Black Box AlertWerks EME102A-R3 User manual

Monitor environmental variations, power,
physical threats, and security.
Includes a proprietary operating system that is similar to Linux®, with TCP/IP
stack, Web server, e-mail, and full SNMP functionality.
AlertWerks™ServSensor Jr. and ServSensors
EME102A-R3 EME106A-R2 EME111A-20-R3 EME113A-20-R3 EME154A-R2
EME103A-R3 EME108A-R3 EME111A-60-R2 EME113A-60-R2 EME155A-R2
EME104A-R3 EME109A-R3 EME112A-20-R3 EME152A-R2 EME158A
EME105A-R2 EME110A-R3 EME112A-60-R2 EME153A-R2
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support 24 hours a day, 7 days a week: Call 877-877-2269 or fax [phone]
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [e-mail]
Customer
Support
Information

877-877-2269 | blackbox.com
Page 2
Trademarks Used in this Manual
We‘re here to help! If you have any questions about your application
or our products, contact Black Box Tech Support at 877-877-2269
or go to blackbox.com and click on “Talk to Black Box.”
You’ll be live with one of our technical experts in less than 60 seconds.
Trademarks Used in this Manual
Black Box and the Double Diamond logo are registered trademarks, and AlertWerks is a trademark, of BB Technologies, Inc.
CA-Unicenter is a registered trademark of CA, Inc.
GNU is a trademark of Free Software Foundation.
HP is a registered trademark of Hewlett-Packard Company.
OpenView is a registered trademark of Hewlett-Packard Development Company.
IBM and Tivoli are registered trademarks of International Business Machines Corporation.
Linux is a registered trademark of Linus Torvalds.
Internet Explorer, Microsoft, Excel, MS-DOS, and Windows are registered trademarks of Microsoft Corporation.
Kiwi is a trademark of SolarWinds Worldwide, LLC.
Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

Page 3
877-877-2269 | blackbox.com
FCC and IC RFI Statements
Federal Communications Commission and Industry Canada Radio Frequency Interference
Statements
This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict
accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to
comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules,
which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial
environment. Operation of this equipment in a residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparatus set out in the Radio
Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques
de la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par Industrie Canada.

877-877-2269 | blackbox.com
Page 4
NOM Statement
Instrucciones de Seguridad
(Normas Oficiales Mexicanas Electrical Safety Statement)
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca
de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de operación.
Todo otro servicio deberá ser referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato eléctrico
sobre una cama, sofá, alfombra o superficie similar puede bloquea la ventilación, no se debe colocar en libreros o gabinetes
que impidan el flujo de aire por los orificios de ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor, estufas u otros
aparatos (incluyendo amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de operación, o como
se indique en el aparato.
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados
sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.

