Black Box PI9120A User manual

1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax [phone]
© Copyright 1995. Black Box Corporation. All rights reserved.

CUSTOMER
SUPPORT
INFORMATION
Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax [phone]
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]
Buffer Activity Power
Intelligent Printer Switch
plus
Intelligent Printer Switch plus
NOVEMBER 1995
PI9120A PI9120AE PI9121A PI9121AE PI9122A PI9122AE
PI9123A PI9123AE PI9124A PI9124AE PI9125A PI9125AE
PI9126A PI9126AE PI9127A PI9127AE PI9128A PI9128AE
PI9129A PI9129AE PI9130A PI9130AE PI9131A PI9131AE
PI9140A PI9140AE PI9141A PI9141AE PI9145 PI9146

3
FCC AND IC STATEMENTS, TRADEMARKS
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO-FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy
and if not installed and used properly, that is, in strict accordance with the
manufacturer’s instructions, may cause interference to radio communication.
It has been tested and found to comply with the limits for a Class A
computing device in accordance with the specifications in Subpart J of
Part 15 of FCC rules, which are designed to provide reasonable protection
against such interference when the equipment is operated in a commercial
environment. Operation of this equipment in a residential area is likely to
cause interference, in which case the user at his own expense will be required
to take whatever measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from
digital apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.
TRADEMARKS
AT®and IBM®are registered trademarks, and PC/XT™is a trademark,
of IBM Corporation.
Calcomp®is a registered trademark of Calcomp, Incorporated.
Centronics®is a registered trademark of GENICOM Corporation.
Diablo®is a registered trademark of Xerox Corporation.
Epson®is a registered trademark of Seiko Epson Corporation.
Hewlett-Packard®, HP®, and LaserJet®are registered trademarks
of Hewlett-Packard.
Microsoft®and Windows®are registered trademarks of Microsoft Corporation.
OKIDATA®is a registered trademark of Oki America, Incorporated.
QUME®is a registered trademark of DTC Data Technology.
Any other trademarks mentioned in this manual are acknowledged to be the property
of the trademark owners.

4
INTELLIGENT PRINTER SWITCH PLUS
Eurpoean Union Declaration of Conformity
This equipment has been tested and found to comply with the limits
for a class A computing device in accordance with the specifications in the
European standard EN55022. These limits are designed to provide reasonable
protection against harmful interference in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio or television reception.
Operation of this equipment in a domestic environment may cause radio
interference. If this equipment does cause interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to correct the interference by one or more of the
following measures.
* Reorient or relocate the receiving antenna
* Increase the separation between the equipment and the receiver
* Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected
* Consult the dealer or an experienced radio/TV technician for help
Warning
Shielded interface cables must be used with this equipment to maintain
compliance with radio-frequency emission regulations and ensure a
suitably high level of immunity to environmental electromagnetic
disturbances.

5
NOM STATEMENT
NORMAS OFICIALES MEXICANAS (NOM) ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes
de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo,
cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca,
etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales
que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como
sea recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más
allá a lo descrito en las instrucciones de operación. Todo otro servicio
deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama,
sofá, alfombra o superficie similar puede bloquea la ventilación, no se
debe colocar en libreros o gabinetes que impidan el flujo de aire por los
orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de
calor como radiadores, registros de calor, estufas u otros aparatos
(incluyendo amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo
del tipo descrito en el instructivo de operación, o como se indique en
el aparato.

6
INTELLIGENT PRINTER SWITCH PLUS
12. Precaución debe ser tomada de tal manera que la tierra fisica y la
polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen
del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las
lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no
sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del
aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en
su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

7
TABLE OF CONTENTS
Chapter Page
1. Specifications ....................................................................................................9
2. Introduction ....................................................................................................12
2.1 Overview.................................................................................................12
2.2 Package Contents ..................................................................................12
2.3 Cable Requirements..............................................................................13
3. Installation.......................................................................................................14
3.1 Configuring Your Intelligent Printer Switch plus ...................................14
3.1.1 Parallel Models .............................................................................14
3.1.2 Serial Models ................................................................................16
3.2 Selecting Ports for Your Equipment ...................................................16
3.3 Connecting PCs and Printers ...............................................................16
3.4 Powering On Attached Devices ............................................................17
3.5 Enabling Your Computer Ports ............................................................18
3.5.1 For Parallel Models ......................................................................18
3.5.2 For Serial Models..........................................................................18
3.6 Using the Intelligent Printer Switch plus ................................................19
3.7 Front-Panel Indicators ..........................................................................19
4. ADMENU Printer-Control Software..............................................................20
4.1 Overview.................................................................................................20
4.2 Installing the ADMENU Software ........................................................20
4.3 Running ADMENU ..............................................................................21
4.4 Installing ADMENU for Use in Microsoft Windows ...........................21
4.5 Command-Line Options ......................................................................22
4.6 Using ADMENU ....................................................................................23
4.7 Main Menu ............................................................................................24
4.8 Selecting a Destination Printer ............................................................25
4.9 The FUNCTIONS Menu.......................................................................26
4.10 The OPTIONS Menu...........................................................................27
4.11 Direct Output of Typed Keyboard Characters ...................................28
Contents

