1. Specifications
Speed — 300 to 115,200 bps
Memory — PI405, PI415, PI420, PI425 models: 128 KB; PI406, PI416, PI421,
PI426 models: 256 KB; PI407, PI417, PI422, PI427 models: 512 KB; PI408,
PI418, PI423, PI428 models: 1 MB; PI409, PI419, PI424, PI429 models: 2 MB
Flow Control — Serial: X-ON/X-OFF or hardware; Parallel: Hardware, Busy,
ACK
Data Format — 7 or 8 data bits, Parity even or odd
Interface — RS-232 async ASCII (input port is DTE, output port is DCE)
Connectors — (1) DB25 female input; (1) DB25 female output
Display — Four-digit LED display
Power — 115/230 VAC, 50/60 Hz, 20 watts, 5 VDC, 1 amp
Size — 2.4"H x 8.1"W x 6.3"D (6.1 x 20.6 x 16 cm)
Weight — 2.5 lb. (1.1 kg)

7
DATABUFFER PLUS
2. Introduction
The DataBuffer Plus is a versatile buffering device that accepts data rapidly from
your computer and sends it to a printer or plotter. The DataBuffer Plus also takes
data from or sends data to other devices such as scanners and modems. The
DataBuffer Plus comes in the following models:
• DataBuffer Plus-128K-S/S (PI405A(E))— serial-to-serial version with 128 KB
of memory.
• DataBuffer Plus-128K-S/P (PI415A(E))— serial-to-parallel version with 128 KB
of memory.
• DataBuffer Plus-128K-P/P (PI420A(E))— parallel-to-parallel version with
128 KB of memory.
• DataBuffer Plus-128K-P/S (PI425A(E))— parallel-to-serial version with 128 KB
of memory.
• DataBuffer Plus-256K-S/S (PI406A(E))— serial-to-serial version with 256 KB
of memory.
• DataBuffer Plus-256K-S/P (PI416A(E))— serial-to-parallel version with 256 KB
of memory.
• DataBuffer Plus-256K-P/P (PI421A(E))— parallel-to-parallel version with
256 KB of memory.
• DataBuffer Plus-256K-P/S (PI426A(E))— parallel-to-serial version with 256 KB
of memory.
• DataBuffer Plus-512K-S/S (PI407A(E))— serial-to-serial version with 512 KB
of memory.
• DataBuffer Plus-512K-S/P (PI417A(E))— serial-to-parallel version with 512 KB
of memory.
• DataBuffer Plus-512K-P/P (PI423A(E))— parallel-to-parallel version with
512 KB of memory.
• DataBuffer Plus-512K-P/S (PI427A(E))— parallel-to-serial version with 512 KB
of memory.
• DataBuffer Plus-1M-S/S (PI408A(E))— serial-to-serial version with 1MB
of memory.

8
DATABUFFER PLUS
• DataBuffer Plus-1M-S/P (PI418A(E))— serial-to-parallel version with 1 MB
of memory.
• DataBuffer Plus-1M-P/P (PI423A(E))— parallel-to-parallel version with 1 MB
of memory.
• DataBuffer Plus-1M-P/S (PI428A(E))— parallel-to-serial version with 1 MB
of memory.
• DataBuffer Plus-2M-S/S (PI409A(E))— serial-to-serial version with 2 MB
of memory.
• DataBuffer Plus-2M-S/P (PI419A(E))— serial-to-parallel version with 2 MB
of memory.
• DataBuffer Plus-2M-P/P (PI424A(E))— parallel-to-parallel version with 2 MB
of memory.
• DataBuffer Plus-2M-P/S (PI429A(E))— parallel-to-serial version with 2 MB
of memory.