Page 5
877-877-2269 | blackbox.com
Table of Contents
Table of Contents
1. Specifications...................................................................................................................................................................... 6
2. Overview ........................................................................................................................................................................ 8
2.1 Introduction ................................................................................................................................................................ 8
2.1.1 What is the AlertWerks ServSensor? ...............................................................................................................8
2.1.2 Available Models ............................................................................................................................................. 8
2.1.3 How to Use this Manual.................................................................................................................................. 9
2.2 Features ......................................................................................................................................................................9
2.3 What’s Included .......................................................................................................................................................... 9
2.4 Hardware Description ............................................................................................................................................... 13
2.4.1 ServSensor Jr. (EME102A-R3, EME103A-R3, EME104A-R3, EME152A-R2, EME153A-R2, EME154A-R2)....... 13
2.4.2 ServSensor 4 (EME105A-R2, EME106A-R2, EME155A-R2) ............................................................................ 14
2.4.3 ServSensor 8 (EME108A-R3, EME109A-R3, EME110A-R3, EME158A)........................................................... 15
2.4.4 ServSensor X20 (EME111A-20-R3, EME111A-60-R2, EME112A-20-R3, EME112A-60-R2,
EME113A-20-R3, EME113A-60-R2)................................................................................................................ 16
2.4.5 ServSensor 8-X20 20 Extra Dry Contact Inputs ............................................................................................. 17
3. Installation ...................................................................................................................................................................... 18
3.1 Assigning an IP Address ........................................................................................................................................... 18
3.2 Testing Your New IP Address .................................................................................................................................... 21
3.3 Upgrading the Firmware ...........................................................................................................................................22
4. Setting up a Sensor and Downloading Sensor Data......................................................................................................... 27
4.1 Basic Setup................................................................................................................................................................ 27
4.2 Downloading Sensor Data ........................................................................................................................................30
5. Notifications ..................................................................................................................................................................... 33
5.1 Setting Up a Trap...................................................................................................................................................... 33
5.2 Setting Up E-mail Notifications .................................................................................................................................34
