Black Box LE1605A-ST-US User manual

1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax [phone]
© Copyright 2003. Black Box Corporation. All rights reserved.

MAY 2003
LE1605A-ST-US LE1606A-SC-US
LE1605A-ST-EU LE1606A-SC-EU
LE1605A-ST-UK LE1606A-SC-UK
LE1605A-ST-AU LE1606A-SC-AU
LE1605A-ST-JP LE1606A-SC-JP
10BASE-T to 10BASE-FL
Media Converters
CUSTOMER SUPPORT INFORMATION
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]

1
FCC AND IC RFI STATEMENTS
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy,
and if not installed and used properly, that is, in strict accordance with the
manufacturer’s instructions, may cause interference to radio communication.
It has been tested and found to comply with the limits for a Class A computing
device in accordance with the specifications in Subpart B of Part 15 of FCC rules,
which are designed to provide reasonable protection against such interference
when the equipment is operated in a commercial environment. Operation of
this equipment in a residential area is likely to cause interference, in which case
the user at his own expense will be required to take whatever measures may be
necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from
digital apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.

2
10BASE-T TO 10BASE-FL MEDIA CONVERTERS
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes
de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,
cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,
etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más
allá a lo descrito en las instrucciones de operación. Todo otro servicio
deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama,
sofá, alfombra o superficie similar puede bloquea la ventilación, no se
debe colocar en libreros o gabinetes que impidan el flujo de aire por los
orificios de ventilación.

3
NOM STATEMENT
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el
aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la
polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las
lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no
sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del
aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en
su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

4
10BASE-T TO 10BASE-FL MEDIA CONVERTERS
TRADEMARKS USED IN THIS MANUAL
ST is a registered trademark of AT&T.
Any other trademarks mentioned in this manual are
acknowledged to be the property of the trademark owners.

5
CONTENTS
Contents
Chapter Page
1. Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2 What the Package Includes. . . . . . . . . . . . . . 10
3. Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 MDI/MDI-X Connection . . . . . . . . . . . . . . . 11
3.2 Typical Applications . . . . . . . . . . . . . . . . . . . 12
3.3 Installing the Converter . . . . . . . . . . . . . . . . 15
4. LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.1 Calling Black Box. . . . . . . . . . . . . . . . . . . . . . 18
5.2 Shipping and Packaging . . . . . . . . . . . . . . . . 19

6
10BASE-T TO 10BASE-FL MEDIA CONVERTERS
1. Specifications
NOTE
In this manual (except where noted otherwise), LE1605A-
ST represents models LE1605A-ST-US, LE1605A-ST-EU,
LE1605A-ST-UK, LE1605A-ST-AU, and LE1605A-ST-JP.
LE1606A-SC represents models LE1606A-SC-US,
LE1606A-SC-EU, LE1606A-SC-UK, LE1606A-SC-AU, and
LE1606A-SC-JP.
Standards: IEEE 802.3
Operation: Half duplex
Maximum Distance: Twisted pair: 328 ft. (100 m);
Fiber: LE1605A-ST: 1.2 miles (2 km) 820-nm
multimode; LE1606A-SC: 9.3 miles (15 km) 1310-nm
single mode
User Controls: (1) Pushbutton for twisted-pair
MDI/MDI-X connection
Connectors: LE1605A-ST: (1) RJ-45, (2) ST®,
(1) barrel connector for Power;
LE1606A-SC: (1) RJ-45, (2) SC,
(1) barrel connector for Power
Indicators: (5) LEDs: (2) Link, (2) Receive, (1) Power

7
CHAPTER 1: Specifications
Temperature Tolerance:
Operating: 32 to 158°F (0 to 70°C);
Storage: -4 to +158°F (-20 to +70°C)
Relative Humidity: Up to 90%, noncondensing
Power: All models: External power supply:
Output: 12 VDC @ 0.8 A;
LE1605A-ST-US, LE1606A-SC-US:
Input: 120 VAC, 60 Hz (2-prong);
LE1605A--ST-EU, LE1606A-SC-EU:
Input: 230 VAC, 50 Hz (2-prong);
LE1605A--ST-UK, LE1606A-SC-UK:
Input: 230 VAC, 50 Hz (3-prong);
LE1605A--ST-AU, LE1606A-SC-AU:
Input: 240 VAC, 50 Hz, (3-prong);
LE1605A--ST-JP, LE1606A-SC-JP:
Input: 100 VAC, 50/60 Hz (2-prong)
Size: 0.9"H x 2.9"W x 4.9"D (2.3 x 7.4 x 12.4 cm)
Weight: 0.3 lb. (0.1 kg)

8
10BASE-T TO 10BASE-FL MEDIA CONVERTERS
2. Introduction
2.1 Description
Use the 10BASE-T to 10BASE-FL Media Converters to
connect conventional copper-based networks to fiber-
based networks. These converters support both an RJ-45
jack and a pair of ST or SC fiberoptic connectors. They
comply with the IEEE 802.3 10BASE-T and 10BASE-FL
standards, and are compatible with other 10BASE-T/
10BASE-FL and 10/100-Mbps Ethernet devices.
An MDI/MDI-X button allows the media converter to
connect directly to either a workstation, switch, or hub
using crossover or straight-through cable.
Using 820-nm multimode fiber, the LE1605A-ST
converter spans distances up to 1.2 miles (2 km). With
1310-nm single-mode fiber and the LE1606A-SC, the
distance between a LAN switch and another switch or a
file server can be up to 9.3 miles (15 km).
Figures 2-1 and 2-2 show the available models.

