IE Managed Miniature Media Converter Quick Start Guide
The compact media converter with full
SNMP management and PoE.
About this Quick Start Guide
This Quick Start Guide was designed to be used as a supplement to the
product installation manual to ease setup and installation of the IE Managed
Miniature Media Converter. Please refer to the user manual included on the
product documentation CD for more detailed instructions.
1. Advanced Features
•Bandwidth Control
•Q-in-Q Support
•VLANS
•Link Fault Pass-Through (LFPT)
The IE Managed Miniature Media Converter is a CPE device and is not
recommended to be installed in pairs. It can be installed as a Remote device
that is configured as a Host.
2. Power Options
The IE Managed Miniature Media Converter includes multiple powering options.
Users can choose any of the following three options, or more than one for
power redundancy:

IE Managed Miniature Media Converter
Page 2 724-746-5500 | blackbox.com LMM101A-R2
1. A country-specific, high-reliability power adapter (included). 100 to 240
VAC input, 5 VDC output.
2. IEEE 802.3af Power over Ethernet (Powered Device) standard; draws
power from PoE (Power Sourcing Equipment).
3. 4-terminal DC power block.
7 to 50 VDC
Console/Serial Port Power Adapter Connector
The IE Managed Miniature Media Converter powering options include AC and
DC power as well as Power over Ethernet, functioning as a PD compliant with
802.3af. To use the DC terminal block, connect to any one positive and any
one negative terminal from a power source.
CAUTION: This equipment is designed to permit the connection of the grounded
conductor of the DC supply circuit to the grounding conductor at the equipment.
3. Connecting Fiber and Twisted Pair Cables
The IE Managed Miniature Media Converter is a CPE device (Remote) and can
be connected to a Host device.
A Host device can be an IE Managed Miniature Media Converter or a switch.
For other types of installation, please see the user manual.
1. Connect the fiber cable to the fiber port.
FX LNK/ACT: Glows green when a link is established on the fiber port;
blinks green when activity is detected on the fiber port.
2. Plug in the RJ-45 cable to the Twisted Pair port.
TX LNK/ACT: Glows amber when a link is established on the copper port;
blinks amber when activity is detected on the copper port.
4. Configuration via Console Session
PoE (PD) Port
+5 to +24 VDC

IE Managed Miniature Media Converter
LMM101A-R2 724-746-5500 | blackbox.com Page 3
1. Set the computer / terminal for VT-100 emulation with the following
settings: 38.4K baud, 8 data bits, 1 stop bit, no parity, no flow control.
2. Connect the RS232 cable to the Console port, backside of the unit
3. Start the Serial session and press the Enter Key.
4. Set IP Address, Subnet Mask, Default Gateway and SNMP Community
String if direct SNMP / Telnet management is required.
5. Set Mode and Ethernet Port Config.
6. Set Password if serial port security is required (optional).
7. Type Reboot for changes to take effect.
5. Configuration via iView2(iConfig)
1. The computer must be attached to the local LAN connection via the fiber
port and on the same Subnet Mask.
2. Start iView2and scan for devices.
3. A new device will show IP Address 10.10.10.10 with its name IE Managed
Miniature Media Converter.
4. Open a session by typing in the USER NAME and USER PASSWORD.
(admin / admin are the defaults)
5. Set the IP Address, Subnet Mask and Default Gateway as required.

LMM101A-R2 Quick Start Guide, rev. 1 56-85722BB-00 A2