6. System Settings ................................................................................................................................................................38
6.1 Network Settings ......................................................................................................................................................38
6.2 System Tab................................................................................................................................................................40
7. Making Your Unit Visible to the Internet..........................................................................................................................46
7.1 Simple Setup.............................................................................................................................................................46
7.2 Setting Up Your PC’s Routing Table ..........................................................................................................................46
8. Frequently Asked Questions (FAQs).................................................................................................................................. 47

877-877-2269 | blackbox.com
Page 6
Chapter 1: Specifications
1. Specifications
Color — EME102A-R3–EME104A-R3, EME152A-R2–EME154A-R2: Blue;
EME105A-R2–EME106A-R2, EME155A-R2, EME108A-R3–EME110A-R3, EME158A, EME111A-20-R3, EME111A-60-R2,
EME112A-20-R3, EME112A-60-R2, EME113A-20-R3, EME113A-60-R2,: Black
Default IP Address — 192.168.0.100
Enclosure — EME102A-R3–EME104A-R3, EME152A-R2–EME154A-R2: Plastic housing;
EME105A-R2–EME106A-R2, EME155A-R2, EME158A, EME108A-R3–EME110A-R3, EME111A-20-R3, EME111A-60-R2,
EME112A-20-R3, EME112A-60-R2, EME113A-20-R3, EME113A-60-R2: Steel housing
Mounting — EME102A-R3–EME104A-R3, EME152A-R2–EME154A-R2: Shelf- or DIN-rail mounting;
EME105A-R2–EME106A-R2, EME155A-R2, EME158A, EME108A-R3–EME110A-R3, EME111A-20-R3, EME111A-60-R2,
EME112A-20-R3, EME112A-60-R2, EME113A-20-R3, EME113A-60-R2: 1U rackmount
Number of Dry Contacts — EM E111A -20 - R3 – EM113A -20 - R2: 20 ;
EME111A-60-R2–EME113A-60-R2: 60
Operating System — Proprietary, similar to Linux®, including TCP/IP stack, Web server, e-mail, and full SNMP functionality
Operating Environment — Indoor
Standards — EME152A-R2–EME154A-R2, EME158A: IEEE 802.3af compliant
Connectors — EME102A-R3–EME104A-R3: Network: (1) RJ-45 10-Mbps full-duplex Ethernet;
Sensor Input: (2) RJ-45; Power: (1) 5-VDC power connector;
EME152A-R2–EME154A-R2: Network: (1) RJ-45, 10-Mbps full-duplex Ethernet /PoE input,
Sensor Input: (2) RJ-45; Power: (1) 5-VDC power connector;
EME105A-R2–EME106A-R2: Network: (1) RJ-45 10-Mbps full-duplex Ethernet, Sensor Input: (4) RJ-45, Power: (1) 5-VDC
input;
EME155A-R2: Network: (1) RJ-45 10-Mbps full-duplex Ethernet/PoE input, Sensor Input: (4) RJ-45, Power: (1) 5-VDC input;
EME108A-R3–EME110A-R3: Network: (1) RJ-45 10-Mbps full-duplex Ethernet, Sensor Input: (8) RJ-45,
Power: (1) 5-VDC input;
EME158A: Network: (1) RJ-45 10-Mbps full-duplex Ethernet/PoE input, Sensor Input: (8) RJ-45, Power: (1) 5-VDC input;
EME111A-20-R3–EME113A-20-R3: Network: (1) RJ-45 10-Mbps full-duplex Ethernet/PoE input, Sensor Input: (8) RJ-45,
Power: (1) 5-VDC input, Dry contact: (20) 2-wire terminal blocks;
EME111A-60-R2–EME113A-60-R2: Network: (1) RJ-45 10-Mbps full-duplex Ethernet/PoE input, Sensor Input: (8) RJ-45,
Power: (1) 5-VDC input, Dry contact: (60) 2-wire terminal blocks
Indicators — EME102A-R3–EME104A-R3, EME152A-R2–EME154A-R2: (5) LEDs: Power, Link, Activity,
Sensor 1, Sensor 2
Temperature Tolerance — Operating: -31 to +131 F (-35 to 55° C)
Relative Humidity — Operating: 20 to 80% noncondensing
Power — EME102A-R3–EME104A-R3, EME108A-R3–EME110A-R3: Power: 5 VDC,
Consumption: 1.2 amps, 1.125 watts, 0.15 A;
EME152A-R2–EME154A-R2, EME158A: Power: 5 VDC, Consumption: 1.2 amps, 1.125 watts, 0.15 A, PoE: 802.3af;
EME105A-R2–EME106A-R2: Power: 5 VDC, Consumption: 1.2 amps, 1.12 watts, 0.13 A;
EME155A-R2: Power: 5 VDC, Consumption: 1.2 amps, 1.12 watts, 0.13 A, PoE: 802.3af;
EME111A-20-R3–EME113A-20-R3: Power: 5 VDC, Consumption: 3 amps, 1.9 watts, 0.21 A;
EME111A-60-R2–EME113A-60-R2: Power: 5 VDC, Consumption: 3 amps, 2.9 watts, 0.32 A

