMER SAFETY INFORMATION
WARNING: This product may not be equipped with a spark arresting
muffler. If the product is not equipped and will be used around flammable
materials, or on land covered with materials such as agricultural crops, forest,
brush, grass, or other similar items, then an approved spark arrester must
be installed and is legally required in the state of California. It is a violation
of California statutes section 130050 and/or sections 4442 and 4443 of the
California Public Resources Code, unless the engine is equipped with a spark
arrester, as defined in section 4442, and maintained in effective working order.
Spark arresters are also required on some U.S. Forest Service land and may
also be legally required under other statutes and ordinances.
WARNING: This product contains chemicals known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash
hands after handling.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Do not operate this unit until you have read and understand this
Operators Manual and the Engine Owners Manual for Safety, Operation, and
Maintenance Instructions.
read and save these instructions
DANGER: RISK OF EXPLOSION OR FIRE
WHAT CAN HAPPEN HOW TO PREVENT IT
• Spilled gas o line and it’s vapors
can become ignited from cigarette
sparks, electrical arcing, exhaust
gases and hot engine components
such as the muffler.
• Shut off en gine and allow it to cool
before adding fuel to the tank.
• Use care in fill ing tank to avoid
spilling fuel. Move pressure washer
away from fueling area before
starting engine.

3- ENG
• Heat will ex pand fuel in the tank
which could result in spillage and
possible fire explosion.
• Fill tank to 1/2 inch (12.7 mm) below
bottom of filler neck to provide space
for fuel expansion.
• Operating the pressure washer in
an explosive environment could
result in a fire.
• Operate and fuel equipment in
well-ventilated areas free from
ob struc tions. Equip areas with fire
extinguisher suitable for gasoline
fires.
• Materials placed against or near
the pressure washer can interfere
with its proper ventilation features
causing overheating and possible
ignition of the materials.
• Never op er ate pressure wash er in
an area containing dry brush or
weeds.
• Muffler exhaust heat can damage
painted surfaces, melt any material
sensitive to heat (such as siding,
plastic, rubber, vinyl or the pressure
hose, itself), and damage live
plants.
• Always keep pressure washer a min
imum of 4 feet (1.2 m) away from
surfaces (such as houses, automo-
biles or live plants) that could be
damaged from muffler exhaust heat.
• Improperly stored fuel could lead
to accidental ignition. Fuel improp-
erly secured could get into the
hands of children or oth er un qual
ified persons.
• Store fuel in an OSHAap proved
container, in a secure location away
from work area.
• Use of acids, toxic or cor ro sive
chemicals, poisons, insecticides, or
any kind of flammable solvent with
this product could result in serious
injury or death.
• Do not spray flammable liquids
DANGER: RISK TO BREATHING (ASPHYXIATION)
WHAT CAN HAPPEN HOW TO PREVENT IT
• Breathing ex haust fumes will cause
serious injury or death! Engine
exhaust contains carbon monox-
ide, an odorless and deadly gas.
• Operate pressure washer in a well
ventilated area. Avoid enclosed
areas such as garages, basements,
etc.
• Never op er ate unit in a lo ca tion
occupied by humans or animals.
• Some clean ing fluids con tain sub
stances which could cause injury to
skin, eyes or lungs.
• Use only clean ing fluids spe cif i cal
ly recommended for high-pressure
washers. Follow manufacturers
recommendations. Do not use
chlorine bleach or any other
corrosive compound.

4- ENG
DANGER: RISK OF FLUID INJECTION AND LACERATION
WHAT CAN HAPPEN HOW TO PREVENT IT
• Your pressure washer operates at
fluid pressures and velocities high
enough to penetrate human and
animal flesh, which could result in
amputation or other serious injury.
Leaks caused by loose fittings or
worn or damaged hoses can result
in injection injuries. DO NOT TREAT
FLUID INJECTION AS A SIMPLE
CUT! See a physician immediately!
• Inspect the highpressure hose
regularly. Replace the hose
immediately if it is damaged, worn,
has melted from contacting the
engine, or shows any signs of cracks,
bubbles, pinholes, or other leakage.
Never grasp a high-pressure hose
that is leaking or damaged.
• Never touch, grasp or attempt to
cover a pinhole or similar water
leak on the high-pressure hose.
The stream of water IS under high
pressure and WILL penetrate skin.
• Never place hands in front of
nozzle.
• Direct spray away from self and
others.
• Make sure hose and fit tings are
tightened and in good condition.
Never hold onto the hose or fittings
during operation.
• Do not allow hose to contact
muffler.
• Never attach or remove wand
or hose fittings while system is
pressurized.
• Injuries can result if system pressure
is not reduced before attempting
maintenance or disassembly.
• To relieve sys tem pres sure, shut off
engine, turn off water supply and
pull gun trigger until water stops
flowing.
• Use only hoses and accessories
rated for pressure higher than your
pressure washer's psi.
DANGER: RISK OF INJURY FROM SPRAY
WHAT CAN HAPPEN HOW TO PREVENT IT
• Highvelocity fluid spray can cause
objects to break, propelling particles
at high speed.
• Light or unsecured objects can
become hazardous projectiles.
• Always wear ANSIapproved Z87.1
safety glasses. Wear protective
clothingtoprotectagainstaccidental
spraying.
• Never point wand at or spray people
or animals.
• Always secure trigger lock when
wand is not in service to prevent
accidental operation.
• Never permanently secure trigger in
pull-back (open) position.

