Black Box ServSwitch DTX5000-R User manual

September 2006
DTX5000-R
DTX5000-T

SERVSWITCHTM FAMILY
1
Welcome to the ServSwitchTM Family!
Thank you for purchasing a BLACK BOX®ServSwitch DTX5000 system! We appreciate
your business, and we think you’ll appreciate the many ways that your new DTX5000
System will save you money, time, and effort.
The BLACK BOX® DTX5000 system allows desktop users to access a full computer
experience from anywhere on the corporate TCP/IP network, while maintaining the
computers securely housed in a corporate data center. This desktop experience includes
access for the desktop user to keyboard, mouse, both digital and analog video, audio and
USB mass storage devices.
This solution can be deployed as a point-to-point extender system or may over-laid on the
standard 100 Mbps/1 Gbps TCP/IP network.
The ServSwitch™ family from BLACK BOX—the one-stop answer for all your KVM
switching needs!
*
This manual will tell you all about your new ServSwitch DTX5000 system, including how
to install, operate and troubleshoot it. For an introduction to the ServSwitch DTX5000
system see Chapter 2. The ServSwitch DTX5000 product codes covered in this manual are
as follows:
DTX5000-R DTX5000-T

SERVSWITCH DTX5000 USER GUIDE
2
FEDERAL COMMUNICATIONS COMMISSION
AND INDUSTRY CANADA
RADIO-FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy and if not
installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested and found
to comply with the limits for a Class A computing device in accordance with the
specifications in Subpart B of Part 15 of FCC rules, which are designed to provide
reasonable protection against such interference when the equipment is operated in a
commercial environment. Operation of this equipment in a residential area is likely to
cause interference, in which case the user at his own expense will be required to take
whatever measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from
digital apparatus set out in the Radio Interference Regulation of Industry Canada. Le
présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.
EUROPEAN UNION DECLARATION OF CONFORMITY
This equipment has been tested and found to comply with the limits for a Class A
computing device in accordance with the specifications in the European standard
EN55022. These limits are designed to provide reasonable protection against harmful
interference. This equipment generates, uses and can radiate radio-frequency energy, and
if not installed and used in accordance with the instructions, might cause harmful
interference to radio or television reception.
However, there is no guarantee that harmful interference will not occur in a particular
installation. If this equipment does cause interference to radio or television reception,
which can be determined by turning the equipment on and off, you can correct the
interference with one or more of the following measures:
a. Reorient or relocate the receiving antenna.
b. Increase the separation between the equipment and the receiver.
c. Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
d. Consult the supplier or an experienced radio/TV technician for help.

COMPLIANCE STATEMENTS
3
This equipment has also been found to comply with European standards EN50082 and
EN60950.
Other Agency Approvals
USA (UL, FCC)
Canada (cUL, ICES-003)
European Union (CE)
TRADEMARKS USED IN THIS MANUAL
BLACK BOX® and the logo are registered trademarks, and ServSwitch is a trademark of
BLACK BOX Corporation.
Mac and Macintosh are registered trademarks of Apple Computer, Inc.
PS/2 is a registered trademark of International Business Machines Corporation.
Microsoft, HyperTerminal, Windows, Windows NT, and Windows XP are trademarks or
registered trademarks of Microsoft Corporation in the United States and/or other
countries.
Sun and Sun Microsystems are registered trademarks of Sun Microsystems, Inc. in the
United States and other countries.
Any other trademarks mentioned in this manual are acknowledged to be the property of
the trademark owners.

SERVSWITCH DTX5000 USER GUIDE
4
1. Specifications...................................................................................................6
1.1 Factory Default Settings ................................................................................................9
2. Product Overview...........................................................................................11
2.1 Features and Benefits...................................................................................................11
2.2 Safety Precautions........................................................................................................14
3. Installation......................................................................................................15
3.1 Getting Started.............................................................................................................15
3.2 Mounting Option..........................................................................................................15
3.3 Installation Options......................................................................................................15
4. Operations......................................................................................................21
4.1 Overview......................................................................................................................21
4.2 Accessing the System ..................................................................................................21
4.3 The OSD ......................................................................................................................22
4.4 The Serial Interface......................................................................................................23
4.5 Configuring Network Settings.....................................................................................25
4.6 Access Control.............................................................................................................29
4.7 Flash Upgrading your ServSwitch DTX5000 System.................................................33
4.8 Restoring Factory Default Settings..............................................................................36
4.9 Resetting the ServSwitch DTX5000 System...............................................................37
4.10 Viewing System Information.....................................................................................38
4.11 Configuring Video Input Settings..............................................................................40
4.12 Configuring the OSD Hotkey Sequence....................................................................40
4.13 OSD Inactivity Timeout.............................................................................................42
4.14 Session Inactivity Timeout ........................................................................................43
4.15 Session Retry Settings ...............................................................................................44
5. Troubleshooting.............................................................................................47
5.1 Troubleshooting Tips...................................................................................................47
5.2 Calling Black Box........................................................................................................49
5.3 Shipping and Packaging...............................................................................................50