Page 7
877-877-2269 | blackbox.com
Chapter 1: Specifications
Size — EME102A-R3–EME104A-R3, EME152A-R2–EME154A-R2: 0.5"H x 2.5"W x 1.25"D (1.3 x 6.3 x 3.2 cm);
EME105A-R2–EME106A-R2: EME108A-R3–EME110A-R3, EME155A-R2, EME158A: 1.8"H (1U) x 8.5"W x 5.4"D
(4.6 x 21.6 x 13.7 cm),
EME111A-20-R3–EME112A-20-R3, EME112A-60-R2–EME113A-60-R2: 1.7"H (1U) x 18"W x 5"D (4.3 x 45.7 x 12.7 cm)
Weight — EME102A-R3–EME104A-R3, EME152A-R2–EME154A-R2: 0.66 lb. (0.3 kg);
EME105A-R2–EME106A-R2, EME155A-R2: 3.53 lb. (1.6 kg);
EME108A-R3–EME110A-R3, EME158A: 3.85 lb. (1.75 kg);
EME111A-20-R3–EME113A-20-R3: 4.96 lb. (2.25 kg);
EME111A-60-R2–EME113A-60-R2: 7.17 lb. (3.25 kg)

877-877-2269 | blackbox.com
Page 8
Chapter 2: Overview
2. Overview
2.1 Introduction
2.1.1 What is the AlertWerks ServSensor?
The AlertWerks ServSensors are intelligent devices for monitoring environmental variables, power, physical threats, and security.
The units are IP based and have a Web interface for configuration. Included in this is a TCP/IP stack, Web server, full SNMP, and
e-mail support.
Any of our Intelligent Sensors can be connected via the RJ-45 connections (excluding our 8-port, sensor-controlled relay, thermo-
couple, or PMS sensors), or you can add dry contact connection for monitoring UPS, security systems, and air conditioning status.
2.1.2 Available Models
Table 2-1. Available models.
Part Number Name
EME102A-R3 ServSensor Jr.
EME103A-R3 ServSensor Jr. with Temperature Sensor
EME104A-R3 ServSensor Jr. with Dual Temperature/Humidity Sensor
EME152A-R2 ServSensor Jr. with PoE
EME153A-R2 ServSensor Jr. with PoE and Temperature Sensor
EME154A-R2 ServSensor Jr. with PoE and Dual Temperature/Humidity Sensor
EME105A-R2 ServSensor 4
EME106A-R2 ServSensor 4 with Temperature Sensor
EME155A-R2 ServSensor 4 with PoE and Temperature Sensor
EME108A-R3 ServSensor 8
EME109A-R3 ServSensor 8 with Temperature Sensor
EME110A-R3 ServSensor 8 with Dual Temperature/Humidity Sensor
EM E111A -20 - R3 ServSensor 8 with 20 Dry Contacts
EM E111A - 6 0 - R 2 ServSensor 8 with 60 Dry Contacts
EME112A-20-R3 ServSensor 8 with 20 Dry Contacts and Temperature Sensor
EME112A-60-R2 ServSensor 8 with 60 Dry Contacts and Temperature Sensor
EME113A-20-R3 ServSensor 8 with 20 Dry Contacts and Dual Temperature/Humidity Sensor
EME113A-60-R2 ServSensor 8 with 60 Dry Contacts and Dual Temperature/Humidity Sensor
What’s the difference between the ServSensor Jr., ServSensor 4, and the ServSensor 8?
The ServSensor Jr. is a small unit with two RJ-45 sensor inputs, the ServSensor 4 has four RJ-45 sensor inputs, and the ServSensor
8 has eight RJ-45 inputs.
What’s the difference between the ServSensor 8 and the ServSensor X20?
The ServSensor X20 has eight RJ-45 intelligent sensor ports AND 20 extra dry contact inputs; the ServSensor 8 only has eight 8
RJ-45 sensor ports. For more on these extra dry contacts, see Section 2.4.5.

Page 9
877-877-2269 | blackbox.com
Chapter 2: Overview
2.1.3 How to Use this Manual
This manual is a step-by-step guide on how to get your unit set up and functioning. It will introduce the primary features of the
unit by way of tutorials. You can either go through the whole procedure from start to finish, or, if you wish, use each tutorial as a
standalone lesson. The start of each lesson gives an “entry point profile,” which details how to get to the start point of the lesson
and assumes previous knowledge through completion of previous tutorials.
NOTE: Throughout this manual, you will find notes in each section that will relate to the information you are reviewing. Also,
Chapter 8 contains covers common questions and problems you may encounter. If you need any further assistance, contact
Black Box Technical Support at 724-746-5500 or [e-mail].
2.2 Features
• Support all major communications protocols.
• Embedded Web server.
• Support up to (2) intelligent sensors (EME102A-R3, EME103A-R3, EME104A-R3, EME152A-R2, EME153A-R2, EME154A-R2
only).
• Support up to (4) intelligent sensors (EME105A-R2, EME106A-R2, EME155A-R2).
• Support up to (8) intelligent sensors (EME108A-R3, EME109A-R3, EME110A-R3).
• ServSensor Jr. (EME102A-R3, EME103A-R3, EME104A-R3, EME152A-R2, EME153A-R2, EME154A-R2 only) supports up to 10
dry contact inputs (use two EME1DC-XXX sensors and the EME1DC-UPG).
• Comply with SNMP v1 standard.
• Include SNMP MIB.
• Include SNMP utilities for setting and getting parameters.
• Support SNMP polling to allow sensor values to be collected and graphed.
• Send trap notifications.
• Send e-mail notifications.
• Include sensor description and sensor values in notifications.
• User-configurable sensor thresholds.
• Use the optional “Continuous Time” feature to eliminate false alerts and notifications.
• Optional IEEE 802.3af Power over Ethernet (PoE) compliant (EME152A-R2, EME153A-R2, and EME154A-R2 only).
• 100-Mbps full-duplex Ethernet port.
2.3 What’s Included
Your package should include the following items. If anything is missing or damaged, contact Black Box Technical Support
at 724-746-5500 or [e-mail].
EME102A-R3:
• ServSensor Jr.
• CD containing this user‘s manual in PDF format
• (1) power supply
• (1) RJ-45 to RJ-45 patch cord, 5-ft. (1.5-m)