8
INTELLIGENT PRINTER SWITCH PLUS
Contents (continued)
Chapter or Appendix Page
5. Controlling the Intelligent Printer Switch plus with PC Commands...............29
5.1 Overview.................................................................................................29
5.2 The CONNECT Command ..................................................................30
5.3 The CLEAR Command.........................................................................31
5.4 The END OF FILE Command..............................................................31
5.5 Creating Batch Files for IBM PCs.........................................................32
5.6 Setting Up Default Start-of-Day Destination Ports ..............................33
6. ADMODE Serial-Port Control Utility ............................................................34
Appendix A: Parallel-Port Specifications ..........................................................36
Appendix B: Serial-Port Specifications .............................................................37
B.1 RS-232 Pin Assignments........................................................................37
B.2 Connecting to Computers ....................................................................37
B.2.1 Connecting to IBM PC and Compatible Computers.................38
B.2.2 Connecting to IBM AT and Compatible Computers ................38
B.3 Connecting to Printers..........................................................................39
B.4 Connecting to Modems ........................................................................39
B.5 Connecting to Plotters .........................................................................40

9
CHAPTER 1: Specifications
For all specifications in which the phrase “depending on the model” appears,
refer to Section 2.1 of this manual (especially to Table 2-1) for a breakdown
of features by model.
System Hardware Required — For included software: IBM PC, PC/XT,
AT, or PS/2 computers
System Software Required — For included ADMENU software: DOS 2.1
or later or Windows 3.0, 3.1, or 95;
For included ADMODE software: DOS 2.1
or later
System Memory Required — For included ADMENU software:
10 KB if installed for text only;
22 KB if installed for text and graphics;
For included ADMODE software: 1 KB
System Disk Space
Required — Minimum (ADMENU and ADMODE):
30 KB;
Maximum (all included software): 450 KB
Compliance — FCC Part 15 Class A, DOC Class/
MDC classe A
Interface — EIA RS-232 serial (DTE) or IBM PC
parallel, depending on the model
Protocol — Serial: Asynchronous only
Data Format — Serial: 7 or 8 data bits, 1 or 2 stop bits, and
odd, even, or no parity (user-selectable)
Flow Control — Hardware (DTR/CTS) or software (X-ON/
X-OFF or ETX/ACK), user-selectable
Operating Mode — Serial: Full duplex
Data Rate — Serial: 57,600, 38,400, 19,200, 9600, 4800,
2400, 1200, or 300 bps (user-selectable)
1. Specifications

10
INTELLIGENT PRINTER SWITCH PLUS
Throughput — Up to 55,000 characters per second (cps)
per printer port
Maximum Distance — From computers to Intelligent Printer
Switch plus:
Distances above 33 feet (10 m) are not
recommended;
From Intelligent Printer Switch plus to
printers:
328 feet (100 m);
Maximum distance will be affected by data
rate and cable quality
Internal Memory — 256 KB, 1 MB, 2 MB, or 4 MB of buffer
RAM, depending on the model;
Optional 1-MB and 4-MB Memory
Expansion Kits are available (buffer can
be expanded to a maximum of 4 MB)
User Controls — Parallel models: (1) Bottom-mounted
6-position DIP switch for timeout, normal
vs. burst mode, and Port 2 direction;
Serial models: (3) Bottom-mounted
10-position DIP switches for data rate,
data format, and flow control:
(1) for Port 1, (1) for Port 2, and (1) for
Ports 3 through 6 or 8
Indicators — (6) LEDs: (1) Power, (1) Activity, (4) Buffer
Connectors — (6) or (8) DB25 female, depending on the
model:
(1) dedicated printer port;
(1) printer or computer port (user-
selectable on parallel models, auto-
configuring on serial models);
(4) or (6) ports for computers only

