Black Box Ultra2 LVD SCSI Cables and Terminators User manual

Black Box has what you need for
Ultra2 LVD SCSI connections.
Black Box has what you need for
Ultra2 LVD SCSI connections.
Ultra2 LVD SCSI Cables and Terminators
© 2007. All rights reserved. Black Box Corporation.
FREE 24-hour Tech Support: 724-746-5500
blackbox.com

2 of 2
8/7/2007
#23197
724-746-5500 blackbox.com
FEATURES
• LVD technology is fully compatible with
older SCSI devices including Ultra-wide,
single-ended SCSI devices.
External Ultra2 LVD SCSI Cable
• Extend your SCSI bus to 12 meters
and connect RAID drives and mass
storage devices.
• Transfer data at up to 80 MBps across
the entire SCSI bus.
Internal Ultra2 LVD SCSI Cable
• For internal, 68-in, Ultra2 wide devices.
• Connects multiple internal devices.
• Use for internal single-ended and
different SCSI applications that require
twisted pairs.
Ultra2 LVD SCSI Terminators
• Terminate 80-MBps LVD and single-
ended SCSI buses.
OVERVIEW
External Ultra2 LVD SCSI Cable
Constructed of double-shielded twisted pair, these cables
transfer data at up to 80 MB per second across the entire
SCSI bus.
The External Ultra2 LVD SCSI Cables are fully compatible
with older SCSI devices, including Ultra-Wide single-ended
SCSI devices. And they can increase your SCSI bus length to
up to 12 meters!
Internal Ultra2 LVD SCSI Cable
Use the Internal Ultra2 LVD SCSI Cables for internal single-
ended or differential SCSI applications requiring twisted pairs.
These cables feature flat sections and loose, unbonded
twisted pairs that are perfect for connecting multiple internal
devices. And they terminate to industry-standard 0.025" IDC
connectors.
Ultra2 LVD SCSI Terminators
Select either internal or external models that support
termination for both LVD and/or single-ended SCSI buses.
All models support the 80-MB-per second LVD specification.
Connect the internal terminator directly on the internal
flat ribbon cable assembly.
The external terminators feature an LED that identifies
the bus being terminated for LVD or single-ended devices.
And to ensure secure VHDC1 and Micro D68 connections,
thumbscrew connections are provided.
TECH SPECS
EVMSCC20–EVMSCC22:
Conductors — 30 AWG 7/38 strand, tinned copper
Insulation — 0.006" PVC
Color Code — First pair red/gray followed by blue/gray and repeat
Laminate — Polyester
Temperature Rating — 176°F (80°C)
Impedance — 110 ohms
Capacitance — 13 pF/ft.
Propagation Delay — 1.5 ns/ft.
Voltage Rating — 150 volts
Current Rating — 0.75 amp
DC Resistance — 106 ohm/1000 ft.
Attenuation — 5 MHz: 4 dB/100 ft.;
10 MHz: 5 dB/100 ft.
Item Code
External Ultra2 LVD SCSI Cable
MD68 to MD68
3-ft. (0.9-m) EVMS25-0003
6-ft. (1.8-m) EVMS25-0006
VHDCI to MD68
3-ft. (0.9-m) EVMS26-0003
6-ft. (1.8-m) EVMS26-0006
Internal Ultra2 LVD SCSI Cable
Flat Twisted Wire, Micro D68 Male
30" (76.2 cm), 2 Connectors EVMSCC20
60" (152.4 cm), 5 Connectors EVMSCC21
80" (203.2 cm), 7 Connectors EVMSCC22
Ultra2 LVD SCSI Terminators, Single-Ended
External Micro D68 with LED FA970
External VHDCI with LED FA971
Internal Micro D68 FA972
Internal Micro D68 for Flat Ribbon FA973