877-877-2269 | blackbox.com
Page 10
Chapter 2: Overview
EME103A-R3:
• ServSensor Jr.
• Temperature Sensor (EME1T1-001)
• CD containing this user‘s manual in PDF format
• (1) power supply
• (1) RJ-45 to RJ-45 patch cord, 5-ft. (1.5-m)
EME104A-R3:
• ServSensor Jr.
• Dual Temperature/Humidity Sensor (EME1TH1-001)
• CD containing this user‘s manual in PDF format
• (1) power supply
• (1) RJ-45 to RJ-45 patch cord, 5-ft. (1.5-m)
EME152A-R2:
• ServSensor Jr. PoE Hub
• Power supply
• Power cable
• CAT5 crossover patch cable
• CD containing this user‘s manual in PDF format
EME153A-R2:
• ServSensor Jr. PoE Hub
• Temperature Sensor (EME1T1-001)
• Power supply
• Power cable
• CAT5 crossover patch cable
• CD containing this user‘s manual in PDF format
EME154A-R2:
• ServSensor Jr. PoE Hub
• Dual Temperature/Humidity Sensor (EME1TH1-001)
• Power supply
• Power cable
• CAT5 crossover patch cable
• CD containing this user‘s manual in PDF format

Page 11
877-877-2269 | blackbox.com
Chapter 2: Overview
EME108A-R3:
• ServSensor 8
• Power supply
• (1) 5-ft. (1.5-m) RJ-45 to RJ-45 cable
• (1) set of rackmount brackets with hardware
• CD containing this user‘s manual in PDF format
EME109A-R3:
• ServSensor 8
• Temperature Sensor with 1-ft. (3.2-m) cable (EME1T1-001)
• Power supply
• (1) 5-ft. (1.5-m) RJ-45 to RJ-45 cable
• (1) set of rackmount brackets with hardware
• CD containing this user‘s manual in PDF format
EME110A-R3 :
• ServSensor 8
• Dual Temperature/Humidity Sensor with 1-ft. (3.2-m) cable (EME1TH1-001)
• Power supply
• (1) 5-ft. (1.5-m) RJ-45 to RJ-45 cable
• (1) set of rackmount brackets with hardware
• CD containing this user‘s manual in PDF format
EME111A-20 - R3 :
• ServSensor 8 with 20 dry contact ports
• Power supply
• (1) 5-ft. (1.5-m) RJ-45 to RJ-45 cable
• (1) set of rackmount brackets with hardware
• CD containing this user‘s manual in PDF format
EM E111A- 6 0 -R 2:
• ServSensor 8 with 60 dry contact ports
• Power supply
• (1) 5-ft. (1.5-m) RJ-45 to RJ-45 cable
• (1) set of rackmount brackets with hardware
• CD containing this user‘s manual in PDF format