SERVSWITCH DTX5000 USER GUIDE
5

SERVSWITCH DTX5000 USER GUIDE
6
1. Specifications
During the course of this product’s lifetime, modifications might be made to its hardware
or firmware that could cause these specifications to change without notice.
DTX5000-R Product Specifications
Network
Ethernet Standard Ethernet II
Extension Ports
Number 1
Connectors RJ45
User Ports
Number PS/2: 2; USB: 4; DVI-I video: 1; audio microphone: 1; audio line
out: 1; power jack: 1
Type PS/2, USB Type A, DVI-I video
Connectors 6-pin miniDIN, PS/2 keyboard and mouse; USB Type A, USB keyboard and mouse; DVI-I, female; 3.5 mm stereo audio
jacks, line out and mic; 2.5 mm DC power jack.
Encryption
Type Authenticated SSL
Update Port
Number 1
Type Three-wire Serial interface: RX, TX, GND via 16450-compatible
UART
Connectors 9-pin D-Shell (DB9)
Dimensions
H x W x D 26.5 x 210 x 130 mm (1.04 x 8.27 x 5.12 in)
Weight 0.7 Kg (1.54 lb)
without packaging, cables, power supply and literature
Heat Dissipation 22 W/H
Power Consumption 20 W (including power supplied to USB ports)
AC-input power 100-240 V AC
AC-input current rating 1 A

CHAPTER 1: SPECIFICATIONS
7
DTX5000-R Product Specifications (continued)
AC-frequency 50/60 Hz
Operating Temperature 0° to 35° Celsius (32° to 95° Farenheit)
Storage Temperature -20° to 60° Celsius (-4° to 140° Farenheit)
Transit Temperature -30
° to 60° Celsius (-22° to 140° Farenheit)
Operating Humidity 10 to 90% noncondensing
Storage Humidity 5 to 95%
Supported Hardware
Peripherals PS/2 keyboard and mouse, USB keyboard and mouse,
speakers, microphone
Keyboard
Standard 104/105/109 keyboards for PC, Macintosh, and Sun
USB keyboards for PC, Macintosh and Sun
Default keyboard drivers are fully supported for Microsoft
Windows, MacOS, Solaris and Redhat Linux
Mouse 2-, 3-, and 5-button; scroll and tilt wheel
Mass Storage Devices All Mass Storage Class devices that use: SCSI Mass Storage subclass
Bulk Only Transfer Protocol
Video Resolution CRT 1280 x 1024 @ 60 Hz
LCD 1280 x 1024 @ 60 Hz
Video Standard DDC version 2B
Color Depth 24 Bit
Audio Standard PC99
Audio Sampling 44.1 kHz over a single channel at a resolution of 16 bits.
Target Sync Types
(Analog output only) Separate horizontal and vertical
Safety and
EMC Approvals and
Markings UL, FCC, cUL, CE
DTX5000-T Product Specifications
Network
Ethernet Standard Ethernet II
Extension Ports

SERVSWITCH DTX5000 USER GUIDE
8
Number 1
Connectors
RJ45
User Ports
Number USB: 2; DVI-I video: 1; audio microphone: 1; audio line out: 1
Type USB Type A, DVI-I video
Connectors USB, male; DVI-I, male; 3.5 mm stereo audio jacks, line out
and mic; 2.5 mm DC power jack.
Encryption
Type Authenticated SSL
Dimensions
H x W x D 68 x 21 x 153 mm (2.68 x 0.83 x 6.02 in)
Weight 0.3 Kg (0.66 lb) including cables
Heat Dissipation 22 W/H
Power Consumption 6 W
AC-input power 100-240 V AC
AC-input current rating 1 A
AC-frequency 50/60 Hz
DC-input power 5 V
DC-input current rating 1.1 A
Operating Temperature 0° to 35° Celsius (32° to 95° Farenheit)
Storage Temperature -20° to 60° Celsius (-4° to 140° Farenheit)
Transit Temperature -30
° to 60° Celsius (-22° to 140° Farenheit)
Operating Humidity 10 to 90% noncondensing
Storage Humidity 5 to 95%
Video Resolution CRT 1280 x 1024 @ 60 Hz
LCD 1280 x 1024 @ 60 Hz
Video Standard DDC version 2B
Color Depth 24 Bit
Audio Standard PC99
Audio Sampling 44.1 kHz over a single channel at a resolution of 16 bits

