Black Box AVX-HDMI2-HDB-KIT User manual

24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM
HDMI 2.0
EXTENDER
AVX-HDMI2-HDB-KIT
USER MANUAL
DC 12V
RECEIVER
POWER STATUS HDCP LINK
RS232 HDMI OUT ETHERNET
HDBT IN IR IN IR OUT AUDIO IN
+
I
AUDIO CONTROL
ARC S/PDIF IN
IIII
RS232 HDMI IN ETHERNET
HDBT OUT IR IN IR OUT AUDIO OUT
+
I
DC 12V
POWER STATUS HDCP LINK
TRANSMITTER

2
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ........................................................................................................................................... 3
1. SPECIFICATIONS........................................................................................................................................................................... 4
2. OVERVIEW...................................................................................................................................................................................... 6
2.1 Introduction...............................................................................................................................................................................................6
2.2 Features ....................................................................................................................................................................................................6
2.3 What’s Included........................................................................................................................................................................................7
2.4 Hardware Description..............................................................................................................................................................................8
2.4.1 Transmitter ..........................................................................................................................................................................................................8
2.4.2 Receiver..............................................................................................................................................................................................................10
3. CONNECTIONS AND INSTALLATION........................................................................................................................................ 12
Installation Steps..........................................................................................................................................................................................12
4. OPERATING WITH IR................................................................................................................................................................... 15
4.1 IR Control.................................................................................................................................................................................................15
4.2 Control the Display.................................................................................................................................................................................15
4.3 Control the Source .................................................................................................................................................................................16
5. OPERATING WITH RS-232 .......................................................................................................................................................... 17
5.1 RS-232 Pinout .........................................................................................................................................................................................17
5.2 RS-232 Passthrough..............................................................................................................................................................................18
6. TROUBLESHOOTING................................................................................................................................................................... 19
6.1 Troubleshooting Steps...........................................................................................................................................................................19
6.2 Contacting Black Box.............................................................................................................................................................................19
APPENDIX A. REGULATORY INFORMATION ................................................................................................................................ 20
A.1 FCC Statement .......................................................................................................................................................................................20
A.2 NOM Statement .....................................................................................................................................................................................21
APPENDIX B. DISCLAIMER/TRADEMARKS ................................................................................................................................. 22
B.1 Disclaimer ...............................................................................................................................................................................................22
B.2 Trademarks Used in this Manual ..........................................................................................................................................................22

3
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
IMPORTANT SAFETY INSTRUCTIONS
1. Do not expose this apparatus to rain, moisture, dripping or splashing liquids. Do not place any objects filled with liquids, such as vases, on
the apparatus.
2. Do not install or place this unit in a bookcase, built-in cabinet or in another confined space. Make sure the unit is well ventilated.
3. To prevent risk of electric shock or fire hazard due to overheating, do not obstruct the unit’s ventilation openings with newspapers,
tablecloths, curtains, and similar items.
4. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
5. Do not place sources of open flames, such as lighted candles, on the unit.
6. Clean this apparatus only with a dry cloth.
7. Unplug this apparatus during lightning storms or when unused for long periods of time.
8. Do not walk on or pinch the power cord, particularly at plugs.
9. Only use attachments/accessories specified by the manufacturer.
10. Refer all servicing to qualified service personnel.

41. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 1: SPECIFICATIONS
TABLE 1-1. SPECIFICATIONS
SPECIFICATION DESCRIPTION
Transmitter
Video Input (1) Locking HDMI female
Input Signal Type HDMI with 4K
Input/Output Resolution
Support
800 x 600, 1024 x 768, 1280 x 720, 1280 x 768, 1280 x 800, 1280 x 960, 1280 x 1024, 1360 x 768, 1366 x 768,
1440 x 900,1600 x 900,1600 x 1200,1680 x 1050,1920 x 1080,1920 x 1200, 2560 x 1440, 2560 x 1600, 3840 x 2160P,
4096 x 2160P
Maximum Data Rate 18 Gbps
Input Video Level 0.5 – 1.0 V p-p
Input DDC Signal 5 V p-p
Maximum Pixel Clock 594 MHz
Output (1) HDBaseT
Output Signal Type HDBaseT
Video Impedance 100 ohms
Power Consumption
(Maximum)
Receiver powered by transmitter:
18.6 W (1080p)
21.6 W (4K @ 60 Hz YUV 4:4:4)
Transmitter and Receiver powered separately:
11.6 W (1080p)
18.96 W (4K @ 60 Hz YUV 4:4:4)
Receiver
Video Input (1) HDBaseT
Input Signal Type HDBaseT
Output Signal Type HDMI 2.0 and HDCP 2.2
Input/Output Resolution
Support
800 x 600, 1024 x 768, 1280 x 720, 1280 x 768, 1280 x 800, 1280 x 960, 1280 x 1024, 1360 x 768, 1366 x 768,
1440 x 900,1600 x 900,1600 x 1200,1680 x 1050,1920 x 1080,1920 x 1200, 2560 x 1440, 2560 x 1600, 3840 x 2160P,
4096 x 2160P
Maximum Data Rate 18 Gbps
Input Video Level 0.5 – 1.0 V p-p
Input DDC Signal 5 V p-p
Maximum Pixel Clock 584 MHz
Output (1) Locking HDMI
Output Signal Type HDMI with 4K
Video Impedance 100 ohms
Power Consumption
(Maximum)
Transmitter and Receiver powered separately:
7.44 W (1080p)
7.2 W (4K @ 60 Hz YUV 4:4:4)

5
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 1: SPECIFICATIONS
TABLE 1-1 (CONTINUED). SPECIFICATIONS
SPECIFICATION DESCRIPTION
General
ESD Protection Human-Body Model: ±8 kV (air-gap discharge)/±4 kV (contact discharge)
Surge Protection Voltage: ±1 kV
Electrical Fast Transient/Burst Data communication cord: 1 kV
Power cord: 2 kV
Approvals CE, FCC, IC, RCM, and VCCI
Power
Power Supply Each unit: (1) External 12 VDC, 3 A
Environmental
Operating Temperature 32 to 113° F (0 to 45° C)
Storage Temperature -4 to +158° F (-20 to +70° C)
Humidity 10 to 90%, noncondensing
Mechanical
Dimensions Each unit: 0.8” H x 6.8” W x 3.7” D (2.1 x 17.3 x 9.5 cm)
Weight Each unit: 0.9 lb. (0.4 kg)
TABLE 1-2. CABLE SPECIFICATIONS
CABLE TYPE RANGE SUPPORTED VIDEO
CAT5e/6 328 ft. (100 m) 1080p @ 60 Hz, 36 bpp
230 ft. (70 m) 1080p @ 60 Hz, 48 bpp
1080p @ 60 Hz 3D
4K @ 60 Hz YUV 4:4:4
CAT6a/7 328 ft. (100 m)

61. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 2: OVERVIEW
2.1 INTRODUCTION
The HDMI 2.0 HDBaseT Extender supports 4K @ 60 4:4:4 resolution and complies with HDR and HDCP 2.2 standars. It distributes
uncompressed UHD video, audio, power, and IR together up to 328 feet (100 meters) over a single CATx cable.
The extender supports Dolby and DTS HD audio, bi-directional IR control, in a low-profile box. You can configure the ARC channel feed
for a TV (with ARC support) or an auxiliary S/PDIF Input port via an audio output DIP switch on the receiver.
The extender uses proprietary one-way PoH technology to power the receiver from the transmitter.
LEDs show power and signal status for established connections between devices.
2.2 FEATURES
4K/UHD capability @ 60 Hz with 4:4:4 Chroma sampling, plus support for HDR formats
HDCP 2.2 compliant
Supports HD signal transmission up to 100 meters (1080p) and 70 meters (4K @ 60 Hz YUV 4:4:4) via a single CAT5e/6 cable
Supports HD signal transmission up to 100 meters (1080p) and 100 meters (4K @ 60 Hz YUV 4:4:4) via a single CAT6a/7 cable
Visually Lossless Compression enables 4K @ 60 HDR extension over HDBaseT
Receiver to transmitter audio return via ARC or digital coax pathway
Extends RS232, IR and Ethernet control signals
Standard One way PoH (Transmitter power to receiver)
Automatic EDID management
Visual LED indication
Locking HDMI connector prevents accidental cable disconnects