877-877-2269 | blackbox.com
Page 12
Chapter 2: Overview
EME112A-20 - R3 :
• ServSensor 8 with 20 dry contact ports
• Temperature Sensor with 1-ft. (3.2-m) cable (EME1T1-001)
• (1) 5-ft. (1.5-m) RJ-45 to RJ-45 cable
• (4) terminal blocks (installed)
• (1) set of rackmount brackets with hardware
• CD containing this user‘s manual in PDF format
EME112A-60-R2:
• ServSensor 8 with 60 dry contact ports
• Temperature Sensor with 1-ft. (3.2-m) cable (EME1T1-001)
• (1) 5-ft. (1.5-m) RJ-45 to RJ-45 cable
• (4) terminal blocks (installed)
• (1) set of rackmount brackets with hardware
• CD containing this user‘s manual in PDF format
EME113A-20-R3:
• ServSensor 8 with 20 dry contact ports
• Dual Temperature/Humidity Sensor with 1-ft. (3.2-m) cable (EME1TH1-001)
• (1) 5-ft. (1.5-m) RJ-45 to RJ-45 cable
• (4) terminal blocks (installed)
• (1) set of rackmount brackets with hardware
• CD containing this user‘s manual in PDF format
EME113A-60-R2:
• ServSensor 8 with 60 dry contact ports
• Dual Temperature/Humidity Sensor with 1-ft. (3.2-m) cable (EME1TH1-001)
• (1) 5-ft. (1.5-m) RJ-45 to RJ-45 cable
• (4) terminal blocks (installed)
• (1) set of rackmount brackets with hardware
• CD containing this user‘s manual in PDF format

Page 13
877-877-2269 | blackbox.com
Chapter 2: Overview
2.4 Hardware Description
2.4.1 ServSensor Jr. (EME102A-R3, EME103A-R3, EME104A-R3, EME152A-R2, EME153A-R2,
EME154A-R2)
Figures 2-1 and 2-2 show the front and top panels of the ServSensor Jr. Table 2-2 describes its components.
5V DC
1 2 3 4
Figure 2-1. ServSensor Jr. front panel.
5 6 7 8 9
Figure 2-2. ServSensor Jr. top panel.
Table 2-2. ServSensor Jr. components.
Number Component Description
1(1) RJ-45 port Links to Sensor2
2(1) RJ-45 port Links to Sensor1
3(1) RJ-45 port Connects to 10BASE-T network.
4Barrel connector Links to 5 -VDC power.
5Power LED Lights when power is on.
6Link LED Lights when a link is established.
7Activity LED Lights when the unit is active.
8Sensor 1 LED Lights when sensor 1 is active.
9Sensor 2 LED Lights when sensor 2 is active.
NOTE: The EME152A-R2–EME154A-R2 use Power over Ethernet (PoE) instead of a power supply jack.

877-877-2269 | blackbox.com
Page 14
Chapter 2: Overview
2.4.2 ServSensor 4 (EME105A-R2, EME106A-R2, EME155A-R2)
Figures 2-3 and 2-4 show the front and back panels of the ServSensor 4. Table 2-3 describes its components.
1 2 3
4 5
Figure 2-3. ServSensor 4 front panel.
6 7 8 9 10
5V DC
Figure 2-4. ServSensor 4 back panel.
Table 2-3. ServSensor 4 components.
Number Component Description
1(1) Power LED Lights when power is on.
2(1) Link LED Lights when a link is present.
3(4) Online LEDs Lights when the sensor is on-line.
4(1) Activity LED Lights when the unit is active.
5(4) Status LEDs Lights when the sensor is in alarm state.
6(4) RJ-45 ports Sensor ports
7(1) RJ-45 port Links to RS-232 device.
8(1) RJ-45 port Links to Ethernet.
9(1) barrel connector Links to 5 -VDC power.
10 Ground connector Links to external ground.

Page 15
877-877-2269 | blackbox.com
Chapter 2: Overview
2.4.3 ServSensor 8 (EME108A-R3, EME109A-R3, EME110A-R3. EME158A)
Figures 2-5 and 2-6 show the front and back panels of the ServSensor 8. Table 2-4 describes its components.
1 2 3
45
Figure 2-5. ServSensor 8 front panel.
5V DC
6 7 8 9 10
Figure 2-6. ServSensor 8 back panel.
Table 2-4. ServSensor 8 components.
Number Component Description
1(1) Power LED Lights when power is on.
2(1) Link LED Lights when a network link is present.
3(8) Online LEDs Light when sensors are on-line.
4(1) Activity LED Lights when network is communicating.
5(8) Status LEDs Light when sensors are in alarm state.
6(8) RJ-45 connectors Sensor ports.
7(1) RJ-45 connector Links to RS-232 device.
8(1) RJ-45 connector Connects to Ethernet.
9(1) barrel connector Connects to power.
10 External ground Grounds the unit.