11
CHAPTER 1: Specifications
Power — Models with “A” suffix:
From wallmount power supply:
Input: 115-VAC, 50 to 60 Hz;
Output: 9-VAC, 1.5 A;
Models with “AE” suffix:
From desktop power supply:
Input: 230-VAC, 50 to 60 Hz;
Output: 9-VAC, 1.5 A
Size — 3.2"H x 10.2"W x 5.5"D (8.1 x 26 x 14 cm)
Weight — 4.3 lb. (2 kg)

12
INTELLIGENT PRINTER SWITCH PLUS
2.1 Overview
The Intelligent Printer Switch plus (IPSP) is a high-performance buffered data
switch that provides fast turnaround for multiple PC users sharing one or two
printers. Operation is fully automatic when sharing a single printer. With two
printers, ADMENU PC software (included) or PC commands let you control
operation.
The IPSP can accept data simultaneously from all the attached computers,
buffering the overflow until your printer is ready for more. It accepts data files
from each computer on a first-come, first-served basis and recognizes each as
a single printable file. It won’t start printing another file until there’s been a
break in transmission that exceeds the timeout period. Only then will the
IPSP recognize input from the next computer.
The IPSP is available in a variety of models. Parallel models are compatible
with PCs, printers, and plotters that support IBM®PC and Centronics®parallel
interfaces. Serial models support the EIA RS-232 standard serial interface.
Table 2-1 provides a complete list of all the models. Unless otherwise noted,
the information in this manual is applicable to all the models.
2.2 Package Contents
• Intelligent Printer Switch plus (IPSP)
• Power supply
• 3.5" ADMENU software diskette for IBM compatible PCs
• This manual
2. Introduction

13
CHAPTER 2: Introduction
Table 2-1. Available Intelligent Printer Switch plus Models
NOTE
Models with product codes ending in “A” have 115-VAC power adapters.
Product codes ending in “AE” have 230-VAC adapters.
2.3 Cable Requirements
F OR M ODELS WITH P ARALLEL P ORTS :
• PC to Intelligent Printer Switch plus (input ports)
DB25 male to DB25 male, all lines connected.
Cables longer than 25 feet (7.6 m) might not function reliably; you
might be able to reach or exceed this distance by using a powered
parallel extension cable (call your supplier for technical support).
• Intelligent Printer Switch plus to Printer (output ports)
DB25 male to 36-pin Centronics male (standard printer cable).
Maximum distance: Up to 330 feet (100 m).
F OR M ODELS WITH S ERIAL P ORTS :
Cable requirements will vary depending on your equipment.
See Appendix B.
Name Product Codes Buffer Size
6 Port Parallel PI9120A, PI9120AE 256 KB
PI9121A, PI9121AE 1 MB
PI9122A, PI9122AE 2 MB
PI9140A, PI9140AE 4 MB
8 Port Parallel PI9123A, PI9123AE 256 KB
PI9124A, PI9124AE 1 MB
PI9125A, PI9125AE 2 MB
PI9141A, PI9141AE 4 MB
6 Port Serial PI9126A, PI9126AE 256 KB
PI9127A, PI9127AE 1 MB
PI9128A, PI9128AE 2 MB
8 Port Serial PI9129A, PI9129AE 256 KB
PI9130A, PI9130AE 1 MB
PI9131A, PI9131AE 2 MB
Optional Memory Expansion PI9145 1 MB
PI9146 4 MB

14
INTELLIGENT PRINTER SWITCH PLUS
3.1 Configuring Your Intelligent Printer Switch plus
Figure 3-1 below shows the rear panel of an eight-port Intelligent Printer
Switch plus (IPSP). On a six-port model, the top two connector slots on the left
would be empty. On all models, Port 1 is a dedicated printer-output port. Port
2 is a bidirectional input/output port. The remaining ports are all computer-
input ports.
Refer to Figure 3-1 as you read the configuration instructions.
Figure 3-1. Rear view of an Intelligent Printer Switch plus.
3.1.1 P ARALLEL M ODELS
Set the option switches on the underside of the IPSP to the settings required
by your system. (See Figure 3-2 on the next page.) The default settings are
suitable for most installations. Note that the option switches are read only
when the IPSP is first powered on.
Timeout
The IPSP switches between users on a timeout basis. If no data has been sent
from the current user for the timeout period, the IPSP will switch to the next
user. A timeout period of 16 seconds (the default setting) is suitable for most
systems.
Mode
If you are using fast PCs and printers with enhanced parallel ports, burst
mode may speed up your printing performance. For most systems normal
mode (the default setting) will give the best overall performance.
IN / OUT PORT
Computer or Printer
OUTPUT PORT
Printer
2
1
INPUT PORT
Computer
INPUT PORT
Computer
INPUT PORT
Computer
INPUT PORT
Computer
INPUT PORT
Computer
INPUT PORT
Computer
9V~
50-60Hz
1A
PARALLEL Ports
3. Installation