7
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 2: OVERVIEW
2.3 WHAT’S INCLUDED
Your package should include the following items. If anything is missing or damaged, contact Black Box Technical Support
at 877-877-2269 or [e-mail]
AVX-HDMI2-HDB-KIT includes:
(1) Transmitter (AVX-HDMI2-HDB-TX)
(1) Receiver (AVX-HDMI2-HDB-RX)
(1) Power adapter (12 VDC, 2 A)
(2) Phoenix male connectors (3.5-mm, 3-pin)
(2) IR emitter cables
(2) IR broadband receiver cables (30 kHz – 50 KHz)
(4) Mounting brackets
AVX-HDMI2-HDB-TX includes:
(1) Transmitter
(1) Power adapter (12 VDC, 2 A)
(1) Phoenix male connector (3.5-mm, 3-pin)
(1) IR emitter cable
(1) IR broadband receiver cable (30 kHz – 50 KHz)
(2) Mounting brackets
AVX-HDMI2-HDB-RX includes:
(1) Receiver
(1) Phoenix male connector (3.5-mm, 3-pin)
(1) IR emitter cable
(1) IR broadband receiver cable (30 kHz – 50 KHz)
(2) Mounting brackets

81. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 2: OVERVIEW
2.4 HARDWARE DESCRIPTION
The HDMI 2.0 Extender — HDBaseT, 4K60, Audio, IR consists of a Transmitter unit and a Receiver unit.
2.4.1 TRANSMITTER
Figures 2-1 and 2-2 show the front, top and back panels of the transmitter. Table 2-1 describes its components.
POWER
12 3 4
STATUS HDCP LINK
FIGURE 2-1. TRANSMITTER FRONT PANEL
12 3 4
TRANSMITTER DC 12V HDBT OUT IR IN
IR IN
IR OUT
IR OUT TX RX G
RS232 HDMI IN
HDMI IN
ETHERNET AUDIO OUT
AUDIO OUT
5 6 7
+
I
REAR PANEL
FIGURE 2-2. TRANSMITTER TOP AND BACK PANEL

9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 2: OVERVIEW
TABLE 2-1. TRANSMITTER COMPONENTS
NUMBER IN
FIGURE 2-1 COMPONENT DESCRIPTION
1 Power LED ON: The transmitter is powered on.
OFF: The transmitter is powered off.
2 Status LED Flashing: The transmitter is working properly.
OFF: The transmitter is not working properly.
3 HDCP LED
ON: HDCP video is being transmitted.
Flashing: Non-HDCP video is being transmitted.
OFF: No HDMI signal.
4 Link LED ON: HDBT link is normal
OFF: No HDBT link
NUMBER IN
FIGURE 2-2 COMPONENT DESCRIPTION
1 Power connector Links to 12-VDC power input
2 HDBT OUT Connects to HDBT IN port of receiver
3 IR IN Connects to IR receiver
3 IR OUT Connects to IR emitter
4 RS-232 Connects to control system for RS-232 passthrough
5 Locking HDMI IN connector Connects to an HDMI source
6 RJ-45 Ethernet connector Connects to internet with computer while the receiver is connected to the internet via a router
7AUDIO OUT Connects to an audio system such as an AV receiver

10 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 2: OVERVIEW
2.4.2 RECEIVER
Figures 2-3 and 2-4 show the front and back panels of the receiver. Table 2-2 describes its components.
POWER
12 3 4
STATUS HDCP LINK
AUDIO CONTROL
ARC S/PDIF IN
5
IIII
FRONT PANEL
FIGURE 2-3. RECEIVER FRONT PANEL
12 3 4
RECEIVER DC 12V HDBT IN IR IN
IR IN
IR OUT
IR OUT TX RX G
RS232 HDMI OUT
HDMI OUT
ETHERNET AUDIO IN
AUDIO IN
5 6 7
+
I
REAR PANEL
FIGURE 2-4. RECEIVER BACK PANEL

11
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 2: OVERVIEW
TABLE 2-2. RECEIVER COMPONENTS
NUMBER IN
FIGURE 2-3 COMPONENT DESCRIPTION
1 Power LED ON: The receiver is powered on.
OFF: The receiver is powered off.
2 Status LED Flashing: The receiver is working properly.
OFF: The receiver is not working properly.
3 HDCP LED
ON: HDCP video is being transmitted.
Flashing: Non-HDCP video is being transmitted.
OFF: No HDMI signal.
4 Link LED ON: HDBT link is normal.
OFF: No HDBT link.
5 Audio Control ARC: Configure ARC channel feed by TV
S/PDIF IN: Configure auxiliary S/PDIF input
NUMBER IN
FIGURE 2-4 COMPONENT DESCRIPTION
1 Power connector Links to 12-VDC power input
2 HDBT IN Connects to an HDBT OUT port of transmitter
3 IR IN Connects to IR receiver
3 IR OUT Connects to IR emitter
4 RS-232 Connects to a control system for RS-232 passthrough
5 Locking HDMI OUT connector Connects to an HDMI display
6 RJ-45 Ethernet connector Connects to internet with computer while the transmitter is connected to the internet via a router
7 AUDIO OUT Connects to an audio system on S/PDIF IN mode