877-877-2269 | blackbox.com
Page 16
Chapter 2: Overview
2.4.4 ServSensor X20 (EME111A-20-R3, EME111A-60-R2, EME112A-20-R3, EME112A-60-R2,
EME113A-20-R3, EME113A-60-R2)
Figures 2-7 and 2-8 show the front and back panels of the ServSensor 8 X20. Table 2-5 describes its components.
1 2 3
5 6 4
Figure 2-7. ServSensor 8 X20 front panel.
5V DC
7 8 9 10 11 12
Figure 2-8. ServSensor 8 X20 back panel.
Table 2-5. ServSensor 8 X20 components.
Number Component Description
1(1) Power LED Lights when power is on.
2(1) Link LED Lights when there is a network connection.
3(8) Online LEDs Light when sensors are on-line.
4(20) LEDs Light when dry contacts are on-line.
5(1) Activity LED Lights when there is network traffic.
6(8) Status LEDs Light when sensors are in alarm state.
7(20) Dry contact ports Connect to dry contacts.
8(8) RJ-45 ports Sensor ports.
9(1) RJ-45 port Connects to RS-232.
10 (1) RJ-45 port Network connection.
11 (1) barrel connector Power connector.
12 External ground Ground lug.

Page 17
877-877-2269 | blackbox.com
Chapter 2: Overview
2.4.5 ServSensor 8-X20 20 Extra Dry Contact Inputs
The 20 extra dry contact inputs on, for example, the ServSensor with 20 or 60 DC inputs, can be configured as inputs only up to
5 volts in normal operation. In opto-isolation mode, they can input up to 30 volts DC. This will protect these inputs and the unit
from high voltages and spikes.
Opto-isolators provide complete electrical separation between the ServSensor and the dry contact. The base units are therefore
protected against possible large voltage spikes caused by lightning for example.
Figure 2-9 shows the JUMPERS (on the dry contact board) set up to provide opto-isolator support. Opto-isolators provide
complete electrical separation between the ServSensor and the dry contact.
Figure 2-9. Jumpers on the dry contact board.
The OID for the extra dry contact inputs is:- .1.3.6.1.4.1.3854.1.2.2.1.18.1.3.<port>
Extra dry contact input practical applications:
The extra dry contact inputs can be used to monitor many types of equipment, for example, you can run the connection from
warning lights on alarm panels to the dry contact inputs, so that when the warning light on the alarm panel is activated, the dry
contact is triggered in the unit’s Web interface, enabling you to send notifications via e-mails or SNMP traps.

877-877-2269 | blackbox.com
Page 18
Chapter 3: Installation
3. Installation
3.1 Assigning an IP Address
These units are plug-and-play devices that will easily connect to your existing network setup. Every unit ships with a default IP
address. This is 192.168.0.100. To install your unit, you must first assign it an IP address to match your current network
configuration. Before starting this, make sure you have the following items:
• RJ-45 CAT5 crossover cable with RJ-45 male connection
• A PC with Ethernet card or LAN socket.
• Power socket for the unit to connect to
1, Connect the unit via the CAT5 crossover cable to the Ethernet/LAN port on your computer.
2. Open your Web browser and go to the default IP address http://192.168.0.100.
Figure 3-1. Enter default address.
NOTE: In some cases, your computer might not be able to connect to this default IP address. In this situation, you need to set up
your computer’s routing table to allow access to this.

Page 19
877-877-2269 | blackbox.com
Chapter 3: Installation
3. You will now be presented with the following login screen.
Figure 3-2. Login screen.
4. After logging in, you will be taken to the Main Summary page.

877-877-2269 | blackbox.com
Page 20
Chapter 3: Installation
Figure 3-3. Main Summary page.
5. From the summary page, select the “Network” tab. Type in your new IP address, then click “Save.”
Figure 3-4. Input New Address screen.