15
CHAPTER 3: Installation
Port 2 Direction
Port 2 can be used as an input from a computer or an output to a printer. In
automatic mode (the default setting), the port intelligently detects the type of
device that it is connected to and configures itself automatically. You can also
manually switch the port from input to output using the option switches.
When using data boosters or powered cables, you should set the direction
of the port manually, because automatic detection might not work. If you
experience any problems with Port 2, set the direction manually.
123456
ON
123456
ON
FRONT
REAR
Underside of
Parallel Models
Timeout Port 2 direction
Mode
Unused
Burst mode
Normal mode
30 seconds
16 seconds
1 minute
4 minutes Automatic IN / OUT
detection on port 2
Set Port 2 as INPUT
Set Port 2 as OUTPUT
INPUT = Computer connections
OUTPUT = Printer connections
Default settings
123456
ON
Figure 3-2. Option switches and settings for parallel models.
(Factory-default settings are shown in larger type.)
16 seconds Normal mode
Automatic IN/OUT
detection on port 2

16
INTELLIGENT PRINTER SWITCH PLUS
3.1.2 S ERIAL M ODELS
Set the option switches on the underside of the IPSP to those required by
your system. (See Figure 3-3.) The default settings are suitable for most
installations. Note that the option switches are read only when the IPSP
is first powered on. The IPSP can be set to use these types of flow control
(handshaking):
DTR/CTS (Hardware Handshake)—Uses hardware signal lines (Pins 5
and 20) to control the flow of data.
X-ON/X-OFF (Printer & Plotter Connections Only)—The flow of data is
controlled by the receiving device, which transmits X-OFF (stop data flow)
and X-ON (start data flow) characters to the IPSP. Use this setting only on
ports connected to printers and plotters.
X-ON/X-OFF (Computer Connections Only)—The flow of data is controlled
by the IPSP, which transmits X-ON (start data flow) and X-OFF (stop data
flow) characters to the computer. Use this setting only on ports connected
to computers.
NOTE
The X-ON/X-OFF setting for printer and plotter connections WILL NOT
WORK correctly for computer connections and vice versa. The X-ON and
X-OFF characters are not passed through the IPSP.
ETX/ACK—The flow of data is controlled by sending blocks of data and
waiting for an ACKnowledgement character to be received.
3.2 Selecting Ports for Your Equipment
If you’re sharing one printer, connect it to Port 1. You may use any of the
other ports to connect to computers. If you have two printers, connect the
most commonly used printer to Port 1 and the other to Port 2. By default,
all print data will automatically be routed to Port 1.
All ports have equal-priority access to the Intelligent Printer Switch plus, and
data output is handled on a first-come, first-served basis.
3.3 Connecting PCs and Printers
Turn off power to all computers and printers before connecting them to the
Intelligent Printer Switch plus.

17
CHAPTER 3: Installation
3.4 Powering On Attached Devices
You can switch on your equipment in any order; however, it is generally better to
switch on all your devices at the same time or switch on the Intelligent Printer
Switch plus last. When the IPSP is powered on, the Buffer and Activity LEDs will
flash for a few seconds while the unit performs a self-test.
FRONT
REAR
Underside of
Serial Models
57k6 baud
12345678910
ON
12345678910
ON
1 2 3 4 5 6 7 8 9 10
ON
1 2 3 4 5 6 7 8 9 10
ON
12345678910
ON
12345678910
ON
12345678910
ON
12345678910
ON
12345678910
ON
12345678910
ON
12345678910
ON
12345678910
ON
12345678910
ON
12345678910
ON
38k4 baud
19k2 baud
9k6 baud
4k8 baud
2k4 baud
1k2 baud
300 baud
XON/OFF - (printer & plotter
connections only)
XON/OFF - (computer
connections only)
ETX/ACK handshake
DTR/CTS handshake
Sets protocol for
serial port 1
Sets protocol for
serial port 2
Sets protocol for
serial port 3 to 8
ABC
Even parity
Odd parity
No parity
2 stop bits
1 stop bit
7 bits per character
8 bits per character
Figure 3-3. Option switches and settings for serial models.
(Factory-default settings are shown in larger type.)
DTR/CTS
No parity
1 stop bit
8 data bits
57.6 Kbps
38.4 Kbps
19.2 Kbps
9.6 Kbps
4.8 Kbps
2.4 Kbps
1.2 Kbps
300 bps
X-ON/X-OFF (printer and plotter
connections only)
X-ON/X-OFF (computer
connections only)
ETX/ACK
7 data bits
Sets data rate, data
format, & flow control
for serial port 1
Sets data rate, data
format, & flow control
for serial port 2
Sets data rate, data
format, & flow control
for other serial ports