5- ENG
DANGER: RISK OF UNSAFE OPERATION
WHAT CAN HAPPEN HOW TO PREVENT IT
• Unsafe op er a tion of your pressure
washer could lead to serious injury
or death to you or others.
• Do not use chlorine bleach or any
other corrosive compound.
• Be come fa mil iar with the op er a
tion and controls of the pressure
washer.
• Keep operating area clear of all
persons, pets and obstacles.
• Do not operate the product when
fatigued or under the influence of
alcohol or drugs. Stay alert at all
times.
• Never defeat the safety fea tures of
this product.
• Do not op er ate machine with
missing, broken or unauthorized
parts.
• Never leave wand unattended while
unit is running.
• If proper starting procedure is not
followed, engine can kickback
causing serious hand and arm
injury.
• If engine does not start after two
pulls, squeeze trigger of gun to
relieve pump pressure. Pull starter
cord slowly until resistance is felt.
Then pull cord rapidly to avoid
kickback and prevent hand or arm
injury.
• The spray gun/wand is a powerful
cleaning tool that could look like a
toy to a child.
• Keep chil dren away from the
pressure washer at all times.
• Reactive force of spray will cause
gun/wand to kickback, and could
cause the operator to slip or fall
or misdirect the spray. Improper
control of gun/wand can result in
injuries to self and others.
• Do not over reach or stand on an
unstable support.
• Do not use pressure washer while
standing on a ladder.
• Grip gun/wand firmly with both
hands. Expect the gun to kickback
when triggered.

6- ENG
DANGER: RISK OF INJURY OR PROPERTY DAMAGE WHEN
TRANSPORTING OR STORING
WHAT CAN HAPPEN HOW TO PREVENT IT
• Fuel or oil can leak or spill and could
result in fire or breathing hazard.
Serious injury or death can result.
Fuel or oil leaks will damage carpet,
paint or other surfaces in vehicles or
trailers.
• If pressure washer is equipped with
a fuel shut-off valve, turn the valve to
the OFF position before transporting
to avoid fuel leaks. If pressure wash-
er is not equipped with a fuel shut
off valve, drain the fuel from tank
before transporting. Only transport
fuel in an OSHAapproved container.
Always place pressure washer on a
protective mat when transporting to
protect against damage to vehicle
from leaks. Remove pressure washer
from vehicle immediately upon arrival
at your destination.
WARNING: RISK OF BURSTING
WHAT CAN HAPPEN HOW TO PREVENT IT
• Over inflation of tires could result
in serious injury and property
damage.
• Use a tire pressure gauge to check
the tires pressure before each use
and while inflating tires; see the tire
sidewall for the correct tire pressure.
NOTE: Air tanks, compressors and
similar equipment used to inflate tires
can fill small tires similar to these very
rapidly. Adjust pressure regulator on
air supply to no more than the rating
of the tire pressure. Add air in small
increments and frequently use the
tire gauge to prevent over inflation.
• Highvelocity fluid spray directed at
pneumatic tire sidewalls (such as
found on automobiles, trailers and
the like) could damage the sidewall
resulting in serious injury.
• On pressure washers rated above
1600 PSI (110 Bar) use the wid-
est fan spray (40º nozzle) and keep
the spray a minimum of 8" (20 cm)
from the pneumatic tire sidewall. Do
not aim spray directly at the joint
between the tire and rim.
WARNING: RISK OF HOT SURFACES
WHAT CAN HAPPEN HOW TO PREVENT IT
• Con tact with hot sur fac es, such
as engines exhaust components,
could result in serious burn.
• During op er a tion, touch only the
control surfaces of the pressure
washer. Keep children away from
the pressure washer at all times.
They may not be able to recognize
the hazards of this product.