CHAPTER 1: SPECIFICATIONS
9
1.1 Factory Default Settings
Playout Buffer (jitter) 350 ms
Target Sync Types
(Analog input only) Separate horizontal and vertical; sync on green (as used on SGI and HP9000)
Safety and
EMC Approvals and
Markings UL, FCC, cUL, CE
DTX5000-R
Name RX_<MAC address>
IP Address 192.168.13.1
Default Gateway 0.0.0.0
Netmask 255.255.255.0
OSD Hotkey Sequence PRINT SCREEN
OSD Inactivity Timer 00 hours 10 minutes
OSD Inactivity Check
Box Enabled
Session Inactivity Timer 00 hours 10 minutes
Session Inactivity
Check Box Disabled
Session Retry Timeout 30 seconds
DTX5000-T
Name TX_<MAC address>
IP Address 192.168.13.2
Default Gateway 0.0.0.0
Netmask 255.255.255.0
Video DVI

SERVSWITCH DTX5000 USER GUIDE
10

CHAPTER 2: PRODUCT OVERVIEW
11
2. Product Overview
2.1 Features and Benefits
The ServSwitch DTX5000 provides users with a full computer desktop experience from
anywhere on the corporate TCP/IP network, while maintaining the computers securely
housed in a corporate data center. This desktop experience includes access for the desktop
user to keyboard, mouse, video, audio and USB mass storage devices.
The ServSwitch DTX5000 system consists of:
• The DTX5000-T that connects externally to the remote computer
• The DTX5000-R that is located at the user’s desk
Figure 2-1. ServSwitch DTX5000 Basic System
DTX5000-T (Transmitter)
The DTX5000-T connects to the video, audio and USB ports of the computer and is
available as a Transmitter that attaches externally to the remote computer.
The Transmitter is attached directly to the remote computer and draws its power directly
from two USB ports on the remote computer. This removes the need for additional power
supply connections at the rack.
NOTE:
If the remote computer cannot supply the required power or if two USB connections are not available, an
external power supply can be obtained from Black Box.
The Transmitter captures, compresses and encrypts the computer’s media streams and
transmits them to the DTX5000-R (Receiver) over a standard TCP/IP network.

SERVSWITCH DTX5000 USER GUIDE
12
DTX5000-R (Receiver)
The Receiver enables the desktop user’s keyboard, mouse, video, audio and mass storage
devices to connect to the ServSwitch DTX5000 system. It is available as a desktop user
station.
Automatic Connection
When the Receiver is powered up, a connection is automatically established with the
remote computer via the Transmitter. No intervention is required from the user. See
“Accessing the System” on page 21.
Ethernet addressing
The Receiver and the Transmitter are IP-addressable devices; this gives you the flexibility
to locate back-racked computers anywhere within your enterprise and at any distance from
your desktop users. The Receiver and the Transmitter use standard network protocols to
transfer data streams between the remote computer and the peripheral devices located at
the user’s desk. The ServSwitch DTX5000 system can operate on a network connection of
10 Mbps, 100 Mbps or 1 Gbps. For optimum performance a 1 Gbps connection is
recommended. For more information see Chapter 3.
Multiplatform support
The Transmitter is connected to the remote computer via USB connectors. This enables
the ServSwitch DTX5000 system to interoperate seamlessly with PC, Sun and Macintosh
target computers. PC, Sun and Macintosh USB keyboards can be connected to the
Receiver. PS/2 keyboards and mice can also be used.
You can attach the ServSwitch DTX5000 system to computers running the following
operating systems:
• Microsoft Windows
• Redhat Linux
•Solaris
•MacOS
The default keyboard drivers for these operating systems are fully supported by the
ServSwitch DTX5000 system.
Flexible installation
The Receiver can be desk mounted or mounted on the back of a monitor. Installation
requires no new drivers or software. Standard UTP cabling makes installation simple and
keeps costs low.
Security
The ServSwitch DTX5000 system supports Secure Sockets Layer (SSL) over a TCP/IP
connection. All media streams transmitted between the Receiver and the Transmitter are
encrypted. In addition, password protection is provided to control access to all
administration functions. For example, network configuration information, see “Access
Control” on page 29.
OSD
The Receiver includes an On-Screen Display (OSD) that allows you to view information
about the configuration of your ServSwitch DTX5000 system. See “The OSD” on
page 22.

