CAT5 ClassWork Plus
Instructor and Student Unit Kits
123
0
456
789
Help Enter Prog Clear
Master
All
Group
Audio
Print
KB
Dark
From
F1 F2 F3 F4
Help
CAT5 ClassWork Plus
Instructor Unit
CAT5 ClassWork Plus

1
FCC AND IC STATEMENTS
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio frequency energy and if not
installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of FCC rules, which are designed to
provide reasonable protection against such interference when the equipment is
operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct
the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from d
igital apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.

2
CAT5 CLASSWORK PLUS
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes
de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe colocar
en libreros o gabinetes que impidan el flujo de aire por los orificios de
ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.

3
NOM STATEMENT
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

4
CAT5 CLASSWORK PLUS
TRADEMARKS USED IN THIS MANUAL
IBM®and PS/2®are registered trademarks of International Business Machines
Corporation.
Mac®is a registered trademark of Apple Computer, Inc.
National Electrical Code®and NEC®are registered trademarks of National Fire
Protection Association.
Any other trademarks mentioned in this manual are acknowledged to be the property of the
trademark owners.

5
CONTENTS
Contents
Chapter Page
1. Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3. Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.1 Multiloop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2 The Classroom Layout` . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. CAT5 ClassWork Plus Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 About the CAT5 ClassWork Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2 The Instructor Interface Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.3 The Student Interface Standalone Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.4 The Student Interface Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.5 The Instructor Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5. Pre-Installation Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.1 The System Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Ground Loop Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.3 Ground Loop Solutions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6. Installing and Connecting the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.1 Connecting the Instructor Interface Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.1.1 Connecting the System Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.1.2 Connecting the Monitor Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
6.1.3 Connecting the Keyboard/Mouse Cable. . . . . . . . . . . . . . . . . . . . . . . . 23
6.1.4 Connecting the Control Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6.1.5 Connecting the Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.2 Installing the Student Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2.1 Connecting the Student Units to the System . . . . . . . . . . . . . . . . . . . . 28
6.2.2 Connecting the System Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6.2.3 Connecting the Keyboard/Mouse Cable. . . . . . . . . . . . . . . . . . . . . . . . 29
6.2.4 Connecting the Screen In/Out Cable. . . . . . . . . . . . . . . . . . . . . . . . . . 30
6.2.5 Connecting the Student Interface Standalone Unit
to the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6.3 Connecting the System to the Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

6
CAT5 CLASSWORK PLUS
Chapter Page
7. Setting the ID Numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.1 The Instructor’s ID Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2 The Students’ ID Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.3 Testing the ID Numbers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8. Image Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.1 Transferring Screen Images. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.2 Tuning an Image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
8.2.1 Transferring the Instructor’s Image to All Students . . . . . . . . . . . . . . 35
8.2.2 Transferring Each Student’s Image to the Instructor . . . . . . . . . . . . . 36
8.2.3 Transferring Each Student’s Image to Another Student . . . . . . . . . . . 36
9. Operating the Instructor Control Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
9.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
9.1.1 Screen Transfer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
9.1.2 Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
9.1.3 Darkening Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
9.1.4 Keyboard and Mouse Transfer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
9.1.5 Audio/Intercom Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
9.2 About the Instructor Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
9.3 Instructor Control Unit Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
9.3.1 Screen Transfer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
9.3.2 Keyboard and Mouse Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
9.3.3 Scan Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
9.3.4 Dark Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
9.3.5 Macro Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
9.3.6 Help Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
9.3.7 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
9.4 Instructor Option: Projector Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