7- ENG
WARNING: RISK OF CHEMICAL BURN
WHAT CAN HAPPEN HOW TO PREVENT IT
• Use of acids, toxic or cor ro sive
chemicals, poisons, insecticides, or
any kind of flammable solvent with
this product could result in serious
injury or death.
• Do not use ac ids, gasoline, ker
osene, or any other flammable
materials in this product. Use only
household detergents, cleaners and
degreasers recommended for use in
pressure washers.
• Wear pro tec tive clothing to protect
eyes and skin from contact with
sprayed materials.
WARNING: RISK OF ELECTRICAL SHOCK
WHAT CAN HAPPEN HOW TO PREVENT IT
• Spray di rect ed at elec tri cal outlets or
switches, or objects connected to
an electrical circuit, could result in
a fatal electrical shock.
• Unplug any elec tri cal ly op er at ed
product before attempting to clean
it. Direct spray away from electric
outlets and switches.
WARNING: RISK OF INJURY FROM LIFTING
WHAT CAN HAPPEN HOW TO PREVENT IT
• Serious injury can result from
attempting to lift too heavy an
object.
• The pressure washer is too heavy
to be lifted by one person. Obtain
assistance from others before
lifting.
read and save these instructions
NOTE: Photographs and line drawings used in this manual are for reference only
and do not represent a specific model.

8- ENG
GET TO KNOW THE
PRESSURE WASER
Compare the illustrations with your unit
to familiarize yourself with the location
of various controls and adjustments.
Save this manual for future reference.
D
O
N
H
I
J
C
A
Q
L
K
B
G
E
F
M
A. Quick Connect Nozzles
B. Nozzle Holder
C. Handle
D. High Pressure Hose: Carries the
pressurized water from the pump
to the gun and spray wand.
E. Pump Outlet
F. Pump Inlet
G. High Pressure Pump: Increases
the pressure of the water supply.
H. Engine ON/OFF Switch: Enables
and disables ignition system.
I. Engine: Drives the high pressure
pump. Refer to the engine manual
for location and operation of engine
controls.
J. Frame
K. Starter Grip: Pulling starter grip
operates recoil starter to crank
engine
L. Choke Control: Opens and closes
carburetor choke valve.
M. Fuel Valve Lever: Opens/closes
connection between fuel tank and
carburetor.
N. QuickConnect Spray Wand:
Allows the user to quickly change
out high-pressure nozzles. Refer to
Spray Wand Nozzles.
O. Spray Gun: Connects with spray
wand to control water flow rate,
direction, and pressure.
P. Chemical Hose (not shown): Feeds
cleaning agents into the pump to
mix with the water. See How To
Apply Chemicals/Cleaning Solvents
instructions in this section.
Q. Gas fill
CARTON CONTENTS
A. Quick Connect Nozzles
B. Nozzle Holder
C. Handle
D. High Pressure Hose
I/J. Engine Frame and Wheel
Assembly
N. Quick Connect Spray Wand
O. Spray Gun
P. Chemical Hose
R. Operation Manual
S. Engine Manual
T. Nozzle Cleaning Tool
U. Bagged Parts
I/J
D
O
N
C
R
U
S
PT
B
A

9- ENG
ASSEMBLY INSTRUCTIONS
1. Locate and remove all loose parts
from the carton.
2. Cut four corners of the carton
from top to bottom and lay the
panels flat.
3. Place handle (C)
onto frame (J),
depress the snap
buttons, and slide
the handle assembly
onto the frame until
snap buttons snap
into place.
CAUTION: Risk of personal injury.
Avoid placing hands between handle
and frame when assembling to pre-
vent pinching.
4. Connect wand (N) to gun (O).
Tighten securely.
5. Attach high
pressure hose
(D) to gun (O).
Tighten
securely.
6. To Assemble Quick Connect
Grommets:
a. Squeeze grommet and place
into hole, fitting groove to rim.
b. Push grommet into place.
c. Repeatstepsuntilallgrommets
are assembled.
7. Remove four colored quick connect
nozzles (A) from plastic bag and
insert them into correct grommet on
the nozzle holder. NOTE: Nozzles
are color coded to match colored
nozzles on panel.
NOTE: The high pressure pump was
filled with oil at the factory. There is
no need to add oil at this time, see the
Maintenance section of this manual
for Maintenance information.
8. Roll the unit off the carton and
discard carton.
WARNING: Risk of bursting. Use a
tire pressure gauge to check the tires
pressure before each use and while
inflating tires; see the tire sidewall for
the correct tire pressure.
NOTE: Air tanks, compressors and
similar equipment used to inflate tires
can fill small tires similar to these very
rapidly. Adjust pressure regulator on
air supply to no more than the rating of
the tire pressure. Add air in small incre-
ments and frequently use the tire gauge
to prevent over inflation.
OPERATING INSTRUCTIONS
PRESSURE WASHER
TERMINOLOGY
PSI: Pounds per Square Inch. The unit of
measure for water pressure. Also used
for air pressure, hydraulic pressure, etc.
GPM: Gallons Per Minute. The unit of
measure for the flow rate of water.
CU: Cleaning Units. GPM multiplied by
PSI. GPM x PSI = CU