12 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 3: CONNECTIONS AND INSTALLATION
INSTALLATION STEPS
1. Using quality HDMI cables, connect an HDMI source (such as Blu-ray, games console, satellite/cable TV, media server etc.) to the
HDMI IN port of the transmitter.
2. Connect an audio system such as an AV receiver to the AUDIO OUT port of the transmitter.
3. Connect a good quality, well-terminated CATx cable between the HDBT OUT port of the transmitter to the HDBT IN port of the
receiver.
4. Connect the HDMI display device such as a TV to the HDMI OUT port of the receiver.
5. For two-way IR control of connected sources and displays from either location, first, connect IR Emitters to the IR OUT ports of
the transmitter and receiver, and then insert IR Receivers into the IR IN ports of the transmitter and receiver.
6. For the DIP switch of the audio output of the receiver:
When you configure the ARC channel feed by TV, switch it to ARC mode. The TV should be supported and ARC and CEC should be
open. See Figure 3-1.
When you configure the auxiliary S/PDIF input, switch it to S/PDIF mode and connect an audio system to the AUDIO IN port of the
receiver. See Figure 3-2.
7. Connect the included 12-V power supply to the transmitter. The PoE function carries power along the length of cable to power the
receiver.
Check that Power, Status, and HDCP and Link lights are illuminated on both units to indicate successful connection, with a lit HDCP
light illustrating the presence of encryption within the signal. Power and Link are static lights. Status should be blinking.

13
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 3: CONNECTIONS AND INSTALLATION
DC 12V
TRANSMITTER
AUDIO
OUT
BROADBAND IR
RECEIVER
TV REMOTE
TRANSMITTER
RECEIVER
DVD AV RECEIVER
HDMI
IN
POWER STATUS HDCP LINK
RS232 HDMI IN ETHERNET
HDBT OUT IR IN IR OUT AUDIO OUT
+
I
DC 12V
RECEIVER
POWER STATUS HDCP LINK
RS232 HDMI OUT ETHERNET
HDBT IN IR IN IR OUT AUDIO IN
+
I
  
  
  
EXTERNAL
AUDIO INPUT
IR
EMITTER
IR
EMITTER
CATX
CABLE
BROADBAND IR
RECEIVER
DVD REMOTE TV
HDMI
OUT
AUDIO CONTROL
ARC S/PDIF IN
III I
  
  
  
FIGURE 3-1. CONFIGURE ARC CHANNEL

14 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 3: CONNECTIONS AND INSTALLATION
DC 12V
TRANSMITTER
AUDIO
OUT
IR
EMITTER
BROADBAND IR
RECEIVER
TV REMOTE
TRANSMITTER
RECEIVER
DVD AV RECEIVER
HDMI
IN
POWER STATUS HDCP LINK
RS232 HDMI IN ETHERNET
HDBT OUT IR IN IR OUT AUDIO OUT
+
I
DC 12V
RECEIVER
POWER STATUS HDCP LINK
RS232 HDMI OUT ETHERNET
HDBT IN IR IN IR OUT AUDIO IN
+
I
n n n
n n n
n n n
SWITCH
TO S/PDIF
IN MODE
IR
EMITTER
CATX
CABLE
BROADBAND IR
RECEIVER
DVD REMOTE TV AUDIO SYSTEM
HDMI
OUT AUDIO IN
AUDIO CONTROL
ARC S/PDIF IN
III I
n n n
n n n
n n n
FIGURE 3-2. CONFIGURE S/PDIF