9
DATABUFFER PLUS
3. Installation and Configuration
To install the DataBuffer Plus, simply connect the unit’s input side to your
computer and the unit’s output side to your printer using the appropriate cables.
The cables you use will depend on your application. Typical input and output
cable order codes are listed below. Figures 3-1 and 3-2 show two typical
applications of the DataBuffer Plus.
Typical Input Cables:
• PC/XT™Serial Port— EVNBXL-0010
•AT
®Serial Port— EHNPI02-0010
• PC Parallel Port— ECN25C-0010
Typical Output Cables:
• Serial Printer— ECN25C-0010
• Parallel Printer— EYN600-0010
Figure 3-1. DataBuffer Plus in a Serial-to-Parallel Application.
PC
EHNPI02 EYN600
DataBuffer
Plus
Parallel
Printer

10
DATABUFFER PLUS
Figure 3-2. DataBuffer Plus in a Parallel-to-Serial Application.
3.1 Configuration
The DataBuffer Plus has one output port and one input port. Each serial port
must be configured individually for speed, parity, data format, and handshaking
method. Table 3-1 lists these settings. The unit is also equipped with Copy/Pause
and Reset buttons on the front panel. The 8-position DIP switches—S3 for the
output port and S4 for the input port—are located on the rear panel of the unit.
The switches are for setting speed, data format, and flow-control options on serial
ports. Parallel ports do not have DIP switches.
S3 controls the output port and S4 controls the input port. Setting S3 or S4 to
the “up” position opens the switch (OFF position); setting S3 or S4 to the “down”
position closes it (ON position).
After you reset S3 or S4, either power down the unit or press the Reset switch
again.
3.2 Self-Test
The DataBuffer Plus also has a self-test feature. To begin the self-test, press and
hold the Reset switch while you press and hold the Copy/Pause switch. Release
Reset, then release Copy/Pause. The unit transmits the test message to the output
port only. The test message continues to print until you press the Reset switch
again.
PC
ECN25C ECN25C
DataBuffer
Plus
Serial
Printer

11
DATABUFFER PLUS
Table 3-1. Switch Settings (Up=Off, Down=On).
Switch Position
(S3 input, S4 output) 1 2 3 4 5 6 7 8
Baud Rate
115200 OFF OFF OFF
57600 ON OFF OFF
38400 OFF ON OFF
19200 ON ON OFF
9600 OFF OFF ON
2400 ON OFF ON
1200 OFF ON ON
300 ON ON ON
Data Bits
8 OFF
7ON
Parity
Even OFF
Odd ON
Parity
Disable OFF
Enable ON
Flow Control
Hardware OFF
Software ON
Port Type
Serial OFF

12
DATABUFFER PLUS
4. Operation
You can set all the options with the Reset and Copy/Pause buttons. Different
options and settings are described below. The placement of the buttons and
switches is shown in Figures 4-1 and 4-2.
4.1 Switches and Pushbuttons
4.1.1 R ESET B UTTON
When pressed, Reset causes the unit to “read” the settings. If you change any of the
DIP switches on the rear of the unit, you must press Reset for the unit to “read”
those changes. Reset also clears the copy feature (see Copy/Pause) and clears all
data in the buffer.
Figure 4-1. Front Panel of the DataBuffer Plus.
Figure 4-2. Rear Panel of the DataBuffer Plus.
COPY / PAUSE
RESET
FOUR 7-SEGMENT
DISPLAYS
Output Connector
DB25 female
S3 S4 Input Connector
DB25 female