10- ENG
Bypass Mode: Allows water to
re-circulate within pump when the gun
trigger is not pulled.
NOTICE: Allowing the unit to run for
more than two minutes without the
gun trigger pulled could cause over-
heating and damage to the pump.
Thermal Relief Valve:
When the temperature
inside the pump rises
too high the valve will
open and release a
gush of water in an
effort to lower the tem-
perature inside the pump. The valve will
then close.
Chemical Injection System: Mixes
cleaners or cleaning solvents with the
water to improve cleaning effectiveness.
Water Supply: All pressure washers must
have a source of water. The minimum
requirements for a water supply are 20 psi
and 5 gallons per minute.
PRESSURE WASHER
OPERATING FEATURES
Pressure Adjustments
The pressure setting is preset at the fac-
tory to achieve optimum pressure and
cleaning. If you need to lower the pres-
sure, it can be accomplished by these
methods.
1. Back away from the surface to be
cleaned. The further away you are,
the less the pressure will be on the
surface to be cleaned.
2. Change to the 40º nozzle - (white)
this nozzle delivers a less powerful
stream of water and a wider spray
pattern.
NOTICE: DO NOT attempt to increase
pump pressure. A higher pressure
setting than the factory set pressure
may damage pump.
Spray Wand Nozzles
The nozzles for the spray wand are
stored in the nozzle holder on the panel
assembly. Colors on the panel identify
nozzle location and spray pattern. Refer
to the following chart to choose the cor-
rect nozzle for the job to be performed.
Changing Nozzles on Spray Wand
DANGER: Risk of fluid injec-
tion. Do not direct discharge stream
toward persons, unprotected skin,
eyes or any pets or animals. Serious
injury will occur.
WARNING: Flying objects could
cause risk of serious injury. Do not
attempt to change nozzles while
pressure washer is running. Turn
engine off before changing nozzles.
Nozzle Color Spray Pattern Uses Surfaces*
Red
0˚ powerful pinpoint
for spot cleaning
of hard, unpainted
surfaces or for high
reach areas
unpainted metal or
concrete;
DO NOT use on wood
Yellow
15˚ intense cleaning
of unpainted hard
surfaces
grills, driveways, concrete
or brick walkways,
unpainted brick or stucco
White
40˚cleaning of painted
or delicate surfaces
Auto/RV, marine, wood,
painted brick and stucco,
vinyl, painted siding
Black
low pressure applies cleaning
solutions
Low pressure spray is safe
on all surfaces. Always
verify compatibility of
cleaning solution prior to
use.

11- ENG
1. Pull quick
connect cou-
pler back and
insert nozzle.
2. Release quick
connect cou-
pler and twist
nozzle to make sure it is secure in
coupler.
WARNING: Flying object could
cause risk of serious injury. Ensure
nozzle is completely inserted in quick-
connect socket and quick-connect
snap ring is fully engaged (forward)
before squeezing gun trigger.
How to Apply Chemicals/cleaning
Solvents
Applying chemicals or cleaning solvents
is a low pressure operation. NOTE: Use
only soaps and chemicals designed
for pressure washer use. Do not use
bleach.
To Apply Chemicals:
1. Press chemical
T
P
hose (P) onto
barbed fitting (T)
located near high
pressure hose
connection of
pump as shown.
2. Place other end of chemical hose
with filter on it into container hold-
ing chemical/cleaning solution.
NOTE: For every 7 gallons of water
pumped 1 gallon of chemical/
cleaning solution will be used.
3. Install low pressure (black) noz-
zle into quick connect fitting of
spray wand, see How To Use
Spray Wand paragraph in this sec-
tion.
4. After use of chemicals, place
chemical hose into container of
clean water and draw clean water
through chemical injection sys-
tem to rinse system thoroughly. If
chemicals remain in the pump it
could be damaged. Pumps dam-
aged due to chemicals will not be
covered under warranty.
NOTE: Chemicals and soaps will not
siphon when spray wand is in the high
pressure setting.
WARNING: To reduce the risk
of injury, read the pressure washer
instruction manual and the engine
instruction manual before starting
pressure washer.
DANGER: Risk of fluid injection
and laceration. When using the high-
pressure setting, DO NOT allow the
high-pressure spray to come in con-
tact with unprotected skin, eyes, or
with any pets or animals. Serious
injury will occur.
• Your washer operates at fluid pressures
and velocities high enough to penetrate
human and animal flesh, which could
result in amputation or other serious
injury. Leaks caused by loose fittings or
worn or damaged hoses can result in
injection injuries. DO NOT TREAT FLUID
INJECTION AS A SIMPLE CUT! See a
physician immediately!
WARNING: Risk of Fire,
Asphyxiation and Burn. Never fill fuel
tank when engine is running or hot.
Do not smoke when filling fuel tank.
• NEVER fill fuel tank completely. Fill tank
to 1/2 inch )12.7 mm) below bottom
of filler neck to provide space for fuel
expansion. Wipe any fuel spillage from
engine and equipment before starting
engine.
• NEVERrun engine indoors or inenclosed,
poorly ventilated areas. Engine exhaust
contains carbon monoxide, an odorless
*CAUTION: The high pressure spray from your pressure washer is capable of
causing damage to surfaces such as wood, glass, automobile paint, auto strip-
ing and trim, and delicate objects such as flowers and shrubs. Before spraying,
check the item to be cleaned to assure yourself that it is strong enough to resist
damage from the force of the spray.