9
CHAPTER 2: Introduction
Figure 2-1. 10BASE-T to 10BASE-FL Media Converter
with ST connectors.
Figure 2-2. 10BASE-T to 10BASE-FL Media Converter
with SC connectors.

10
10BASE-T TO 10BASE-FL MEDIA CONVERTERS
2.2 What the Package Includes
• (1) 10BASE-T to 10BASE-FL Media Converter
• (1) AC power adapter
• (4) Non-skid rubber feet
• (2) Mounting screws
• This users’ manual
If anything is missing or damaged, please contact Black
Box at 724-746-5500.

11
CHAPTER 3: Installation
3. Installation
3.1 MDI/MDI-X Connection
Before plugging in and installing your media converter,
you’ll need to set the MDI/MDI-X button. This button
selects whether you need to use crossover or straight-
through twisted-pair cabling to connect the RJ-45 ports
on the 10BASE-T portion of your network. (See Figure
3-1.) Simply set the button as described in Table 3-1.
Figure 3-1. MDI/MDI-X button.
NOTE
When the button is pressed in, MDI-X is selected. When the
button is out, MDI is selected.

12
10BASE-T TO 10BASE-FL MEDIA CONVERTERS
Table 3-1. Crossover selection.
Connected Device Cable Configuration Setting
Hub or switch Straight-through MDI-X
Hub or switch Crossover MDI
DTE (NIC) Straight-through MDI
DTE (NIC) Crossover MDI-X
3.2 Typical Applications
Once you’ve set the MDI/MDI-X button, you’ll need to
determine which application you’ll use.
In Examples 1 through 3 (see Figures 3-2 through 3-4),
two media converters are used to extend the distance via
fiberoptic cable between two 10BASE-T devices. In
Example 4 (see Figure 3-5), one media converter is used
to connect a 10BASE-T network to a 10BASE-FL device
via fiberoptic cable.

13
E XAMPLE
1: T WO LAN S WITCH W ORKGROUPS
Figure 3-2. Converters connecting two LAN switch workgroups.
E XAMPLE 2: LAN S WITCH AND A N ETWORK S ERVER
Figure 3-3. Converters connecting a LAN switch and a network server.
CHAPTER 3: Installation
10BASE-T switch
10BASE-T to 10BASE-FL
Media Converter
10BASE-T to 10BASE-FL
Media Converter
10BASE-T switch
328 ft. 328 ft.
Fiber cable
(Multimode: 2 km;
Single-mode: 15 km)
10BASE-T switch
Server
328 ft. 328 ft.
Fiber cable
(Multimode: 2 km;
Single-mode: 15 km)
10BASE-T to
10BASE-FL Media
Converter 10BASE-T to
10BASE-FL Media
Converter

E XAMPLE
3: 10BASE-T H UB AND A W ORKSTATION
Figure 3-4. Converters connecting a 10BASE-T hub and a workstation.
E XAMPLE 4: 10BASE-T N ETWORK AND A 10BASE-FL D EVICE
Figure 3-5. Converter connecting a
10BASE-T network and a 10BASE-FL device.
14
10BASE-T TO 10BASE-FL MEDIA CONVERTERS
Server
328 ft.
Fiber cable
(Multimode: 2 km;
Single-mode: 15 km)
Workgroup printer with
fiber print server
10BASE-T hub
Workstation
328 ft. 328 ft.
Fiber cable
(Multimode: 2 km;
Single-mode: 15 km)
10BASE-T to 10BASE-FL
Media Converter
10BASE-T to
10BASE-FL Media
Converter
10BASE-T to
10BASE-FL Media
Converter

15
3.3 Installing the Converter
After you set the MDI/MDI-X button as described in
Section 3.1 and determine how you will use your
converter as shown in Section 3.2, you’ll need to place
the converter on a desktop or mount it on a wall. Next,
power on the converter. Connect the converter to a
10BASE-T device or network segment. Finally, connect
the converter to a 10BASE-FL device or to another
media converter via fiberoptic cable. Follow the steps
listed below:
1. For desktop installation, affix the four non-skid
rubber feet to the bottom of the converter.
For wallmount installation, use the underside of
the converter as a template to measure and mark
out the position of the holes onto the surface
where you will install the converter. Then use the
two mounting screws provided to mount the
converter firmly in place.
2. Connect the appropriate power supply for your
country to the power connector on the side of the
converter. Plug the power supply into a suitable
power outlet.
CHAPTER 3: Installation

16
10BASE-T TO 10BASE-FL MEDIA CONVERTERS
3. Power on the converter. The power LED should
light. If it does not, make sure that the power
cable is plugged in properly.
NOTE
When the converter is connected to a 10/100BASE-T
device, it will run at 10 Mbps, half-duplex mode.
4. Make sure that the Category 5 straight-through
twisted-pair cable between the 10BASE-T device
(hub or switch) and the converter is no longer
than 328 ft. (100 m).
5. Connect one end of the cable to the RJ-45 jack on
the converter.
6. Connect the other end of the cable to the RJ-45
jack on the 10BASE-T device.
7. Connect one end of a fiber cable to the ST or SC
connectors on the converter.
8. Connect the other end of the fiber cable to the ST
or SC connectors on the other converter or
10BASE-FL device.
Installation is complete.

17
4. LED Indicators
Once your 10BASE-T to 10BASE-FL Media Converter is
properly installed, it operates maintenance-free.
Several LEDs tell you the status of the converter and the
network at a glance. See Figure 4-1.
Figure 4-1. LED location.
• The Power LED (located on the side of the
converter) lights to indicate normal operation.
• (2) Link LEDs light when receiving link pulses
from a compliant device.
• (2) Receive LEDs flash or light when data packets
are being received.
CHAPTER 4: LED Indicators