15
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 4: OPERATING WITH IR
4.1 IR CONTROL
The IR passthrough function allows you to control the source from the display location or control the display from the source location.
4.2 CONTROL THE DISPLAY
In this case, IR IN port on the transmitter is connected to a broadband IR receiver and the IR OUT port on the receiver is connected to an
IR emitter. You can control the TV from the DVD location with the TV remote.
DC 12V
TRANSMITTER
BROADBAND IR
RECEIVER
TV REMOTE
TRANSMITTER
RECEIVER
DVD
HDMI
IN
POWER STATUS HDCP LINK
RS232 HDMI IN ETHERNET
HDBT OUT IR IN IR OUT AUDIO OUT
+
I
DC 12V
RECEIVER
POWER STATUS HDCP LINK
RS232 HDMI OUT ETHERNET
HDBT IN IR IN IR OUT AUDIO IN
+
I
n n n
n n n
n n n
IR
EMITTER
CATX
CABLE
TV
HDMI
OUT
AUDIO CONTROL
ARC S/PDIF IN
III I
FIGURE 4-1. CONTROL THE DISPLAY

16 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 4: OPERATING WITH IR
4.2 CONTROL THE SOURCE
In this case, the IR OUT port of the transmitter is connected to an IR emitter and the IR IN port of the receiver is connected to a broadband
IR receiver. You can control the DVD player from the TV location with the DVD remote.
DC 12V
TRANSMITTER
TRANSMITTER
RECEIVER
DVD
HDMI
IN
POWER STATUS HDCP LINK
RS232 HDMI IN ETHERNET
HDBT OUT IR IN IR OUT AUDIO OUT
+
I
DC 12V
RECEIVER
POWER STATUS HDCP LINK
RS232 HDMI OUT ETHERNET
HDBT IN IR IN IR OUT AUDIO IN
+
I
CATX
CABLE
TV
HDMI
OUT
AUDIO CONTROL
ARC S/PDIF IN
III I
BROADBAND IR
RECEIVER
IR
EMITTER
DVD REMOTE
n n n
n n n
n n n
FIGURE 4-2. CONTROL THE SOURCE

17
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 5: OPERATING WITH RS-232
5.1 RS-232 PINOUT
The following figure shows the RS-232 pinout. Please connect with the Phoenix connectors provided.
FIGURE 5-1. RS-232 PINOUT

18 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 5: OPERATING WITH RS-232
5.2 RS-232 PASSTHROUGH
According to the bi-directional RS-232 pass through function, you can use two RS-232 control systems for serial communication by
connecting to the devices via serial cables to control the source device or the display.
DC 12V
TRANSMITTER
TRANSMITTER
RECEIVER
CONTROL SYSTEM
RS232 CABLE
POWER STATUS HDCP LINK
RS232 HDMI IN ETHERNET
HDBT OUT IR IN IR OUT AUDIO OUT
+
I
DC 12V
RECEIVER
POWER STATUS HDCP LINK
RS232 HDMI OUT ETHERNET
HDBT IN IR IN IR OUT AUDIO IN
+
I
CATX
CABLE
AUDIO CONTROL
ARC S/PDIF IN
II II
CONTROL SYSTEM
RS232 CABLE
FIGURE 5-2. RS-232 PASSTHROUGH

19
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 6: TROUBLESHOOTING
6.1 TROUBLESHOOTING STEPS
Follow these steps to troubleshoot your extender:
1. Power: Make sure all devices are powered on (the sources, extender and display).
2. Indicator: Make sure LED indicators of the extender is normal according to user manual.
3. Devices: Make sure a picture can be shown normally when connecting source to display devices directly.
4. Cable: Plug in and out an HDMI/CATx cable or try another HDMI/CATx cable. Make sure the specific cable length is within the
transmission range in the user manual Specification section. CAT5e/6/6a/7 cable is recommended, do not use CAT5 cable. Make sure
the two connectors of one CATx cable are the same standard (EIA/TIA 568B).
5. Compatibility: Test other source and display devices to determine if it is a compatibility issue.
6.2 CONTACTING BLACK BOX
If you determine that your extender is malfunctioning, do not attempt to alter or repair the unit. It contains no user-serviceable parts.
Contact Black Box Technical Support at 877-877-2269 or [e-mail].
Before you do, make a record of the history of the problem. We will be able to provide more efficient and accurate assistance if you have a
complete description, including:
the nature and duration of the problem.
when the problem occurs.
the components involved in the problem.
any particular application that, when used, appears to create the problem or make it worse.

20
CHAPTER 1: HEADLINE
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
APPENDIX A: REGULATORY COMPLIANCE
A.1 FCC STATEMENT
This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict
accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to
comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules,
which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparatus set out in the Radio
Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de
classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.