12- ENG
and deadly gas.
• DO NOT let hoses come in contact
with very hot engine muffler during or
immediately after use of your pressure
washer. Damage to hoses from contact
with hot engine surfaces will NOT be
covered by warranty.
NOTICE: Risk of property damage.
NEVER pull water supply hose to move
pressure washer. This could damage
hose and/or pump inlet.
• DO NOT use hot water, use cold water
only.
• NEVER turn water supply off while pres-
sure washer engine is running or dam-
age to pump will result.
• DO NOT stop spraying water for more
than two minutes at a time. Pump oper-
ates in bypass mode when spray gun
trigger is not pressed. If pump is left in
bypass mode for more than two minutes
internal components of the pump can
be damaged.
If you do not understand these precau-
tions, please call 1-800-544-6986 to
speak to a service representative for fur-
ther instructions.
STARTING
Prior to starting, refer to your engine
manual for proper starting procedure.
1. In a well ventilated outdoor area
add fresh, high quality, unleaded
gasoline with a pump octane rating
of 86 or higher. Do not overfill. Wipe
up spilled fuel before starting the
engine. Refer to Engine Owners
Manual for correct procedure.
2. Check engine oil level. See
Engine Owners Manual for correct
procedure.
3. Connect the water hose to the
water source. Turn the water
source on to remove all air from
the hose. When a steady stream
of water is present, turn the water
source off.
4. Verify the filter
screen is in water
inlet of pump.
NOTE: Cone side
faces out.
5. Connect water source to pump
inlet. NOTE: Water source must
provide a minimum of 5 gallons
(18.9 liters) per minute at 20 psi
(137.9 kPa).
Water
Source
D
WARNING: To reduce the possibil-
ity of contamination always protect
against backflow when connected to
a potable water system.
6. Connect high pressure hose to
pump outlet.
7. If applying a chemical or clean-
ing solution, see How To Apply
Chemicals/Cleaning Solvents
instructions in this section.
8. Turn water source on.
NOTICE: Risk of property damage.
Failure to do so could cause damage
to the pump.
9. Remove all air from the pump and
high pressure hose by depressing
trigger until a steady stream of
water is present.
10.
Turn the engine
ON/OFF switch
(H) to the ON
position.
11. Place the fuel
valve lever (M) in
the ON postion.
12. If the engine is cold, move the
choke (L) to the CLOSED position
as shown.

