Black Box DVI Cables User manual

© 2010. All rights reserved. Black Box Corporation.
FREE 24-hour Tech Support: 724-746-5500
blackbox.com
1 of 2
2/25/2010
#25357
DVI Cables
Connect a laptop computer
to a projector via a
DVI interface cable.

724-746-5500 blackbox.com
BL A C K B O X®
2 of 2
2/25/2010
#25357
»Connect two devices via a DVI interface.
»Models for all-digital, or analog or digital
connection.
»Eliminates pixel-look adjustments on
your projector, and resolution or color
changes to your computer.
FEATURES
Digital Visual Interface (DVI), the digital video computer standard
developed by Silicon Image, offers a simple, plug-and-play method for
connecting a laptop computer to a projector. DVI cable provides a
connection between two devices via the DVI interface.
We offer a cable that has a DVI-I male connector on one end and
an HD15 male, or DVI-D male to DVI-D male or female connector. All
cables come in 6-foot (1.8-m) and 10-foot (3-m) lengths.
There are five different types of DVI connectors: DVI-D, DVI-I,
DVI-A, DFP, and EVC.
• DVI-Disadigital-onlyconnector;it’stheleadingconnector
standard for digital-only connection.
• DVI-Icansupportdigitalandanalog(RGB).Theconnector
has a few more pins, and some display- and graphics-card
manufacturers are offering this connector type on their products,
as opposed to separate analog and digital connectors. Some
manufacturers do not support analog connection.
• DVI-AisusedtocarryananalogDVIsignaltoaVGAdevice,
such as a display.
• DFPwasanearlydigital-onlyconnectorusedonsomedisplays,
butit’sbeingphasedout.
• EVC(orP&D)isanotherconnectorthatsomemanufacturersare
using on their projectors. This connector looks a lot like the DVI-I
connector, but is slightly larger in size. Like DVI-I, it also handles
analog and digital.
OVERVIEW
These DVI cables use either DVI-I or DVI-D connectors.
Tech SPecS
Connectors —
 EVNDVI01,EVNDVI04:(1)DVI-IM,(1)HD15M;
 EVNDVI02:(2)DVI-DM;
 EVNDVI03:(1)DVI-DM,(1)DVI-DF;
 FA461:(1)DVI-IM,(1)HD15F;
 FA462:(1)DVI-IF,(1)HD15M;
 FA463:(1)DVI-DM,(1)DFPF;
FA464: (1) DVI-D F, (1) DFP M
Item Code
Digital Visual Interface (DVI) Cables
 DVI-AMale,StraightHood/VGAHD15Male
6-ft. (1.8-m) EVNDVI01-0006
10-ft. (3-m) EVNDVI01-0010
15-ft. (4.5-m) EVNDVI01-0015
25-ft. (7.6-m) EVNDVI01-0025
 DVI-AMale,90°Hood/VGAHD15Male
6-ft. (1.8-m) EVNDVI04-0006
10-ft. (3-m) EVNDVI04-0010
Custom Lengths EVNDVI04
DVI-D Male/DVI-D Male, Straight Hoods
6-ft. (1.8-m) EVNDVI02-0006
10-ft. (3-m) EVNDVI02-0010
15-ft. (4.5-m) EVNDVI02-0015
25-ft. (7.6-m) EVNDVI02-0025
DVI-D Male/DVI-D Female Extension
6-ft. (1.8-m) EVNDVI03-0006
10-ft. (3-m) EVNDVI03-0010
DVI Adapters
 DVI-IMale–VGAHD15Female  FA461
 DVI-IFemale–VGAHD15Male  FA462
DVI-D Male–DFP Female FA463
DVI-D Female–DFP Male FA464
