Black Box AVSP-HDMI1X2 User manual

BL A C K B O X®
Broadcast the same video plus audio signal source
to two, four, or eight HDMI or DVI compatible
outputs.
Support HDMI /DVI display resolutions of up to Full HD (1920 x 1080),
WUXGA (1920 x 1200), and UXGA (1600 x 1200).
Splitters are Blu-ray ready.
1 x 2, 1 x 4, and 1 x 8 HDMI Splitters
AVSP-HDMI1X2
AVSP-HDMI1X4
AVSP-HDMI1X8
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.
call 724-746-5500) • FREE technical support 24 hours a day, 7 days a
week: Call 724-746-5500 or fax [phone] • Mailing address:
Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
Customer
Support
Information

724-746-5500 | blackbox.com
Page 2 AVSP-HDMI1X2
Trademarks Used in this Manual
Trademarks Used in this Manual
Black Box and the Double Diamond logo are registered trademarks of BB
Technologies, Inc.
Any other trademarks mentioned in this manual are acknowledged to be
the property of the trademark owners.

724-746-5500 | blackbox.com Page 3
AVSP-HDMI1X2
FCC and IC RFI Statements
FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY
CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy, and if
not installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart B of Part 15 of FCC rules, which are designed
to provide reasonable protection against such interference when the equipment
is operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct
the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission
from digital apparatus set out in the Radio Interference Regulation of Industry
Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant
les limites applicables aux appareils numériques de classe A prescrites dans le
Règlement sur le brouillage radioélectrique publié par Industrie Canada.
Normas Oficiales Mexicanas (NOM)Electrical Safety Statement
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes
de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.

724-746-5500 | blackbox.com
Page 4 AVSP-HDMI1X2
NOM Statement
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que
sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe colocar
en libreros o gabinetes que impidan el flujo de aire por los orificios de
ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen del
aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.

724-746-5500 | blackbox.com Page 5
AVSP-HDMI1X2
NOM Statement
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

724-746-5500 | blackbox.com
Page 6 AVSP-HDMI1X2
Table of Contents
Table of Contents
1. Specifications.................................................................................................... 7
2. Overview ...................................................................................................... 8
2.1 Introduction............................................................................................. 8
2.2 Features ................................................................................................... 8
2.3 What’s Included ...................................................................................... 9
2.4 Optional Items You Might Need ............................................................. 9
2.5 Hardware Requirements.......................................................................... 9
2.6 Hardware Description............................................................................ 10
2.6.1 AVSP-HDMI1X2 .......................................................................... 10
2.6.2 AVSP-HDMI1X4 .......................................................................... 11
2.6.3 AVSP-HDMI1X8 .......................................................................... 13
3. Installation .................................................................................................... 15
4. Operation .................................................................................................... 20
5. Troubleshooting ................................................................................................. 21

724-746-5500 | blackbox.com Page 7
AVSP-HDMI1X2
Chapter 1: Specifications
1. Specifications
Enclosure: Metal
Maximum Cable Length: 16.4 feet (5 meters)
Maximum Video Resolution/Signal Type:
Full HD 1080p (1920 x 1080), VGA (640 x 480), SXGA (1280 x 1024),
UXGA (1800 x 1200), WUXGA (1920 x 1200);
Number of Video Outputs: AVSP-HDMI1X2: (2);
AVSP-HDMI1X4: (4);
AVSP-HDMI1X8: (8)
Rackmountable: AVSP-HDMI1X2: No;
AVSP-HDMI1X4, AVSP-HDMI1X8: Yes
Connectors: AVSP-HDMI1X2: Input: (1) HDMI female, (1) set of audio jacks,
Output: (2) HDMI female, (1) set of audio jacks;
AVSP-HDMI1X4: Input: (1) HDMI female, (1) set of audio jacks,
Output: (4) HDMI female, (2) sets of audio jacks;
AVSP-HDMI1X8: Input: (1) HDMI female, (1) set of audio jacks,
Output: (8) HDMI female, (4) sets of audio jacks
Indicators: AVSP-HDMI1X2: (1) dual-color LED: Power Active/Video OK,
(2) Video Output LEDs;
AVSP-HDMI1X4: (1) dual-color LED: Power Active/Video OK,
(4) Video Output LEDs;
AVSP-HDMI1X8: (1) dual-color LED: Power Active/Video OK,
(8) Video Output LEDs
Power: All: Input: 9–12 VDC;
AVSP-HDMI1X2: Output: 2.8 W;
AVSP-HDMI1X4: Output: 4.1 W;
AVSP-HDMI1X8: Output: 10.2 W
Size: AVSP-HDMI1X2: 0.8"H x 7.1"W x 3.4"D (2 x 18 x 8.5 cm);
AVSP-HDMI1X4: 1.7"H x 8.7"W x 5.3"D (4.4 x 22 x 13.5 cm);
AVSP-HDMI1X8: 1.7"H x 17.2"W x 7.1"D (4.4 x 43.8 x 18 cm)