13- ENG
13. WARNING: Risk of unsafe
operation. Pull starter grip slowly
until resistance is felt. Then pull
starter grip (I) rapidly to avoid
kickback and prevent hand or
arm injury.
NOTE: Do not allow the starter grip to
snap back. Return it gently by hand.
WARNING: Risk of unsafe opera-
tion. If engine does not start after two
pulls, squeeze trigger of gun to relieve
pump pressure. Pull starter cord slowly
until resistance is felt. Then pull cord
rapidly to avoid kickback and prevent
hand or arm injury.
NOTE: If the oil level in the engine is
low, the engine will not start. If the
engine does not start, check the oil level
and add oil as needed.
14. As the engine
warms up, move
the choke to the
OPEN position.
15. Depress trigger
on gun to start
water flow.
WARNING: Risk of unsafe opera-
tion. Stand on a stable surface and
grip gun/spray wand firmly with both
hands. Expect the gun to kick when
triggered.
16. Release trigger to stop water
flow.
DANGER: Risk of injury from
spray. Always engage the trigger lock
when gun is not in use. Failure to do
so could cause accidental spraying.
Trigger Lock Engaged
17. Adjust nozzle spray for the task
being performed. See How To Use
Wand instructions in this section.
SHUTTING DOWN
1. After each use, if you have applied
chemicals, place chemical hose
into container of clean water and
draw clean water through chemical
injection system to rinse system
thoroughly.
NOTICE: Risk of property damage.
NEVER turn the water off with the
engine running. Failure to do so could
cause damage to the pump.
2. Place the engine ON/OFF switch to
the OFF Position.
3. Place the fuel valve lever (M) in the
OFF postion.
4. Turn water source off.
5. Pull trigger on spray gun to
relieve any water pressure in hose
or spray gun.
6. See Storage section in this manu-
al for proper storage procedures.
MAINTENANCE
WARNING: Risk of burn hazard.
When performing maintenance, you
may be exposed to hot surfaces,
water pressure or moving parts that
can cause serious injury or death.
WARNING: Risk of fire hazard.
Always disconnect, spark plug wire,
let the engine cool and release all
water pressure before perform-
ing any maintenance or repair. The
engine contains flammable fuel. Do
not smoke or work near open flames
while performing maintenance.
To ensure efficient operation and longer
life of your pressure washer, a routine
maintenance schedule should be pre-
pared and followed. If the pressure
washer is used in unusual conditions,
such as high-temperatures or dusty
conditions, more fre quent maintenance
checks will be required.

14- ENG
Engine
Consult the Engine Owners Manual for
the manufacturer's recommendations
for any and all maintenance.
Pump
NOTE: The pump was filled with oil at
the factory.
Change pump oil after the first 10
hours of operation and every 250 hours
thereafter.
To Check Oil
The oil level should
BB
CC
AA
come to the dot in
the middle of the
sight glass (AA).
How To Change
Pump Oil
1. Loosen pump
oil fill plug (BB).
2. Place a con-
tainer under the oil drain plug
(CC).
3. Remove pump oil drain plug.
4. After oil is drained, replace oil drain
plug. Tighten securely.
5. Remove pump oil plug and fill with
8.5 oz. (251 ml) of 30W non deter-
gent oil.
6. Replace pump oil plug and tighten
securely.
Nozzle Cleaning
If the nozzle becomes clogged with for-
eign materials, such as dirt, excessive
pressure may develop. If the nozzle
becomes partially clogged or restricted,
the pump pressure will pulsate. Clean
the nozzle immediately using the nozzle
kit supplied and the following instruc-
tions:
1. Shut off the pressure washer and
turn off the water supply.
2. Pull trigger on gun handle to relieve
any water pressure.
3. Disconnect the spray wand from
the gun.
4. Remove the high-pressure nozzle
from the spray wand. Remove any
obstructions with the nozzle clean-
ing tool provided and backflush
with clean water.
5. Direct water supply into spray wand
to backflush loosened particles for
30 seconds.
6. Reassemble the nozzle to the
wand.
7. Reconnect spray wand to gun and
turn on water supply.
8. Start pressure washer and place
spray wand into high pressure set-
ting to test.
How to Clean the Water Inlet Filter
This screen filter should be checked
periodically and cleaned if necessary.
1. Remove filter by
grasping end and
removing it from
water inlet of
pump as shown.
2. Clean filter
by flushing it with water on both
sides.
3. Re-insert filter into water inlet of
pump. NOTE: Cone side faces
out.
NOTE: Do not operate pressure washer
without filter properly installed.
STORAGE
Engine
Consult the Engine Owners Manual for
the manufacturer's recommendations
for storage.
Pump
The manufacturer recommends using
a pump protector/winterizer when
storing the unit for more than 30 days
and/or when freezing temperatures
are expected. A pump protector/
winterizer is availabe at the store where
the pressure washer was purchased.
If a pump protector/winterizer is not
available, RV antifreeze needs to be
run through the pump as outlined in the
steps below.