7
1. Specifications
Maximum Number of Student PCs: 63 with Multiloop; 31 without Multiloop
Resolution: 1280 x 1024, 75 MHz
Connectors: Instructor Interface Unit, Student Interface Card, Standalone PC
Student Unit: (2) RJ-45 system ports, (1) HD15 female screen in/out, (1) 8-pin
mini-DIN female for keyboard and mouse; Instructor Interface Unit also has
(1) 5-pin DIN female for control and (1) 4-pin DIN female for power;
Instructor Control Unit has (1) 5-pin DIN female; Multiloop: (10) RJ-45
Transmission Distance: With Multiloop: Total cable length should not exceed
980 ft. (299 m); Without Multiloop: Total cable length should not exceed
360 ft. (110 m)
System Requirements:
CPU with PS/2 style keyboard and mouse connectors;
Video: SVGA, VGA, or XGA;
Temperature: 32 to 158°F (0 to 70°C);
Humidity: Up to 85% non-condensing
System Cable Specification: RJ-45 male/RJ-45 male connector, Ethernet
100BASE-T4 CAT5 UTP/STP cable (we recommend Black Box cable part
number EVMSL05)
Power: Instructor Interface Unit, Standalone PC Student Unit, Multiloop:
Input: 120 VAC, 60 Hz, 20 watts;
Output: 9 VAC, 1400 mA (230-VAC version is available, part number
AC840AE-R2);
Instructor Control Unit: From the Instructor Interface Unit;
Student Interface Card: From the PCI bus;
Size: Instructor Control Unit: 3.6"H x 8.6"W x 9"D (9.1 x 21.8 x 22.9 cm);
Instructor Interface Unit: 2"H x 8.9"W x 9"D (5.1 x 22.6 x 22.9 cm);
Student Interface Card: Half card
Standalone PC Student Unit: 1.2"H x 8.9"W x 9.2"D (3.1 x 22.6 x 23.4 cm)
Multiloop: 1.2"H x 8.7"W x 5.6"D (3.1 x 22.1 x 14.2 cm)
Weight: Instructor Control Unit: 2.8 lb. (1.3 kg); Instructor Interface Unit:
2 lb. (0.9 kg); Student Interface Card: 0.3 lb. (0.14 kg)
CHAPTER 1: Specifications

8
CAT5 CLASSWORK PLUS
2. Introduction
The CAT5 ClassWork Plus system gives the instructor control over every student’s
monitor, mouse, and keyboard in the classroom.
The CAT5 ClassWork Plus comes in two versions: an internal PCI card version and
an external box version.
This guide describes the installation of both versions.
NOTE
The two CAT5 ClassWork Plus versions are fully compatible with each
other.
CAT5 ClassWork Plus supports:
• IBM®compatible computers with PS/2®style keyboard and mouse connectors.
• VGA, SVGA, or XGA video standards.
• Up to 31 Student PCs in a loop without Multiloop; Up to 63 Student PCs with
Multiloop.
• A transmission range of 360 ft. (110 m) without Multiloop; Up to 980 ft.
(299 m) with Multiloop.

9
CHAPTER 3: Overview
3. Overview
The basic computer equipment for the Instructor and each Student is a CPU, a
keyboard, a monitor, and a mouse.
The specialized CAT5 ClassWork Plus equipment for the Instructor Unit Kit
(AC840A-R2 or AC840AE-R2) includes:
• (1) keypad/LCD control unit and control cable,
• (1) Instructor Interface Unit that links the instructor’s computer to the first
student’s computer in a loop,
• (1) power supply,
• monitor, keyboard, and mouse cables, and
• this users’ manual.
The specialized CAT5 ClassWork Plus equipment for the Student Unit Kit
(AC841C-R2) or Student Interface Standalone Unit (AC841A) includes:
• (1) Student Interface Card or Student Interface Standalone Unit to link
one student’s computer to the next student’s computer in a loop,
• monitor, keyboard, and mouse cables (all necessary cables are included), and
• this users’ manual.
NOTE
The Student Interface Card and the Student Interface Standalone Unit
are fully compatible with each other.
The CAT5 ClassWork Plus Starter Kit (AC842A or AC842AE) includes:
• (1) keypad/LCD control unit and control cable,
• (1) Instructor Interface Unit that links the instructor’s computer to the first
student’s computer in a loop,
• (1) power supply,
• monitor, keyboard, and mouse cables for Instructor and Student units,

