Black Box SW1035A User manual

SINGLE MODE
FIBER OPTIC A/B SWITCH
(LATCHING)
SEPTEMBER 2008
Model# SW1035A
Model# SW1036A
CUSTOMER
SUPPORT
INFORMATION
Order toll-free in the U.S.: 877-877-BBOX (outside U.S. call 724-746-5500)
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or
fax [phone]
Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: [email protected]

Page 2
Single Mode Fiber Optic A/B Switch (latching)
FEDERAL COMMUNICATIONS COMMISSION
AND
INDUSTRY CANADA
RADIO FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy, and
if not installed and used properly, that is, in strict accordance with the
manufacturer’s instructions, may cause interference to radio communication.
It has been tested and found to comply with the limits for a Class A
computing device in accordance with the specifications in Subpart B of Part
15 of FCC rules, which are designed to provide reasonable protection
against such interference when the equipment is operated in a commercial
environment. Operation of this equipment in a residential area is likely to
cause interference, in which case the user at his own expense will be
required to take whatever measures may be necessary to correct the
interference.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise
emission from digital apparatus set out in the Radio Interference Regulation
of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques
dépassant les limites applicables aux appareils numériques de la classe A
prescrites dans le Règlement sur le brouillage radioélectrique publié par le
Industrie Canada.
FCC STATEMENT

Page 3
Single Mode Fiber Optic A/B Switch (latching)
Contents
Chapter Page
1. Specifications …………………………………... 4
2. Introduction …………………………………. 5
3. Installation …………………………………….. 6
4. Troubleshooting ……………………………….. 6
CONTENTS

Page 4
Single Mode Fiber Optic A/B Switch (latching)
Specifications
Connectors
(3 pairs) ST connectors, (1) 3.5-mm power input
(SW1035A)
(3 pairs) SC connectors, (1) 3.5-mm power input
(SW1036A)
Data Rates
Transparent to signal rates, wavelengths, & formats
Switching Speed
less than 10 ms typical
Sensitivity
1310 / 1550 nanometers
Optical Loss
less than 2.0 dB typical
Compatibility
8 to 10um Single mode fiber
Crosstalk
less than -55 dB typical per FOTP-42
Approvals
UL, CE, and PSE (power supply)
Operating Temperature
14 to 149ºF (-10 to +65ºC)
Relative Humidity Tolerance
10 to 95%, non-condensing
Chapter 1: Specifications

Page 5
Single Mode Fiber Optic A/B Switch (latching)
Mean Time Between Failures
100,000 hours or 10,000,000 cycles
Power
100-240 VAC 50/60 Hz wall-mount PSU, 12 VDC out
Size
2.5”H x 8”W x 6.3”D (6.4 x 20.3 x 16 cm)
Weight
4 lb. (1.8 kg)
Introduction
The Single Mode latching Fiber Optic A/B Switch is a
full-duplex, optical 2 port switch. It can be used to connect
one workstation to two different networks (one at a time)
or to other remote devices. A front panel rotary style knob
allows the user to select which of two ports (A or B) is
connected to the COMMON (C) port on the switch. The
switch operates using a unique all-optical micro-mirror
movement. When you turn the rotary knob on the front of
the switch to select a network, the internal micro-mirror
movement redirects the optical beam from one network
port to another network port by rotating a miniature mirror.
This technique eliminates the need to convert optical
signals to electronic signals for switching and is therefore
transparent to data rates and protocols.
This switch is perfectly suited for applications where a
selected connection must be maintained in the event of a
power failure. You should use a non-latching fiber optic
switch for applications requiring a switch that falls back to
pre-determined connection during the loss of AC power
(please call us). These switches use power only for
switching the selected connection. No power is required to
pass data through the switches.
Chapter 2: Introduction

Page 6
Single Mode Fiber Optic A/B Switch (latching)
Installation
Place the switch in a convenient stable location and
connect the power supply unit to a reliable source of AC
power that meets the requirements shown in the
Specifications section of this manual. Then change the
front panel rotary knob to switch between the different
connection states to insure that the latching fiber optic
switch modules are in a known position before
connecting the switch to your fiber optic devices.
Connect the two fiber leads from the device to be shared
to the common switch port labeled C. Connect the
networks or other devices to the user selectable output
ports labeled A and B.
Your installation of this switch is now complete.
Troubleshooting
If the Fiber Optic A/B Switch fails to operate, check the
following before calling for technical support.
1. Ensure that the power supply connected to a power
source and to the switch.
2. Check the fiber optic connectors for proper
connections to the correct ports of the switch.
3. Operate the switch knob to verify that it’s tightly
secured to the switch shaft and does not spin loosely.
4. Verify the integrity of the fiber optic leads by
replacing a suspect lead with a spare.
Chapter 3: Installation
Chapter 4: Troubleshooting