15- ENG
NOTE: Using a pump protector/ win-
terizer or RV antifreeze is to provide
proper lubrication to the internal seals
of the pump regardless of temperature
or environment.
1. Obtain a funnel,
6 oz. (170 mL)
of RV antifreeze
and 16–36 inch
(40–91cm) of
garden hose
with a male
hose connec-
tor attached to one end.
NOTICE: Risk of property damage. Use
only RV antifreeze. Any other antifreeze
is corrosive and can damage pump.
2. Disconnect spark plug wire.
3. Connect length of garden hose to
water inlet of pump.
4. Add RV antifreeze to hose as
shown.
5. Pull engine starter rope slowly sev-
eral times until antifreeze comes
out of high-pressure hose connec-
tion of pump.
6. Remove garden hose from water
inlet of pump.
7. Reconnect spark plug wire.
Pressure Washer
1. Drain all water from high pressure
hose, coil it, and store it in cradle
of the pressure washer handle.
2. Drain all water from spray gun and
wand by holding spray gun in a
vertical position with nozzle end
pointing down and squeezing trig-
ger. Store in gun holder.
3. Store chemical hose so it is pro-
tected from damage.
4. If space is needed, remove handles
and replace as shown.
ACCESSORIES
DANGER: Risk of fluid injection.
When using replacement lances or
guns with this pressure washer, DO
NOT use a lance and/or lance/gun
combination that is shorter in length
than what was provided with this
pressure washer as measured from
the nozzle end of the lance to the
gun trigger.
NOTICE: The use of any other acces-
sory not recommended for use with
this tool could be hazardous. Use only
accessories rated equal to or greater
than the rating of the pressure washer.
SPECIFICATIONS
Model BDP2600
PSI Max 2600 (17926 kPa)
Operating PSI 2340 (16134 kPa)
GPM Max 2.5
Operating GPM 2.25
SERVICE INFORMATION
Do not return this product to your
retailer. Black & Decker offers a full
network of company-owned and autho-
rized service locations throughout North
America. All Black & Decker Service
Centers are staffed with trained person-
nel to provide cutomers with efficient
and reliable power tool service.
Whether you need technical advice,
repair, or genine factory replacement
parts, contact the Black & Decker loca-
tion nearest you.
Tofind yourlocalservicelocation, referto
the yellow page directory under “Tools—
Electric” or call: 1-800-544-6986.

16- ENG
TWO-YEAR HOME USE WARRANTY
WARRANTY ON PRODUCT
COMPONENTS EXCLUDING PUMP
Black & Decker (U.S.) Inc. warrants
to the original purchaser that the
frame, wheels, gun, hose, wand, spray
nozzle(s) and other components of the
Black & Decker pressure washers cov-
ered under this warranty are free from
defects in material and workmanship
for two year from
the date of purchase.
WARRANTY ON PUMP
Black & Decker warrants to the original
purchaser that the pump of the Black
& Decker pressure washers covered
under this warranty is free from defects
in material and workmanship for two
years from the date of purchase. The
two year limited warranty applies to
the pump only. Black & Decker will
repair or replace, at Black & Decker's
option, products or components which
have failed within the above warran-
ty periods. Service will be scheduled
according to the normal work flow and
business hours at the service center
location, and the availability of replace-
ment parts. All decisions of Black &
Decker with regard to this limited war-
ranty shall be final. This warranty gives
you specific legal rights, and you may
also have other rights which vary from
state to state.
RESPONSIBILITY OF ORIGINAL
PURCHASER (Initial User):
• To process a warranty claim on
your Black & Decker pressure
washer, return it to the place of
purchase.
• Retain original cash register sales
receipt as proof of purchase for
warranty work.
• Use reasonable care in the opera-
tion and maintenance of the prod-
uct as described in the Owners
Manual(s).
THIS WARRANTY DOES NOT
COVER:
• Merchandise sold as recondi-
tioned, used as rental equipment,
or floor or display models.
• Merchandise that has become
damaged or inoperative because
of ordinary wear, misuse, cold,
heat, rain, excessive humidity,
freeze damage, use of improper
chemicals, negligence, accident,
failure to operate the product in
accordance with the instructions
provided in the Owners Manual(s)
supplied with the product, improp-
er maintenance, the use of acces-
sories or attachments not recom-
mended by Black & Decker, or
unauthorized repair or alterations.
• Repair and transportation costs of
merchandise determined not to be
defective.
• Costs associated with assembly,
required oil, adjustments or other
installation and start-up costs.
• Expendable parts or accessories
supplied with the product which are
expected to become inoperative or
unusable after a reasonable period
of use, including but not limited to
springs, nozzles, o-rings, washers,
and similar accessories.
• Merchandise sold by Black &
Decker which has been manu-
factured by and identified as the
product of another company, such
as gasoline engines. The product
manufacturer’s warranty, if any, will
apply.
• ANY INCIDENTAL, INDIRECT
OR CONSEQUENTIAL LOSS,
DAMAGE, OR EXPENSE THAT
MAYRESULTFROMANYDEFECT,
FAILURE OR MALFUNCTION OF
THE PRODUCT IS NOT COVERED
BY THIS WARRANTY. Some states
do not allow the exclusion or limita-
tion of incidental or consequential
damages, so the above limitation
or exclusion may not apply to you.
• IMPLIED WARRANTIES,
INCLUDING THOSE OF
MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE,
ARE LIMITED TO TWO YEAR
FROM THE DATE OF ORIGINAL
PURCHASE. Some states do not
allow limitations on how long an
implied warranty lasts, so the above
limitations may not apply to you.
Black & Decker (U.S.) Inc.,
701 E. Joppa Rd.
Towson, MD 21286 U.S.A.
See ‘Tools-Electric’
– Yellow Pages –
for Service & Sales