10
CAT5 CLASSWORK PLUS
• (3) Student Interface Cards to link one student’s computer to the next
student’s computer in a loop, and
• this users’ manual.
You can also order the Instructor and Student Unit Standalone boxes separately:
• For the CAT5 ClassWork Plus Instructor Unit, order part number AC845A
(includes monitor, keyboard, and mouse cables; power cord; power supply;
and this users’ manual).
• For the CAT5 ClassWork Plus Student Unit, order part number AC846A
(includes monitor, keyboard, and mouse cables; power cord; power supply;
and this users’ manual).
3.1 Multiloop
There are three things to consider when deciding whether to include the
Multiloop (part number AC844A or AC844AE; these are covered in a separate
manual) in your system.
• The number of CAT5 ClassWork Plus Student Interface Cards or Student
Interface Standalone Units you’ll be connecting.
• The length of the system cable.
• The screen resolutions and refresh rates.
With Multiloop, you can:
• Connect up to 63 CAT5 ClassWork Plus Student Interface Cards or Standalone
Units to the CAT5 ClassWork Plus system.
• Increase the overall system cable distance up to 980 ft. (299 m).
We recommend installing Multiloop when:
• There are more than 15 Student Interface Cards or Standalone Units.
• The overall cable length exceeds 360 ft. (110 m).
This recommendation is dependent upon the screen resolution and refresh rates
of the computers. You can still install the CAT5 ClassWork Plus system for more
than 15 Student Interface Cards or Standalone Units without the Multiloop and
still achieve acceptable screen transfer results. However, if you use high screen
resolutions and refresh rates, then consider using Multiloop.

11
CHAPTER 3: Overview
3.2 The Classroom Layout
Figure 3-1. CAT5 ClassWork Plus Configuration.
Instructor
Interface Unit
Instructor Control
Unit
Instructor
computer
First student
computer
Last
student
computer

12
CAT5 CLASSWORK PLUS
4. CAT5 ClassWork Plus
Components
4.1 About the CAT5 ClassWork Plus
Each CAT5 ClassWork Plus system uses:
• An Instructor Control Unit (described in Chapter 9).
• An Instructor Interface Unit, which is a closed box that you connect to the
Instructor’s position (see Section 4.2).
• A Student unit, which is a PCI card (you insert it in the Student’s computer) or
a standalone unit. (See Sections 4.3 and 4.4.)
CAT5 ClassWork Plus supports up to 31 student units connected in a loop (without
Multiloop).
4.2 The Instructor Interface Unit
Figure 4-1 shows the Instructor Interface Unit.
Figure 4-1. The Instructor Interface Unit.
CAT5 ClassWork Plus

13
CHAPTER 4: CAT5 ClassWork Plus Components
Figure 4-2 shows the Instructor Interface Unit’s rear-panel connectors.
Figure 4-2. Connectors on the Instructor Interface Unit’s Rear Panel.
Figure 4-3 shows all the connectors used by the Instructor Interface Unit.
Figure 4-3. The Instructor Interface Unit’s Connectors.
Screen I/O Out InKB/MPower Control
RJ-45
female
RJ-45
female
HDD15
female
8-pin mini-
DIN female
5-pin DIN
female
4-pin DIN
female
Port To Connector To Cable
(RJ-45 male) System In
System Out
Screen In/Out
PS/2 Mouse/
Keyboard In/Out
Control
Power
(RJ-45 male)
(HDD15 male)
(8-pin mini-
DIN male)
(5-pin DIN
male)
(4-pin DIN
male)

14
CAT5 CLASSWORK PLUS
4.3 The Student Interface Standalone Unit
Figure 4-4. The Student Interface Standalone Unit.
Figure 4-5. The Student Interface Standalone Unit’s Connectors.
Screen
In/Out port
On/Off LED
On/Off
switch
Power
connector
Keyboard/
Mouse port
System
In/Out
ports

15
4.4 The Student Interface Card
Each Student Interface Card is a PCI (Peripheral Component Interconnect) card.
Figure 4-6 shows the Student Interface Card.
Figure 4-6. The Student Interface Card.
Figure 4-7 shows the Student Interface Card’s bracket.
Figure 4-7. The Student Interface Card’s Bracket.
CHAPTER 4: CAT5 ClassWork Plus Components
Screen I/O
Screen I/O
KB/M
KB/M
In
In
Out
Out