CHAPTER 2: PRODUCT OVERVIEW
13
Operations administration and maintenance
The Receiver incorporates a Serial Interface menu that allows you to perform
administration and maintenance tasks for both the Receiver and the Transmitter. Examples
of tasks you can perform include, configuration of network settings and firmware Flash
upgrades. See “The Serial Interface” on page 23.
Flash upgradeable
Upgrade your firmware at any time using the XMODEM or HTTP protocols to ensure that
your ServSwitch DTX5000 system is always running the most current version available.
Both the Transmitter and the Receiver are Flash upgradeable. See “Flash Upgrading your
ServSwitch DTX5000 System” on page 33.
Support for keyboards and mice
USB and PS/2 keyboards and mice are fully supported by the ServSwitch DTX5000
system. The system also allows for mix and match of USB and PS/2 peripherals. For
example, it is possible to use a USB keyboard in conjunction with a PS/2 mouse. The
default keyboard and mouse drivers of the remote computer are fully supported. This
enables the ServSwitch DTX5000 system to support 2-, 3- and 5-button mice with scroll-
and tilt-wheel capability. Composite mouse and keyboard devices are also supported.
USB support
The ServSwitch DTX5000 system is compatible with the USB 2.0 standard, and provides
support for low-, full- and high-speed USB devices. The Receiver provides four USB 2.0
compliant ports that can be used to access USB removable drives and CD-ROM drives,
keyboards, mice and USB hubs. Hot plugging of USB devices is supported.
NOTE:
A hub cannot be used to expand the number of USB ports available.
Virtual media
Mass storage devices, such as removable drives and external CD-ROM drives, can be
attached to the Receiver and will function as if they are directly connected to the remote
computer. Data can be both read from and written to these mass storage devices. You can
connect both a removable drive and an external drive at any one time to the Receiver.
NOTE:
It is not possible to connect two mass storage devices of the same type to the Receiver at any one time.
For example, you cannot connect two removable drives to the Receiver.
The transfer speed between the mass storage device and the remote computer is dependant
on the Ethernet network. A 1 Gbps connection is required for high-performance virtual
media transfer. The system is capable, however, of operating over a 100 Mbps Ethernet
connection. By default, 20 per cent of the available connection bandwidth is allocated to
virtual-media transfer.
The following mass storage devices are supported:
• Removable drives
• External USB hard drives
• External USB CD-ROM drives
Hot plugging of USB mass storage devices is supported.

SERVSWITCH DTX5000 USER GUIDE
14
NOTE:
The ServSwitch DTX5000 system supports the default drivers for mass storage devices.
Audio
The ServSwitch DTX5000 system supports CD-quality stereo from the remote computer
to peripheral speakers, and mono-quality audio from a peripheral microphone to the
remote computer.
Video
Video of 24-bit color depth up to a resolution of 1280 x 1024 at 60 Hz is supported by the
ServSwitch DTX5000 system. Both CRT and flat-panel LCD monitors are supported, and
can be connected to the ServSwitch DTX5000 system via a DVI-I video connector. VGA
monitors can be attached to the system by using a DVI to VGA adaptor. The system
supports DDC version 2B.
Reduced Total Cost of Ownership (TCO)
The ServSwitch DTX5000 system delivers significantly lower TCO when compared to
traditional distributed computer systems. Centralized maintenance enables greater security
and convenience as well as reduced workplace disruption and down-time. IT
administration costs are also significantly reduced by housing all PCs in one central
location. Relocating the computer away from the user frees up valuable office space and
reduces desktop power and heating, ventilation and air conditioning (HVAC)
requirements.
2.2 Safety Precautions
To avoid potential video and/or keyboard problems when using Black Box products:
• If the building has 3-phase AC power, ensure that the computer and monitor are on
the same phase. For best results, they should be on the same circuit.
To avoid potentially fatal shock hazard and possible damage to equipment, please observe
the following precautions:
• Do not use a 2-wire extension cord in any Black Box product configuration.
• Test AC outlets at the computer and monitor for proper polarity and grounding.
• Use only with grounded outlets at both the computer and monitor. When using a
backup Uninterruptible Power Supply (UPS), power the computer and the
Transmitter off the same supply.
NOTE:
The AC inlet is the main disconnect.