724-746-5500 | blackbox.com
Page 8 AVSP-HDMI1X2
Chapter 2: Overview
2. Overview
2.1 Introduction
The 1 x 2, 1 x 4, or 1 x 8 HDMI Splitters broadcast the same video plus audio
signal source to two, four, or eight HDMI or DVI compatible outputs.
Depending on the cable’s length and quality, these fully compliant splitters support
HDMI/DVI display resolutions of up to Full HD (1920 x 1080), WUXGA (1920 x
1200), and UXGA (1600 x 1200), and are also Blu-ray ready.
You don’t need to install or configure an interface card. Just connect the cables,
power up the system, and you are ready to have duplicated video images on
multiple monitors with excellent clarity. The 1 x 8 model can also be rackmounted.
Use the HDMI Splitters for a variety of public broadcasting applications, including:
• Presentations • Exhibits
• Demonstrations • Trade shows
• Monitor testing and burn-in • Business meetings
• News • Stock tickers
• Airline/train/bus schedules • Retail stores
2.2 Features
• Provides an easy and affordable way to duplicate video input to multiple HDMI
outputs.
• Includes automatic power-save when the signal input is lost.
• Cascade units for more signal outputs.
• Gives you crisp, clear video images.
• Supports EDID, HDCP, and is Blu-ray ready for high-definition display.
• Supports HDMI display resolutions of up to UXGA (1600 x 1200),
WUXGA (1920 x 1200), and Full HD 1080p (1920 x 1080).
• LED indicators enable you to monitor signal activity.
• Accurately and reliably reproduces digital video signals without attenutation and
distortion.
• Installs in seconds.

724-746-5500 | blackbox.com Page 9
AVSP-HDMI1X2
Chapter 2: Overview
2.3 What’s Included
Your package should include the following items. If anything is missing or damaged,
contact Black Box Technical Support at 724-746-5500 or [e-mail].
• Video splitter
• Power adapter with AC cord or plug-in power adapter
• Foot pad
• Rackmount bracket (included with 1 x 8 unit only)
• This user’s manual
2.4 Optional Items You Might Also Need
• HDMI male-to-male cable for connecting the HDMI source
• Audio cable
• DVI-to-HDMI adapter
• HDMI-to-DVI adapter
2.5 Hardware Requirements
• Video sources (PS3, Blu-ray, DVD players, etc. with HDMI output and audio output
• HDMI cables
• HDCP-compliant display devices (TVs, monitors, projectors, etc.) for the HDCP
video source (optional)
• Speakers for audio

724-746-5500 | blackbox.com
Page 10 AVSP-HDMI1X2
Chapter 2: Overview
2.6 Hardware Description
2.6.1 AVSP-HDMI1X2
Figures 2-1 and 2-2 show the front and side panels of the AVSP-HDMI1X2. Table 2-1
describes its components.
1 2 3
Figure 2-1. AVSP-HDMI1X2 front panel.
4 5 6
7 8
Figure 2-2. AVSP-HDMI1X2 side panel.

724-746-5500 | blackbox.com Page 11
AVSP-HDMI1X2
Chapter 2: Overview
Table 2-1. AVSP-HDMI1X2 components.
Number Component Description
1Port 1 LED Lights when there is activity on Port 1.
2Port 2 LED Lights when there is activity on Port 2.
3Power input LED Lights when power is connected.
4Power connector Connects to AC power source.
5HDMI connector Connects to input source.
6(2) HDMI connectors Links to output monitors..
7Audio connector Connects to audio input.
8(2) audio connectors Connects to audio outputs.
2.6.2 AVSP-HDMI1X4
Figures 2-3 and 2-4 show the front and back panels of the AVSP-HDMI1X4. Table
2-2 describes its components.
1 2
Figure 2-3. AVSP-HDMI1X4 front panel.

724-746-5500 | blackbox.com
Page 12 AVSP-HDMI1X2
Chapter 2: Overview
6 7
3 4 5
Figure 2-4. AVSP-HDMI1X4 back panel.
Table 2-2. AVSP-HDMI1X4 components.
Number Component Description
1Ports 1–4 LEDs Lights when there is activity on Ports
1–4.
2Power input LED Lights when power is connected.
3Power connector Connects to AC power source.
4HDMI connector Connects to input source.
5(4) HDMI connectors Links to output monitors.
6Audio connector Connects to audio input.
7(4) audio connectors Connects to audio outputs.