17- ENG
TROUBLE SHOOTING GUIDE
PROBLEM CAUSE CORRECTION
Engine will
not start (see
Engine Manual
for further
engine
troubleshoot-
ing)
No fuel. Add Fuel.
Pressure builds up after two
pulls on the recoil starter or
after initial use.
Squeeze gun trigger to relieve
pressure.
Choke lever in the "No Choke"
position. Move choke to the "Choke" position.
Spark plug wire not attached. Attach spark plug wire.
Engine switch in OFF
position. Place engine switch in on posi- tion.
Choke lever in the "Choke"
position on a "hot" engine
or an engine that has been
exposed to thermal heat for a
long period of time.
Move choke to the "No Choke"
position.
Fuel valve closed. Move the fuel valve lever to the
OPEN position.
No or low
pressure
(initial use)
Spray wand not in high pres-
sure. See How to Use Spray Wand instructions in the Operation
Section.
Low water supply. Water supply must be at least
5 GPM @ 20 psi.
Leak at high pressure hose
fitting. Repair leak. Apply sealant tape if necessary.
Nozzle obstructed. See Nozzle Cleaning instruc-
tions in the Maintenance sec-
tion.
Water filter screen clogged. Remove and clean filter.
No or low
pressure
(initial use)
Air in hose. Turn off the engine, then the
water source. Disconnect the
water source from the pump
inlet and turn the water source
on to remove all air from the
hose. When there is a steady
stream of water present, turn
water source off. Re-connect
water source to pump inlet and
turn on wa ter source. Squeeze
trigger to remove remaining air
Choke in the “Choke” position. Move choke to the “No Choke”
position.
High pressure hose is too
long. Use high pressure hose under 100 feet (30 m).

18- ENG
PROBLEM CAUSE CORRECTION
Will not draw
chemicals Spray wand not in low pres- sure. See How to Use Spray Wand paragraph in the Operation
Section.
Chemical filter clogged. Clean filter.
Chemical screen not in clean-
ing solution. Make sure end of chemical hose is fully submerged into
cleaning solution.
Chemical too thick. Dilute chemical. Chemical
should be the same consistency
as water.
Pressure hose is too long Lengthen water supply hose
instead of high pressure hose.
Chemical build up in chemical
injector. Contact B&D Customer Service Representative at
1-800-544-6986.
No or low
pressure
(after period of
normal use)
Worn seal or packing Contact B&D Customer
Service Representative at
1-800-544-6986.
Worn or obstructed valves. Contact B&D Customer
Service Representative at
1-800-544-6986.
Worn unloader piston. Contact B&D Customer
Service Representative at
1-800-544-6986.
Water leaking
at gun/spray
wand connec-
tion
Worn or broken o-ring. Check and replace.
Loose hose connection. Tighten.
Water leaking
at pump Loose connections. Tighten.
Piston packings worn. Contact B&D Customer
Service Representative at
1-800-544-6986.
Worn or broken o-rings. Contact B&D Customer
Service Representative at
1-800-544-6986.
Pump head or tubes damaged
from freezing. Contact B&D Customer Service Representative at
1-800-544-6986.
Pump Pulsates Nozzle obstructed. See Nozzle Cleaning para-
graph in the Maintenance sec-
tion for the correct procedure.

19- ENG
PROBLEM CAUSE CORRECTION
Oil leaking at
pump
Oil seals worn. Contact B&D Customer
Service Representative at
1-800-544-6986.
Loose drain plug. Tighten.
Worn drain plug o-ring. Check and replace.
Worn fill plug o-ring. Check and replace.
Pump overfilled. Check for correct amount.
Incorrect oil used. Drain and fill with correct amount
and type of oil.
Vent plug is clogged. Clean vent plug; blow air through it
to remove any blockage. If problem
persists, replace plug.

20- ENG