18
INTELLIGENT PRINTER SWITCH PLUS
3.5 Enabling Your Computer Ports
3.5.1 F OR P ARALLEL M ODELS
Your PC’s parallel interfaces do not normally need to be configured.
However, for IBM PCs running DOS, PC timeouts may occur if the buffer on
the Intelligent Printer Switch plus becomes full. To prevent timeouts in case of
a full buffer, use the MODE command with the “P” parameter, like this:
>MODE LPT1:,,P
This forces your PC to retry sending the data to the IPSP instead of timing
out. Refer to your DOS manual for more information about the MODE
command.
3.5.2 F OR S ERIAL M ODELS
To enable your PC’s serial ports, set the required data rate and data format.
On IBM compatible PCs this can be done with the DOS MODE command.
You may also use the ADMODE software utility supplied with the IPSP (see
Chapter 6). The MODE command can be used together with the ADMODE
command.
The ADMODE settings will always override the MODE settings, and the
MODE command (with “P” option) can be used to prevent application
timeouts. The example shown below would set COM1 to 57,600 bps, no
parity, eight data bits, one stop bit, and no application timeout. (See
Chapter 6.)
>MODE COM1:9600,N,8,1,P
>ADMODE COM1:57600,N,8,1
On IBM PCs running DOS, you might also want to redirect all print data that
would have been sent to the parallel printer port (LPT1) to the serial port. To
do this, use the MODE command this way:
>MODE LPT1:=COM1:

19
CHAPTER 3: Installation
3.6 Using the Intelligent Printer Switch plus
Once all the preceding connections are made, your Intelligent Printer Switch plus
is ready for use. Each attached computer can commence printing as if directly
connected to a printer. By default all print data is routed to Port 1.
If you want to route data to a second printer attached to Port 2, you’ll need
to use the ADMENU software utility (see Chapter 4) or appropriate PC
commands (see Chapter 5). Once a computer has selected a new printer, all
print data from that computer will be routed to this printer until a different
printer is selected, or until the IPSP is switched off.
3.7 Front-Panel Indicators
Activity LED
Lights — When data is available or a timeout is pending. (If data has been
sent in on a port, the activity light will remain on until the port has timed
out.)
Dark — When no data is being transferred and no data is available.
Flashes — When data is being transferred.
Buffer-Status LEDs
These show the current state of the internal buffer’s memory capacity:
■
■—Buffer is more than 1⁄4full ■ —Buffer is more than 1⁄2full
■ ■ ■
■ ■ —Buffer is more than 3⁄4full ■ ■ —Buffer is completely full
If your buffer frequently fills to the 3⁄4level, you should consider ordering the
optional Memory Expansion to increase performance. The Intelligent Printer
Switch plus will continue to operate even if its buffer is full.

20
INTELLIGENT PRINTER SWITCH PLUS
4.1 Overview
The ADMENU printer-control software allows you to switch between printers
and to control printer functions. It’s located on the utility-software diskette
supplied with your Intelligent Printer Switch plus and is for use with IBM
compatible PCs. You can run the software as a memory-resident or
nonresident program in both DOS and Windows®environments. Installing
ADMENU as a memory-resident program allows you to “pop up” the menu
on your screen using a hotkey combination.
4.2 Installing the ADMENU Software
The ADMENU installation program (INSTALL) will automatically copy files
to your hard disk and install ADMENU as a memory-resident or nonresident
program as required. You can also install the software by adding the
ADMENU command line to your AUTOEXEC file (see Section 4.5).
The following commands refer to the floppy drive as drive “A”. If your floppy
drive has a letter designation other than “A,” substitute that letter for “A” in
these commands.
To install ADMENU:
• Insert the ADMENU disk in drive A and type:
A: <enter>
• Then (at the A: prompt) type:
INSTALL <enter>
• Follow the instructions given in the installation program.
• Reboot your PC.
4. ADMENU Printer-Control Software