724-746-5500 | blackbox.com Page 13
AVSP-HDMI1X2
Chapter 2: Overview
2.6.3 AVSP-HDMI1X8
Figures 2-5 and 2-6 show the front and back panels of the AVSP-HDMI1X8. Table
2-3 describes its components.
1 2
Figure 2-5. AVSP-HDMI1X8 front panel.
6 7
3 4 5
Figure 2-6. AVSP-HDMI1X8 back panel.

724-746-5500 | blackbox.com
Page 14 AVSP-HDMI1X2
Chapter 2: Overview
Table 2-3. AVSP-HDMI1X8 components.
Number Component Description
1Ports 1–8 LEDs Lights when there is activity on Ports
1–8.
2Power input LED Lights when power is connected.
3Power connector Connects to AC power source.
4HDMI connector Connects to input source.
5(8) HDMI connectors Links to output monitors.
6Audio connector Connects to audio input.
7(8) audio connectors Connects to audio outputs.

724-746-5500 | blackbox.com Page 15
AVSP-HDMI1X2
Chapter 3: Installation
3. Installation
WARNINGS: Before installation, make sure you power off all devices that will be
connected to this system.
Make sure that all devices you will connect are properly grounded.
Place cables away from fluorescent lights, air conditioners, and
machines that are likely to generate electrical noise.
Use one HDMI male-to-male cable to connect a video source to the video splitter
input (SOURCE). Connect multiple monitors or TVs to the video splitter’s output
ports as shown in Figures 3-1 through 3-3.
Plug a set of audio jacks from the speaker to the splitter’s audio port.
Turn on your video source only after you’ve made all the connections.

724-746-5500 | blackbox.com
Page 16 AVSP-HDMI1X2
Chapter 3: Installation
HDMI displays connected
to output ports
Computer connected
to input port
Audio output
ports
Audio input
port
AVSP-HDMI1X2
Figure 3-1. AVSP-HDMI1X2 connection.

724-746-5500 | blackbox.com Page 17
AVSP-HDMI1X2
Chapter 3: Installation
HDMI displays connected
to output ports
Computer connected
to input port
Audio output
ports
Audio input
port
AVSP-HDMI1X4
Figure 3-2. AVSP-HDMI1X4 connection.

724-746-5500 | blackbox.com
Page 18 AVSP-HDMI1X2
Chapter 3: Installation
HDMI displays connected
to output ports
Computer connected
to input port
Audio output
ports
Audio input
port
AVSP-HDMI1X8
Figure 3-3. AVSP-HDMI1X8 connection.
NOTES: At least one monitor connection to the splitter unit is required when
powering on the source device.
Connect the splitter unit to the computer before powering on the
computer.
The splitter unit is HDMI compliant and must use the HDCP compliant
display when it is connecting to the HDCP video source.
NOTE: Do not use mixed (HDMI and DVI) ouptut connections, as shown in Figure
3-4. This configuration might cause signal degradation. For example, an
AVSP-HDMI1X4 unit cannot have one output connection to an HDMI monitor
via an HDMI cable and another output connection to a DVI monitor via a DVI
cable.

724-746-5500 | blackbox.com Page 19
AVSP-HDMI1X2
Chapter 3: Installation
DVI
monitor
HDMI
monitor
DVI
monitor
HDMI
monitor
Figure 3-4. Do not use this type of mixed connection pattern
Blu-ray Ready
The splitter can support high-definition video such as DVD or Blu-ray and
multichannel audio, and carry the best signal from source to displays. The high
bandwidth enables large amounts of information to transmit at a very high speed.
Blu-ray uses a blue-violet laser to read and write data, while current optical disk
technologies such as DVD, DVD±R, DVD±RW, and DVD-RAM rely on a red laser to
read and write data. The blue-violet laser operates at a shorter wavelength (405 nm)
than the red laser (650 nm). The shorter-wavelength laser spot focuses with even
greater precision, so more data will fit on the disk even though it’s the same size as
a CD/DVD.

724-746-5500 | blackbox.com
Page 20 AVSP-HDMI1X2
Chapter 4: Operation
4. Operation
The quality of the output signal depends upon the quality of the video source, cable,
and display device used. Low-quality cables degrade the output signal, causing
elevated noise levels. Use the proper cable and make sure the display can handle
the resolution and refresh rate you select. Interference from nearby electrical devices
can adversely affect signal quality.
LED Display
The splitter has two LEDs: one dual-color LED (lights green for power on and blue
for video signal OK), and one video output signal LED.