13
DATABUFFER PLUS
4.1.2 LED S
Four 7-segment LEDs are located on the front panel of the DataBuffer Plus. These
LEDs are similar to a digital-clock display. The LEDs continuously display the
amount of data in the buffer in kilobytes. These LEDs also aid you when you preset
multiple copies. You don’t have to remember how many copies you set, simply
press the Copy/Pause button again and the LEDs will give you a digital display
of the amount.
4.1.3 C OPY /P AUSE B
UTTON
Presetting multiple copies. First, press the Reset button to clear all previous settings.
Before you send the data, depress the Copy/Pause switch once for each copy you
want printed. For example, if you want 10 copies of a document, press the
Copy/Pause button 10 times before sending the document to the DataBuffer Plus.
The LED displays the number of copies set each time you add a copy. You can set
the unit to print up to 999 copies.
Printing one additional copy. For one additional copy of the data you just sent, press
the Copy/Pause button. One copy of the most recent job sent to the buffer is sent
to the printer. The LEDs display the original number of preset copies. As you add
copies, the LEDs display your changes. If a 7-second time period of inactivity on
the input port occurs, the unit considers it the end of a print job.
Stopping data output. Pressing Copy/Pause while data is being sent stops the output of
data from the buffer while allowing data input to continue. The buffer remains in
the “Pause” mode until you press Copy/Pause again. The LED display gives a readout
of the current buffer status and flashes to indicates the unit is in pause mode.
4.2 Handshaking
The DataBuffer Plus usually accepts data much faster than the output devices
(such as printers) to which it is attached. Handshaking is a form of flow control
that prevents the unit’s output from overrunning the printer’s ability to accept
the data.
Data loss is prevented if equipment connected to the input and output serial
ports support hardware or X-ON/X-OFF handshaking.
4.2.1 H ARDWARE H ANDSHAKING
When the unit’s buffer is nearly full on the input end, it changes Pin 20 from a
high voltage to a low voltage. When the output device (printer) has emptied the
unit’s buffer so that more input data can be accepted, the DataBuffer Plus raises
Pin 20 to a high-level signal.

14
DATABUFFER PLUS
The DataBuffer Plus monitors Pin 20 for activity from the output device. When
the device attached to the output port cannot accept any more data, it drops Pin
20. When the output device is ready to accept more data, it returns Pin 20 to a high
level to the DataBuffer Plus.
4.2.2 X-ON/X-OFF H ANDSHAKING
When the unit’s buffer is almost full, it sends an X-OFF character to the input
device via Pin 2. The unit sends an X-ON character via Pin 2 once the output
device has accepted enough data to leave room in the buffer for more input data.
When the output device cannot accept any more data, it sends an X-OFF
character to Pin 2 on the DataBuffer Plus’s output port. When the output device
is ready to receive more data, it sends an X-ON character via Pin 2.
4.3 DataBuffer Plus Input and Output Port Pinouts
Serial Pin Configurations (Input Port DTE) DB25 Female.
Pin Name Source Function
1 FG Chassis ground
2 TD Buffer unit Output from buffer
3 RD Input device Input to buffer
4 RTS Buffer unit Request to send (Held High)
5 CTS Input device Input to buffer
7 GND Signal Ground
20 DTR Buffer unit Output from buffer (hardware
handshaking pin)
Serial Pin Configurations (Output Port DCE) DB25 Female.
Pin Name Source Function
1 FG Chassis ground
2 TD Output device Input to buffer
3 RD Buffer unit Output from buffer
5 CTS Buffer unit Output from buffer
6 DSR Buffer unit Held high tied to 8
7 GND Signal Ground
8 CD Output device Held high tied to 6
20 DTR Buffer unit Input to buffer (hardware
handshaking pin)

15
DATABUFFER PLUS
Centronics®Port Pin Configurations (DB25 Input female, Output male).
Pin Name Function
1 Strobe
2 Data1
3 Data2
4 Data3
5 Data4
6 Data5
7 Data6
8 Data7
9 Data8
10 ACK
11 Busy
12 PE GND
13 Select High
14 Autofeed NC
15 Fault High
16
17 NC
18 NC
19-25 GND

16
DATABUFFER PLUS
5. Troubleshooting
Problem: No output to the printer.
Solution: Try outputting the self-test to the printer (see Section 3.2).
A.If the self-test works, the problem is with the input port. Check your
cable and switch settings.
B.If the self-test will not work on the output serial port, the unit may be set up for
hardware handshaking and Pin 20 (DTR) may not be set high on the output
port. When the unit is set up for hardware handshaking, the unit must
recognize a high voltage on Pin 20 to enable data to output from the unit.
Problem: The self-test works, but the data will not pass through the unit.
Solution: For serial-to-serial or parallel-to-parallel models, try to connect the two
cables connected to the unit’s input and output ports. Try to pass data through
both cables. If this is unsuccessful, contact Black Box Technical Support.
NOTE
Parallel cables should not exceed 20 feet (6.1 m) for a valid test. Typical
serial cables should not exceed 50 feet (15.2 m).