CHAPTER 3: INSTALLATION
15
3. Installation
3.1 Getting Started
Before installing your ServSwitch DTX5000 system, refer to the list below to ensure that
you have all the items necessary for installation.
Needed to install the ServSwitch DTX5000 system
• DTX5000-R Receiver
• DTX5000-T Transmitter
• External power supply for the Receiver
•IECpowercord
• ServSwitch DTX5000 Quick Installation Guide
• UTP cable (not supplied)
• Three-wire serial cable or null modem cable (not supplied)
Needed for non-standard installations
To connect a VGA monitor to the Receiver:
• A DVI to VGA adaptor (not supplied)
To connect the Transmitter to a remote computer that has VGA video output:
• A VGA to DVI-I adaptor (not supplied)
To connect the Transmitter to a remote computer that has DVI-D video output:
• A DVI-D to DVI-I adaptor (not supplied)
3.2 Mounting Option
The Receiver features the following mounting option that allows you to adapt easily to
most work environments:
• Mounting to the rear of a flat-panel monitor via a mounting plate accessory
NOTE:
Mounting accessories are ordered separately. Contact Black Box for more information.
3.3 Installation Options
CAUTION:
To reduce the risk of electric shock or damage to your equipment,
disconnect the power from the Receiver by unplugging the power supply from the electrical outlet.
CAUTION:
To reduce the risk of electric shock or damage to your equipment,
power up the remote computer and the Receiver in the sequence described in the following procedures.
You can install the ServSwitch DTX5000 system in one of two ways:
1. Point-to-point
2. Networked

SERVSWITCH DTX5000 USER GUIDE
16
Point-to-point installation
The following instructions will enable you to install your ServSwitch DTX5000 system in
a point-to-point configuration. In a point-to-point configuration no administrator setup of
the Transmitter or the Receiver is required. This enables you to install the system quickly,
directly out-of-the-box. However, if you choose the point-to-point configuration you can
install only one Transmitter and Receiver pair on a subnet. If you use this configuration
you must also locate both the Transmitter and the Receiver on the same subnet.
Figure 3-1. Point-to-point Installation
To connect the Transmitter:
1. Power down the remote computer.
2. Connect the video connector on the Transmitter to the appropriately labeled port on
the back of the computer.
NOTE:
A VGA-only computer can be connected to the Transmitter using a VGA to DVI-I adaptor.
You must configure the Transmitter’s video settings for VGA through the Serial Interface menu.
For more information see “Configuring Video Input Settings” on page 40.
3. The Transmitter has two USB connectors. Connect each of these connectors to a cor-
responding USB port on the remote computer.
4. Connect the Transmitter’s audio and microphone connectors to the appropriately
labeled ports on the back of the computer.
5. Connect the UTP cable to the Transmitter’s RJ45 connector.
6. Power up the computer.
7. Route the other end of the UTP cable to the location you have chosen for the
Receiver. If necessary you can extend the UTP cable via junctions or a hub - subject
to normal Ethernet cabling practices.
The Transmitter draws electrical power from two USB ports on the remote computer. One
USB port is not sufficient to power the Transmitter. If you have only one USB port on
your remote computer, you will need to order an external power supply for the Transmitter
from Black Box

CHAPTER 3: INSTALLATION
17
.
Figure 3-2. Transmitter
To connect the Receiver:
1. Connect your keyboard, monitor, mouse and other peripherals cables to the appropri-
ately labeled ports on the back of the Receiver.
2. Connect the UTP cable to the RJ45 port on the back of the Receiver.
3. Power up the Receiver. A connection will be automatically established with the
remote computer.
NOTE:
VGA monitors can be connected to the Receiver by using a DVI-I to VGA adaptor.
Video
USB Mic Line out

SERVSWITCH DTX5000 USER GUIDE
18
Figure 3-3. Receiver and Transmitter Installation
Connecting Power
The Receiver features an external power supply. A DC power jack is located on the rear of
the Receiver.
NOTE:
Use only the power supply provided by Black Box.
To connect power to the Receiver:
1. Plug the external power supply’s 2.5mm connector into the DC power jack on the
rear of the Receiver.
2. Connect the detachable IEC power cord to the power supply.
3. Plug the IEC power cord into an appropriate wall outlet.
Networked Installation
The following instructions will enable you to install your ServSwitch DTX5000 system in
a networked configuration. In this installation, the Transmitter and the Receiver are both
connected to an Ethernet network. Communication between the Transmitter and the
Receiver takes place over IP.
Microphone
Speakers
Serial
Transmitter
Remote
PC
Receiver
Local Peripherals
attached via USB
External
Power
Supply PS/2