16
CAT5 CLASSWORK PLUS
Figure 4-8 shows the Student Interface Card’s connectors.
Figure 4-8. The Student Interface Card’s Connectors.
4.5 The Instructor Control Unit
Figure 4-9. The Instructor Control Unit.
123
0
456
789
Help Enter
Prog Clear
Master
All
Group
Audio
Print
KB
Dark
From
F1 F2 F3 F4
Help
CAT5 ClassWork Plus
Instructor Unit
RJ-45
female
RJ-45
female
HDD15
female
8-pin mini-
DIN female
Port To Connector To Cable
(RJ-45 male) System In
System Out
Screen In/Out
PS/2 Mouse/
Keyboard In/Out
(RJ-45 male)
(HDD15
male)
(8-pin mini-
DIN male)

17
5. Pre-Installation Guidelines
Please note the following:
• A certified electrician should prepare sufficient electrical wall sockets. Each
outlet should have the same phase and a common ground.
• Place cables away from fluorescent lights, air conditioners, and machines that
generate electrical noise.
• All the computers must be PS/2 type.
• All mice, keyboards, and monitors must be PS/2 type.
• Make sure that the total system cable length does not exceed the transmission
distance.
• A raised floor in the classroom can significantly reduce the system cable
length.
• Run cables through a conduit in the floor or wall where available.
• Check whether Power Poles are used.
5.1 The System Cable
For the system cable, use the FTP shielded 4 x 2 x 24 AWG CAT5 or CAT5e data
cable. We strongly advise against using patch cable because of its higher resistance
and capacitance.
NOTE
Run the system cable as short as possible to ensure better screen
transfer quality.
5.2 Ground Loop Problems
Before installing the CAT5 ClassWork Plus, check for ground loop problems.
These are caused by having equipment connected to different ground points via
interconnected cables. If the difference in ground potentials (voltage) is great
enough, it can create a current sufficient to cause the problem. It can also weaken
electronic components and be a safety hazard.
CHAPTER 5: Pre-Installation Guidelines

18
CAT5 CLASSWORK PLUS
5.3 Ground Loop Solutions
• Have a qualified professional measure the AC and DC voltages between the
ground points. Ground potential differences greater than 2 volts will affect the
ClassWork Plus system.
WARNING
Risk of electric shock! Electrical measurements and modifications
should only be attempted by qualified personnel.
• The most important element in reducing ground loops is good wiring
throughout the building. Faulty wiring can be lethal, as well as hazardous to
equipment. Use full-size ground conductors to reduce the ground impedance.
Use ground grids to equalize the ground potential. Refer to the National
Electrical Code®(NEC®). The online version can be found at
http://www.necdirect.org.
• The simplest method of controlling ground loops is to connect all equipment
to the same building ground point. This is not always possible because of the
physical placement of system components and the distances between them.
• Cable routing is also important. Keep cable runs as short as possible. This will
keep cable resistance to a minimum. The less cable, the less ground loop
voltage created.
NOTE
Cables and equipment placed in close proximity to light dimmers,
motorized electronics, and electronics generating RF emissions can
create noise in the system.
• If ground loop origination points are difficult to pinpoint, connect equipment
chassis grounds using 8- or 10-gauge ground wire.
NOTE
Do not open equipment. External ground points should be present on
most equipment.

19
6. Installing and Connecting the
System
This chapter describes how to connect the Instructor Interface Unit, the Instructor
Control Unit, and each of the Student Units; together they form the CAT5
ClassWork Plus classroom.
Before connecting the ClassWork Plus classroom:
• Make sure all computers are in working order.
• Switch off all the computers.
• Disconnect all cables and power cords.
6.1 Connecting the Instructor Interface Unit
You connect the following cables to the Instructor Interface Unit:
• System In/Out
• Monitor In/Out
• Mouse/Keyboard In/Out
• Control
• Power
Figure 6-1. Connectors on the Instructor Interface Unit’s Rear Panel.
CHAPTER 6: Installing and Connecting the System
Screen I/O Out InKB/MPower Control
