Overview
This in-line surge protector uses a solid-state design and
multistage hybrid circuits to give maximum protection. It
protects all wires and pins 1, 2, 4, and 5 on the ISDN ST
interface.
What’s included
• In-line surge protector
• RJ-45 patch cable
• Specification sheet
Specifications
Application: CSU/DSU, T1, DDS
Ground Wire: Yes
Maximum Shunt Capacitance: <75 pF
Peak Pulse Current: 50 amps
Pins Protected: All
Protection Type: Avalanche diode and thyristor technology
Response Time: <5 ns
Standard Clamping Voltage: 60 volts
Connectors: (2) RJ-45 F

BL A C K BOX®
FREE, live, 24/7 Tech Support is just 30 seconds away.
724-746-5500 | blackbox.com
Installation Steps
1. Disconnect the RJ-45 line from the equipment you wish to protect.
2. If the equipment you wish to protect is metal, plug the surge protector into the unit and attach the ground wire to the unit’s
chassis. If the unit is plastic, connect the ground wire to the electrical outlet ground for the unit.
3. Connect the network-side RJ-45 cable to the surge protector and connect the patch cable included with the surge protector
between the surge protector and the equipment you are protecting.
